engine HONDA CR-V 2007 RD1-RD5, RE7 / 3.G Manual PDF

The three way catalytic converter
contains precious metals that serve
as catalysts, promoting chemical
reactions to convert the exhaust
gasses without af f ecting the metals.
The catalytic converter is ref erred to
as a three-way catalyst, since it acts
on HC, CO, and NOx. A replacement
unit must be an original Honda part
or its equivalent.Always use unleaded gasoline.
Even a small amount of leaded
gasoline can contaminate the
catalyst metals, making the three
way catalytic converter inef f ective.Keep the engine well maintained.
The three way catalytic converter
must operate at a high temperature
for the chemical reactions to take
place. It can set on f ire any
combustible materials that come
near it. Park your vehicle away from
high grass, dry leaves, or other
f lammables. A defective three way catalytic
converter contributes to air pollution,
and can impair your engine’s per-
f ormance. Follow these guidelines to
protect your vehicle’s three way
catalytic converter. Have your vehicle diagnosed and
repaired if it is misf iring, back-
f iring, stalling, or otherwise not
running properly.
Three Way Catalytic Converter
Technical Inf ormation
331
THREE WAY CATALYTIC CONVERTER

If you take your vehicle f or a state
emissions test shortly af ter the
battery has been disconnected or
gone dead, it may not pass the test.
This is because of certain ‘‘readiness
codes’’ that must be set in the on-
board diagnostics f or the emissions
systems. These codes are erased
when the battery is disconnected,
and set again only after several days
of driving under a variety of
conditions.
If the testing f acility determines that
the readiness codes are not set, you
will be requested to return at a later
date to complete the test. If you must
get the vehicle retested within the
next two or three days, you can
condition the vehicle f or retesting by
doing the f ollowing.Make sure the gas tank is nearly,
but not completely, f ull (around
3/4). Without touching the accelerator
pedal, start the engine, and let it
idle f or 20 seconds. Make sure the vehicle has been
parked with the engine of f f or 6
hours or more.
Make sure the ambient
temperature is between 40° and
95°F.
Keep the vehicle in Park. Increase
the engine speed to 2,000 rpm, and
hold it there until the temperature
gauge rises to at least 1/4 of the
scale (about 3 minutes).
Select a nearby lightly traveled
major highway where you can
maintain a speed of 50 to 60 mph
f or at least 20 minutes. Drive on
the highway in D. Do not use the
cruise control. When traf f ic allows,
drive f or 90 seconds without
moving the accelerator pedal.(Vehicle speed may vary slightly;
this is okay.) If you cannot do this
f or a continuous 90 seconds
because of traf f ic conditions, drive
f or at least 30 seconds, then repeat
it two more times (f or a total of 90
seconds).
Then drive in city/suburban
traffic for at least 10 minutes.
When traffic conditions allow, let
the vehicle coast f or several
seconds without using the
accelerator pedal or the brake
pedal.
Make sure the vehicle has been
parked with the engine of f f or 30
minutes.
If the testing f acility determines the
readiness codes are still not set, see
your dealer.
T esting of Readiness Codes
State Emissions T esting
332

µµ
µ
(


%
)
$
%

.
"

#
) This manual covers maintenance and recommended
procedures f or repair to engine and chassis components.
It is written f or the journeyman mechanic, but is simple
enough f or most mechanically-inclined owners to under-
stand.
This manual describes the procedures involved in the
replacement of damaged body parts. This manual complements the service manual by
providing in-depth troubleshooting inf ormation f or each
electrical circuit in your vehicle. Service Manual:
Electrical T roubleshooting Manual:
Body Repair Manual:
Authorized Manuals
338
NOTE: Dealers and companies, please provide dealer or company name,
and the name of the person to whose attention the shipment should be
sent. For purchases outside U.S.A. please write to the address shown
below for a quotation.
P.O. BOX 07280·DETROIT, MICHIGAN 48207·1-800-782-4356
Customer Name Attention
Apartment Number
State & Zip Code
City
Daytime Telephone Number
Check or money order enclosed payable to Helm Inc U.S. funds only.
Do not send cash
Master
Card VISA Check here if your billing address is different
from the shipping address shown above.
Account Number Expiration: Mo. Yr.
CUSTOMER SIGNATURE DATE
Street Address No P.O. Box Number
()
These publications cannot be returned for credit without receiving advance authorization within 14
days of delivery. On returns, a restocking fee may be applied against the original order.

