If they do, they
could be very seriously injured in a
crash.
Devices intended to improve
occupant comf ort or reposition the
shoulder part of a seat belt can
reduce the protective capability of
the seat belt and increase the
chance of serious injury in a crash.
Carrying hard or sharp
objects on your lap, or driving with
a pipe or other sharp objects in
your mouth, can result in injuries
if your f ront airbag inf lates. If your
hands or arms are close to an
airbag cover, they could be injured
if the front airbag inflates.
Objects on
the covers marked ‘‘SRS AIRBAG’’
could interf ere with the proper
operation of the airbags or be
propelled inside the vehicle and
hurt someone if the airbags inf late.
If a side airbag or a
side curtain airbag inf lates, a cup
holder or other hard object
attached on or near the door could
be propelled inside the vehicle and
hurt someone. This could make the driver’s seat
position sensor or the f ront
passenger’s seat weight sensors
inef f ective.
This could cause
problems with the driver’s seat
position sensor or the f ront
passenger’s seat weight sensors.
This could make the front
passenger’s weight sensors
inef f ective. Make sure the right
rear f loor mat is hooked over the
f loor mat anchor (see page ). 235
Protecting A dults and Teens
Driver and Passenger Saf ety
Additional Saf ety Precautions
T wo people should never use t he
same seat belt .
Do not put any accessories on seatbelts.
Do not place hard or sharp object sbet ween yourself and a f rontairbag. K eep your hands and arms away
f rom t he airbag covers.
Do not at t ach or place object s onthe f ront airbag covers.
On models wit h side airbags, donot at t ach hard object s on or neara f ront door. Do not modif y t he f ront seat s.
Do not place any it ems under t hefront seats.
Do not place t he right rear f loormat under t he f ront passenger’sseat .
18
— — y
y
(
y
y
Page 21 of 301
Your airbag system includes:Two SRS (Supplemental Restraint
System) f ront airbags. The driver’s
airbag is stored in the center of
the steering wheel; the f ront
passenger’sairbagisstoredinthe
dashboard. Both are marked ‘‘SRS
AIRBAG.’’
On models equipped with two side
airbags, one for the driver and one
f or a f ront passenger. The airbags
arestoredintheouteredgesof
the seat-backs. Both are marked
‘‘SIDE AIRBAG’’ (see page ).
On models equipped with two side
curtain airbags, one f or each side
of the vehicle. The airbags are
stored in the f ront, center, and
rear pillars. The f ront and center
pillars on both sides are marked
‘‘SIDE CURTAIN AIRBAG’’ (see
page ). 28 27
Additional Inf ormation About Your Airbags
Driver and Passenger Saf ety
A irbag System Components
22
(1)
(3) (7)
(6) (5)
(4)
(10)
(9)
(2)
(8) (6)
(5)
(10) (11) (4)
(1) Driver’s Airbag
(2) Front passenger’s Airbag
(3) CONTROL UNIT
(4) Seat Belt Tensioners
(5) Side Airbags
(6) Front Impact Sensors
(7) OPDS Sensor/Seat-back
(8) Passenger’s Airbag Off Indicator
(9) Front Passenger’s Weight Sensors
(10) Side Impact Sensors
(11) Driver’s Seat Position Sensor
— — y
y
(
y y
Page 22 of 301
Front passenger’s weight sensors
that monitor the weight on the
seat. These prevent the passenger’s
airbag from inflating if the weight
is less than about 65 lbs (30 kg)
(see page ).If you ever have a moderate to
severe f rontal collision, sensors will
detect the vehicle’s rapid
deceleration. If the rate of
deceleration is high enough, the
control unit will instantly inf late the
driver’s and f ront passenger’s f ront
airbags, at the time and with the
f orce needed.
Automatic front seat belt
tensioners (see page ).
Sensors that can detect a
moderate to severe frontal impact
or side impact in models equipped
with side airbags.
A sophisticated electronic system
that continually monitors and
records inf ormation about the
sensors, the control unit, the
airbag activators, and driver and
passenger seat belt use when the
ignition is ON (II).
An indicator light on the
instrument panel that alerts you to
a possible problem with your
airbags (see page ).
An indicator on the dashboard that
alerts you that the passenger’s
f ront airbag has been turned of f
(see page ).
Emergency backup power in case
your vehicle’s electrical system is
disconnected in a crash.
A driver’s seat position sensor that
monitors the seat position. If the
seat is too far forward, the airbag
will inf late with less f orce (see
page ). 20
26
63
26 31
CONT INUED
Additional Inf ormation About Your Airbags
How Your Front Airbags Work
Driver and Passenger Saf ety23
— — y
y
(
y y
Page 24 of 301
Your f ront airbags are dual-stage
airbags. This means they have two
inf lation stages that can be ignited
sequentially or simultaneously,
depending on crash severity.
In a crash, both stages
will ignite simultaneously to provide
the quickest and greatest protection.
