jump start HONDA CR-V 2013 RM1, RM3, RM4 / 4.G Owners Manual

Contents
Child Safety P. 52 Exhaust Gas Hazard P. 65 Safety Labels P. 66
Opening and Closing the Tailgate P. 104 Security System P. 106 Opening and Closing the Windows P. 108
Operating the Switches Around the Steering Wheel P. 111 Adjusting the Mirrors P. 120
Interior Lights/Interior Convenience Items P. 132 Heating and Cooling System
* P. 142
Rear Entertainment System* P. 174 Audio Error Messages P. 186
Bluetooth® HandsFreeLink® P. 194 Compass P. 223
Off-Highway Driving Guidelines P. 237 When Driving P. 239 Braking P. 254
Refueling P. 260 Fuel Economy P. 263 Accessories and Modifications P. 264
Maintenance Under the Hood P. 275 Replacing Light Bulbs P. 287
Checking and Maintaining Tires P. 298 Battery P. 307 Remote Transmitter Care P. 308
Heating and Cooling System
*/Climate Control System* Maintenance P. 311 Cleaning P. 312
Engine Does Not Start P. 325 Jump Starting P. 326 Shift Lever Does Not Move P. 328
Fuses P. 335 Emergency Towing P. 338When You Cannot Open the Tailgate P. 339
Devices that Emit Radio Waves P. 345 Reporting Safety Defects P. 346
Authorized Manuals P. 351 Customer Service Information P. 352
Quick Reference GuideP. 2
Safe DrivingP. 23
Instrument PanelP. 67
ControlsP. 95
FeaturesP. 149
DrivingP. 225
MaintenanceP. 265
Handling the UnexpectedP. 317
InformationP. 341
IndexP. 353

18
Quick Reference Guide
Handling the Unexpected (P317)
Flat Tire (P319)
●Park in a safe location and replace the
flat tire with the compact spare tire in the
cargo area.
Indicators Come On
(P331)
●Identify the indicator and consult the
owner's manual.
Engine Won't Start (P325)
●If the battery is dead, jump start using a
booster battery.
Blown Fuse (P335)
●Check for a blown fuse if an electrical
device does not operate.
Overheating (P329)
●Park in a safe location. If you do not see
steam under the hood, open the hood,
and let the engine cool down.
Emergency Towing (P338)
●Call a professional towing service if you
need to tow your vehicle.

317
Handling the Unexpected
This chapter explains how to handle unexpected troubles.
Tools
Types of Tools .................................. 318
If a Tire Goes Flat
Changing a Flat Tire ......................... 319
Engine Does Not Start
Checking the Engine ........................ 325
Jump Starting.................................... 326
Shift Lever Does Not Move.............. 328
Overheating
How to Handle Overheating ............. 329Indicator, Coming On/BlinkingIf the Low Oil Pressure Indicator Comes
On ............................................. 331
If the Charging System Indicator Comes
On ................................................. 331
If the Malfunction Indicator Lamp Comes
On or Blinks ................................... 332
If the Brake System Indicator Comes On
(Red) .............................................. 333
If the EPS System Indicator Comes On ... 333If the Low Tire Pressure Indicator Comes
On ................................................. 334If the TPMS Indicator Comes On ...... 334
Fuses
Fuse Locations ................................. 335
Inspecting and Changing Fuses ........ 337
Emergency Towing........................... 338
When You Cannot Open the Tailgate.. 339

325
Handling the Unexpected
Engine Does Not Start
Checking the Engine
If the engine does not start, check the starter.
Starter conditionChecklistStarter doesn’t turn or turns
over slowly.
The battery may be dead. Check
each of the items on the right and
respond accordingly.Check the brightness of the interior lights.
Turn on the interior lights and check the brightness.
●If the interior lights are dim or do not come on at all2Battery P. 307●If the interior lights come on normally 2 Inspecting and Changing Fuses P. 337The starter turns over normally
but the engine doesn’t start.
There may be a problem with the
fuse. Check each of the items on
the right and respond accordingly.Review the engine start procedure.
Follow its instructions, and try to start the engine again. 2 Starting the Engine P. 239Check the immobilizer system indicator.
When the immobilizer system indicator is blinking, the engine cannot be started.
2Immobilizer System P. 106Check the fuel level.
There should be enough fuel in the tank. 2 Fuel Gauge P. 77Check the fuse.
Check all fuses, or have the vehicle checked by a dealer.
2Inspecting and Changing Fuses P. 337If the problem continues:2Emergency Towing P. 338
1Checking the Engine
If you must start the vehicle immediately, use an
assisting vehicle to jump start it.
2Jump Starting P. 326

