warning HONDA CR-V 2009 RD1-RD5, RE7 / 3.G User Guide

µ
See pages f or important saf ety
inf ormation and warnings about how toproperly position the seats and seat-backs. 17 18
EX-L model only
The controls f or the power
adjustable driver’s seat are on the
outside edge of the seat bottom. You
can adjust the seat with the ignition
switch in any position. Make all seat
adjustments before you start driving.
The f ront passenger’s seat can be
adjusted manually (see the next
page). Moves the seat forward
and backward.
Moves the f ront of the
seat up or down.
Raises or lowers the seat.Moves the whole seat up
and f orward, or down
and backward. The front
of the seat also tilts up or
down at the same time.
Adjusts the seat-back
angle f orward or
backward.
Increases or decreases
the lumbar support.
Seats
Driver’s Seat Power A djustments
94
——y
y
(,yy
2009 CR- V

µ
CONT INUED
The height of your driver’s seat is
adjustable. To raise the seat,
repeatedly pull up the lever on the
outside of the seat cushion. To lower
the seat, push the lever down
repeatedly.
Make all seat adjustments bef ore
you start driving.
To adjust the seat f orward or
backward, pull up on the bar under
the seat cushion’s f ront edge. Move
the seat to the desired position, and releasethebar.Trytomovetheseat
to make sure it is locked in position.
To change the seat-back angle of the
f ront seat, pull up the lever on the
outside of the seat bottom.
Once a seat is adjusted correctly,
rock it back and f orth to make sure it
is locked in position.
See pagesf or important saf ety
inf ormation and warnings about how toproperly position the seats and seat-backs.
LX/EX models
1311
Seats
Seat A djustments
Inst rument s and Cont rols
95
\f—\f—y
\fy
(,\fy\f
\f\fy
2009 CR- V

See pagef or important saf etyinf ormation and a warning aboutimproperly positioning head restraints. 13
Your vehicle is equipped with head
restraints in all seating positions to
help protect you and your
passengers f rom whiplash and other
injuries.
They are most ef f ective when you
adjust them so the center of the back
of the occupant’s head rests against
the center of the restraint.The head restraints adjust f or height.
You need both hands to adjust a
restraint.Donotattempttoadjustit
while driving. To raise it, pull upward.
To lower the restraint, push the
release button sideways, and push
the restraint down.
Head Restraints
Seats
A djust ing t he Head Rest raint
98
RELEASE BUTTON
LEGS
SEAT-BACK CUSHION
Front Position
\f—\f—y
\fy
(,\fy\f
\fy
2009 CR- V

µ
If your vehicle’s battery is
disconnected, or goes dead, the
audio system will disable itself . The
nexttimeyouturnontheradio,you
may see ‘‘CODE’’ in the f requency
display. Use the preset buttons to
enter the code (see page ).
Check the terminals f or corrosion (a
white or yellowish powder). To
remove it, cover the terminals with a
solution of baking soda and water. It
will bubble up and turn brown. When
this stops, wash it of f with plain
water. Dry off the battery with a
cloth or paper towel. Coat the
terminals with grease to help prevent
f uture corrosion.
If additional battery maintenance is
needed, see your dealer or a
qualif ied technician.
Battery posts,
terminals, and related accessories
contain lead and lead compounds.
If you need to connect the battery to
a charger, disconnect both cables to
prevent damaging your vehicle’s
electrical system. Always disconnect
the negative ( ) cable first, and
reconnect it last.
218
Checking the Battery
WARNING:
Wash your hands af ter handling.
Maint enance
309
TEST INDICATOR WINDOW
The battery gives off explosive
hydrogen gas during normal
operation.
A spark or flame can cause the
battery to explode with enough
force to kill or seriously hurt you.
Wear protective clothing and a
face shield, or have a skilled
technician do the battery
maintenance.
——y