In a crash, one stage will
ignite first, then the second stage
will ignite a split second later. This
provides longer airbag inf lation time
with a little less force.Your f ront airbags are also dual-
threshold airbags. Airbags with this
f eature have two deployment
thresholds that depend on whether
or not the occupant is wearing a seat
belt.
Your f ront airbags are also advanced
airbags. The main purpose of this
feature is to prevent airbag-caused
injuries to short drivers and children
who ride in f ront.
For the advanced airbag to work
properly, occupants must sit upright
and wear their seat belts properly. If
a child seat is installed in the f ront, it
must be properly secured.
It the occupant’s belt is , the
airbag will inf late at a slightly higher
threshold, when the airbag would be
needed to supplement the protection
provided by the seat belt.
If the occupant’s belt is ,
the airbag will deploy at the same
threshold as a conventional airbag,
because the occupant would need
extra protection.
In addition, do not spill any liquids,
cover the sensors, or put any cargo
or metal objects under the f ront
seats. Ask rear seat passengers to
not put their f eet under the f ront
seats. Any of these actions could
damage the sensors or prevent them
f rom working properly.
CONT INUED
Additional Inf ormation About Your Airbags
Driver and Passenger Saf ety
Dual-Stage A irbags
more severeless severe Dual-T hreshold A irbags
latched
not lat chedAdvanced Airbags
25
— — y
y
(
y y
Page 25 of 301
The driver’s advanced front airbag
system includes a seat position
sensor under the seat. If the seat is
positioned too f ar f orward, the
airbag will inf late sequentially,
regardless of the severity of the
impact.
If there is a problem with the seat
position sensor, the SRS indicator in
the instrument will come on in the
instrument panel. In this case, the
driver’s airbag will inf late in thenormal manner during a crash
regardless of the driver’s seating
position.
The passenger’s advanced f ront
airbag system has weight sensors
under the seat. If sensors detect a
total weight on the seat of about 65
lbs (30 kg) or less, the system will
automatically turn the passenger’s
front airbag off.
When the airbag is turned of f , a light
in the center of the dashboard will
come on indicating ‘‘Passenger
Airbag Off’’ (see page ).
If there is no passenger in the f ront
seat, the but the
indicator .
31
Additional Inf ormation About Your Airbags
Driver and Passenger Saf ety
airbag will be of f
light will not come on
26
DRIVER’S
SEAT
POSITION
SENSOR
PASSENGER’S
SEAT WEIGHT
SENSOR
— — y
y
(
y y
Page 26 of 301
Only on models equipped with sideairbags
If you ever have a moderate to
severe side impact, the sensors will
detect rapid deceleration and signal
the control unit to instantly inf late
either the driver’s or the passenger’s
side airbag.
To ensure that the passenger’s
advanced front airbag system will
work properly,
This includes:
A rear passenger pushing or
pulling on the back of the
passenger’s seat.
Moving the f ront seat f orcibly
back against cargo on the seat or
f loor behind it.
Hanging heavy items on the f ront
passenger seat, or placing heavy
items in the seat-back pocket.
Make sure the rear f loor mat is
hooked to the f loor mat anchor. If
not, the f loor mat will prevent the
seat operation and the sensors
may not work properly. Only one airbag will deploy during a side impact. If the impact is on the
passenger’s side, the passenger’s side airbag will deploy even if there
is no passenger.
To get the best protection f rom the
side airbags, front seat occupants
should wear their seat belts and sit
upright and well back in their seats.
The passenger’s side airbag has a
cutof f system designed to turn of f
the passenger’s side airbag if a child’s
head is in the airbag’s deployment
path (see page ).
If the side airbag of f indicator light
comes on, have the passenger sit
upright. Once the passenger is out of
the deployment path of the side
airbag, the system will turn the
airbag back on and the light will go
out.
A f ront seat passenger should not
use a cushion or other object as a
backrest. It may prevent the cutof f
system f rom working properly.
31
Additional Inf ormation About Your Airbags
Driver and Passenger Saf ety
How Your Side A irbags Work
do not do anyt hing
t hat would increase or decrease t he weight on t he f ront passenger’s seat .
27
— — y
y
(
y y
Page 27 of 301
The SRS indicator light
alerts you to a potential
problem with your f ront airbags, side
airbags, side curtain airbags, f ront
seat belt tensioners, or the driver’s
seat position sensor and the f ront
passenger’s weight sensors (see
pages and ).
In a moderate to severe side impact,
sensors will detect rapid deceleration
and signal the control unit to
instantly inflate the side curtain
airbag on the driver’s or the
passenger’s side of the vehicle. If the
impact is on the passenger’s side, the
passenger’s side curtain airbag will
inflate even if there are no occupants
on that side of the vehicle.
To get the best protection f rom the
side curtain airbags, occupants
should wear their seat belts and sit
upright and well back in their seats.
