door lock HONDA CIVIC SEDAN 2011 Owner's Manual (in English)
[x] Cancel search | Manufacturer: HONDA, Model Year: 2011, Model line: CIVIC SEDAN, Model: HONDA CIVIC SEDAN 2011Pages: 390, PDF Size: 6.95 MB
Page 9 of 390
Î
Î
Î
Î
Î
Î
Î
CONT INUED: If equipped
Your Vehicle at a Glance
Your Vehicle at a Glance
3
Vehicle with navigation system is shown.DRIVER’S FRONT
AIRBAG
AUDIO SYSTEM
MOONROOF SWITCH
DOOR LOCK TAB
ACCESSORY
POWER SOCKET
AUXILIARY INPUT JACK (P.102)
(P.100)
(P.9, 24)
(P.205) PASSENGER’S
FRONT AIRBAG
HEATING/COOLING
CONTROLS
(P.114)
INSTRUMENT PANEL INDICATORS
(P.57)
GAUGES
MIRROR CONTROLS
(P.104)
POWER DOOR LOCK
MASTER SWITCH
POWER WINDOW
SWITCHES
(P.101) (P.66)
(P.82)
FUEL FILL DOOR
RELEASE HANDLE
(P.239)
TRUNK RELEASE
HANDLE
(P.88) (P.9, 30)
(P.110)
(P.81)
(P.108)
SEAT HEATER SWITCHES AUTOMATIC TRANSMISSION (P.260)
MANUAL TRANSMISSION
(P.257)
10/06/23 13:49:05 31SNA650_008
Page 11 of 390
µ
This section gives you important
inf ormation about how to protect
yourself and your passengers. It
shows you how to use seat belts. It
explains how your airbags work. And
it tells you how to properly restrain
inf ants and children in your vehicle.
.........
Important Safety Precautions . 6
.......
Your Vehicle’s Saf ety Features . 7
.......................................
Seat Belts . 8
...........................................
Airbags . 9
.........
Protecting Adults and Teens . 11
.....
1. Close and Lock the Doors . 11
...........
2. Adjust the Front Seats . 11
............
3. Adjust the Seat-Backs . 12
...
4. Adjust the Head Restraints . 13
5. Fasten and Position the
.............................
Seat Belts . 14
6. Maintain a Proper Sitting ................................
Position . 15
.....
Advice f or Pregnant Women . 16
...
Additional Safety Precautions . 17 Additional Inf ormation About Your
.................................
Seat Belts . 18
..
Seat Belt System Components . 18
......................
Lap/Shoulder Belt . 19
Automatic Seat Belt
...............................
Tensioners . 19
...............
Seat Belt Maintenance . 20
Additional Inf ormation About ...........................
Your Airbags . 21
......
Airbag System Components . 21
How Your Front Airbags
.........................................
Work . 24
...
How Your Side Airbags Work . 27
How Your Side Curtain Airbags
.........................................
Work . 29
..
How the SRS Indicator Works . 29
How the Side Airbag Of f
......................
Indicator Works . 30
How the Passenger Airbag Of f ......................
Indicator Works . 30
.............................
Airbag Service . 31
...
Additional Safety Precautions . 32
Protecting Children General ................................
Guidelines . 33
All Children Must Be ...............................
Restrained . 33 All Children Should Sit in a
.................................
Back Seat . 34
The Passenger’s Front Airbag .........
Can Pose Serious Risks . 34
If You Must Drive with Several ...................................
Children . 36
If a Child Requires Close ..................................
Attention . 36
...
Additional Safety Precautions . 37
Protecting Inf ants and Small ...................................
Children . 38
.......................
Protecting Inf ants . 38
.........
Protecting Small Children . 39
.....................
Selecting a Child Seat . 40
....................
Installing a Child Seat . 41
...............................
With LATCH . 42
.........
With a Lap/Shoulder Belt . 44
..............................
With a Tether . 45
...........
Protecting Larger Children . 47
...............
Checking Seat Belt Fit . 47
..................
Using a Booster Seat . 48
When Can a Larger Child Sit in
.........................................
Front . 49
...
Additional Safety Precautions . 50
.............
Carbon Monoxide Hazard . 51
...................................
Saf ety Labels . 52
Driver and Passenger Saf ety
Driver and Passenger Saf ety
5
10/06/23 13:49:18 31SNA650_010
Page 13 of 390
Your vehicle is equipped with many
features that work together to
protect you and your passengers
during a crash.
