Preface
With the increase of automobile demand in China, our automobile industry also experiences a rapid
development. The trucks including SUV, manufactured by Great Wall Motor Co., Ltd, which are sold all over
China, are in the leading place in terms of their sales volume, in order to satisfy the demands of various maintain-
ing staff, technicians and managing staff of Changcheng Co., Ltd, we compile this maintenance manual accord-
ing to the latest technological data. This manual covers six vehicle models including Deer, Safe, Sailor, Sing, So
Cool and Pegasus, its main content includes:
Part I is general introduction, which introduces the application index of this manual.
Part II introduces the chassis system, which mainly includes the technologies of dismantle, inspection,
adjustment, repairing, assembly and mount of the clutch, gear box, transfer box, drive shaft, suspension system
and automobile axle, braking system and steering system, etc. each operation approach is illustrated with figure,
which not only presents the maintenance procedure, but also clearly describes the technical requirements and
application limit.
Part III introduces the electric system and air-conditioning system of the automobile body, which mainly
covers such items as the location and content of protective box, power supply system, starting system, lighting
system, combination instrument, backup radar system, wiping and washing system, center control locking and
power window system, acoustical equipment system, full wire harness and air-conditioning system, etc. Electric-
ity diagrams for those electric systems are given in this manual so as to facilitate the maintaining technicians to
find out the problem easily and quickly.
Part IV introduces the external and internal body decoration, which mainly covers the dismantling, inspect-
ing and assembling requirements of the engine cover, front and rear doors, adhesive strip of body collision
avoidance, wheel shield, wrapping angle of wheel-shield and exterior trim panel, front and rear windshields,
side-window glass, rear-door glass, rear platform of cargo compartment, rear door, instrument panel, safety belt,
seat, tail-fin, luggage rack, and reserve tire bracket etc. The dimensions of vehicle body and frame are also given
to maintaining staff for reference during their repairing.
During the narrations of each part, items such as troubleshooting, maintenance notice, maintenance data
and application limit, fastening torques of bolts and nuts for special purpose, SST, SSM and lubricant materials
and so on are also introduced. Various maintenance data are briefed in attachment for reference.
Altogether, this manual is comprehensive in content, visual in illustration, clarifying in requirement and
plain in language. It can be referred by the maintaining staff, technicians and professional managing staff.
Even though we try our best to compile this manual in a strict earnest manner, we cannot guarantee that all
contents in this manual are correct. Therefore, users shall not put forward any claim with Great Wall Company
according to this manual; we are not in the position to hold the responsibility for the loss caused by usage of this
manual. Due to our limited knowledge, it is unavoidable to find error in this manual, any criticism and correction
from you is welcomed.
The final explanation power for this manual is subject to Great Wall Motor Co., Ltd
Compiler
May 2006
Page 3 of 484
Page 4 of 484
Service manual for
chassis and body
GeneralIN
ClutchCL
Gear boxMT
Transfer boxTF
Drive shaftPR
Suspension system and automobile axleSA
Braking systemBR
Steering systemSR
Body electric systemBE
Air-conditioning systemAC
Vehicle bodyBO
Maintenance and Up-keepingA
Special ToolB
Page 5 of 484
IN-1
Page
How to use this manual ................................................. IN-2
Instruction for overall repairing ...................................... IN-4
Body lifting height and support position ........................ IN-5
fk
Introduction
Page 6 of 484
IN-2
How to use this manual
In order to help you to look in this manual, we marked the chapter
name and main theme at the top of each page.
In order to introduce the repairing items to you, we make the index on
the first page of each chapter, and notices need to be taken during all
repairing operation are also given in the related chapter.
Please read these notices carefully before the repairing work.
The troubleshooting form for each system will help you to diagnose
the system trouble and its cause.
We furnish with the repairing approaches for each possible cause in
the repairing approach column, which will help you to acquire the
solution in a short time. IntroductionHow to Use This Manual
Repairing approach
Most repairing operation can begin with referring to these illustrations.
These illustrations can help you identify the parts and their coordina-
tion situation
Example
snapping ring
front minor half-shaft
front speed reducer
and differential
oil seal-front semi-axle
front long
semi-axis
snapping ring
88
N*mspecified torque
Parts that cannot be reused after being used
Page 7 of 484
IN-3IntroductionHow to Use This Manual
Introductionóhow to use this manual
The repairing approaches are described step by step:
The illustrations show you what to do and at which position.
The theme of repairing operation tell you what you need to do.
The detailed instruction show you how to accomplish the repairing and
introduce to you other related affairs, such as specification, warning etc.
Example:
Check and adjust the flange bounce
(a) Attach the dial indicator seat to the reducer housing, and touch the
flange face with the measuring head of dial indicator, run the flange
and observe the pendular range of the indicator carefully.
Full bounce tolerance of face : 0.10mm
Illustration:
what to do and at which positionSpecification
This formula can help the experienced technicians find out the failure
causes in short time. Overhauling staff can browse the operation theme
and refer to the detailed description thereunder where necessary; impor-
tant specifications and warnings are written out in boldface.
