engine coolant HONDA CIVIC 2013 9.G User Guide

275
uuMaintenance Under the Hood uEngine Coolant
Continued
Maintenance
Engine CoolantThis coolant is premixed with 50% antifreeze and 50% water. Do not add any
straight antifreeze or water.
We recommend you check the engine coolant level every time you refuel. Check the
reserve tank first. If it is completely empty, also check the coolant level in the
radiator. Add the engine coolant accordingly.
1.Check the amount of coolant in the reserve
tank.
2. If the coolant level is below the MIN mark,
add the specified coolant until it reaches
the MAX mark.
3. Inspect the cooling system for leaks.Specified coolant: Honda Long Life Antifreeze/Coolant Type 2■Reserve Tank
1Engine CoolantNOTICEIf temperatures consistently below −22°F (−30°C) are
expected, the coolant mixture should be changed to
a higher concentration. Consult a dealer for more
information.
If Honda antifreeze/coolant is not available, you may
use another major brand non-silicate coolant as a
temporary replacement. Check that it is a high quality
coolant recommended for aluminum engines.
Continued use of any non-Honda coolant can result
in corrosion, causing the cooling system to
malfunction or fail. Have the cooling system flushed
and refilled with Honda antifreeze/coolant as soon as
possible.
Do not add rust inhibitors or other additives to your
vehicle's coolant system. They may not be compatible
with the coolant or with the engine components.
Reserve
Tank
MAX
MIN

uuMaintenance Under the Hood uEngine Coolant
276Maintenance
1. Make sure the engine and radiator are
cool.
2. Turn the radiator cap counterclockwise and
relieve any pressure in the coolant system.
Do not push the cap down when turning.
3. Push down and turn the radiator cap
counterclockwise to remove it.
4. The coolant level should be up to the base
of the filler neck. Add coolant if it is low.
5. Put the radiator cap back on, and tighten it
fully.
6. Pour coolant into the reserve tank until it
reaches the MAX mark. Put the cap back
on the reserve tank.
■Radiator
1 RadiatorNOTICEPour the fluid slowly and carefully so you do not spill
any. Clean up any spills immediately; they can
damage components in the engine compartment.
3
WARNING
Removing the radiator cap while the
engine is hot can cause the coolant to spray
out, seriously scalding you.
Always let the engine and radiator cool
down before removing the radiator cap.
Radiator Cap
1.8 ℓ engine models2.4 ℓ engine models
Radiator Cap

uuCleaning uExterior Care
312Maintenance
A good coat of automotive body wax helps protect your vehicle’s paint from the
elements. Wax will wear off over time and expose your vehicle’s paint to the
elements, so reapply as necessary.
If you get gasoline, oil, engine coolant, or battery fluid on resin coated parts, they
may be stained or the coating may peel. Promptly wipe it away using a soft cloth and
clean water.
Wipe using a glass cleaner.
Aluminum is susceptible to deterioration caused by salt and other road
contaminants. Use a sponge and mild detergent to wipe away promptly.
Be careful not to use harsh chemicals (including some commercial wheel cleaners) or
a stiff brush. They can damage the clear coat of the aluminum alloy wheels that
helps keep the aluminum from corroding and tarnishing.■Applying Wax■Maintaining the Bumpers and Other Resin Coated Parts■Cleaning the Window■Maintaining Aluminum Wheels
*
1 Applying WaxNOTICEChemical solvents and strong cleaners can damage
the paint, metal, and plastic on your vehicle. Wipe up
spills immediately.1Maintaining the Bumpers and Other Resin Coated Parts
Ask a dealer about the correct coating material when
you want to repair the painted surface of the parts
made of resin.1Cleaning the Window
Wires are mounted to the inside of the rear window.
Wipe along the same direction as the wires with a
soft cloth so as not to damage them.
* Not available on all models

uuOverheating uHow to Handle Overheating
336Handling the Unexpected
■Next thing to do
1.Check that the cooling fan is operating and
stop the engine once the high temperature
indicator goes off.
u If the cooling fan is not operating,
immediately stop the engine.
2. Once the engine has cooled down, inspect
the coolant level and check the cooling
system components for leaks.
u If the coolant level in the reserve tank is
low, add coolant until it reaches the
MAX mark.
u If there is no coolant in the reserve tank,
check that the radiator is cool. Cover the
radiator cap with a heavy cloth and open
the cap. If necessary, add coolant up to
the base of the filler neck, and put the
cap back on.■Last thing to do
Once the engine has cooled sufficiently, restart it and check the high temperature
indicator.
If the high temperature indicator is off, resume driving. If it stays on, contact a dealer
for repairs.
1 How to Handle Overheating
If the coolant is leaking, contact a dealer for repairs.
Use water as an emergency/temporary measure only.
Have a dealer flush the system with proper antifreeze
as soon as possible.
3
WARNING
Removing the radiator cap while the
engine is hot can cause the coolant to spray
out, seriously scalding you.
Always let the engine and radiator cool
down before removing the radiator cap.
MAX
Reserve
TankMIN

