set clock HONDA CR-V 2011 RD1-RD5, RE7 / 3.G Owners Manual

The heating and air conditioning
system in your vehicle provides a
comf ortable driving environment in
all weather conditions.
The standard audio system has
many f eatures. This section
describes those f eatures and how to
use them.
Your vehicle has an anti-theft audio
system that requires a code number
to enable it.
The security system helps to
discourage vandalism and thef t of
your vehicle..............
Vents, Heating, and A/C . 130
...............
Climate Control System . 135
..........
Dual Temperature Control . 140
..............
Climate Control Sensors . 142
................................
Audio System . 143 ..........
Playing the AM/FM Radio . 145
................................
Playing a Disc . 149
.......
Disc Player Error Messages . 156
..........
Playing the FM/AM Radio . 157
................
Playing the XM
Radio . 161
.................................
Playing Discs . 166
...
Disc Changer Error Messages . 176
............................
PlayinganiPod
. 177
.................
iPod
Error Messages . 183
Playing a USB Flash Memory
........................................
Device . 184
USB Flash Memory Device Error
...................................
Messages . 193
..........
Playing the AM/FM Radio . 194
................
Playing the XM
Radio . 200
................................
Playing a Disc . 206
.......
Disc Player Error Messages . 214 ...................................
CD Changer . 215
.....
CD Changer Error Messages . 221
..........................
Playing a PC card . 222
.............
PC card Error Messages . 234
............................
PlayinganiPod
. 235
.................
iPod
Error Messages . 241
Playing a USB Flash Memory ........................................
Device . 242
USB Flash Memory Device Error ...................................
Messages . 249
............
AM/FM Radio Reception . 250
..................
Protecting Your Discs . 252
................
Remote Audio Controls . 255
...
Playing an Optional Audio Unit . 257
.................
Radio Thef t Protection . 258
..........................
Setting the Clock . 259
.........................................
Compass . 260
............................
Security System . 264
...
Rearview Camera and Monitor . 265
...............................
Cruise Control . 266
........
HandsFreeLink. 269
LX model
EX and EX-L models without navigationsystem
Canadian EX model and EX-L model without navigation system
EX-L model with navigation system Bluetooth
Except LX model
Features
Features
129
Main Menu

Turn this dial to increase or decrease
the fan speed and airflow.
Turning this dial clockwise increases
the temperature of the airflow.When the recirculation indicator is
on, air f rom the vehicle’s interior is
sent throughout the system again.
When the indicator is off, air is
brought in f rom the outside of the
vehicle (fresh air mode).
The outside air intakes f or the
heating and cooling system are at
the base of the windshield. Keep this
area clear of leaves and other debris.
Thesystemshouldbeleftinfresh
air mode under almost all conditions.
Keeping the system in recirculation
mode, particularly with the A/C of f ,
can cause the windows to fog up.
Switch to recirculation mode when
driving through dusty or smoky
conditions, then return to fresh air
mode.
This button turns the air
conditioning on and of f . The
indicatorinthebuttonisonwhen
the A/C is on.
The system automatically
turns on the A/C and switches to
recirculation mode (see page to
use this setting). Air f lows f rom the
center and side vents in the
dashboard. Pressing the , A/C,
or any of the mode buttons cancels
MAX A/C, but the A/C stays on. Airf low is divided between
the vents in the dashboard and the
f loor vents. Air flows from the center
and corner vents in the dashboard.
Use the mode control buttons to
select the vents air flows from. Some
air will f low f rom the dashboard
corner vents in all modes.
This button turns the rear window
def ogger of f and on (see page ).
Pushing this button also turns the
power mirror heaters on and of f .
/
80
133
CONT INUED
Canadian models only
Vents, Heating, and A/C
Fan Control Dial
T emperature Control Dial
Air Conditioning (A/C) Button Recirculation Button
MAX A/C Button Mode Control
Rear Window Def ogger
Button
Features
131
Main MenuTable of Contents

On vehicles with navigation systemThe automatic climate control
system in your vehicle maintains the
interior temperature you select. The
system also adjusts the f an speed
and airf low levels.The driver’s side temperature and
the passenger’s side temperature can
be set separately. Turn the dial of
the appropriate temperature control
clockwisetoincreasethe
temperature of airf low. Turn the dial
counterclockwise to decrease it.
Each set temperature is shown in the
display.
When you set the temperature to its
lower limit ( ) or its upper limit
( ), the system runs at f ull
cooling or heating only. It does not
regulate the interior temperature.
When the indicator in the dual
button is on, the driver’s side and
passenger’s side temperature can be
controlled independently (see page
).
The climate control system f or your
vehicle can also be operated using
the voice control system. See the
navigation system manual f or
complete details.
Press the AUTO button.
Set the desired temperature by
turning the driver’s side
temperature control dial. You will
see AUTO and the selected
temperature in the display. You
can also set the passenger’s side
temperature by turning the
passenger’s side dial.
The system automatically selects the
proper mix of conditioned and/or
heated air that will, as quickly as
possible, raise or lower the interior
temperature to your pref erence.
1. 2.
140
Climate Control System
Voice Control System Using A utomatic Climate ControlT emperat ure Cont rol
136
Main MenuTable of Contents

