The rotating switch on the lef t lever
controls the lights. Turning this
switch to the ‘‘ ’’ position turns
on the parking lights, taillights,
instrument panel lights, side-marker
lights, and rear license plate lights.
Turning the switch to the ‘‘ ’’
position turns on the headlights.If you leave the lights on with the
ignition switch in ACCESSORY (I)
or LOCK (0), you will hear a
reminder beeper when you open the
driver’s door.
To change f rom low beams to high
beams, push the turn signal lever
f orward until you hear a click. The
blue high beam indicator will light
(see page ). To return to low
beams, pull the turn signal lever
back.59
Headlights
Controls Near the Steering Wheel
Inst rument s and Cont rols
66

Signal a turn or lane change with this
lever. Push down on the lever to
signal a lef t turn, and up to signal a
right turn. If you push it up or down
all the way, the turn signal continues
to blink even when you release the
lever. It shuts off automatically as
you complete the turn.To signal a lane change, push lightly
on the turn signal lever in the proper
direction and hold it. The lever will
return to the center position as soon
as you release it.
The right lever controls the wind-
shield wipers and washers. The
rotary switch at the end of the lever
has f ive positions;MIST: mist
OFF: off
INT: intermittent
LO: low speed
HI: high speed
Controls Near the Steering Wheel
Inst rument s and Cont rols
T urn Signals
Windshield Wipers
68

In addition, any modif ications that
decrease ground clearance increase
the chance of undercarriage parts
striking a curb, speed bump, or other
raised object, which could cause
your airbags to deploy.
Do not modif y your steering wheel
or any other part of your
Supplemental Restraint System.
Modif ications could make the
system inef f ective.
Do not remove any original
equipment or modif y your car in any
way that would alter its design or
operation. This could make your car
unsaf e and illegal to drive.
For example, do not make any
modif ications that would change the
ride height of your car, or install
wheels and tires with a dif f erent
overall diameter.
Covering the outside edge of a
f ront seat-back, with a non-Honda
seat cover for example, could
prevent the airbag from inflating
properly.
Such modif ications can adversely
af f ect handling, and interf ere with
the operation of the vehicle’s anti-
lock brakes and other systems. Any object attached to
or placed on the covers marked ‘‘SRS
AIRBAG,’’ in the center of the
steering wheel and on top of the
dashboard, could interf ere with the
proper operation of the airbags. Or,
if the airbags inf late, the objects
could be propelled inside the vehicle
and hurt someone. If a side airbag
inflates,acupholderorotherhard
object attached on or near the
door could be propelled inside the
vehicle and hurt someone.Only when equipped with side airbagsModif ications
Additional Saf ety Precautions
Bef ore Driving
A ccessories and Modif ications
Do not place any object s over t he outsideedgeof afront seat-back.
Do not at t ach or place object s on t he airbag covers. Do not at t ach hard object s on or
near a f ront door.
136

this defeats the
purpose of the ABS. Let the ABS
work f or you by always keeping f irm,
steady pressure on the brake pedal
as you steer away from the hazard.
This is sometimes ref erred to as
You will f eel a pulsation in the brake
pedal when the ABS activates, and
you may hear some noise. This is
normal; it is the ABS rapidly
pumping the brakes.
Activation varies with the amount of
traction your tires have. On dry
pavement, you will need to press on
thebrakepedalveryhardbeforeyou
activate the ABS. However, you may
feel the ABS activate immediately if
you are trying to stop on snow or ice. such as trying to take a
corner too f ast or making a sudden
lane change. Always drive at a safe,
prudent speed f or the road and
weather conditions. it
only helps with steering control
during braking. You should always
maintain a saf e f ollowing distance
f rom other vehicles.
Always steer moderately
when you are braking hard. Severe
or sharp steering wheel movement
can still cause your car to veer into
oncoming traffic or off the road. on loose or
uneven surfaces, such as gravel or
snow, than a vehicle without anti-
lock. Slow down and allow a greater
distance between vehicles under
those conditions.
‘‘stomp and steer.’’
CONT INUED
You should never pump the
brake pedal;
A BS will not prevent a skid that
results f rom changing direction
abruptly,
A BS does not reduce the time or
distance it takes to stop the car;
A BS cannot prevent a loss of
stability. A vehicle with A BS may require a
longer distance to stopImport ant Saf et y Reminders
The Braking System
Driving
149