347
uuSpecifications u
Continued
Information
■Brake/Clutch Fluid
■ Automatic Transmission Fluid
■ Manual Transmission FluidSpecified
Honda Heavy Duty Brake Fluid DOT 3
Specified
Honda ATF DW-1
(automatic transmission fluid)
Capacity Change 2.5 US qt (2.4 ℓ)
Specified
Honda Manual Transmission Fluid
Capacity Change 1.5 US qt (1.4 ℓ)
■ Engine Oil
■ Engine CoolantRecommended
·Genuine Honda Motor Oil 0W-20
·API Premium-grade 0W-20 detergent oil
Capacity Change 3.7 US qt (3.5 ℓ)
Change
including
filter
3.9 US qt (3.7 ℓ)
Specified
Honda Long-Life Antifreeze/Coolant Type2
Ratio 50/50 with distilled water
Capacity
1.48 US gal (5.59 ℓ)
(change including the remaining
0.125 US gal (0.475 ℓ) in the reserve tank)
■ Tire*1: Canadian DX models
*2: LX models
*3: HF model
*4: EX and U.S. EX-L models
*5: Canadian Touring modelsRegular
Size
P195/65R15 89H
*1, *2
P195/65R15 89S
*3
P205/55R16 89H
*4
P215/45R17 87V
*5
Pressure
psi(kPa[kgf/cm
2])
30 (210 [2.1])
*1, *2
32 (220 [2.2])
*3, *4, *5
Compact
Spare
*
Size T135/80D15 99M
Pressure
psi(kPa[kgf/cm
2]) 60 (420 [4.2])
Wheel Size
Regular
15 x 6J
*1, *3
15 x 6 1/2J
*2
16 x 6 1/2J
*4
17 x 7J
*5
Compact Spare
*
15 x 4T
* Not available on all models

349
uuSpecifications u
Information
■Brake/Clutch Fluid
■ Manual Transmission FluidSpecified
Honda Heavy Duty Brake Fluid DOT 3
Specified
Honda Manual Transmission Fluid
Capacity Change 2.0 US qt (1.9 ℓ)
■ Engine Oil
■ Engine CoolantRecommended
·Genuine Honda Motor Oil 0W-20
·API Premium-grade 0W-20 detergent oil
Capacity Change 4.2 US qt (4.0 ℓ)
Change
including
filter
4.4 US qt (4.2 ℓ)
Specified
Honda Long-Life Antifreeze/Coolant Type2
Ratio 50/50 with distilled water
Capacity
1.45 US gal (5.5 ℓ)
(change including the remaining
0.125 US gal (0.475 ℓ) in the reserve tank)
■ Tire*1: Optional for U.S. models (summer tires)Regular
Size
P215/45R17 87V
215/45ZR17 91W
*1
Pressure
psi(kPa[kgf/cm
2])
32 (220 [2.2])
Compact
Spare Size
T135/80D16 101M
Pressure
psi(kPa[kgf/cm
2]) 60 (420 [4.2])
Wheel Size
Regular
17 x 7J
Compact Spare
16 x 4T

