Pour the f luid slowly and caref ully
so you do not spill any. Clean up
any spill immediately; it could
damage components in the engine
compartment.
Remove the dipstick and check
the f luid level. It should be
between the upper and lower
marks. If the level is below the lower
mark, add f luid into the dipstick
hole to bring it to the level
between the upper and lower
marks.
The transmission should be drained
and ref illed with new f luid according
to the Maintenance Minder (see
page ).
If you are not sure how to add f luid,
contact your dealer.
Always use Honda ATF DW-1
(automatic transmission f luid).
Insert the dipstick all the way back
into the transmission securely as
shown in the illustration.
5.
4. 6. 341
T ransmission Fluid
358
V6 models
LOWER
MARK UPPER
MARK
TM
Use only Honda ATF DW-1 (automatic
transmission f luid). Do not mix with
other transmission f luids.
Using transmission f luid other than
Honda ATF DW-1 may cause
deterioration in transmission operation
and durability, and could result in
damage to the transmission.
Damage resulting f rom the use of
transmission f luid other than Honda
ATF DW-1 is not covered by the Honda
new vehicle warranty.

Maint enance
2012 Accord Coupe

Check the f luid level with the
transmission at normal operating
temperature and the vehicle sitting
on level ground.Reinstall the under cover and put the
holding clips back in place. Make
sure the under cover is installed
under the edge of the f ront bumper.
The transmission should be drained
and ref illed with new f luid according
to the Maintenance Minder (see
page ).
If you are not sure how to check and
add f luid, contact your dealer.
Remove the transmission f iller bolt,
and caref ully f eel inside the bolt hole
with your f inger.
The f luid level should be up to the
edge of the bolt hole. If it is not, add
Honda Manual Transmission Fluid
(MTF) until it starts to run out of the
hole. Reinstall the f iller bolt, and
tighten it securely.
To check the transmission f luid level,
remove the under cover holding clips
with a flat-tip screwdriver, then
remove the under cover caref ully. If Honda MTF is not available, you
may use an SAE 0W-20 or 5W-20
viscosity motor oil with the API
Certif ication Seal that says ‘‘FOR
GASOLINE ENGINES’’ as a
temporary replacement. However,
motor oil does not contain the proper
additives, and continued use can
cause stif f er shif ting. Replace as
soon as it is convenient.
341
CONT INUED
4-cylinder models
T ransmission Fluid
Manual Transmission
359
Correct level FILLER BOLT
TM

Maint enance
2012 Accord Coupe

Remove the check bolt and look for
transmission f luid coming out of the
bolt hole. If a small amount of f luid
drips out of the bolt hole, reinstall
the check bolt.
Check the f luid level with the
transmission at normal operating
temperature and the vehicle sitting
on level ground.
If no f luid comes out, remove the
f iller bolt and washer. Slowly add
Honda Manual Transmission Fluid
(MTF) until it starts to run out of the
check bolt hole.
V6 models
T ransmission Fluid
360
FILLER BOLT
WASHER
CHECK BOLT
DRAIN BOLT

Maint enance
2012 Accord Coupe

Pour the f luid into the f iller hole
slowly and caref ully so you do not
spill any. Clean up any spills
immediately; it could damage
components in the engine
compartment.The transmission should be drained
and ref illed with new f luid according
to the Maintenance Minder (see
page ).
If you are not sure how to check and
add f luid, contact your dealer.
Let the f luid run out until it stops,
then reinstall the check bolt and the
f iller bolt.
Make sure to put a new washer on
each bolt when reinstalling it.
Reinstall the under cover and put the
holding clips back in place. Make
sure the under cover is installed
under the edge of the f ront bumper. If Honda MTF is not available, you
may use an SAE 0W-20 or 5W-20
viscosity motor oil with the API
Certif ication Seal that says ‘‘FOR
GASOLINE ENGINES’’ as a
temporary replacement. However,
motor oil does not contain the proper
additives, and continued use can
cause stiffer shifting. Replace as
soon as it is convenient.
341
T ransmission Fluid
361
TM

Maint enance
2012 Accord Coupe

Check the f luid level in the
reservoirs monthly. There are up to
two reservoirs, depending on the
model. They are:Brake f luid reservoir (all models)
Clutch f luid reservoir
(manual transmission only) Always use Honda Heavy Duty
Brake Fluid DOT 3. If it is not
available, you should use only DOT 3
or DOT 4 f luid, f rom a sealed
container, as a temporary
replacement.
Using any non-Honda brake f luid can
cause corrosion and decrease the lif e
of the system. Have the brake
system f lushed and ref illed with
Honda Heavy Duty Brake Fluid
DOT 3 as soon as possible.
Brake f luid marked DOT 5 is not
compatible with your vehicle’s
braking system and can cause
extensive damage.
The f luid level should be between
theMINandMAXmarksontheside
of the reservoir. If the level is at or
below the MIN mark, your brake
system needs attention. Have the
brake system inspected f or leaks or
worn brake pads.
Independent of the Maintenance
Minder inf ormation, replace the
brake f luid every 3 years.
Brake and Clutch Fluid
Brake Fluid
362
MAX
MIN