Specification
The corresponding specifications are given in boldface in each repairing
approach of this manual, which allows the overhauling staff to check the
specification while keeping on repairing work.
Warning, Notice and Remark
Warning written out in boldface means there is possibility of self-
injury or harm to others.
Notice written out in boldface means there is possibility of damage
to parts under repairing.
Remarks singled out independently, but not in boldface, serve as
supplementary descriptions to help you accomplish the work more
efficiently.
Vehicle Code
There are six vehicle models in this manual, the model codes are as follows:
Deer modelDr
Sailor modelSL
SO COOL modelSK
Safe modelSF
Sing modelSY
PEGASUS modelSJ
Abbreviation used in this manual
A/Cair-conditioner
ECUelectronic controller unit
SSTspecial service tool
2WDtwo-wheel drive
4WDfour-wheel drive
PMãã
Topic:what to do ?
Detailed introductionz;How to do?
Page 8 of 484
IN-4
Overall Repairing Description
1. Keep the vehicle clean and prevent it from
damage with guard plate, seat and floor cover
cloth.
2. Put down the dismantled parts in order during
the dismantle process so as to facilitate the re-
assembly
3. Observe the following items:
a) Disconnect the cable cathode from the
accumulator terminal before the electric
operation;.
b) Disconnect the cable from the cathode
connected to the vehicle body when check-
ing or repairing the accumulator where
necessary.
c) In order to avoid the damage of terminal
post of accumulator, loose the bolts first,
then pull up the cable vertically when
dismantling, dont wring it or prize it.
d) Clean the terminal posts of the accumula-
tor with dishcloth, and do not scrape them
with file or other similar tools to avoid
damage.e) Mount the cable terminal on the post with loosened nut, then
fasten the nut. donít tap the terminal onto the post with
hammer.
f) Be sure to check whether the cover of positive terminal (+) is
well located or not.
4. Check all hoses and wire plugs to verify whether they are
connected solidly and correctly.
5. Parts that cannot be reused after being used.
a) The following parts should be changed with new one regularly:
split pin, sealing washer, O-ring and oil seal, etc.
b) parts that cannot be reused after being used is marked with
in the element figure.
6. Pre-coated parts
The pre-coated parts including the bolt and nut are coated with
locking seal glue in factory.
a) In case the pre-coated parts are moved due to its fastening,
loosening or other causes, they must be coated again with the
specified seal glue.
b) Coating procedure of pre-coated parts
1) Clear away the former seal glue from the screw thread of
the said parts.
2) Dry the parts with compressed air.
3) Coat the screw thread of the parts with the specified
locking seal glue.
c) The pre-coated parts are marked with the in element
figure.
7. When necessary, sealing agent or sealing ring to prevent the
leakage.
8. Each specification shall be followed strictly. And the torque
spanners should be used.
9. Determine the necessity of using the special service tools (SST)
or special service materials (SSM) according to the real situation.
SST and SSM must be used where necessary and the repairing
should be in accordance with the repairing approach. SST list
and SSM list are attached to this manual.
10. Be sure to check whether the rated current of the new fuse is
correct when changing the fuse. The fuse rated current should
not larger than that of securing fitting and the fuse of smaller
rated current must not be used.
11. Be careful to hang or support the vehicle on the suitable place
when propping up or raising it.
a) In case prop up the vehicle at the front or back part, the wheels
must be blocked to guarantee the safety work. IntroductionOverall Repairing Rescription
tighten seal glue
Page 9 of 484
IN-5
Body lifting height and supporting position
wrong correct
IntroductionBody Lifting Height and Supporting Position
Jack lifting position
...........................................................................................................
Front......the front the beam center
Rear.....rear differential
Supporting position
safety bracket .............................................................................................
front
123456
123456
123456
123456
123456
12345
12345
12345
12345
b) The raised vehicle must be supported with the bracket; it is
dangerous to conduct the repairing work on the vehicle propped
up with one jack, even though such repairing can be finished in
short time.
12. The following items shall be taken notice to avoid the parts damage:
a) Do not open the covers of ECU and various computers where not
necessary absolutely. (if the IC terminal is touched, it be leaded
into static damage) .
b) Pull the hose at its ends when dismantling it, do not pull it at the
center section.
c) Pull the wire joint instead of the wire when pulling the joint
away.
d) Take notice to avoid of the drop of electric parts such as the
sensors or repeaters. In case those parts drop to the hard ground,
they must be changed instead of being reused.
e) Do not use the striking spanner to dismantle or mount the
thermostatic switch or thermostatic sensor.
f) Plug the needles of the multi-meter into the wire connector
carefully when checking its conductance and do not bend the
terminals.
g) Do not sheath the hose of the vacuum gauge into the very large
connector when using the gauge, instead, the stage joint shall be
used because once the hose expands, it is possible to lead into
the leakage.
Page 10 of 484