CONT INUED
BatteryCharging System ...........................
Indicator . 60, 309
............................
Jump Starting .305
..............................
Maintenance .294
............................
Specif ications .323
..............................
Bef ore Driving .213
....................................
Belts,Seat .8,18
.........................
Beverage Holders .110
..................................
Booster Seats .51
Brakes ...........
Anti-lock System (ABS) . 238
.............
Break-in, New Linings . 214
....................
Bulb Replacement .277
...........................................
Fluid .275 .........................................
Parking .78
.................
System Indicator . 60, 311
..........................
System Design .237
........................
Wear Indicators .237
.............................
Braking System .237
.................
Break-in, New Vehicle . 214
..
Brightness Control, Instruments . 75
..................
Brights, Headlights . 74, 75
Bulb Replacement ..........................
Back-up Lights .281
..............................
Brake Lights .281
................
Front Parking Lights . 280
........
Front Side Marker Lights . 280
.................................
Headlights .277
.........
High-mount Brake Light . 282
.........
Rear Side Marker Lights . 281
............................
Specif ications .323
....................
Turn Signal Lights . 279
..............................
Bulbs, Halogen .277
............................
Capacities Chart .322
.............
Carbon Monoxide Hazard . 54
....................................
Accessories .220
ACCESSORY (Ignition Key .......................................
Position) .81
............
Accessory Power Sockets . 117
....................
Additives, Engine Oil . 268
.......
Adjusting the Steering Wheel . 78
...........................
Advanced Airbags .27
...............................
Airbag (SRS) . 9, 22
..............
Air Conditioning System . 124
.........................................
Usage .125
.......................
Air Pressure, Tires .289
.......................
Alcohol in Gasoline .214
......................................
Antif reeze .270
Anti-lock Brakes (ABS) ...............................
Indicator . 61, 238
...................................
Operation .238
..............
Anti-thef t, Audio System . 205
.
Anti-thef t Steering Column Lock . 81
................................
Audio System .129
.....
Auto Door Locking/Unlocking . 84
...
Automatic Seat Belt Tensioners . 20
.............
Automatic Speed Control . 209
..............
Automatic Transmission . 231
..........................
Capacity, Fluid .322 ...............
Checking Fluid Level . 273
.....................................
D Mode .233
.......................................
Shif ting .231
Shif t Lever Position ...............................
Indicators .231
................
Shif t Lever Positions . 232
....................
Shif t Lock Release . 235
......................
Auxiliary Input Jack .204
3
Index
A
B
C
INDEX
I

Î
...............
DANGER, Explanation of .iii
...................................
Dashboard . 4, 72
................
Daytime Running Lights .75
Daytime Running Lights
.......................................
Indicator .63
.................................
Dead Battery .305
............
Def ects, Reporting Saf ety .336
................
Def ogger, Rear Window .77
..............
Def rosting the Windows .128
.......................
Detachable Anchor .104
....................................
Dimensions .322
.........
Dimming the Headlights . 74, 75
Dipstick ..........
Automatic Transmission .273
..................................
Engine Oil .218
..........................
Directional Signals .74
........
Disc Brake Wear Indicators .237
.....................
Disposal of Used Oil .269
..............................................
Cargo .222
...........................
Cargo area Light .121
.................................
Cargo Hooks .225
.............................
Carrying Cargo .222
....................
Cargo, How to Carry .222
.............
CAUTION, Explanation of .iii
.........................................
CD Care .202
..........................
CD Changer . 154, 181
CD Changer Error ...........................
Messages . 159, 187
.............
CD Error Messages . 159, 187
......................
CD Player . 135, 152, 172
...............................
Center Pocket .110
..................................
Center Table .114
........................
Certif ication Label .320
.................................
Chains, Tires .292
....................
Changing a Flat Tire .299
.................................
Changing Oil .267
........................................
How to .267
......................................
When to .263
....
Charging System Message . 60,309
............
Check Fuel Cap Indicator . 216
............
Checklist, Bef ore Driving . 229
.....................................
Child Saf ety . 34
..............................
Booster Seats .51
.............................
Child Seats . 34, 39 .....
Important Saf ety Reminders . 34
..........................................
Inf ants .39
............................
Large Children .50
.........................................
LATCH .43
......................
Risks with Airbags .35
.............................
Small Children .40
.........................................
Tethers .48
...........................
Warning Labels .36
.........
Where Should a Child Sit? . 35
.................................
Child Seats . 34, 39
.........................................
LATCH .43
..........
Tether Anchorage Points . 48
..................
Childproof Door Locks . 88
.......................
Cleaning Seat Belts .283
..............................................
Clock .206
........................
CO in the Exhaust .329
............
Cold Weather, Starting in . 230
...............
Consumer Inf ormation . 334
.............
Controls, Instruments and . 57
....................
Conversation Mirror .117
Coolant ........................................
Adding .270
....................................
Checking .218
.........................
Proper Solution .270
...................
Temperature Gauge . 69
..............................
Courtesy Light .121 Crankcase Emissions Control
........................................
System .329
................
Cruise Control Indicator . 62
............
Cruise Control Operation . 209
.............
Customer Service Of f ice . 334
Index
D
II