Your vehicle is equipped with side
curtain airbags. These airbags are
stored in the f ront, center, and rear
pillars on both sides. The f ront and
rear pillars on both sides are marked
‘‘SIDE CURTAIN AIRBAG.’’ On models with side airbags, this
indicator will also alert you to a
potential problem with your side
airbags, the passenger’s side airbag
automatic cutoff system (see page
), or the side curtain airbags.
When you turn the ignition ON (II),
this indicator will light brief ly then
go out. This tells you that the system
is working properly. 26 31
29(On models equipped)
How Your Side Curtain A irbags
Work How the SRS Indicator L ight
Works
Additional Inf ormation About Your Airbags
Driver and Passenger Saf ety28
SIDE CURTAIN AIRBAG
— — y
y
(
y
y
Page 31 of 301
Your airbag systems are virtually
maintenance-f ree, and there are no
parts you can saf ely service.
However, you must have your
vehicle serviced if:Any airbag
that has deployed must be
replaced along with the control
unit and other related parts. If a
f ront airbag inf lates, the seat belt
tensioners must also be replaced.
Do not try to remove or replace
anyairbagbyyourself.Thismust
be done by a Honda dealer or a
knowledgeable body shop.
Take your vehicle to
an authorized Honda dealer as
soon as possible. If you ignore this
indication, your airbags may not
operate properly. Even if your
airbags do not inflate, your dealer
should inspect the driver’s seat
position sensor and the f ront
passenger’s weight sensors to
make sure they are operating
properly.
Additional Inf ormation About Your Airbags
Driver and Passenger Saf ety
Airbag ServiceAn airbag ever inf lates.
T he SRS indicat or light alert s yout o a problem. If your vehicle has a moderat e t o
severe impact .
32
— — y
y
(
y y
Page 32 of 301
Together, airbags and
seat belts provide the best
protection.
Tampering could cause
the airbags to deploy, possibly
causing very serious injury.
If water or another liquid
soaks into a seat-back, it can
prevent the side airbag cutof f
system f rom working properly. This could make the
driver’s seat position sensor or the
f ront passenger’s weight sensors
inef f ective. If it is necessary to
remove or modif y a f ront seat to
accommodate a person with
disabilities, f irst contact American
Honda at 800-999-1009.
This could make the
driver’s seat position sensor and
the f ront passenger’s weight
sensors inef f ective. This could make the front
passenger’s weight sensors
inef f ective. Make sure the right
rear f loor mat is hooked over the
f loor mat anchor (see page ).
Improperly
replacing or covering f ront seat-
back covers can prevent your side
airbags f rom inf lating during a
side impact.
Pushing or
pulling on the back of the seat,
placing heavy items in the back
seat pocket, pushing cargo against
the seat, or hanging heavy items
on the seat back can interf ere with
the proper operation of the
passenger’s advanced front airbag. 235
Additional Inf ormation About Your Airbags
Driver and Passenger Saf ety
Additional Saf ety Precautions
Donotattempttodeactivateyour
airbags.
Do not t amper wit h airbagcomponent s or wiring f or any
reason.
Do not expose t he f ront seat -backsto liquid. Do not remove or modif y a f ront
seat wit hout consult ing a Hondadealer.
Do not place any it ems under t he front seats. Do not place t he right rear f loor
mat under t he f ront passenger’sseat .
Do not cover or replace f ront seat -back covers wit hout consult ing aHonda dealer.
Do not do anyt hing t hat wouldincrease or decrease weight on t hef ront passenger’s seat .
33
— — y
y
(
y y
Page 34 of 301
µµ
µ
µ
(see pages ).
Children who ride in back are less
likely to be injured by striking
interior vehicle parts during a
collision or hard braking. Also,
children cannot be injured by an
inf lating airbag when they ride in the
back. (see pages ).
According to accident statistics,
children of all ages and sizes are
saf er when they are restrained in the
back seat. The National Highway
Traffic Safety Administration and
Transport Canada recommend that
all children age 12 and under be
properly restrained in the back seat. Front airbags have been designed to
help protect adults in a moderate to
severe f rontal collision. To do this
the passenger’s f ront airbag is quite
large and it can inf late with enough
f orce to cause very serious injuries.
To help prevent airbag-caused
injuries to children, this vehicle has
an advanced airbag system.
With this system, the front
passenger’s airbag is turned of f if
sensors detect a total weight of less
thanabout65lbs(30kg)ontheseat
(see pages f or additional
inf ormation about how the f ront
passenger’s advanced airbag works).Even if the passenger’s f ront airbag
is turned of f , we strongly
recommend that children age 12 and
under ride properly restrained in a
back seat where they will be saf er.
40 50
55
51
25 26
CONT INUED
Inf ant s and small children must berest rained in an approved child seatt hat is properly secured t o t hevehicleLarger children must be restrained wit h a lap/shoulder belt and ride ona boost er unt il t he seat belt f it s t hem
properly
All Children Should Sit in the
Back Seat The Passenger’s Front Airbag
Can Pose Serious Risks
Driver and Passenger Saf ety
Protecting Children General Guidelines
35
— — y
y
(
y y
