255
uuBrakinguABS (Anti-lock Brake System)
Driving
ABS (Anti-lock Brake System)
Helps prevent the wheels from locking up, and helps you retain steering control by
pumping the brakes rapidly, much faster than you.
The electronic brake distribution (EBD) system, which is part of the ABS, also
balances the front-to-rear braking distribution according to vehicle loading.
You should never pump the brake pedal. Let the ABS work for you by always
keeping firm, steady pressure on the brake pedal. This is sometimes referred to as
"stomp and steer." ■ABS operation
The brake pedal may pulsate slightly when the ABS is working. Keep holding the
pedal firmly down. On dry pavement, you will need to press on the brake pedal very
hard before the ABS activates. However, you may feel the ABS activate immediately
if you are trying to stop on snow or ice.
When the vehicle speed goes under 6 mph (10 km/h), the ABS stops.
■ABS1ABS (Anti-lock Brake System)
NOTICEThe ABS may not function correctly if you use an
incorrect tire type and size.
When the ABS indicator comes on while driving,
there may be a problem with the system.
While normal braking is not affected, there is a
possibility of the ABS not operating. Have the vehicle checked by a dealer immediately.
The ABS does not reduce the time or distance it takes
to stop the vehicle. It only helps with steering control
during hard braking.
In the following cases, your vehicle may need more
stopping distance than a vehicle without the ABS: • When driving on rough road surfaces, including
when driving on uneven surfaces, such as gravel or
snow.
• When tire chains are installed.
You may hear a motor sound coming from the
engine compartment while system checks are being
performed immediately after starting the engine or
while driving. This is normal.

304
uuChecking and Maintaining TiresuWinter Tires
Maintenance
Winter Tires
If driving on snowy or frozen roads, mount all season marked ”M+S” tires, snow
tires, or tire chains; reduce speed; and maintain sufficient distance between vehicles
when driving.
Be particularly careful when operating the steering wheel or brakes to prevent
skidding.
Use tire chains, snow tires, or all season tires when necessary or according to the law.
When mounting, refer to the following points.
For winter tires: • Select the size and load ranges that are the same as the original tires.
• Mount the tires to all four wheels.
For tire chains:• Install them on the front tires only.
• Because your vehicle has limited tire clearance, we strongly recommend using the
chains listed below:
• Follow the chain manufacturer's instruc tion when installing. Mount them as
tightly as you can.
• Check that the chains do not touch the brake lines or suspension.
• Drive slowly.
Cable-type: SCC Radial Chain SC1042
1Winter Tires
NOTICETraction devices that are the wrong size or improperly
installed can damage your vehicle's brake lines,
suspension, body, and wheels. Stop driving if they are
hitting any part of the vehicle.
When tire chains are mounted, follow the chain
manufacturer's instructions regarding vehicle
operational limits.
If your vehicle is equipped with summer tires, be
aware that these tires are not designed for winter
driving conditions. For more information, contact a dealer.
3WARNING
Using the wrong chains, or not properly
installing chains, can damage the brake
lines and cause a crash in which you can be
seriously injured or killed.
Follow all instruction s in this owner's
manual regarding the selection and use of
tire chains.