CONT INUED
Doors..........................
Auto Door Lock .84
.......................
Auto Door Unlock .86
..............
Childproof Door Locks .88
..............
Locking and Unlocking .84
......................
Power Door Locks .82
..........
DOT Tire Quality Grading .324
...........
Driver and Passenger Safety. 5
...........................................
Driving .227
....................................
Economy .219
........................
Driving Guidelines .228
.........................................
D Mode .233
................
Dual Deck Cargo Shelf .111
..................
Dust and Pollen Filter .284
..............................
Economy, Fuel .219
..................................
Emergencies .297
.............
Battery, Jump Starting .305
...........
Brake System Indicator .311
................
Changing a Flat Tire .299
.....
Charging System Indicator .309
..................
Checking the Fuses .312
.........
Hazard Warning Flashers . 76
............................
Jump Starting .305 .....
Low Oil Pressure Indicator .309
...
Malf unction Indicator Lamp .310
..................
Overheated Engine .307
.......................................
Towing .317
...........................
Emergency Brake .78
......................
Emergency Flashers .76
......................
Emergency Towing .317
.......................
Emissions Controls .329
.............
Emissions Testing, State .332
Engine
............
Adding Engine Coolant .270
....
Coolant Temperature Gauge .69
.........................
If It Won’t Start .303
Malf unction Indicator
................................
Lamp . 60, 310
........
Oil Pressure Indicator . 60, 309
..............
Oil, What Kind to Use . 267
...............................
Overheating .307
............................
Specif ications .322
............................
Speed Limiter .234
.......................................
Starting .230
......................
Ethanol in Gasoline .214
.
Evaporative Emissions Controls . 329
...............................
Exhaust Fumes .54
Expectant Mothers, Use of Seat ........................................
Belts by .16 ...................................
Fan, Interior .125
.........................................
Features .123
....................
Filling the Fuel Tank . 215
Filters .........................
Dust and Pollen .284
...............................................
Oil .268
.............
Flashers, Hazard Warning . 76
...................
Flat Tire, Changing a . 299
Fluids ..........
Automatic Transmission . 273
..........................................
Brake .275
..........................
Power Steering .276
..................
Windshield Washer . 272
...................
Folding Rear Seat . 99, 102
..........................
Four-way Flashers .76
..............................
Front Airbags . 9, 25
Front Seat ......................................
Adjusting .94
.......................................
Heaters .105
.....................................
Airbags . 9, 25
3
Index
E F
INDEX
III