y
(,y
y
2009 CR- V

If you have a f lat tire while driving,
stop in a saf e place to change it.
Drive slowly along the shoulder until
you get to an exit or an area to stop
that is far away from the traffic lanes.
Park the vehicle on f irm, level, and
non-slippery ground. Put the
transmission in Park. Apply the
parking brake.
If you are towing a trailer, unhitch
the trailer.
Turn on the hazard warning lights,
and turn the ignition switch to the
LOCK (0) position. Have all
passengers get out of the vehicle
while you change the tire.
Open the tailgate. Raise the cargo
area f loor lid by lif ting up with the
strap, and remove it f rom cargo
area by disengaging the tabs.
When you store the f lat tire in the
spare tire well, do not reinstall the
cargo area f loor lid f orcibly. This
will damage the tabs on the lid.
Take the tool kit out of the spare
tire.
1.
2.3.
4.
CONT INUED
Changing a Flat Tire
T aking Care of t he Unexpect ed
313
JACK
SPARE TIRE
TOOLS
The vehicle can easily roll off
the jack, seriously injuring
anyone underneath.
Follow the directions for
changing a tire exactly, and
never get under the vehicle
when it is supported only by the
jack.
——y
y
(,y
y
2009 CR- V

If the vehicle overheats, you should
take immediate action. The only
indication may be the temperature
gauge climbing to or above the red
mark. Or you may see steam or
spray coming f rom under the hood.
The reading of the vehicle’s
temperature gauge should stay in
the midrange. If it climbs to the red
mark, you should determine the
reason (hot day, driving up a steep
hill, etc.).
If you do not see steam or spray,
leave the engine running, and
watch the temperature gauge. If
the high heat is due to overloading,
the engine should start to cool
down almost immediately. If it
does, wait until the temperature
gauge reading comes down to the
midpoint, then continue driving.
If the temperature gauge reading
stays at the red mark, turn off the
engine.
If you see steam and/or spray
coming f rom under the hood, turn
of f the engine. Wait until you see
no more signs of steam or spray,
then open the hood.
Saf ely pull to the side of the road.
Put the transmission in Park, and
set the parking brake. Turn of f all
accessories, and turn on the
hazard warning lights.
1.
2.
3.
4.
If theEngineOverheats
322
Steam and spray from an
overheated engine can
seriously scald you.
Do not open the hood if steam
is coming out.
Driving with the temperature gauge
reading at the red mark can cause
serious damage to the engine.
——y
y
(,yy
2009 CR- V

Let the vehicle sit f or a minute.
Open the hood, and check the oil
level (see page ). An engine
very low on oil can lose pressure
during cornering and other driving
maneuvers.
If necessary, add oil to bring the
level back to the full mark on the
dipstick (see page ).
Saf ely pull of f the road, and shut
of f the engine. Turn on the hazard
warning lights.
Start the engine, and watch the oil
pressure indicator. If it does not go
out within 10 seconds, turn of f the
engine. There is a mechanical
problem that needs to be repaired
bef ore you can continue driving
(seeon page
).
This indicator should never come on
when the engine is running. If it
starts flashing or stays on, the oil
pressure has dropped very low or
lost pressure. Serious engine
damage is possible, and you should
take immediate action.
If the charging system indicator
comes on brightly when the engine
is running, the battery is not being
charged.
Immediately turn of f all electrical
accessories. Try not to use other
electrically operated controls such as
the power windows. Keep the engine
running; starting the engine will
discharge the battery rapidly.
Go to a service station or garage
where you can get technical
assistance.
1.
2.
4.
3.
230
281
332 Emergency T owing
L ow Oil Pressure
Indicator
Charging System
Indicator
L ow Oil Pressure Indicator, Charging System Indicator
324
Running the engine with low oil
pressure can cause serious mechanical
damage almost immediately. Turn of f
the engine as soon as you can saf ely get
the vehicle stopped.
\f—\f—y

y
(,\fy\fy
2009 CR- V

The tires on your vehicle meet all
U.S. Federal Saf ety Requirements.
All tires are also graded f or
treadwear, traction, and temperature
perf ormance according to
Department of Transportation
(DOT) standards. The f ollowing
explains these gradings.
Quality grades can be f ound where
applicable on the tire sidewall
between tread shoulder and
maximum section width. For
example:The treadwear grade is a compara-
tive rating based on the wear rate of
the tire when tested under controlled
conditions on a specif ied government
test course. For example, a tire
graded 150 would wear one and one-
half (1 1/2) times as well on the
government course as a tire graded
100. The relative perf ormance of
tires depends upon the actual condi-
tions of their use, however, and may
depart signif icantly f rom the norm
due to variations in driving habits,
service practices and dif f erences in
road characteristics and climate.The traction grades, f rom highest to
lowest, are AA, A, B, and C. Those
grades represent the tire’s ability to
stop on wet pavement as measured
under controlled conditions on
specif ied government test surf aces
of asphalt and concrete. A tire
marked C may have poor traction
perf ormance.
Warning: The traction grade
assignedtothistireisbasedon
straight-ahead braking traction tests,
and does not include acceleration,
cornering, hydroplaning, or peak
traction characteristics.
All passenger car tires must conf orm
to Federal Saf ety Requirements in
addition to these grades. T readwear 200
Traction AA
Temperature A
Unif orm T ire Quality Grading T readwear
T raction
DOT Tire Quality Grading (U.S. Vehicles)
338
\f—\f—y