Index
359Index
Index
AABS (Anti-lock Brake System).................. 243
Accessories and Modifications ................ 251
Accessory Power Sockets ......................... 139
Additives Coolant .................................................. 275
Engine Oil ............................................... 268
Washer ................................................... 281
Additives, Engine Oil ............................... 268
Adjusting
Armrest .................................................. 134
Front Seats.............................................. 127
Head Restraints ....................................... 130
Mirrors.................................................... 126
Rear Seats ............................................... 133
Steering Wheel ....................................... 125
Temperature ............................................. 84
Air Conditioning System (Climate Control System) ....................... 146
Changing the Mode................................ 147
Defrosting the Windshield and Windows........................................ 147
Dust and Pollen Filter .............................. 308
Recirculation/Fresh Air Mode.... ............... 147
Sensor .................................................... 148
Using Automatic Climate Control............ 146
Air Conditioning System (Heating and Cooling System) ............... 142
Cooling................................................... 144
Defrosting the Windshield and Windows........................................ 145 Dust and Pollen Filter ............................... 308
Heating ................................................... 143
Air Pressure ............................... 298, 347, 349
Airbags ........................................................ 37
Advanced Airbags ..................................... 43
After a Collision......................................... 40
Airbag Care ............................................... 49
Event Data Recorder .................................. 22
Front Airbags (SRS) .................................... 40
Indicator .............................................. 47, 69
Passenger Airbag Off Indicator .................. 48
Sensors...................................................... 37
Side Airbags .............................................. 44
Side Curtain Airbags .................................. 46
AM/FM Radio .................................... 154, 159
Anti-lock Brake System (ABS) .................. 243
Indicator .................................................... 69
Armrest ..................................................... 134
Audio Remote Controls ............................ 157
Audio System ............................................ 150
Adjusting the Sound ........................ 153, 158
Auxiliary Input Jack .................................. 151
Error Messages ........................................ 175
General Information ................................ 178
Internet Radio.......................................... 168
MP3/WMA ...................................... 155, 162
MP3/WMA/AAC ...................................... 170
Reactivating............................................. 152
Recommended CDs ................................. 178
Recommended Devices ............................ 180
Remote Controls ..................................... 157 Security Code .......................................... 152
Theft Protection ...................................... 152
USB Adapter Cable.................................. 151
USB Flash Drives ...................................... 180
Authorized Manuals ................................ 357
Auto Door Locking/Unlocking ................. 105
Customize ......................................... 91, 106
Automatic Lighting .................................. 119
Automatic Transmission ........................... 226
Creeping ................................................. 226
Fluid ........................................................ 277
Kickdown ................................................ 226
Operating the Shift Lever................... 16, 228
Shift Lever Does Not Move ...................... 334
Shifting ................................................... 227
Auxiliary Input Jack .................................. 151
Average Fuel Economy ........................ 80, 83
Average Speed ........................................... 83
BBattery...................................................... 306
Charging System Indicator................. 67, 337
Jump Starting .......................................... 331
Maintenance (Checking the Battery) ........ 306
Maintenance (Replacing) ......................... 307
Belts (Seat) .................................................. 30
Beverage Holders ..................................... 138
Bluetooth ® Audio ..................................... 173
Bluetooth ® HandsFreeLink ®..................... 181
Booster Seats (For Children) ...................... 61

360Index
Brake System............................................. 241
Anti-lock Brake System (ABS) ................... 243
Brake Assist System ................................. 244
Fluid ........................................................ 280
Foot Brake ............................................... 242
Indicator ............................................ 66, 339
Parking Brake .......................................... 241
Brightness Control (Instrument Panel) .... 123
Bulb Replacement ..................................... 282
Brake/Taillights, Rear Turn Signal Lights and
Rear Side Marker Lights ......................... 291
Fog Lights ................................................ 286
Front Turn Signal/Parking/Side Marker
Lights..................................................... 289
Headlights ............................................... 282
High-Mount Brake Light .......................... 294
Rear License Plate Lights .......................... 293
Taillights and Back-Up Lights ................... 292
Bulb Specifications ............................ 346, 348CCarbon Monoxide Gas ................................ 62
Carrying Cargo .................................. 215, 217
CD Player ........................................... 155, 162
Center Pocket ............................................ 137
Certification Label .................................... 350
Changing Bulbs ......................................... 282
Charging System Indicator ................. 67, 337
Child Safety ................................................. 50
Childproof Door Locks ............................. 104 Emergency Trunk Opener ........................ 111
Child Seat .................................................... 50
Booster Seats ............................................ 61
Child Seat for Infants................................. 52
Child Seat for Small Children ..................... 53
Installing a Child Seat with a Lap/Shoulder Seat Belt .................................................. 57
Larger Children ......................................... 60
Rear-facing Child Seat ............................... 52
Selecting a Child Seat ................................ 54
Using a Tether ........................................... 59
Childproof Door Locks ............................. 104
Cleaning the Exterior ............................... 311
Cleaning the Interior ................................ 309
Climate Control System ............................ 146
Changing the Mode ................................ 146
Defrosting the Windshield and Windows ........................................ 147
Dust and Pollen Filter............................... 308
Recirculation/Fresh Air Mode ..... .............. 147
Sensors ................................................... 148
Using Automatic Climate Control ............ 146
Clock ............................................................ 98
Clutch Fluid ............................................... 280
Coat Hook ................................................. 140
Compact Spare Tire .................. 315, 347, 349
Console Compartment ............................. 136
Controls ....................................................... 97
Coolant (Engine) ...................................... 275
Adding to the Radiator ......... ............... .... 276
Adding to the Reserve Tank..................... 275 High Temperature Indicator ...................... 69
Low Temperature Indicator ....................... 73
Overheating ............................................ 335
Creeping (Automatic Transmission) ........ 226
Cruise Control .......................................... 233
Indicator ................................................... 74
Cup Holders .............................................. 138
Customer Service Information ................ 358
Customized Features ................................. 85
DDaytime Running Lights .......................... 121
Dead Battery ............................................ 331
Defrosting the Windshield
and Windows ................................. 145, 147
Devices that Emit Radio Waves ............... 351
Dimming
Headlights .............................................. 118
Rearview Mirror ...................................... 126
Dipstick (Engine Oil) ................................ 269
Directional Signals (Turn Signal) ............. 118
Display/Information Button ...................... 81
Door Mirrors ............................................. 126
Doors .......................................................... 99
Auto Door Locking.................................. 105
Auto Door Unlocking .............................. 105
Door Open Indicator ........................... 29, 70
Keys.......................................................... 99
Locking/Unlocking the Doors
from the Inside...................................... 103

