display HONDA ACCORD COUPE 2004 CL7 / 7.G User Guide

µ
The system automatically selects the
proper mix of conditioned and/or
heated air to raise or lower the
interior temperature to the
temperature you selected.
If you set the temperature to its
lower limit ( ) or its highest limit
( ), the system runs at f ull cooling
or heating only. It does not regulate
the interior temperature.
In cold weather, the f an will not
come on automatically until the
heater starts to develop warm air.
You can manually select various
f unctions of the Climate Control
System when it is in AUTO. All other
f eatures remain automatically
controlled.
Manual selections will cause the
word AUTO in the display to go out.
If you press the A/C button next to
the display, the manual selections
will show in the display. Manual
selection will cause the light in the
AUTO button to turn of f .Turningthefanspeedand
temperature control dials all the way
to left shuts off the system
completely.
If you press OFF, the Climate
Control system shuts of f completely.
Keep the system completely of f
f or short periods only.
When
the indicator in the Dual button is on,
the driver’s side and passenger’s side
temperature can be controlled
independently (see page ). To keep stale air and mustiness
f rom collecting, you should have
the f an running at all times.
When the Climate Control System is
turned OFF, the temperature in the
upper display will also turn of f .
117
Without Navigation System
With Navigation System
With Navigation System
On EX-L and EX-V6 models
Except f or EX-L and EX-V6 models
On EX-L and EX-V6 models
Vents, Heating, and A/C
Comf ort and Convenience Feat ures
Lo
Hi Manual Operation To Turn Everything Of f
Dual Temperature Control
116
——y

y
(%
y

y

Without Navigation SystemWith Navigation System
On EX-L and EX-V6 models
Your vehicle has two temperature
control dials, one f or the driver, and
one f or the passenger.
Your vehicle has four temperature
control buttons, two f or the driver,
and two f or the passenger.
Thedriver’ssideandthepassenger’s
side can be controlled independently
by adjusting these dials or buttons
when the green indicator in the
DUAL button is lit.
Push AUTO or . The selected
temperatures appears in the display
(in the upper display with the
navigation system). When the
indicator in the DUAL button is of f ,
you can adjust both sides to the
same temperature by adjusting the
driver’s side temperature control dial
or buttons.
CONT INUED
Dual Temperature Control
Comf ort and Convenience Feat ures
T emperat ure Cont rol Dials/But t ons
117
DUAL BUTTON
Without Navigation System
DUAL BUTTON
DRIVER’S SIDE
TEMPERATURE
CONTROL BUTTONS PASSENGER’S SIDE
TEMPERATURE
CONTROL BUTTONS
With Navigation System
DRIVER’S SIDE
TEMPERATURE
CONTROL DIAL
PASSENGER’S SIDE
TEMPERATURE
CONTROL DIAL
——y

y
(%
y
y

ÛÝÛÝ
To set the driver’s side temperature
to a different value than the
passenger’s, press the DUAL button,
then turn the driver’s control dial or
press the or buttons on the
driver’s side. To set the passenger’s
side to a dif f erent value than the
driver’s, turn the passenger’s control
dial or press the or buttons on
the passenger’s side. You can adjust
the passenger’s side without
pressing the DUAL button first.
When you set the temperature to its
lower limit or its upper limit, it will be
displayed as ‘‘ ’’ or ‘‘ ’’.
Dual Temperature Control
Comf ort and Convenience Feat ures118
DRIVER’S SIDE PASSENGER’S SIDE
——y
y
(%
y

y

Playing the Radio
Comf ort and Convenience Feat ures122
AM/FM BUTTON
PWR/VOL KNOBSEEK BAR UPPER DISPLAY
AUDIO DISPLAY BUTTON TUNE/SOUND KNOB
SOUND ICON
AUDIO SELECT ICON
SCAN BUTTON
STEREO INDICATOR
SCAN ICON
EX-L and EX-V6 models
with Navigation System (U.S. Vehicles only)
PRESET ICONS
——y
y
(%
y
y