y
(,\fy\fy
2009 CR- V

Warning: The temperature grade f or
this tire is established f or a tire that
is properly inf lated and not
overloaded. Excessive speed,
underinf lation, or excessive loading,
either separately or in combination,
can cause heat buildup and possible
tire f ailure.
The temperature grades are A (the
highest), B, and C, representing the
tire’s resistance to the generation of
heat and its ability to dissipate heat
when tested under controlled
conditions on a specif ied indoor
laboratory test wheel. Sustained high
temperature can cause the material
of the tire to degenerate and reduce
tire life, and excessive temperature
can lead to sudden tire f ailure. The
grade C corresponds to a level of
perf ormance which all passenger car
tires must meet under the Federal
Motor Vehicle Saf ety Standard No.
109. Grades B and A represent
higher levels of perf ormance on the
laboratory test wheel than the
minimum required by law.
Temperature
DOT Tire Quality Grading (U.S. Vehicles)
Technical Inf ormation
339
\f—\f—y

y
(,\fy\fy
2009 CR- V

Î
...............
DANGER, Explanation of .iii
...................................
Dashboard .4,72
................
Daytime Running Lights .75
Daytime Running Lights
.......................................
Indicator .63
.................................
Dead Battery .320
............
Def ects, Reporting Saf ety .352
................
Def ogger, Rear Window .77
..............
Def rosting the Windows .130
.......................
Detachable Anchor .107
....................................
Dimensions .336
.........
Dimming the Headlights .74,75
............................
Capacities Chart .336
.............
Carbon Monoxide Hazard .54
..............................................
Cargo .236
...........................
Cargo area Light .124
.................................
Cargo Hooks .241
.............................
Carrying Cargo .236
....................
Cargo, How to Carry .236
.............
CAUTION, Explanation of .iii
.........................................
CD Care .213
..........................
CD Changer .162,191
CD Changer Error ...........................
Messages .169,197
.............
CD Error Messages .169,197
..............................
CD Player .145,182
...............................
Center Pocket .113
..................................
Center Table .117
........................
Certif ication Label .334
.................................
Chains, Tires .307
....................
Changing a Flat Tire .313
.................................
Changing Oil .281
........................................
How to .281
......................................
When to .279
....
Charging System Message .60,324
............
Check Fuel Cap Indicator .228 ............
Checklist, Bef ore Driving .245
.....................................
Child Saf ety .34
..............................
Booster Seats .51
.............................
Child Seats .34,39
.....
Important Saf ety Reminders .34
..........................................
Inf ants .39
..........................
Larger Children .50
.........................................
LATCH .43
......................
Risks with Airbags .35
.............................
Small Children .40
.........................................
Tethers .48
...........................
Warning Labels .36
.........
Where Should a Child Sit? .35
.................................
Child Seats .34,39
.........................................
LATCH .43
..........
Tether Anchorage Points .48
..................
Childproof Door Locks .88
.......................
Cleaning Seat Belts .297
...............
Climate Control System .132
..............................................
Clock .219
........................
CO in the Exhaust .344
............
Cold Weather, Starting in .246
...............
Consumer Inf ormation .350
.............
Controls, Instruments and .57
....................
Conversation Mirror .120Coolant
........................................
Adding .284
....................................
Checking .230
.........................
Proper Solution .284
...................
Temperature Gauge .69
..............................
Courtesy Light .124
Crankcase Emissions Control ........................................
System .344
................
Cruise Control Indicator .62
............
Cruise Control Operation .222
.........................
Customer Service .350
Index
D
C
II
——y


y
(,y
y
2009 CR- V
