navigation HONDA CIVIC HYBRID 2010 8.G Technology Reference Guide

Voice Command/HFL/Navigation
Using the Voice Command System
• Speak in a clear, natural voice.
• Reduce all background noise.
• Adjust the dashboard and sidevents away from the microphone in
the ceiling.
• Close the windows.
Voice Command
To reduce driver distraction, use voice commands for hands-free calling, \
navigation, climate control, and
audio functions. A full list of these commands is in the navigation system manual.
Voice Command Tips:
• Press and release the HFL or NAVI Talk button, wait for a
beep, then give a command.
• For a list of available HFL commands, press and release the HFL Talk button and say “Hands-free help.”
• For a list of available navigation commands, press and release the NAVI Talk button and say “Voice command help.”
HFL Talk button: Give HFL commands
or answer incoming calls.
HFL Back button: End a call, go back to
the previous command, or cancel an
operation. NAVI Talk button:
Give navigation,
climate control, and
audio commands.
NAVI Back button:
Cancel a command or
return to the previous
screen.
10 Civic Hybrid TRG_Base:Base 6/30/2009 9:06 AM Page 7 2010 Civic Hybrid

Making a Call1. Press the HFL Talk button, and say “Call”or
“Dial” and the desired phone number .
2. Pressthe HFL Talk button, and say“Call” or
“Dial” to continue.
3. The call is connected and heard through the
vehicle’s speakers.
Receiving a Call
1. A notification is heard, and the following screen appears on the navigation display.
2. Press the HFL Talk button to accept the
call.
3. Press the HFL Back button to end or
decline the call.
10 Civic Hybrid TRG_7abc:ExtraPages.qxd 6/30/2009 9:09 AM Page b7 2010 Civic Hybrid

Navigation(if equipped)
Say “City” (or “Change state” if
necessary). Say “Display menu.”
1
Say “Address.”2
3
A list of city names appears. Say
the number listed next to the city you
want to select.
Say the street name. Do not include
the direction (N, S, E, W) or type
(St., Ave., Blvd., etc.).
4
6
Say the name of the city you want, or
say “Current city” to select the city
currently shown.
5
A list of street names appears. Say
the number listed next to the street
you want to select.
Say the entire street address number.
For example, “1-2-5-0.”7
8
The system calculates the route
and displays the “Calculate route to”
screen. Say “OK” to set the route.9
Entering a Destination Using Voice Commands
Press and release the NAVI Talk button before you give a command.
Note: Entering destinations can also be done manually
from the Menu screen.
10 Civic Hybrid TRG_7abc:ExtraPages.qxd 6/30/2009 9:09 AM Page c7 2010 Civic Hybrid

Commonly Used Voice Commands (continued)Navigation Commands
(Accepted on Map screen
after a destination is entered)
• How long/far to the destination?
• Display destination
• Display entire route
• Find nearest: - ATM
- gas station
- Mexican restaurant
- post office - bank
- Honda dealer
- airport
- hospital
Display Commands(Accepted on Map screen)
• Display (or hide):
- ATM
- gas station
- Mexican restaurant
- post office • Display north up/
heading up
• Zoom in/out
• Go home
• Display current location
• Display map
• Display menu
• Setup
• Information
• Display audio screen
• What time is it?
Press and release the NAVI Talk button before you give a command.
General Commands
(Accepted on most screens to change displays)
Find Place Commands(Accepted on Map screen)
10 Civic Hybrid TRG_7abc:ExtraPages.qxd 6/30/2009 9:10 AM Page f7 2010 Civic Hybrid

• Brightness up/down
• Volume up/down/min/max/off • Guidance prompts
min/max/normal
Setup Commands(Accepted on the Setup screen)
Help Commands(Accepted on most screens)
• Help (list of available commands for currentscreen)
• Voice command help (list of all available navigation, audio, and climate control
commands)
Voice Command/
HFL/Navigation
Commonly Used Voice Commands (continued)
Press and release the NAVI Talk button before you give a command.
Audio Commands
(Accepted on most screens)
• Radio on
• Radio # FM/AM
• Radio preset 1/2/3/4/5/6
• XM channel # • XM preset 1/2/3/4/5/6
• CD play
• CD play track/disc #
• CD skip forward/back
• Auxiliary (AUX) play
Climate Control Commands(Accepted on most screens)
• Air conditioner
on/off
• Rear defrost on/off
• Climate control recirculate/fresh air • Fan speed up/down
• Temperature #
degrees (# = 57–87)
• Temperature max hot/cold
10 Civic Hybrid TRG_Base:Base 6/30/2009 9:06 AM Page 8 2010 Civic Hybrid

Audio
Components
Playing an iPod®or USB Flash Memory Device
2. Connect your USB connector to your flash
drive or iPod dock connector.
3. Push AUX or touchthe AUX icon to play.
USB Adapter Cable
Without navigation With navigation
USB Connector
Some of the same controls used to operate your in-dash CD player are use\
d to operate an iPod or USB
flash memory device.
iPod is a registered trademark of Apple Computer, Inc.,
registered in the U.S. and other countries. iPod not included.
Connecting and Beginning Play
1. Open the center console, and pull outthe
USB adapter cable.
10 Civic Hybrid TRG_Base:Base 6/30/2009 9:06 AM Page 9 2010 Civic Hybrid

Audio
Components
Connecting and Beginning Play
1. Press OPEN.
PC Card Instructions (Models with Navigation)
2. If necessary, insertyour PC card into a PC
card adapter.4. Press AUDIO to show the audio display. Use
the |

and |buttons to skip through
tracks on the card.
3. Insert the PC card into the slot and press
CLOSE.
CLOSE
Button
PC card
slot
10 Civic Hybrid TRG_Inside Back:Inside Back 6/30/2009 9:10 AM Page 10\
2010 Civic Hybrid
