display HONDA ACCORD HYBRID 2007 CL7 / 7.G Owner's Manual

µ
µ If you do not like the stations Auto
Select has stored, you can store
other f requencies on the preset bars
or icons. Use the TUNE, SEEK, or
SCAN f unction to f ind stations, then
store them in the preset bars or
icons as described previously.
If you are
traveling far from home and can no
longer receive your preset stations,
you can use the auto select feature to
find stations in the local area.
Press the A. SEL button or touch the
A. SEL icon. A. SEL will f lash in the
display, and the system will go into
scan mode f or several seconds. It
stores the f requencies of six AM,
and twelve FM stations in the preset
bars (1 6) or icons. You will see a
‘‘0’’ displayed af ter pressing a preset
bar or icon if Auto Select cannot f ind
a strong station for every preset bar
or icon. press the
A. SEL button or A. SEL icon. This
restores the presets you originally
set.
The preset f requencies may be lost if
your vehicle’s battery goes dead, is
disconnected, or the radio f use is
removed.
To turn of f Auto Select,
Playing the AM/FM Radio
AUTO SELECT
Features
121
06/08/08 14:36:32 31SDR620_126

µ
µ ´µ
Press the SOUND button or icon, or
press the TUNE knob repeatedly to
display the BASS, TREBLE,
BALANCE, and FADER settings.
These two
modes adjust the strength of the
sound coming f rom each speaker.
BALANCE adjusts the side-to-side
strength, while FADER adjusts the
front-to-back strength.
Use the TREBLE/
BASS modes to adjust the tone to
your liking. Eachmodeisshowninthedisplayas
it changes. Turn the PWR/VOL
knob to adjust the setting to your
liking. When the level reaches the
center, you will see a ‘‘ ’’ in the
display.
To adjust treble and bass, touch the
‘‘ ’’ or ‘‘ ’’ icon on each side of the
TREBLE or BASS adjustment bar.
The adjustment bars show you the
current settings.
To adjust balance, touch the ‘‘L’’ or
‘‘R’’ icon. To adjust f ader, touch the
‘‘RR’’ or ‘‘FR’’ icon. The adjustment
bars show you the current settings.
You can also make an adjustment
with the joystick. Move it up and
down to switch the mode, and move
it right and lef t to change the setting.The system will automatically return
the display to the selected audio
mode about f ive seconds af ter you
stop adjusting a mode.
You can adjust the sound on the
navigation screen. To adjust the
sound, push the AUDIO button, then
enter the sound grid by touching the
SOUNDicononthedisplay.
On vehicles with navigation system On vehicles without navigation system
On vehicles with navigation system
Adjusting the Sound
Balance/Fader
Treble/Bass
Playing the AM/FM Radio
122
06/08/08 14:36:44 31SDR620_127

The radio can receive the complete
AM and FM bands.
Those bands cover these f requen-
cies:
AM band: 530 to 1,710 kHz
FM band: 87.7 to 107.9 MHzHow well the radio receives stations
is dependent on many f actors, such
as the distance from the station’s
transmitter, nearby large objects,
and atmospheric conditions.
Driving very near the transmitter of
a station that is broadcasting on a
f requency close to the f requency of
the station you are listening to can
also af f ect your radio’s reception.
You may temporarily hear both
stations,orhearonlythestationyou
are close to.
A radio station’s signal gets weaker
as you get f arther away f rom its
transmitter. If you are listening to an
AM station, you will notice the sound
volume becoming weaker, and the
stationdriftinginandout.If youare
listening to an FM station, you will
see the stereo indicator f lickering of f
and on as the signal weakens.
Eventually, the stereo indicator will
go of f and the sound will f ade
completely as you get out of range of
the station’s signal.
Radio stations on the AM band are
assigned f requencies at least 10 kHz
apart (530, 540, 550). Stations on the
FM band are assigned f requencies at
least 0.2 MHz apart (87.9, 88.1, 88.3).
Stations must use these exact
f requencies. It is f airly common f or
stations to round of f the f requency in
their advertising, so your radio could
display a f requency of 100.9 even
though the announcer may identif y
the station as ‘‘FM101.’’
CONT INUED
Radio Frequencies
Radio Reception
Playing the AM/FM Radio
Features
123
06/08/08 14:36:54 31SDR620_128