µ
µ Being able to see
clearly in all directions and being
visible to other drivers are important
in all weather conditions. This is
more difficult in bad weather. To be
seen more clearly during daylight
hours, turn on your headlights.
Inspect your windshield wipers and
washers f requently. Keep the wind-
shield washer reservoir f ull of the
proper f luid. Have the windshield
wiper blades replaced if they start to
streak the windshield or leave parts
unwiped. Use the def rosters and air
conditioning to keep the windows
f rom f ogging up on the inside (see
page ).
Exercise extra caution when driving
in rain af ter a long dry spell. Af ter
months of dry weather, the f irst
rains bring oil to the surf ace of the
roadway, making it slippery.
Rain, f og, and snow conditions re-
quire a dif f erent driving technique
because of reduced traction and
visibility. Keep your car well-
maintained and exercise greater
caution when you need to drive in
bad weather. Always drive
slower than you would in dry
weather. It takes your car longer to
react, even in conditions that may
seem just barely damp. Apply
smooth, even pressure to all the
controls. Abrupt steering wheel
movements or sudden, hard appli-
cation of the brakes can cause loss of
control in wet weather. Be extra
cautious f or the f irst f ew miles
(kilometers) of driving while you
adjust to the change in driving
conditions. This is especially true in
snow. A person can f orget some
snow-driving techniques during the
summer months. Practice is needed
to relearn those skills. 101
CONT INUED
Visibility
Driving T echnique
Driving in Bad Weather
Driving 151

µCheck your tires
f requently f or wear and proper
pressure. Both are important in
preventing ‘‘hydroplaning’’ (loss of
traction on a wet surface). In the
winter, mount snow tires on all f our
wheels f or the best handling.
Watch road conditions caref ully,
they can change f rom moment to
moment. Wet leaves can be as slip-
pery as ice. ‘‘Clear’’ roads can have
patches of ice. Driving conditions
can be very hazardous when the
outside temperature is near f reezing.
The road surf ace can become
covered with areas of water puddles
mixed with areas of ice, so your
traction can change without warning.
Be caref ul when downshif ting. If
traction is low, you can lock up the
drive wheels f or a moment and cause
askid. Be very cautious when passing, or
beingpassedbyothervehicles.The
spray f rom large vehicles reduces
your visibility, and the wind buf f eting
can cause you to lose control.Your car is not designed to tow a
trailer. Attempting to do so can void
your warranties.
Traction
Towing a Trailer
Driving
Driving in Bad Weather, Towing a Trailer
152

Block the rear wheels.
Fill the f uel tank.
Change the engine oil and f ilter
(see page ).
Wash and dry the exterior
completely.
Cleantheinterior.Makesurethe
carpeting, floor mats, etc. are
completely dry.
If you need to park your car f or an
extended period (more than one
month), there are several things you
should do to prepare it f or storage.
Proper preparation helps prevent
deterioration and makes it easier to
get your car back on the road. If
possible, store your car indoors.
If the car is to be stored for a
longer period, it should be
supported on jackstands so the
tires are of f the ground.
Leave one window open slightly (if
the car is being stored indoors).Coverthecarwitha‘‘breathable’’
cover, one made f rom a porous
material such as cotton.
Nonporous materials, such as
plastic sheeting, trap moisture,
which can damage the paint.
Disconnect the battery.
Support the f ront and rear wiper
blade arms with a f olded towel or
ragsotheydonottouchthe
windshield.
To minimize sticking, apply a
silicone spray lubricant to all door
and hatch seals. Also, apply a body
wax to the painted surf aces that
mate with the door and hatch seals. If possible, run the engine f or a
while periodically (pref erably once
amonth).
If you store your car f or 12 months
or longer, have your Honda dealer
perf orm the inspections called f or in
the 24 months/30,000 miles (48,000
km) maintenance schedule (Normal
Conditions) as soon as you take it
out of storage (see page ). The
replacements called f or in the
maintenance schedule are not
needed unless the car has actually
reached that time or mileage.
Leave the parking brake off. Put
the transmission in Reverse. 158
169
St oring Your Car
Maint enance
212