.................................................
Fuel .214
........
Check Fuel Cap Message .216
......................
Fill Door and Cap .215
.....................
Low Fuel Indicator .63
...........................................
Gauge .66
................
Octane Requirement .214
...............................
Oxygenated .214
........................
Tank, Ref ueling .215
...............................
Fuel Economy .219
.....................
Fuses, Checking the .312
...............
Gas Mileage, Improving .219
..........................................
Gasohol .214
.........................................
Gasoline .214
.....................
Low Fuel Indicator. 63
...........................................
Gauge .69
................
Octane Requirement .214
........................
Tank, Ref ueling .215
................
Gas Station Procedures .215
Gauges
...
Engine Coolant Temperature .69
...............................................
Fuel .69
Gearshif t Lever Positions ..........
Automatic Transmission .231 ......................................
Glove Box .114
Gross Vehicle Weight Rating
.............................
(G VWR) . 246, 322
.............
Halogen Headlight Bulbs . 277
..............
Hazard Warning Flashers . 76
Headlights ........................................
Aiming .277
............
Daytime Running Lights . 75
..................
High Beam Indicator . 63
.........................
Reminder Chime .75
........
Replacing Halogen Bulbs . 277
...................................
Turning on .74
..............................
Head Restraints .97
.............................
Heated Mirrors .109
...................................
Heater, Seat .105
.....................
Heating and Cooling .124
............................
High Beam Lever .74
.......................
Hood, Opening the .217
..............................................
Horn .4,72
...
Identif ication Number, Vehicle . 320Ignition
..............................................
Keys .79
...........................................
Switch .81
............
Timing Control System . 330
........................
Immobilizer System .80
.........
Important Safety Precautions . 6
Indicators ......
ABS (Anti-Lock Brake) . 61, 238
Brake (Parking and Brake ............................
System) . 60, 311
................
Charging System . 60, 309
.............................
Cruise Control .62
DRL (Daytime Running ......................................
Lights) .63
...................................
High Beam .63
........
Key (Immobilizer System) . 61
......................................
Low Fuel .63
................
Low Oil Pressure . 60, 309
..............
Low Tire Pressure . 64, 242
..........
Maintenance Minder . 65,257
Malf unction Indicator ................................
Lamp . 60, 310
.................
Passenger Airbag Of f . 32
...........................
Side Airbag Of f .61
...............................................
SRS .61
...................................
TPMS . 64, 243
Index
G H
I
IV

...................
Neutral Gear Position .233
..................
New Vehicle Break-in .214
...................
NOTICE, Explanation of .i
...............
Numbers, Identif ication .320
...
Octane Requirement, Gasoline .214
.........................................
Odometer .69
...............................
Odometer, Trip .67
....................
Of f -Highway Driving .252
Oil
........................
Change, How to .268
......................
Change, When to .263
......................
Checking Engine .218
..............
Pressure Indicator . 60, 309
Selecting Proper Viscosity ......................................
Chart .267
...........
ON (Ignition Key Position) .81
Onboard Ref ueling Vapor
....................................
Recovery .329
............................
Outside Mirrors .109
....
Outside Temperature Indicator .69
....................
Overheating, Engine .307 ....
Owner’s Maintenance Checks .262
.........................
Oxygenated Fuels .214
..............
Panel Brightness Control .75
........................
Park Gear Position .232
...........................................
Parking .236
.................................
Parking Brake .78
Parking Brake and Brake .................
System Indicator . 60, 311
.................................
Parking Lights .74
..
Parking Over Things that Burn . 236
....
Passenger Airbag Of f Indicator . 32
.............................
PGM-FI System .330
...................................
Pollen Filter .284
..........................
Power Door Locks .82
...............
Power Socket Locations . 117
....................
Power Steering Fluid . 276
............................
Power Windows .106
.........
Pregnancy, Using Seat Belts . 16
........................
Preparing to Drive .229
.........
Protecting Adults and Teens . 11
...
Additional Safety Precautions . 17
.....
Advice f or Pregnant Women . 16........................
Protecting Children .34
.......................
Protecting Inf ants .39
.......
Protecting Larger Children . 50
.........
Protecting Small Children . 40
Using Child Seats with .....................................
Tethers .48
.............................
Using LATCH .43
...................
Radiator Overheating . 307
.............
Radio/CD Sound System . 129
.................
Radio Thef t Protection . 205
...........................
Readiness Codes .310
.................
Rear Dif f erential Fluid . 275
..
Rear Lights, Bulb Replacement . 281
..................
Rear Seat, Folding . 99,102
..........................
Rear View Mirror .108
.................
Rear Window Def ogger . 77
.
Rear Window Wiper and Washer . 74
...............
Reclining the Seat Backs . 94
........................................
Ref ueling .215
.......................
Reminder Indicators .59
.......................
Remote Transmitter .89
Replacement Inf ormation ..............
Dust and Pollen Filter . 284
Index
O
R
P
N
VI