However, you and your passengers
can’t take f ull advantage of these
f eatures unless you remain sitting in
the correct position and. In fact, some safety
f eatures can contribute to injuries if
they are not used properly.
The f ollowing pages explain how you
cantakeanactiveroleinprotecting
yourself and your passengers. Some f eatures do not require any
action on your part. These include a
strong steel f ramework that f orms a
saf ety cage around the passenger
compartment, front and rear crush
zones, a collapsible steering column,
and tensioners that tighten the f ront
seat belts in a crash.
Your Vehicle’s Saf ety Features
always wear
your seat belts
Driver and Passenger Saf ety
7
(8) (9)
(10)
(11) (4)
(6)
(10)
(2)(11)
(11) (4)(6)
(3)
(8)
(7)
(5)
(2) (1)
(9)
(7) (12)(1) Safety Cage
(2) Crush Zones
(3) Seats and Seat-Backs
(4) Head Restraints
(5) Collapsible Steering Column
(6) Seat Belts
(7) Front Airbags
(8) Side Airbags
(9) Side Curtain Airbags
(10) Door Locks
(11) Front Seat Belt Tensioners
(12) Occupant Position Detection System (OPDS) Sensors
10/06/23 13:49:42 31SNA650_012
Page 17 of 390
µAdjust the driver’s seat as far to the
rear as possible while allowing you to
maintain f ull control of the vehicle.
Have a front passenger adjust their
seat as far to the rear as possible.
The f ollowing pages provide
instructions on how to properly
protect the driver, adult passengers,
and teenage children who are large
enough and mature enough to drive
or ride in the f ront.
See pages f or important
guidelines on how to properly
protect inf ants, small children, and
larger children who ride in your
vehicle.
After everyone has entered the
vehicle, be sure the doors are closed
and locked. Your vehicle has a door-
openindicatoronthe
instrument panel to indicate when
any door is open.
Locking the doors reduces the
chance of someone being thrown out
of the vehicle during a crash, and it
helps prevent passengers f rom
accidentally opening a door and
f alling out.
Locking the doors also helps prevent
an outsider f rom unexpectedly
opening a door when you come to a
stop.
See page f or how to lock the
doors, and page f or how the door-
open indicator works.
Some models have the auto door
locking/unlocking f eature. For more
inf ormation, see page .
33 37
8161
83
CONT INUED
Adjust the Front Seats
Introduction
Close and L ock the Doors
1. 2.
Protecting A dults and Teens
Driver and Passenger Saf ety
11
10/06/23 13:50:26 31SNA650_016
Page 25 of 390
CONT INUED
For added protection, the f ront seat
belts are equipped with automatic
seat belt tensioners. When activated,
the tensioners immediately tighten
the belts to help hold the driver and
a f ront passenger in position.
The lap/shoulder belt goes over
your shoulder, across your chest,
and across your hips.
To fasten the belt, insert the latch
plate into the buckle, then tug on the
belt to make sure the buckle is
latched (see page f or how to
properly position the belt).
To unlock the belt, press the red
PRESSbuttononthebuckle.Guide
the belt across your body so that it
retracts completely. Af ter exiting the
vehicle, be sure the belt is out of the
way and will not get closed in the
door.
All seat belts have an emergency
locking retractor. In normal driving,
the retractor lets you move f reely in
your seat while it keeps some
tension on the belt. During a collision
or sudden stop, the retractor
automatically locks the belt to help restrain your body.
If the shoulder part of the belt is
pulled all the way out, the lockable
retractor will activate. The belt will
retract, but it will not allow the
passenger to move f reely.
To deactivate the lockable retractor,
unlatch the buckle and let the seat
belt fully retract. To refasten the
seat belt, pull it out only as f ar as
needed. In addition, the lap/shoulder belts in
all seating positions except the
driver’s have a lockable retractor
that must be activated to secure a
child seat.
14
Additional Inf ormation About Your Seat Belts
A utomatic Seat Belt T ensioners
L ap/Shoulder Belt
Driver and Passenger Saf ety
19
10/06/23 13:51:49 31SNA650_024
Page 43 of 390
µ
During a crash, the
belt could press deep into the child
and cause serious or fatal injuries.
If they do, they
could be very seriously injured in a
crash. Children
who play in vehicles can
accidentally get trapped inside.
