Install the new bulb, and turn it
one-quarter turn clockwise to lock
it in place.
Push the electrical connector onto
the bulb.
Put the inner f ender cover in place.
Install the two holding clips. Lock
each one in place by pushing on
the center. Turn on the headlights to test the
new bulb.Open the hood.
To change the turn signal bulb on
the passenger’s side, remove the
engine coolant reserve tank by
pulling it out of its stay.Remove the socket from the
headlight assembly by turning it
one-quarter turn counterclockwise.
To remove the burned out bulb,
push it in and turn it
counterclockwise until it unlocks.
Remove the air intake duct (see
page ).
1.
2.
8. 7. 6.
9.
3.
366
Driver’s side on V6 models
Lights
Replacing a Front T urn Signal/
Parking L ight Bulb
368
BULB
V6 model is shown. STAY

Maint enance
2012 Accord Coupe

Install the new bulb and turn it
clockwise to lock it in place.
Turn on the lights to make sure
the new bulb is working.
Reinstall the coolant reserve tank.To change the bulb on the driver’s
side, start the engine, turn the
steering wheel all the way to the
right, then turn of f the engine. To
change the bulb on the passenger’s
side, turn the steering wheel to the
lef t.
Insert the socket back into the
headlight assembly. Turn it
clockwise to lock it in place.
Use a f lat-tip screwdriver to
remove the two holding clips f rom
the inner f ender.Remove the socket from the
headlight assembly by turning it
one-quarter turn counterclockwise.
Pull the burned out bulb straight
out of its socket.
Push the new bulb straight into
the socket until it bottoms.
Reinstall the air intake cover and
duct securely. Reinstall the
f astener and secure it by pushing
on the head until it locks.
6.
1.
7. 5. 4.
2.3.
4.
CONT INUED
Passenger’s side
Driver’s side on V6 models
Lights
Replacing a Front Side
369
HOLDING CLIPS BULB

Maint enance
Marker Light Bulb
2012 Accord Coupe

Insert the socket back into the
headlight assembly. Turn it
clockwise to lock it in place.
Turn on the lights to make sure
the new bulb is working.
Reinstall the inner f ender cover.
Then reinstall the holding clips,
andlocktheminplacebypushing
on their centers.Open the trunk.Pull the bulb straight out of its
socket. Push the new bulb straight
into the socket until it bottoms. Remove the socket by turning it
one-quarter turn counterclockwise.
Insert the socket back into the
light assembly. Turn it clockwise
to lock it in place.
Remove the screws in the center
of each of the two f asteners on the
side of the trunk lining. Pull the
lining back.
Determine which of the three
bulbs is burned out: stop/taillight,
back-up light or turn signal light.
5.
6.
7.
2. 1.4. 3.
5.
Lights
Replacing Rear Bulbs
370
SCREW SOCKET
BULB

Maint enance
2012 Accord Coupe

Turn on the lights to make sure
the new bulb is working.
Push the trunk lid trim back into
position.Open the trunk, and remove the
socket f rom the light assembly by
turning it one-quarter turn counter-
clockwise.
Pull the bulb straight out of its
socket. Push the new bulb straight
into the socket until it bottoms.Reinstall the socket. Turn it
clockwise until it locks. Make sure
the new bulb is working.
Put the f asteners into the holes on
the side of the trunk lining.
Reinstall the screws.
2. 1. 3.
6.
7.
8.
Lights
Replacing the High-mount
371
SOCKET
BULB

Maint enance
Brake Light Bulb
2012 Accord Coupe

If equippedPassenger’s side
Your vehicle uses halogen light
bulbs. When replacing a bulb, handle
it by its plastic case, and protect the
glass from contact with your skin or
hard objects. If you touch the glass,
clean it with denatured alcohol and a
clean cloth.
Thefoglightswereproperlyaimed
when your vehicle was new. If you
regularly carry heavy items in the
trunk or pull a trailer, readjustment
may be required. Adjustment should
be done by your dealer or another
qualif ied technician.Pull down the under cover f rom
the bumper caref ully.
Remove the electrical connector
f rom the bulb by pushing on the
tab to unlock it, then slide the
connector of f the bulb.
Remove the bulb by turning it
about one-quarter turn
counterclockwise.
Remove the three holding clips
with a flat-tip screwdriver.
1.
2.
3.
ReplacingaFogLightBulb
Lights
372
ELECTRICAL
CONNECTOR
TAB
HOLDING CLIPS
Halogen light bulbs get very hot when
lit. Oil, perspiration, or a scratch on
the glass can cause the bulb to overheat
and shatter.