361Index
Locking/Unlocking the Doors from the Outside................................... 101
Lockout Prevention System ..................... 102
DOT Tire Quality Grading ........................ 300
Driving ...................................................... 213
Automatic Transmission .......................... 226
Braking ................................................... 241
Cruise Control ........................................ 233
Shifting Gear .................................. 227, 229
Starting the Engine ................................. 223
Dust and Pollen Filter .............................. 308EEco Assist System.......................................... 7
ECON Button ............................................ 232
Elapsed Time .............................................. 83
Electric Power Steering (EPS) System
Indicator ........................................... 71, 339
Electronic Stability Control (ESC) ............ 236
Emergency ................................................ 344
Emergency Trunk Opener ....................... 111
Emissions Testing (Readiness Codes) ...... 353
Engine ....................................................... 350
Coolant .................................................. 275
Jump Starting ......................................... 331
Oil .......................................................... 268
Starting................................................... 223
Switch Buzzer ......................................... 117
Engine Coolant ........................................ 275
Adding to the Radiator ......... .................. 276 Adding to the Reserve Tank ..................... 275
High Temperature Indicator ....................... 69
Low Temperature Indicator ........................ 73
Overheating ............................................ 335
Engine Oil ................................................. 268
Adding .................................................... 271
Checking ................................................. 269
Displaying Oil Life ............................ 257, 261
Low Oil Pressure Indicator.................. 66, 337
Recommended Engine Oil........................ 268
EPS (Electric Power Steering) System ............................................... 71, 339
Exhaust Gas Hazard
(Carbon Monoxide) .................................. 62
Exterior Care (Cleaning) ........................... 311
Exterior Mirrors ........................................ 126
FFeatures..................................................... 149
Filters
Dust and Pollen ....................................... 308
Oil ........................................................... 272
Flat Tire ..................................................... 315
Floor Mats ................................................. 310
Fluids Automatic Transmission........................... 277
Brake/Clutch............................................ 280
Engine Coolant........................................ 275
Manual Transmission ............................... 278
Windshield Washer.................................. 281 Fog Light Indicator
..................................... 72
Folding Down the Rear Seats .................. 133
Foot Brake ................................................ 242
Front Airbags (SRS) ..................................... 40
Front Seats ................................................ 127
Adjusting ................................................ 127
Fuel ...................................................... 17, 247
Economy ................................................. 250
Gauge ....................................................... 77
Instant Fuel Economy .......................... 77, 84
Low Fuel Indicator ..................................... 68
Range ................................................. 80, 83
Recommendation .................................... 247
Refueling................................................. 247
Fuel Economy ........................................... 250
Fuel Fill Cap ........................................ 17, 249
Message.................................................. 338
Fuel Fill Door ...................................... 17, 248
Fuses .......................................................... 341
Inspecting and Changing......................... 343
Locations......................................... 341, 342
GGasoline (Fuel) Economy ................................................. 250
Gauge ....................................................... 77
Information ............................................. 247
Instant Fuel Economy .......................... 77, 84
Low Fuel Indicator ..................................... 68
Refueling................................................. 247