Teach your children not to play in
or around vehicles. Know how to
operate the emergency trunk
opener and decide if your children
should be shown how to use this
feature(seepage ).
If you are not wearing a
seat belt in a crash, you could be
thrown forward and crush the
child against the dashboard or a
seat-back. If you are wearing a
seat belt, the child can be torn
from your arms and be seriously
hurt or killed.
If a child wraps a loose seat belt around their neck, they
can be seriously or f atally injured.
(See pages and f or how to
activate and deactivate the
lockable retractor.)
Leaving children without
adult supervision is illegal in most
states, Canadian provinces and
territories, and can be very
hazardous. This can prevent
children f rom accidentally f alling
out (see page ).
Even very young
children learn how to unlock
vehicle doors, turn on the ignition
switch, and open the trunk, which
can lead to accidental injury or
death.
For example, infants and small
childrenleftinavehicleonahot
day can die f rom heatstroke. A
child lef t alone with the key in the
ignition switch can accidentally set
the vehicle in motion, possibly
injuring themselves or others. 44 45
82 89
Additional Saf ety Precautions
Never put a seat belt over yourself
and a child.
Never let two children use thesame seat belt . L ock all doors and t he t runk when
your vehicle is not in use.
Neverholdaninfantorchildon
your lap.
Make sure any unused seat beltt hat a child can reach is buckled,the lockable retractor is activated,and the belt is f ully retracted andlocked. Do not leave children alone in a
vehicle.
Use t he childproof door locks t o
prevent children f rom opening t herear doors.
K eep vehicle keys/remot etransmitters out of the reach ofchildren.
Protecting Children General Guidelines
Driver and Passenger Saf ety
37
10/06/23 13:55:00 31SNA650_042
Page 61 of 390
This section gives inf ormation about
the controls and displays that
contribute to the daily operation of
your vehicle. All the essential
controls are within easy reach............................
Control Locations . 56
............................
Instrument Panel . 57
..........
Instrument Panel Indicators . 59
.............................................
Gauges . 66
..............
Display Change Button . 66
....................
Inf ormation Display . 67
..................................
Fuel Gauge . 70
...................
Temperature Gauge . 70
Controls Near the Steering ...........................................
Wheel . 71
.
Windshield Wipers and Washers . 72
.........
Turn Signals and Headlights . 73
............
Daytime Running Lights . 74
........................................
Fog Lights . 74
........
Instrument Panel Brightness . 75
.................
Hazard Warning Button . 76
.................
Rear Window Def ogger . 76
..........
Steering Wheel Adjustment . 77
...............................
Keys and Locks . 78
........................
Immobilizer System . 79
................................
Ignition Switch . 80
......................................
Door Locks . 81
......................
Power Door Locks . 82
..............
Childproof Door Locks . 82
.
Auto Door Locking/Unlocking . 83
.....................
Auto Door Locking . 83 .................
Auto Door Unlocking . 85
................................................
Trunk . 88
........
Emergency Trunk Opener . 89
.......................
Remote Transmitter . 90
.................................................
Seats . 93
..................................
Seat Heaters . 100
............................
Power Windows . 101
.......................................
Moonroof . 102
...........................................
Mirrors . 103
...............................
Parking Brake . 105
...............................
Interior Lights . 105
.........
Interior Convenience Items . 107
.....................
Beverage Holders . 108
.........
Accessory Power Socket . 108
..................................
Glove Box . 108
.............
Console Compartment . 108
Instruments and Controls
Inst rument s and Cont rols
55
10/06/23 13:58:04 31SNA650_060
Page 62 of 390
Î
Î Î
Î Î
Î
ÎIf equipped
:
Control L ocations
56
(P.102)
MOONROOF SWITCH
AUXILIARY INPUT JACK AUTOMATIC TRANSMISSION (P.260)
MANUAL TRANSMISSION
POWER WINDOW
SWITCHES AUDIO SYSTEM
POWER DOOR LOCK
MASTER SWITCH
FUEL FILL DOOR
RELEASE HANDLE TRUNK RELEASE
HANDLE(P.101)
(P.88) (P.114)
(P.239) INSTRUMENT PANEL INDICATORS
(P.57)
GAUGES
(P.66)
MIRROR CONTROLS
(P.104)
Vehicle with navigation system is shown. ACCESSORY
POWER SOCKET DOOR LOCK TAB
(P.81) HEATING/COOLING
CONTROLS
(P.110)
(P.108)
(P.257)
(P.205)
SEAT HEATER SWITCHES
(P.100)
(P.82)
10/06/23 13:58:11 31SNA650_061
Page 63 of 390
The U.S. instrument panel is shown. Dif f erences f or Canadian models are noted in the text.