µ
µ µ
The ignition switch must be in the
ACCESSORY (I) or ON (II) position.
Turn the system on by pushing the
PWR/VOL knob or the AM/FM
button. Adjust the volume by turning
thesameknob.
Pushing the AUDIO DISPLAY
button will also turn on the system.
The band and f requency that the
radio was last tuned to is displayed.
To change bands, press the AM/FM
button. On the FM band, ST will be
displayed if the station is broadcast-
ing in stereo. Stereo reproduction on
AM is not available.
XM Satellite Radio inf ormation is
available on page . You can use any of f ive methods to
f ind radio stations on the selected
band: the
preset bars/icons, and
.
Use the TUNE bar or
knob to tune the radio to a desired
f requency. Press the side of the
bar or turn the knob to the right to
tune to a higher f requency, and
press the side or turn the knob
to the left to tune to a lower
f requency.
The SEEK f unction
searches up and down f rom the
current f requency to f ind a station
with a strong signal. To activate it,
press the or side of the
bar, then release it. The SCAN function
samples all stations with strong
signals on the selected band. To
activate it, press the SCAN button,
then release it, or touch the SCAN
icon on vehicles with navigation
system. You will see SCAN in the
display. The system will scan f or a
station with a strong signal. When it
f inds one, it will stop and play that
station f or about f ive seconds.
If you do nothing, the system will the
scan f or the next strong station and
play it f or f ive seconds. When it plays
a station you want to listen to, press
the SCAN button or touch the SCAN
icon again.
128
For Vehicles with Navigation System
CONT INUED
Playing the Radio
Comf ort and Convenience Feat ures
To Play the Radio To Select a Station TUNE,SEEK,SCAN,AUTO
SEL ECT
TUNE SEEK SCAN
123
——y
y
(%
y
y

µµµ
µ
Each side of the bars (1
6) or preset icon can store one
f requency on AM, and two
f requencies on FM.
Select the desired band, AM or
FM. FM1 and FM2 let you store
two f requencies with each side of
the preset bar or each preset icon. The preset f requencies will be lost if
your vehicle’s battery goes dead, is
disconnected, or the radio f use is
removed.
If you are
traveling far from home and can no
longer receive your preset stations,
you can use the Auto Select f eature
to find stations in the local area.
Press the A. SEL button or touch the
AUTO SELECT icon. ‘‘A. SEL’’
f lashes in the display (the upper
display on vehicles with navigation
system), and the system goes into
scan mode f or several seconds. It
stores the f requencies of six AM,
and twelve FM stations in the preset
bars or icons.
You will see a ‘‘0’’ displayed af ter
pressing a preset bar or icon if Auto
Select cannot f ind a strong station
foreverypresetbaroricon. If you do not like the stations Auto
Select has stored, you can store
other f requencies on the preset bars
or icons. Use the TUNE, SEEK, or
SCAN f unction to f ind stations, then
store them in the preset bars or
icons as described previously.
press the
A.SEL button or touch the AUTO
SELECTicon.Thisrestoresthe
presets you originally set.
First push the AUDIO DISPLAY
button to view the preset icons.
Press the SOUND button repeatedly
to display the Bass (BAS), Treble
(TRE), Balance (BAL), and Fader
(FAD) setting. On vehicles with
navigation system, touch the
SOUND icon or press the TUNE
knob.
UsetheTUNE,SEEK,orSCAN
function to tune the radio to a
desired station.
Pick a preset number (1 6), and
hold it until you hear a beep.
Repeat steps 1 to 3 to store a total
of six stations on AM and twelve
stations on FM.
Press the lef t or right side of the
bar or icon and hold it until you
hear a beep.
1. 2. 3. 4.
To turn of f Auto Select,
For Vehicles with Navigation System
Playing the Radio
Comf ort and Convenience Feat ures
Preset
AUTO SELECT
Adjusting the Sound
124
——y
y
(%
y
y

µ
µ The system will automatically return
the display to the selected audio
mode about f ive seconds af ter you
stop adjusting a mode. On vehicles
with navigation system, touch the
RETURN icon to go back to the
audio screen.
If you want to adjust the sound while
the radio/CD is playing, push the
AUDIO DISPLAY button, then touch
the SOUND icon in the display.
These two
modes adjusts the strength of the
sound coming f rom each speaker.
BAL adjusts the side-to-side strength,
while FAD adjusts the f ront-to-back
strength.
Use the TRE/BAS
modes to adjust the tone to your
liking.
Eachmodeisshowninthedisplayas
it changes. Turn the VOLUME knob
to adjust the setting to your liking.
When the level reaches the center,
you will see ‘‘ ’’ in the display. Touch the arrows next to the BAS or
TRE icons. The adjustment shows
you the current setting. Touch the
lef t or right bars on the sound grid.
Balance is equalized when the
vertical lines are centered on the
grid. Touch the f ront or rear bars on
the sound grid. The f ader is
equalized when the horizontal lines
arecenteredonthegrid.
On vehicles with navigation system
On vehicles without navigation system On vehicles with navigation system
Playing the Radio
Comf ort and Convenience Feat ures
Balance/Fader
Treble/Bass
125
FADER ADJUST ICONS
SOUND GRID
RETURN ICON
TREBLE ASJUST ICONS
With Navigation System
BALANCE
ADJUST ICONS
BASS ADJUST ICONS
——y