Maint enance
2012 Accord Coupe

To change the bulb, start the
engine, turn the steering wheel all
the way to the right, then turn off
the engine.
Use a f lat-tip screwdriver to
remove the two holding clips f rom
the inner f ender, and pull the inner
f ender cover back.Insert the new bulb into the hole,
and turn it one-quarter turn
clockwise to lock it in place.
Push the electrical connector back
onto the bulb. Make sure it is on
all the way.
Reinstall the inner f ender. Make
sure it is installed under the edge
of the f ront bumper.
Reinstall the holding clips, and
push in the head of each clip.
Remove the electrical connector
f rom the bulb by pushing on the
tab and pulling the connector
down.
Remove the bulb f rom the f og
light assembly by turning it one-
quarter turn counterclockwise. Turn on the f og lights to test the
new bulb.
Reinstall the under cover and put
the holding clips back in place.
6.
7. 8.
4.
5. 9.
10.
11.
Passenger’s side
Driver’s side
Driver’s side
Lights
373
ELECTRICAL CONNECTOR
TAB
HOLDING CLIPS

Maint enance
2012 Accord Coupe

Dirt build-up around the openings of
the seat belt anchors can cause the
belts to retract slowly. Wipe the
openings with a clean cloth
dampened in mild soap and warm
water or isopropyl alcohol.
If your seat belts get dirty, use a sof t
brush with a mixture of mild soap
and warm water to clean them. Do
not use bleach, dye, or cleaning
solvents. Let the belts air dry bef ore
you use the vehicle.
The license plate has two lights
above it. The bulbs should be
replaced by your dealer.
Cleaning the Seat Belts
Rear License Plate Light Bulbs
Lights, Cleaning the Seat Belts
374
OPENING

Maint enance
2012 Accord Coupe

This f ilter removes the dust and
pollenthatisbroughtinfromthe
outside through the heating and
cooling system/climate control
system.
Have your dealer replace this filter
when this service is indicated by a
maintenance message on the
inf ormation display. It should be
replaced every 15,000 miles (24,000
km) if you drive primarily in urban
areas that have high concentrations
of soot in the air, or if the airf low
from the heating and cooling
system/climate control system
becomeslessthanusual.
If you remove a f loor mat, make sure
tore-anchoritwhenyouputitback
in your vehicle.
If you use a non-Honda f loor mat,
make sure it f its properly and that it
canbeusedwiththefloormat
anchors. Do not put additional f loor
mats on top of the anchored mat.
The driver’s and right rear
passenger’s f loor mats that came
with your vehicle hook over the f loor
mat anchors. This keeps the f loor
mats f rom sliding f orward and
possibly interf ering with the pedals
(driver’s floor mat) or with the seat
weight sensors (right rear f loor mat).
Floor Mats, Dust and Pollen Filter
Dust and Pollen Filter
Floor Mats
375
REAR (Right passenger’s side)
FRONT (Driver’s side)

Maint enance
2012 Accord Coupe

To replace a wiper blade:Raise the wiper arm of f the
windshield. Raise the driver’s side
first, then the passenger’s side.
Check the condition of the wiper
blades at least every six months.
Replace them if you f ind signs of
cracking in the rubber, areas that are
getting hard, or if they leave streaks
and unwiped areas when used.
Disconnect the blade assembly
from the wiper arm:
Put a cloth on the edge of the lock
tab to prevent scratches, then
push up on the lock tab caref ully
with a flat-tip screwdriver.
2.
1.
Wiper Blades
376
WIPER ARMS LOCK TAB
Do not open the hood when the wiper
arms are raised, or you will damage the
hood and wiper arms.

Maint enance
2012 Accord Coupe

Pivot the blade assembly toward
the wiper arm until it releases
from the wiper arm.
When replacing a wiper blade,
make sure not to drop the wiper
blade or wiper arm down on the
windshield.Examine the new wiper blades. If
they have no plastic or metal
reinf orcement along the back
edge, remove the metal
reinf orcement strips f rom the old
wiper blade, and install them in
the slots along the edge of the new
blade.
Remove the blade f rom its holder
by grabbing the tabbed end of the
blade. Pull f irmly until the tabs
come out of the holder. Make sure the two rubber tabs
inside the blade f it to each notch of
the reinf orcement, as shown.
3. 4.
CONT INUED
Wiper Blades
377
WIPER ARM
BLADE
TOP
BLADE REINFORCEMENT

Maint enance