Maint enance
2012 Accord Coupe

Check the level on the side of the
reservoir when the engine is cold.
The f luid should be between the
UPPER LEVEL and LOWER LEVEL.
If not, add power steering f luid to the
UPPER LEVEL.
The f luid level should be between
theMINandMAXmarksontheside
of the reservoir. If it is not, add
brake f luid to bring it up to that level.
Use the same fluid specified for the
brake system. A low f luid level can indicate a leak
in the clutch system. Have this
system inspected as soon as possible.
CONT INUED
Manual transmission only
Power Steering Fluid
Clutch Fluid
Brake and Clutch Fluid, Power Steering Fluid
363
MAX
4-cylinder models
MIN UPPER LEVEL
LOWER LEVEL

Maint enance
2012 Accord Coupe

µµ
The timing belt should be replaced
according to the Maintenance
Minder (see page ).
Replace the timing belt every 60,000
miles (100,000 km) if you regularly
drive your vehicle in any of the
f ollowing conditions:
Always use Honda Power Steering
Fluid. You may use another power
steering f luid as an emergency
replacement, but have the power
steering system f lushed and ref illed
with Honda PSF as soon as possible.
A low power steering f luid level can
indicate a leak in the system. Check
the f luid level f requently, and have
the system inspected as soon as
possible.
Pour the f luid slowly and caref ully
so you do not spill any. Clean up
any spills immediately; it could
damage components in the engine
compartment. In very high temperatures
(over 110°F, 43°C).
In very low temperatures
(under 20°F, 29°C).
If you f requently tow a trailer.341
V6 models
Timing Belt
Power Steering Fluid, Timing Belt
364
UPPER LEVEL
V6 models LOWER LEVEL
TM
Turning the steering wheel to f ull lef t
or right lock and holding it there can
damage the power steering pump.

Maint enance
2012 Accord Coupe

Theheadlightswereproperlyaimed
when your vehicle was new. If you
regularly carry heavy items in the
trunk or pull a trailer, readjustment
may be required. Adjustments
should be done by your dealer or
another qualif ied technician.Your vehicle has halogen headlight
bulbs. When replacing a bulb, handle
it by its base, and protect the glass
f rom contact with your skin or hard
objects. If you touch the glass, clean
it with denatured alcohol and a clean
cloth.
Open the hood.
To change a bulb on the
passenger’s side, remove the
engine coolant reserve tank by
pulling it out of its stay.
1.
CONT INUED
Headlight A iming
Replacing a Headlight Bulb
Lights
High Beam Headlight
365
STAY
4-cylinder modelsHalogen headlight bulbs get very hot
when lit. Oil, perspiration, or a scratch
on the glass can cause the bulb to
overheat and shatter.

Maint enance
2012 Accord Coupe

Remove the electrical connector
f rom the bulb by pushing on the
tab to unlock it, then slide the
connector of f the bulb.
Remove the bulb by turning it
approximately one-quarter turn
counterclockwise.
To change a bulb on the driver’s side,
undo the f astener and remove the air
intake cover by pushing the tab.
Then remove the duct.
3. 2.On V6 models
Lights
366
FASTENERAIR INTAKE COVER BULB
TAB
DUCT
V6 models STAY
V6 models

Maint enance
2012 Accord Coupe

To change the passenger’s side
bulb, start the engine, turn the
steering wheel all the way to the
lef t, and turn of f the engine. To
change the driver’s side bulb, turn
the steering wheel to the right.
Install the new bulb, and turn it
one-quarter turn clockwise to lock
it in place.
Push the electrical connector onto
the bulb.
Turn on the headlights to test the
new bulb.
Reinstall the engine coolant
reserve tank.
Remove the electrical connector
f rom the bulb by pushing on the
tab to unlock it, then slide the
connector of f the bulb. Remove the bulb by turning it
approximately one-quarter turn
counterclockwise. Pull the inner f ender cover away
f rom the f ender and bumper.
Use a f lat-tip screwdriver to
remove the two holding clips f rom
the inner f ender.
Reinstall the air intake cover and
duct securely. Reinstall the
f astener and secure it by pushing
on the head until it locks.
6. 5.
3.
4.
5.
1.
2.
7. 4.
CONT INUED
Passenger’s side
Driver’s side on V6 models L ow Beam Headlight
Lights
367
HOLDING CLIPS
BULB
TAB
