jacking HONDA ACCORD HYBRID 2007 CL7 / 7.G Owners Manual

Use the extension and the wheel
nut wrench as shown to raise the
vehicle until the f lat tire is of f the
ground.
Remove the wheel nuts, then
remove the f lat tire. Handle the
wheel nuts caref ully; they may be
hot f rom driving. Place the f lat tire
on the ground with the outside
surface facing up.
Place the jack under the jacking
point nearest the tire you need to
change. Turn the end bracket
clockwise until the top of the jack
contacts the jacking point. Make
sure the jacking point tab is
restinginthejacknotch.
Loosen the wheel nuts 1/2 of a
turn with the wheel wrench.
8.
9.
7.
6.
Changing a Flat Tire
236
EXTENSION
WHEEL WRENCH
JACKING POINT
WHEEL NUT
WHEEL NUT WRENCH
06/08/08 14:54:09 31SDR620_241

...................................Inside Mirror . 93
.............................Inspection, Tire . 225
....................Installing a Child Seat . 44
..........Tether Anchorage Points . 49
.............................Using LATCH . 45
............................Instrument Panel . 59
........Instrument Panel Brightness . 78
........................................Introduction .i
.................Jacking up the Vehicle . 235
.......................................Jack, Tire . 235
................................Jump Starting . 241
..................................................Keys . 81
.......................Label, Certif ication . 258
.................Lane Change, Signaling . 76
........................Lap/Shoulder Belts . 21
Lights
....................Bulb Replacement . 213
.......................................Indicator . 63
.........................................Parking . 76
............................Turn Signal . 63, 76
....................................Load Limits . 165
......LOCK (Ignition Key Position) . 83
Locks
.......Anti-thef t Steering Column . 83
............................Fuel Fill Door . 157
..................................Glove Box . 102
....................Lockout Prevention . 84
.................................Power Door. 84
...........................................Trunk. 88
........................Low Coolant Level. 160
...Lower Gear, Downshif ting to a . 172
...Low Oil Pressure Indicator . 60, 245
...Lubricant Specif ications Chart . 260
.........................................Luggage. 164
..................................Maintenance. 191
Owner’s Maintenance
...................................Checks. 198
........................................Record. 200
.........................Minder Indicator. 65
..........................................Saf ety. 192
................................Minder . 193-199
.Malfunction Indicator Lamp . 60, 246
...............................Meters, Gauges. 67
..........................Mirrors, Adjusting. 93
.................................Modif ications. 163
.........................................Moonroof. 97
...Octane Requirement, Gasoline . 156
.........................................Odometer. 68
Oil
........................Change, How to. 205
...............Change, When to . 193-199
......................Checking Engine. 159
..............Pressure Indicator . 60, 245
Selecting Proper Viscosity
......................................Chart. 203
...........ON (Ignition Key Position) . 83
...................Neutral Gear Position . 173
..................New Vehicle Break-in . 156
...................NOTICE, Explanation of .i
...............Numbers, Identif ication . 258
Index
J
K
L
M
N
O
IV
06/08/08 15:00:39 31SDR620_285