Playing a CD
Features
125
SEEK/SKIP
BARCD LOAD
INDICATORSEEK BAR
PWR/VOL
KNOB
LOAD
BUTTON
CD LOAD INDICATOR
LOAD BUTTON RPT BUTTON
RDM
BUTTON
EJECT
BUTTON
CD SLOT
PWR/VOL KNOB UPPER DISPLAY
(U.S. model shown)
(U.S. model shown)
SCAN BUTTON SCAN
BUTTON
EJECT
BUTTON
DISC REPEAT
ICON
CD/AUX XM
BUTTON
CD/AUX XM
BUTTON
CD SLOTAUDIO
BUTTON
CHANGE
DISC
BUTTON TRACK
RANDOM
ICON
TRACK
REPEAT
ICON
Without navigation system With navigation system
06/08/08 14:37:11 31SDR620_130

To load or play CDs, the ignition
switch must be in the ACCESSORY
(I) or the ON(II) position.To listen to satellite radio when a CD
is playing, press the CD/AUX XM
button.
You operate the CD changer with
the same controls used f or the radio.
To select the CD changer, press the
CD button. The numbers of the disc
andtruckplayingareshowninthe
display. On vehicles with navigation
system, these numbers also appear
in the upper display. The system will
continuously play a disc until you
change modes. To play the radio when a CD is
playing, press the AM/FM button.
Press the CD button again to switch
back to the CD player.
To play a tape when a CD is playing,
insert a tape in the player (optional).
If a tape is in the player, press the
CD/AUX button. Press the CD/AUX
button again to switch back to the
CD player.
If you turn the system of f while a CD
is playing, either with the PWR/VOL
knob or by turning off the ignition,
the disc will stay in the drive. When
youturnthesystembackon,theCD
will begin playing where it lef t of f .
For vehicles with Satellite RadioTo Play a CD
Playing a CD, CD Changer
126
Do not use discs with adhesive labels.
The label can curl up and cause the
disc to jam in the unit.
06/08/08 14:37:21 31SDR620_131

µµ´
Û
Ý
You can also load a CD into an empty
position while a CD is playing. Select
the empty position (the disc number
indicator is not highlighted) and
press the appropriate preset bar or
touch a disc icon. The current CD
stops playing and starts the loading
sequence. The CD just loaded will
play. To select a dif f erent disc, press the
appropriate side of a preset bar
(1 6) or use the Preset 5 (DISC )
to select the previous disc or Preset
6 (DISC ) to select the next disc in
sequence. On vehicles with
navigation system, touch the
appropriate disc icon or press the
or side of the CH/DISC bar. If
youselectanemptypositioninthe
CD changer, the system will try to
load the CD in the next available slot.
Repeat steps 1 through 3 until all
six positions are loaded. If you are
not loading all six positions, the
system begins playing the last CD
loaded. When the CD load indicator turns
green and ‘‘LOAD’’ appears in the
screen again, insert the next CD in
the slot. Insert the disc into the CD slot
when the green CD load indicator
comes on. Insert it only about
half way; the drive will pull it in the
rest of the way. You will see
‘‘BUSY’’ on the display as the CD
load indicator turns red and blinks
as the CD is loaded. The disc number f or an empty
position is highlighted and the red
light starts blinking. Press and hold the LOAD button
until you hear a beep and see
‘‘LOAD’’ in the display, then
release the button.
1.
2.
3.
4.
5.
CONT INUED
Playing a CD, CD Changer
L oading CDs in the In-dash CD
Changer
Features
127
06/08/08 14:37:31 31SDR620_132

µ
µ µ µ
µ
µ µ
µ
Push the to
play the next track on the disc. Push
the oncetoreplaythetrackin
play; press it twice to replay the
previous track. To move rapidly
within a track, press and hold the or button.
Press the RPT button
to continuously replay a track. You
will see RPT in the display. Press the
RPT button again to turn it off.
To continuously
replay the current CD, press and
hold the RPT button for about a
second. You will see D-RPT in the
display. The system switches to the
normal repeat mode when you press
the RPT button during the disc
repeat mode. Press the RDM
button to play the tracks in random
order. You will see RDM in the
display. Press the RDM button again
to return to normal play.
The SCAN f unction
samples all the tracks on the
selected disc in the order they are
recorded. To activate it, press and
release the SCAN button. You will
see SCAN in the display, and you will
get a 10 second sampling of each
track on the selected CD. Press the
SCAN button again to get out of scan
mode.
When you press and
hold the SCAN button for more than
2 seconds, the system gives you a 10
second sampling of the f irst track on
each disc in the in-dash CD changer.
You will see D-SCAN in the display.
Touch the SCAN button again to get
out of disc scan mode. When you
touch the TRACK REPEAT icon on
the audio display, the system
continuously plays the same track.
You will see REPEAT beside the
track inf ormation on the audio
screen, and RPT in the upper display.
Press the icon again to get out of
track repeat mode.
When you touch
the DISC REPEAT icon on the audio
display, the system continuously
replays the current CD. You will see
REPEAT beside the disc inf ormation
on the audio screen, and D-RPT in
the upper display. Touch the icon
again to get out of disc repeat mode. To use the controls, press the
AUDIO button; the control icons will
appear on the screen.
On vehicles without navigation system On vehicles with navigation system
Playing a CD, CD Changer
SEEK /SK IP
REPEAT
DISC REPEATRANDOM
SCAN
DISC SCAN
T RA CK REPEA T
DISC REPEAT
128
06/08/08 14:37:44 31SDR620_133