326
Handling the Unexpected
Jump Starting
Turn off the power to electric devices, such as audio and lights. Turn off the engine,
then open the hood.
1.Connect the first jumper cable to your
vehicle's + terminal.
2.Connect the other end of the first jumper
cable to the booster battery + terminal.
uUse a 12 volt booster battery only.
3.Connect the second jumper cable to the
booster battery - terminal.
4.Connect the other end of the second
jumper cable to the engine mounting bolt
as shown.
Do not connect this jumper cable to any
other part.
5.If your vehicle is connected to another
vehicle, start the assisting vehicle's engine
and increase its rpm slightly.
6.Attempt to start your vehicle's engine. If it
turns over slowly, check that the jumper
cables have good metal-to-metal contact.■Jump Starting Procedure1Jump Starting
Securely attach the jumper cables clips so that they
do not come off when the engine vibrates. Also be
careful not to tangle the jumper cables or allow the
cable ends to touch each other while attaching or
detaching the jumper cables.
Battery performance degrades in cold conditions and
may prevent the engine from starting.
3WARNINGA battery can explode if you do not follow
the correct procedure, seriously injuring
anyone nearby.
Keep all sparks, open flames, and smoking
materials away from the battery.
Booster Battery

327
uuJump Startingu
Handling the Unexpected
Once your vehicle's engine has started, remove the jumper cables in the following
order.
1.Disconnect the jumper cable from your vehicle's ground.
2.Disconnect the other end of the jumper cable from the booster - terminal.
3.Disconnect the jumper cable from your vehicle's + terminal.
4.Disconnect the other end of the jumper cable from the booster + terminal.
Have your vehicle inspected by a nearby service station or a dealer.■What to Do After the Engine Starts

Index
353
Index
Index
Numbers
4WD.......................................................... 251
AABS (Anti-lock Brake System).................. 256
Accessories and Modifications................ 264
Accessory Power Sockets......................... 135
Additives
Coolant .................................................. 282
Engine Oil ............................................... 277
Washer ................................................... 286
Additives, Engine Oil............................... 277
Adjusting
Armrest .................................................. 131
Front Seats.............................................. 122
Head Restraints ....................................... 125
Mirrors.................................................... 120
Rear Seat Back ........................................ 130
Rear Seats ............................................... 129
Steering Wheel ....................................... 119
Air Conditioning System (Climate
Control System)...................................... 145
Changing the Mode................................ 145
Defrosting the Windshield and
Windows .............................................. 146
Dust and Pollen Filter .............................. 311
Recirculation/Fresh Air Mode................... 145
Sensors ................................................... 148
Synchronized Mode ................................ 147
Using Automatic Climate Control............ 145Air Conditioning System (Heating and
Cooling System)...................................... 142
Cooling ................................................... 144
Defrosting the Windshield and
Windows ............................................... 144
Dust and Pollen Filter ............................... 311
Heating ................................................... 143
Air Pressure....................................... 299, 343
Airbags........................................................ 37
Advanced Airbags ..................................... 43
After a Collision......................................... 41
Airbag Care ............................................... 51
Event Data Recorder .................................. 21
Front Airbags (SRS) .................................... 40
Indicator ........................................ 48, 71, 74
Passenger Airbag Off Indicator .................. 49
Sensors...................................................... 37
Side Airbag Cutoff System ......................... 46
Side Airbag Off Indicator ........................... 50
Side Airbags .............................................. 44
Side Curtain Airbags .................................. 47
AM/FM Radio............................................ 156
Anti-lock Brake System (ABS).................. 256
Indicator .................................................... 71
Armrest..................................................... 131
Audio Antenna......................................... 152
Audio System............................................ 150
Adjusting the Sound ................................ 155
Auxiliary Input Jack .................................. 151
Error Messages ........................................ 186
General Information ................................ 190iPod®....................................................... 164
MP3/WMA/AAC ...................................... 169
Pandora®................................................. 167
Reactivating ............................................ 152
Recommended CDs ................................. 191
Recommended Devices............................ 193
Security Code .......................................... 152
Theft Protection ...................................... 152
USB Adapter Cable.................................. 151
USB Flash Drives ...................................... 193
Authorized Manuals................................ 351
Auto Door Locking/Unlocking................. 103
Customize ................................................. 89
Automatic Lighting.................................. 113
Automatic Transmission........................... 242
Creeping ................................................. 242
Fluid ........................................................ 284
Kickdown ................................................ 242
Operating the Shift Lever................... 15, 244
Shift Lever Does Not Move ...................... 328
Shifting ................................................... 243
Auxiliary Input Jack.................................. 151
Average Fuel Economy........................ 79, 82
Average Speed........................................... 82
AWD.......................................................... 251
BBattery...................................................... 307
Charging System Indicator................. 69, 331
Jump Starting .......................................... 326