y
(%
y
y

Your Honda’s radio can receive the
complete AM and FM bands.
Those bands cover these f requen-
cies:
AM band:
530 to 1,710 kilohertz
FM band:
87.7 to 107.9 megahertz
Radio stations on the AM band are
assigned f requencies at least ten
kilohertz apart (530, 540, 550).
Stations on the FM band are
assigned f requencies at least 0.2
megahertz apart (87.9, 88.1, 88.3).
Stations must use these exact
f requencies. It is f airly common f or
stations to round-of f the f requency in
their advertising, so your radio could
display a f requency of 100.9 even
though the announcer may identif y
the station as ‘‘FM101.’’How well your Honda’s radio
receives stations is dependent on
many f actors, such as the distance
from the station’s transmitter,
nearby large objects, and atmos-
pheric conditions.
A radio station’s signal gets weaker
as you get f arther away f rom its
transmitter. If you are listening to an
AM station, you will notice the sound
volume becoming weaker, and the
stationdriftinginandout.If youare
listening to an FM station, you will
see the stereo indicator f lickering of f
and on as the signal weakens.
Eventually, the stereo indicator will
go of f and the sound will f ade
completely as you get out of range of
the station’s signal.
Driving very near the transmitter of
a station that is broadcasting on a
f requency close to the f requency of
the station you are listening to can
also af f ect your radio’s reception.
You may temporarily hear both
stations,orhearonlythestationyou
are close to.
Radio Reception
Comf ort and Convenience Feat ures
Radio Frequencies Radio Reception
126
——y
y
(%
y
y

Comf ort and Convenience Feat ures
Playing t he XMSatellite Radio
128
PWR/VOL KNOB
TUNE BAR
PWR/VOL KNOB
SCAN BUTTON Without Navigation System
With Navigation System
CD/SAT
BUTTON DISP
BUTTON
PRESET BARS CATEGORY/CHANNEL MODE INDICATOR
MODE ICON
SCAN ICON
CD/SAT
BUTTON
PRESET ICONS
AUDIO DISPLAY
BUTTON
SEEK/SKIP
BAR SCAN
BUTTON
CATEGORY/CHANNEL
MODE INDICATOR
SEEK/SKIP
BAR TUNE KNOB
U.S. EX-L and EX-V6 models
CH/DISC BAR
——y
y
(%
y

y

µ
µ µ
µ
The
SEEK/SKIP f unction selects the
various categories in XM, such as
Jazz/Blues, Rock, Classical, etc.
Push the to change the
category f orward. Push the to
change the category backward. To
search f or channels within a
category, turn the TUNE knob
clockwiseorpresstheTUNEbar .
Press and release this
button to change the display. The
display will change in the f ollowing
sequence: channel name, channel
number, category, artist name, and
music title. The SCAN f unction
samples all channels f or 5 seconds.
To activate the function, push the
SCAN button. Push it again to get
out of the sequence.
Each preset icon or each
side of the preset bar can store one
channel in XM1 and one in XM2.
Push the SAT button, you will see
XM1 or XM2.
Use the TUNE, SEEK or SCAN
function to tune the radio to a
desired channel.
Pick a preset icon or number and
hold it until you hear a beep.
Repeat step 1 to 3 to store a total
of six stations on XM1 and six on
XM2. Once your XM channels are preset,
pressing either side of the CH/DISC
bar will select your preset channels.
1. 2. 3. 4.
Vehicles with Navigation System On vehicles with navigation system
Comf ort and Convenience Feat ures
SEEK /SK IP (CA T EGORY)
DISPSCAN
Preset
Playing t he XMSatellite Radio
130
——y

y
(%
y
y