µµ µWhen you touch
this icon on the audio display or
press the SCAN button, you will get
a10secondsamplingof eachtrack
on the current CD. You will see
SCAN beside the track inf ormation
on the audio screen, and SCAN in
the upper display. Press the icon or
button again to get out of track scan
mode. When you touch the
DISC SCAN icon on the audio
display, or press and hold the SCAN
button for more than 2 seconds, the
system gives you a 10 second
sampling of the f irst track on each
disc in the in-dash CD changer. You
will see SCAN beside the disc
inf ormation on the audio screen, and
D-SCAN in the upper display. The
system switches to the track scan
mode when you press the SCAN
button. To get out of disc scan mode,
touch the icon again, or press and
hold the SCAN button for more than
2 seconds. When you
touch the TRACK RANDOM icon on
the audio display, the system plays
the tracks on the current CD in
random order. You will see
RANDOM beside the track
inf ormation on the audio screen.
Press the icon again to get out of
track random mode.
Playing a CD, CD Changer
T RA CK SCA N DISC SCA N T RA CK RA NDOM
Features
129
06/08/08 14:37:49 31SDR620_134

To remove a dif f erent disc f rom the
changer,firstselectitwiththe
appropriate preset bar or icon. When
that CD begins playing, press the
eject button. Continue pressing the
EJECT button to remove all the discs
f rom the changer.
To remove all the discs in the
changer in a sequence, press and
hold the eject button for about 2
seconds.
To play a tape when a CD is playing,
insert a tape in the player (optional).
If a tape is in the player, press the
CD/AUX button. Press the CD/AUX
button again to switch back to the
CD player.
If you turn the system of f while a CD
is playing, the CD will stay in the
drive. When you turn the system
back on, the CD will begin playing
where it lef t of f .
Press the eject button ( ) to
remove the CD. If you eject the CD,
but do not remove it f rom the slot,
the system will automatically reload
the CD af ter 15 seconds and put it in
pause mode. To begin playing, press
the CD button.
PresstheAM/FMorCD/AUX/XM
button to switch to the AM/FM
radio or satellite radio while a CD is
playing. To play the CD, press the
CD/AUX/XM button again. To remove the disc that is currently
playing, press the eject button. You
will see ‘‘EJECT’’ in the display.
When you press the eject button, the
system switches to the previous
mode (AM/FM radio, satellite radio
(U.S. models), or tape player
(optional)).
Playing a CD, CD Changer
Removing CDs f rom the Changer
To Stop Playing a CD
130
06/08/08 14:37:58 31SDR620_135

Error Message CauseSolution
Thechartontherightexplainsthe
error messages you may see in the
display while playing a disc.
If you see an error message in the
display while playing a disc, press
the eject button. After ejecting the
disc, check it for damage or
deformation. If there is no damage,
insert the disc again.
If there is still a problem, the error
message will appear again. Press the
eject button, and pull out the disc.
Insert a dif f erent disc. If the new
disc plays, there is a problem with
the f irst disc. If the error message
cycle repeats and you cannot clear it,
take your vehicle to a dealer.
FOCUS Error
Mechanical Error
High Temperature Press the eject button and pull out the disc.
Check if the disc is inserted correctly in the CD
player.
Make sure the disc is not scratched or damaged.
Press the eject button and pull out the disc.
Check the disc for damage or deformation.
If the CD cannot be pulled out or the error
indication does not disappear after the disc is
ejected, see your dealer.
Do not try to force the disc out of the player.
Will disappear when the temperature returns to
normal.
or
or
CD Player Error Messages
Features
131
06/08/08 14:38:09 31SDR620_136
