Page 481 of 484
B-3
Application position
Front axle
Rear axle
2WD 4WD
3916011
3916012
3916013
3916014
3916015
3916016
3916017
3916018
3916019
3916020 Press fitting tool of up-
per arm liner
Disassembling and as-
sembling tools of wheel
brake cylinder of front
brake caliper
Disassembling tool of
front drive shaft bearing
Pneumatic caliper of
outer sleeve of front drive
shaft
Press fitting casing of
front drive shaft bearing
Disassembling tool of
main teeth oil seal
Press fitting tool of main
teeth oil seal
Disassembling tool of
long semi-axis
Electric cutch tester
Disassembling tool of oil
seal and needle bearingOil seal of long semi-
axis of front axle
Inner oil seal of rear axle
shaft
Needle bearing of long
semi-axis
SST Special tool
Diagram Tool Name tool number Remark
SST Special ToolSpecial Service Tool
Page 482 of 484
B-4
3916021Press fitting tool of oil
seal of long semi-axis
3916022Disassembling bracket of
long semi-axis bearing
3916023
Disassembling tool of
inner race of small bear-
ing of main teeth
3916024
Disassembling bracket of
inner race of large bear-
ing of main teeth
3916025
Press fitting casing of
inner race of large bear-
ing of main teeth
3916026
Press fitting casing of
outer race of large bear-
ing of main teeth
3916027
Press fitting casing of
outer race of small bear-
ing of main teeth
3916028
Disassembling tool of
differential side bearing
3916029
Press fitting tool of dif-
ferential side bearing
3916030
Mounting tool of needle
bearing of long semi-axis
SSTSpecial Service tool
Diagram Tool name tool number
SST Special ToolSpecial Service Tool
Application position
Front axle
Rear axle
2WD 4WDRemark
Page 483 of 484
B-5
3916031Press fitting tool of long
semi-axis bearing
3916032Electric cutch tester
3916033
Disassembling tool of
half-shaft bearing
3916034
Press fitting casing of
half-shaft bearing and oil
seal
3916035
Mounting tool of rear
axle oil seal
3916036
Mounting tool of main
teeth oil seal
3916037
Change oil seal of rear
axle main teeth on
vehicle
3916038
Mounting tool of main
teeth oil seal
3916039
Mounting tool of main
teeth oil seal
3916040
Spanners of adjusting
ring of side bearing of
differentialUse with torsion
spanner togetherChange oil seal of
rear axle main teeth
on vehicle
SSTSpecial Service tool
Diagram Tool name tool number
SST Special ToolSpecial Service Tool
Application position
Front axle
Rear axle
2WD 4WDRemark