Canadian DX-G model with M/T has the electric power steering (EPS) indicator (see page 62) next to the immobilizer system indicator.
Instrument Panel
Inst rument s and Cont rols
DX, DX-G (Canada), L X (U.S.), L X-S (U.S.), SE (Canada), EX (U.S.), EX-L
57
PARKING BRAKE AND
BRAKE SYSTEM INDICATORANTI-LOCK BRAKE SYSTEM
(ABS) INDICATOR
(P. 60) TRUNK-OPEN
INDICATOR
DOOR-OPEN
INDICATOR
(P.61)
(P.64)
SEAT BELT REMINDER
INDICATOR
(P.65, 340)
(P.65, 341)
(P.65, 340) (P.60)
SUPPLEMENTAL RESTRAINT
SYSTEM INDICATOR (P.64)
TIRE PRESSURE MONITORING
SYSTEM (TPMS) INDICATOR
SECURITY SYSTEM INDICATOR
SIDE AIRBAG OFF INDICATOR
VSA ACTIVATION INDICATOR
(P.62)
DAYTIME RUNNING LIGHTS
INDICATOR
VEHICLE STABILITY ASSIST
(VSA) SYSTEM INDICATOR
(P.62)
MALFUNCTION INDICATOR LAMP CHARGING SYSTEM
INDICATOR IMMOBILIZER SYSTEM
INDICATOR
CRUISE MAIN INDICATOR
MAINTENANCE MINDER
INDICATOR
CRUISE CONTROL INDICATOR (P.59)
(P.64)
LOW TIRE PRESSURE
INDICATOR
(P.63)
LOW FUEL
INDICATOR
(P.63)
(P.59) (P.60)
(P.61)
(P.61)
(P.65)
HIGH BEAM
INDICATOR
LIGHTS ON
INDICATOR (P.61)
(P.61)
LOW OIL PRESSURE
INDICATOR (P.65, 281)(P.60)
10/06/23 13:58:19 31SNA650_062
Page 64 of 390
The U.S. instrument panel is shown. Dif f erences f or Canadian models are noted in the text.
Instrument Panel
Si
58
ANTI-LOCK BRAKE SYSTEM (ABS)
INDICATORLOW TIRE PRESSURE
INDICATOR (P.63)
(P.61)
SEAT BELT REMINDER
INDICATOR
(P.65, 341) (P.65)
(P.64)
SUPPLEMENTAL RESTRAINT SYSTEM INDICATOR
PARKING BRAKE AND BRAKE
SYSTEM INDICATORTRUNK-OPEN INDICATOR
CRUISE CONTROL INDICATOR
MALFUNCTION INDICATOR LAMP
LIGHTS ON INDICATOR
SIDE AIRBAG OFF INDICATOR
(P.60)
VSA ACTIVATION
INDICATOR
FOG LIGHT INDICATOR
DAYTIME RUNNING LIGHTS
INDICATOR
VEHICLE STABILITY ASSIST
(VSA) SYSTEM INDICATOR
IMMOBILIZER SYSTEM
INDICATOR
ELECTRIC POWER STEERING
(EPS) INDICATOR
LOW OIL PRESSURE
INDICATOR
CHARGING SYSTEM INDICATOR
(P.65, 340) HIGH BEAM INDICATOR
(P.61)
(P.61)
(P.62) (P.61)
(P.61) (P.62)
(P.65, 340) CRUISE MAIN INDICATOR
MAINTENANCE MINDER
INDICATOR (P.65, 281) (P.64)
(P.64) LOW FUEL
INDICATOR
SECURITY SYSTEM
INDICATOR
REV LIMIT INDICATOR
TIRE PRESSURE
MONITORING SYSTEM
(TPMS) INDICATOR (P.59)
(P.61)
DOOR-OPEN INDICATOR
(P.60)
(P.64)
(P.60)
(P.63)
(P.60) (P.62) (P.59)
10/06/23 13:58:29 31SNA650_063