357
Index
Seats.......................................................... 122
Adjusting ................................................ 122
Driver’s Seat Lumbar Support .................. 122
Front Seats.............................................. 122
Rear Seats ............................................... 129
Seat Heaters ........................................... 139
Security System ........................................ 106
Immobilizer System Indicator..................... 75
Security System Alarm Indicator ................ 75
SEL/RESET Knob .................................... 78, 81
Select Lever ........................................ 15, 243
Operation ......................................... 15, 244
Releasing ................................................ 326
Won’t Move ........................................... 326
Selecting a Child Seat ................................ 56
Selector Knob (Audio) ............................. 153
Setting the Clock ........................................ 96
Shift Lever .......................................... 15, 243
Shift Lever Position Indicator ............ 69, 244
Shifting (Transmission) ............................ 243
Shoulder Anchor ........................................ 33
Side Airbags ............................................... 44
Cutoff System ........................................... 46
Off Indicator ............................................. 46
Side Curtain Airbags .................................. 47
SMS Text Message ............................ 206, 218
Snow Tires ................................................ 304
Spare Tire ......................................... 317, 341
Spark Plugs ............................................... 340
Specifications ........................................... 340
Specified Fuel ................................... 259, 340 Speedometer
.............................................. 77
SRS Airbags (Airbags) ................................. 40
Starting the Engine .................................. 239
Does Not Start ......................................... 323
Engine Switch Buzzer .............................. 111
Jump Starting .......................................... 324
Steering Wheel ......................................... 119
Adjusting................................................. 119
Stopping .................................................... 257
Summer Tires ............................................ 304
Sunglasses Holder ..................................... 138
Supplemental Restraint System (SRS) ........ 40
Switches (Around the Steering
Wheel) ............................................. 2, 3, 111
Synchronized Mode .................................. 147
T
Tachometer ................................................. 77
Tailgate ..................................................... 104
Unable to Open ....................................... 337
Temperature Gauge ................................... 77
Temperature Sensor ................................. 148
Text Message .................................... 206, 218
Time (Setting) ............................................. 96
Tire Pressure Monitoring System (TPMS) ..................................................... 250
Indicator ............................................ 73, 332
Tires ........................................................... 296
Air Pressure ..................................... 297, 341
Checking and Maintaining....................... 296 Inspection ............................................... 296
Labeling .................................................. 297
Puncture (Flat Tire) .................................. 317
Regulations ............................................. 299
Rotation .................................................. 303
Spare Tire ........................................ 317, 341
Summer .................................................. 304
Tire Chains .............................................. 304
Wear Indicators ....................................... 301
Winter..................................................... 304
Tonneau Cover ......................................... 140
Tools .......................................................... 316
Towing a Trailer ....................................... 231
Equipment and Accessories ..................... 232
Load Limits .............................................. 231
Towing Your Vehicle ................................ 235
Behind a Motorhome .............................. 235
Emergency .............................................. 336
TPMS (Tire Pressure Monitoring
System) .................................................... 250
Indicator............................................ 73, 332
Transmission ............................................. 243
Automatic ............................................... 243
Fluid ........................................................ 282
Number................................................... 342
Shift Lever Position Indicator.............. 69, 244
Trip Meter ................................................... 79
Troubleshooting ....................................... 315
Blown Fuse...................................... 333, 334
Brake Pedal Vibrates .................................. 19
Buzzer Sounds When Opening Door.......... 20

358
Index
Emergency Towing .................................. 336
Engine Won’t Start .................................. 323
Noise When Braking .................................. 20
Overheating............................................. 327
Puncture/Flat Tire ..................................... 317
Rear Door Won’t Open ...................... 19, 102
Select Lever Won’t Move ......................... 326
Warning Indicators .................................... 68
Turn Signals ............................................... 112
Indicators (Instrument Panel) ...................... 74
U
Unlocking the Doors ................................... 99
Unlocking the Front Doors from the
Inside ......................................................... 11
USB Adapter Cable ........................... 150, 151
USB Flash Drives ........................................ 193
V
Valet Key ..................................................... 98
Vanity Mirrors ............................................... 5
Vehicle Identification Number ................. 342
Vehicle Stability Assist (VSA ®).................. 248
Off Button ............................................... 249
Off Indicator .............................................. 72
System Indicator ........................................ 72
Viscosity (Oil) ..................................... 275, 341
VSA ® (Vehicle Stability Assist) .................. 248W
Wallpaper
................................................... 90
Warning Indicator On/Blinking ............... 329
Warning Labels ........................................... 66
Warranties (Warranty Manual provided separately) .............................................. 347
Watts ......................................................... 340
Wear Indicators (Tire) .............................. 301
Wheel Nut Wrench (Jack Handle) ........... 320
Window Washers ..................................... 115
Adding/Refilling Fluid .............................. 284
Switch ..................................................... 115
Windows (Opening and Closing) ............ 108
Windshield ................................................ 115
Cleaning ................................................. 313
Defrosting/Defogging ...................... 144, 146
Washer Fluid ........................................... 284
Wiper Blades ........................................... 292
Wipers and Washers................................ 115
Winter Tires .............................................. 304
Snow Tires .............................................. 304
Tire Chains .............................................. 304
Wipers and Washers ................................. 115
Checking and Replacing Wiper Blades ..... 292
Front ....................................................... 115
Rear ........................................................ 116
WMA ................................................. 160, 168
Worn Tires ................................................ 296 X XM
® Radio ................................................ 158