355
Index
Display Button............................................ 81
Door Mirrors............................................. 121
Doors.......................................................... 97
Auto Door Locking.................................. 103
Auto Door Unlocking .............................. 103
Door Open Indicator ........................... 28, 72
Keys.......................................................... 97
Locking/Unlocking the Doors from the
Inside .................................................... 101
Locking/Unlocking the Doors from the
Outside ................................................... 99
Lockout Prevention System ..................... 100
DOT Tire Quality Grading........................ 301
Driver’s Seat Lumbar Support................. 122
Driving...................................................... 225
Automatic Transmission .......................... 242
Braking ................................................... 254
Cruise Control ........................................ 246
Off-Highway Driving Guidelines .............. 237
Shifting Gear .......................................... 243
Starting the Engine ................................. 239
Dust and Pollen Filter.............................. 311
DVD Player............................................... 174
EEco Assist System.......................................... 7
ECON Button............................................ 245
Elapsed Time.............................................. 82
Electric Power Steering (EPS) System
Indicator ........................................... 73, 333Electronic Stability Control (ESC)............. 249
Emergency................................................ 338
Emissions Testing (Readiness Codes)....... 347
Engine....................................................... 344
Coolant ................................................... 282
Jump Starting .......................................... 326
Oil ........................................................... 277
Starting ................................................... 239
Switch Buzzer .......................................... 111
Engine Coolant......................................... 282
Adding to the Radiator ............................ 283
Adding to the Reserve Tank ..................... 282
Overheating ............................................ 329
Temperature Gauge .................................. 77
Engine Oil................................................. 277
Adding .................................................... 279
Checking ................................................. 278
Displaying Oil Life .................................... 269
Low Oil Pressure Indicator.................. 68, 331
Recommended Engine Oil........................ 277
EPS (Electric Power Steering)
System............................................... 73, 333
Exhaust Gas Hazard (Carbon Monoxide).. 65
Exterior Care (Cleaning)........................... 314
Exterior Mirrors........................................ 121FFeatures..................................................... 149
Filters
Dust and Pollen ....................................... 311Oil ........................................................... 280
Flat Tire..................................................... 319
Floor Mats................................................. 313
Fluids
Automatic Transmission .......................... 284
Brake ...................................................... 285
Engine Coolant ....................................... 282
Windshield Washer ................................. 286
Fog Light Indicator..................................... 74
Folding Down the Rear Seats.................. 129
Foot Brake................................................ 255
Front Airbags (SRS)..................................... 40
Front Seats................................................ 122
Adjusting ................................................ 122
Fuel...................................................... 16, 260
Economy ................................................. 263
Gauge ....................................................... 77
Low Fuel Indicator ..................................... 70
Range ................................................. 79, 82
Recommendation .................................... 260
Refueling................................................. 260
Fuel Economy........................................... 263
Fuel Fill Cap.............................................. 262
Message.................................................. 332
Fuel Fill Door............................................ 261
Fuses.......................................................... 335
Inspecting and Changing......................... 337
Locations......................................... 335, 336

357
Index
Washer Level ............................................ 76
Information.............................................. 341
Information Display................................... 78
Instrument Panel........................................ 67
Brightness Control .................................. 117
Interior Lights........................................... 132
Interior Rearview Mirror......................... 120
iPod®......................................................... 164
JJack (Wheel Nut Wrench)........................ 322
Jump Starting........................................... 326
KKey Number Tag........................................ 98
Keyless Lockout Prevention..................... 100
Keys............................................................. 97
Lockout Prevention ................................. 100
Master Keys .............................................. 97
Number Tag.............................................. 98
Rear Door Won’t Open ........................... 102
Remote Transmitter .................................. 99
Types and Functions.................................. 97
Valet Key .................................................. 98
Won’t Turn ............................................... 19
Kickdown (Automatic Transmission)...... 242
LLanguage (HFL)........................................ 195LATCH (Child Seats).............................. 57, 61
Lights................................................. 112, 287
Automatic ............................................... 113
Bulb Replacement.................................... 287
Daytime Running Lights ........................... 114
Fog Lights................................................ 114
High Beam Indicator .................................. 74
Interior .................................................... 132
Light Switches ......................................... 112
Lights On Indicator .................................... 74
Turn Signals............................................. 112
Load Limits................................................ 229
Locking/Unlocking...................................... 97
Auto Door Locking/Unlocking .................. 103
Childproof Door Locks ............................. 102
From Inside.............................................. 101
From Outside............................................. 99
Keys .......................................................... 97
Using a Key ............................................. 100
Lockout Prevention System...................... 100
Low Battery Charge.................................. 331
Low Fuel Indicator...................................... 70
Low Oil Pressure Indicator................. 68, 331
Lower Anchors...................................... 57, 61
Luggage (Maximum Load Limit)............. 229
MMaintenance............................................. 265
Battery .................................................... 307
Brake Fluid .............................................. 285Cleaning ................................................. 312
Climate Control System ........................... 311
Coolant ................................................... 282
Heating and Cooling System ................... 311
Maintenance Minder™ ........................... 269
Oil ........................................................... 278
Precautions ............................................. 266
Radiator .................................................. 283
Remote Control....................................... 309
Remote Transmitter ................................. 308
Replacing Light Bulbs .............................. 287
Safety...................................................... 267
Service Items ........................................... 272
Tires ........................................................ 298
Transmission Fluid ................................... 284
Under the Hood ...................................... 275
Wireless Headphone................................ 310
Malfunction Indicator Lamp.............. 69, 332
Map Lights................................................ 132
Maximum Load Limit............................... 229
Meters, Gauges........................................... 77
Mirrors...................................................... 120
Adjusting ................................................ 120
Door ....................................................... 121
Exterior ................................................... 121
Interior Rearview ..................................... 120
Modifications (and Accessories).............. 264
Moonroof................................................. 110
MP3................................................... 161, 169
Multi-Information Display......................... 81
Multi-View Rear Camera.......................... 259