Locate the jacking point nearest
thetireyouneedtochange.Place
the jack under the jacking point.
Turn the end bracket clockwise
until the top of the jack contacts
the jacking point. Make sure the
jacking point tab is resting in the
jack notch.
Loosen the f our wheel nuts 1/2
turn with the wheel wrench.
Use the extension and wheel
wrench as shown to raise the car
until the f lat tire is of f the ground.
6.
7.8.
T aking Care of t he Unexpect ed
Changing a Flat T ire
224 JACKING POINT
WHEEL
WRENCH EXTENSION

ÎÎ Î
Î Î Î
Specif ications
T echnical Inf ormation
250 Dimensions
Weights
Engine
Capacities
67.1 in (1,705 mm)
54.1 in (1,375 mm)
101.2 in (2,570 mm)
57.8 in (1,468 mm)
57.8 in (1,468 mm)
3.39 x 3.39 in (86.0 x 86.0 mm) 121.9 cu-in (1,998 cm
)
9.8 : 1 13.2 US gal (50
)
1.32 US gal (5.0
)
164.2 in (4,170 mm)
Length
Width
Height
Wheelbase
Track
Gross vehicle weight ratingType
BorexStroke
Displacement
Compression ratio
Spark plugs See the certification label attached
to the driver’s doorjamb. Fuel tank
Engine
coolant
Engine oil Manual
transmission
fluid
Windshield
washer reservoir1.77 US gal (6.7
)
4.4 US qt (4.2
)
4.2 US qt (4.0)
5.6 US qt (5.3)
1.6 US qt (1.5)
1.8 US qt (1.7)
2.6 US qt (2.5
)
0.13 US gal (0.5
)
Including the coolant in the reserve tank and that remaining in the
engine.
Reserve tank capacity:
Water cooled 4-stroke DOHC
i-VTEC 4-cylinder gasoline engine 5.8 US qt (5.5
)
See spark plug maintenance
section page 183 .
FrontRear
Approx.
Change Manual
Total Manual
Change
Without filter
Total
ChangeTotal
1: 2: 3: On the U.S. model
On Canadian model 1
23
Including filter

Bulb Replacement..........................
Back-up Lights . 206
..................................
Stop Light . 206
......................
Cargo Area Light . 211
................
Front Parking Lights . 205
........
Front Side Marker Lights . 204
.................................
Headlights . 202
.........
High-mount Brake Light . 207
...........................
Interior Lights . 210
.................
License Plate Lights . 209
..................
Side Marker Lights . 204
...........
Side Turn Signal Lights . 208
............................
Specif ications . 251
....................
Turn Signal Lights . 203
..............................
Bulbs, Halogen . 202
.........
Cables, Jump Starting With . 230
............................
Capacities Chart . 250
.............
Carbon Monoxide Hazard . 52
...........................
Cargo Area Cover . 84
.............................
Carrying Cargo . 137
Cassette Player
............................................
Care . 122
...................................
Operation . 119 ..............
CAUTION, Explanation of . ii
...................................
CD Changer . 115
.......................................
CD Player . 113
........................
Certif ication Label . 248
............................................
Chains . 199
Change Oil
........................................
How to . 169
......................................
When to . 158
....................
Changing a Flat Tire . 223
............
Changing Engine Coolant . 173
...
Charging System Indicator . 58, 235
Checking
.....................
Battery Condition . 184
................................
Brake Fluid . 178
...............................
Clutch Fluid . 178
.................................
Drive Belts . 192
..........................
Engine Coolant . 133
..................................
Engine Oil . 132
..........................................
Fuses . 241
....
Manual Transmission Fluid . 177
............
Checklist, Bef ore Driving . 142
.....................................
Child Saf ety . 20
....................
Cleaner Element, Air . 179
Cleaning
....................
Aluminum Wheels . 216
...................................
Carpeting . 216 ......................................
Exterior . 214
.........................................
Fabric . 217
.......................................
Interior . 216
...................................
Seat Belts . 218
...........................................
Vinyl . 217
....................................
Windows . 218
.........................
Clock, Setting the . 109
...................................
Clutch Fluid . 178
........................
CO in the Exhaust . 256
............
Cold Weather, Starting in . 143
..............................
Compact Spare . 222
.............
Controls, Instruments and . 55
Coolant
........................................
Adding . 171
....................................
Checking . 133
.........................
Proper Solution . 171
...................................
Replacing . 173
...................
Temperature Gauge . 64
....................
Corrosion Protection . 219
Crankcase Emissions Control
........................................
System . 256
...............................
Cruise Control . 124
Index
C
II