On models with navigation system
On models without navigation system
The navigation system receives
signals f rom the global positioning
system (GPS), and the displayed
time is updated automatically by the
GPS. Ref er to the navigation system
manual f or how to adjust the time.
Change the hours by pressing the H
(hour) button until the numbers
advance to the desired time. Change
the minutes by pressing the M
(minute) button until the numbers
advance to the desired time.
Press the CLOCK button again to
enter the set time.
For example: 1:06 will reset to 1:001:52 will reset to 2:00
You can quickly set the time to the
nearest hour. If the displayed time is
bef ore the half hour, press and hold
the CLOCK button, then press the R
(reset) button to set the time back to
the previous hour. If the displayed
time is af ter the half hour, the same
procedure sets the time f orward to
the beginning of the next hour.
To set the time, press the CLOCK
button until you hear a beep. The
displayed time begins to blink.
Setting the Clock
Features
259
EX and EX-L models without
navigation system
CLOCK BUTTON
(A.SEL side of the A.SEL/SCAN bar)
HOUR BUTTON
(PRESET 4) RESET BUTTON
(PRESET 6)
LX model
MINUTE BUTTON
(PRESET 5) RESET BUTTON
(PRESET 3)
HOUR BUTTON
(PRESET 1) MINUTE BUTTON
(PRESET 2)
CLOCK BUTTON (FM)
Main MenuTable of Contents

Look f or any obvious coolant leaks,
such as a split radiator hose.
Everything is still extremely hot,
so use caution. If you f ind a leak, it
must be repaired bef ore you
continue driving (seeon page ).
Using gloves or a large heavy
cloth, turn the radiator cap
counterclockwise, without pushing
down, to the f irst stop. Af ter the
pressure releases, push down on
the cap, and turn it until it comes
off.
If you don’t f ind an obvious leak,
check the coolant level in the
radiator reserve tank. Add coolant
if the level is below the MIN mark.
If there was no coolant in the
reserve tank, you may need to add
coolant to the radiator. Let the
engine cool down until the reading
reaches the middle of the
temperature gauge or lower
bef ore checking the radiator. Start the engine, and set the
temperature to maximum heat
(climate control to AUTO at
‘‘ ’’). Add coolant to the
radiator up to the base of the f iller
neck. If you do not have the
proper coolant mixture available,
you can add plain water.
Remember to have the cooling
system drained and ref illed with
the proper mixture as soon as you
can.
If the temperature stays normal,
check the coolant level in the
radiator reserve tank. If it has
gone down, add coolant to the
MAX mark. Put the cap back on
tightly.
Put the radiator cap back on
tightly. Run the engine, and check
the temperature gauge. If it goes
back to the red mark, the engine
needs repair (see
on page ).
9.
8.
7.
6.
5.
10. 11.
403
403
Emergency
Towing
Emergency
Towing
If theEngineOverheats
T aking Care of t he Unexpect ed
393
Removing the radiator cap
while the engine is hot can
cause the coolant to spray out,
seriously scalding you.
Always let the engine and
radiator cool down before
removing the radiator cap.
Main MenuTable of Contents

ÃŽ
CONT INUED
........................
Protecting Children . 35
.......................
Protecting Inf ants . 40
.......
Protecting Larger Children . 51
.........
Protecting Small Children . 41
Using Child Seats with
.....................................
Tethers . 49
.............................
Using LATCH . 44
..................
Protecting Your Discs . 252
...................
Radiator Overheating . 392
Radio/Disc Sound
.......................
System . 145, 157, 194
.................
Radio Thef t Protection . 258
...........................
Readiness Codes . 419
.................
Rear Dif f erential Fluid . 357
..
Rear Lights, Bulb Replacement . 362
................
Rear Seat, Folding . 105, 107
..........................
Rear View Mirror . 114
.................
Rear Window Def ogger . 80
.
Rear Window Wiper and Washer . 76
...
Reclining the Seat Backs . 97, 98, 99
........................................
Ref ueling . 295
.......................
Reminder Indicators . 62
.......................
Remote Transmitter . 92 Replacement Inf ormation
..............
Dust and Pollen Filter . 366
................
Engine Oil and Filter . 350
..........................................
Fuses . 397
................................
Light Bulbs . 359
....................................
Schedule . 341
...........................................
Tires . 374
.............................
Wiper Blades . 367
Replacing Seat Belts Af ter a ............................................
Crash . 22
.............
Reporting Saf ety Def ects . 424
Reserve Tank, Engine
...............................
Coolant . 298, 352
...............................
Restraint, Child . 35
..................
Reverse Gear Position . 316
......................................
Roof Rack . 307
................................
Rotation, Tire . 373
..................................
Saf ety Belts . 9, 19
............
Safety Defects, Reporting . 424
.................................
Saf ety Features . 8
.........................................
Airbags . 10
.......................................
Seat Belts . 9
.............
Saf ety Labels, Location of . 56 ..............................
Saf ety Messages . iii
.....................................
Seat Belts . 9, 15
...............
Additional Information . 19
.....
Advice f or Pregnant Women . 17
Automatic Seat Belt
...............................
Tensioners . 21
.....................................
Cleaning . 365
...................
Detachable Anchor . 109
................
Lap/Shoulder Belt . 15, 20
................................
Maintenance . 22
Reminder Indicator and
................................
Beeper . 19, 62
...................
System Components . 19
...............
Use During Pregnancy . 17
...
Wearing a Lap/Shoulder Belt . 15
..................................
Seat Heaters . 111
..................
Seat Power Adjustment . 97
...................
Seats, Adjusting the . 97-99
.........................
Select/Reset Knob . 68
...............................
Serial Number . 406
...........................
Service Intervals . 341
...........................
Service Manual . 425
.........
Service Station Procedures . 295
..........................
Setting the Clock . 259
Index
INDEX
S
R
VII
Main Menu
