fuses HONDA ACCORD 2006 CL7 / 7.G Owners Manual

The interior f use box is on the
driver’s lower lef t side. To remove
the f use box lid, pull it toward you
and take it out of its hinges.The under-hood f use box is located
near the back of the engine compart-
ment on the driver’s side. To open it,
pushthetabsasshown.If something electrical in your
vehicle stops working, the first thing
youshouldcheckforisablownfuse.
Determine f rom the chart on pages
and , or the diagram on the
f use box lid, which f use or f uses
control that component. Check those
f uses f irst, but check all the f uses
bef ore deciding that a blown f use is
not the cause. Replace any blown
f uses and check if the device works.
Turn the ignition switch to the
LOCK (0) position. Make sure the
headlights and all other
accessories are of f .
Remove the cover f rom the f use
box.
1. 2. 261
260
CONT INUED
Fuses
Checking and Replacing Fuses
T aking Care of t he Unexpect ed
257
INTERIOR UNDER-HOOD
TAB
 — — y  y
( y  y

Check each of the large f uses in
the under-hood f use box by
looking at the wire inside.
Removing these f uses requires a
Phillips-head screwdriver.Check the smaller f uses in the
under-hood f use box and all the
fuses in the interior fuse box by
pulling out each one with the f use
puller provided in the under-hood
fuse box.
Look f or a burned wire inside the
f use. If it is burned out, replace it
withoneof thesparefusesof the
same rating or lower.
3.
4. 5.
Fuses
258
BLOWN
BLOWN BLOWN
 — — y  y
( y
y

If you cannot drive the vehicle
without f ixing the problem, and you
do not have a spare fuse, take a fuse
of the same rating or a lower rating
f rom one of the other circuits with
the f use puller provided in the under-
hood f use box. Make sure you can
do without that circuit temporarily
(such as the accessory power socket
or radio).If you replace the blown f use with a
spare f use that has a lower rating, it
might blow out again. This does not
indicate anything wrong. Replace the
f use with one of the correct rating as
soon as you can.
If the replacement fuse of the
same rating blows in a short time,
there is probably a serious
electrical problem with your
vehicle. Leave the blown fuse in
that circuit, and have your vehicle
checked by a qualif ied mechanic.
6.
Fuses
T aking Care of t he Unexpect ed
259
FUSE PULLER
Replacing a f use with one that has a
higher rating greatly increases the
chances of damaging the electrical
system. If you do not have a
replacement f use with the proper rating
f or the circuit, install one with a lower
rating.
 — — y
y
( y y

ÎÎ
Î
µ µµ µ µµµµµµµµ µµµ
Î ÎÎ
CONT INUED
Specif ications
T echnical Inf ormation
267
Lights Battery
Fuses
12 V 60 W (HB3)
12 V 51 W (HB4)
12 V 24/2.2 CP
12 V 21 W
Headlights
Front turn signal/
Front parking lights
Rear turn signal lights
Back-up lights
License plate light
Ceiling light
Spotlights
Spotlights/Front ceiling lights
Trunk light
Door courtesy light
Vanity mirror lights 12 V
12 V
12 V
12 V
12 V
12 V
12 V
12 V 21 W
3CP8W8W8W5W
2CP
1.1 W Capacity 12 V
12 V
12 V36 AH/5 HR
38 AH/5 HR
52 AH/5 HR
Interior
Under-hood See page 261 or the fuse label
attached to the inside of the fuse
box door on each side of the
dashboard.
See page 260 or the fuse box
cover.
HighLow
4-cylinder
6-cylinder
U.S. LX, SE and LX-V6
Canadian SE and SE-V6
U.S. EX, EX-L and EX-V6
Canadian EX-L and EX-V6
Except U.S. VP and Canadian DX-G
1: 2:3:
1
2
3
 — — y
y
( y  y

.......................................