ÎÎ Î
CONT INUED
................
Engine Oil and Filter .268
..........................................
Fuses .312
................................
Light Bulbs .277
....................................
Schedule .263
...........................................
Tires .288
.............................
Wiper Blades .285
Replacing Seat Belts Af ter a ............................................
Crash .21
..........
Reporting Saf ety Def ects .336
Reserve Tank, Engine
...............................
Coolant . 218, 270
...............................
Restraint, Child .34
..................
Reverse Gear Position .232
...........................
Reverse Lockout .235
......................................
Roof Rack .224
................................
Rotation, Tire .291
..................................
Safety Belts . 8, 18
.........
Safety Defects, Reporting .336
.................................
Saf ety Features .7
...........................................
Airbags .9
.......................................
Seat Belts .8
.............
Saf ety Labels, Location of .55
..............................
Saf ety Messages .iii .....................................
Seat Belts . 8, 18
...............
Additional Information .18
.....
Advice f or Pregnant Women .16
Automatic Seat Belt
...............................
Tensioners .20
.....................................
Cleaning .283
...................
Detachable Anchor .104
................
Lap/Shoulder Belt . 14, 19
................................
Maintenance .20
Reminder Indicator and
......................................
Beeper .60
...................
System Components .18
...............
Use During Pregnancy .16
...
Wearing a Lap/Shoulder Belt .14
..................................
Seat Heaters .105
........................
Seats, Adjusting the .94
.......................
Select/Reset Button .66
...............................
Serial Number .320
...........................
Service Intervals .263
...........................
Service Manual .337
.........
Service Station Procedures .215
..........................
Setting the Clock .206
...
Shif t Lever Position Indicators .231
........................
Shif t Lock Release .235
................................
Side Airbags .9,28
...
How Your Side Airbags Work .28 How the Side Airbag Of f
......................
Indicator Works .31
..................
Side Curtain Airbags .9,30
How Your Side Curtain Airbags .........................................
Work .30
Side Marker Lights, Bulb ..............................
Replacement .280
...............................
Signaling Turns .74
.....................................
Snow Tires .292
................................
Sound System .129
......................................
Spare Tire .298
....................................
Spark Plugs .322
........................
Specific ations . 322, 323
................................
Speed Control .209
................................
Speed Limiter .234
Index
S
INDEX
VII

Î
..........
SRS, Additional Inf ormation .22
...
Additional Safety Precautions .33
.............................
Airbag Service .33
......
Airbag System Components .22
How the Side Airbag Of f
......................
Indicator Works .31
..
How the SRS Indicator Works .31
How Your Front Airbags
.........................................
Work .25
...
How Your Side Airbags Work .28
How Your Side Curtain Airbags
.........................................
Work .30
.............................
SRS Indicator .31,61
....
START (Ignition Key Position) .81
.......................
Starting the Engine .230
In Cold Weather at High ..................................
Altitude .230
................
With a Dead Battery .303
..............
State Emissions Testing .332
........
Steam Coming f rom Engine .307
Steering Wheel
..................................
Adjustment .78
.............
Anti-theft Column Lock .81
.......
Steering Wheel Buttons . 203, 209
...................
Stereo Sound System .129
....................
Storing Your Vehicle .295 ........................................
Sun Visor .116
........................
Sunglasses Holder .116
Supplemental Restraint
..................................
System .9,22
......................................
Servicing .33
.........................
SRS Indicator .31,61
...................
System Components .22
..................................
Synthetic Oil .268
Table
........................................
Center .114
Tailgate ............................
Open Indicator .63
.................................
Opening the .92
..........
Taillights, Changing Bulbs . 281
.
Taking Care of the Unexpected . 297
Technical Descriptions ....
DOT Tire Quality Grading . 324
.....
Emissions Control Systems . 329
.....................
Oxygenated Fuels .214
Three Way Catalytic ...............................
Converter .331 Tire Pressure Monitoring System
(TPMS)-Required Federal ........................
Explaration .327
.......................
Temperature Gauge .69
....................
Temperature, Outside . 69
..............
Tether Anchorage Points . 48
................
Thef t Protection, Radio . 205
..
Three Way Catalytic Converter . 326
..................
Tilt the Steering Wheel . 78
..........................
Time, Setting the .206
....................................
Tire Chains .292
.........
Tire, How to Change a Flat . 299
...........................
Tire Inf ormation .324
...............................................
Tires .287
..............................
Air Pressure .289
........................................
Chains .292
.........................
Checking Wear .290
......
DOT Tire Quality Grading . 324
......................................
Inf lation .288
..................................
Inspection .290
.....................................
Labeling .326
Low Tire Pressure ...........................
Indicator . 64, 242
..............................
Maintenance .290
..
Pressure Monitoring System . 243
...................................
Replacing .291
Index
T
VIII