359
Index
Seats.......................................................... 122
Adjusting ................................................ 122
Driver’s Seat Lumbar Support .................. 122
Front Seats.............................................. 122
Rear Seats ............................................... 129
Seat Heaters ........................................... 139
Security System........................................ 106
Immobilizer System Indicator..................... 75
Security System Alarm Indicator ................ 75
Select Lever........................................ 15, 243
Operation ......................................... 15, 244
Releasing ................................................ 328
Won’t Move ........................................... 328
Select/Reset Knob...................................... 78
Selecting a Child Seat................................ 56
Selector Knob (Audio)............................. 153
Setting the Clock........................................ 96
Shift Lever.......................................... 15, 243
Shift Lever Position Indicator............ 69, 244
Shifting (Transmission)............................ 243
Shoulder Anchor........................................ 33
Side Airbags............................................... 44
Cutoff System ........................................... 46
Off Indicator ............................................. 46
Side Curtain Airbags.................................. 47
SMS Text Message............................ 206, 218
Snow Tires................................................ 306
Spare Tire......................................... 319, 343
Spark Plugs............................................... 342
Specifications........................................... 342
Specified Fuel................................... 260, 342Speedometer.............................................. 77
SRS Airbags (Airbags)................................. 40
Starting the Engine.................................. 239
Does Not Start ......................................... 325
Engine Switch Buzzer .............................. 111
Jump Starting .......................................... 326
Steering Wheel......................................... 119
Adjusting................................................. 119
Stopping.................................................... 258
Summer Tires............................................ 306
Sunglasses Holder..................................... 138
Supplemental Restraint System (SRS)........ 40
Switches (Around the Steering
Wheel)............................................. 2, 3, 111
Synchronized Mode.................................. 147
TTachometer................................................. 77
Tailgate..................................................... 104
Unable to Open ....................................... 339
Temperature Gauge................................... 77
Temperature Sensor................................. 148
Text Message.................................... 206, 218
Time (Setting)............................................. 96
Tire Pressure Monitoring System
(TPMS)..................................................... 251
Indicator ............................................ 73, 334
Tires........................................................... 298
Air Pressure ..................................... 299, 343
Checking and Maintaining....................... 298Inspection ............................................... 298
Labeling .................................................. 299
Puncture (Flat Tire) .................................. 319
Regulations ............................................. 301
Rotation .................................................. 305
Spare Tire ........................................ 319, 343
Summer .................................................. 306
Tire Chains .............................................. 306
Wear Indicators ....................................... 303
Winter..................................................... 306
Tonneau Cover......................................... 140
Tools.......................................................... 318
Towing a Trailer....................................... 231
Equipment and Accessories ..................... 232
Load Limits .............................................. 231
Towing Your Vehicle................................ 235
Behind a Motorhome .............................. 235
Emergency .............................................. 338
TPMS (Tire Pressure Monitoring
System).................................................... 251
Indicator............................................ 73, 334
Transmission............................................. 243
Automatic ............................................... 243
Fluid ........................................................ 284
Number................................................... 344
Shift Lever Position Indicator.............. 69, 244
Trip Meter................................................... 79
Troubleshooting....................................... 317
Blown Fuse...................................... 335, 336
Brake Pedal Vibrates .................................. 19
Buzzer Sounds When Opening Door.......... 20
