automatic transmission HONDA CR-Z 2011 1.G Technology Reference Guide

Default Lock\bUnlock Setting
Default Lock Setting
All doors and hatch are preset to
lock when your vehicle reaches
about 1\f mph.
Programmable Auto Door Lock\bUnlock Settings
Below are the different programmable options you can choose. See your owner's
manual for additional instructions on programming these settings.
Default Unlock Setting
Only the driver’s door and hatch
are preset to unlock when you shift
into Park (P)
*.
23
AUTO DOOR UNLOCK
Auto Unlock
(all doors and hatch)
When you turn
the ignition OFFWhen you shift into Park*
Auto Unlock
(only driver’s door andhatch)
When you turn
the ignition OFFWhen you shift into Park*
Turn off
Auto Unlock
Operate manually
AUTO DOOR LOCK
Auto Lock
When you
reach 1\f mphWhen you shift out of Park*
Turn off
Auto Lock
Operate manually
Modifying the Auto Door Unlock Setting
Press either Info (/) button to toggle to the “Customize Settings” display on the
MID\b then pressSEL/RESET to activate the menu.
1. Select “CHG SETTING.”
CHG SETTING
2.Select “DOOR SETUP.”
3. Select “AUTO DOOR UNLOCK.” 4.
Select “SHIFT TO P” (or “IGN OFF”
for manual transmission).
6. Select “EXIT” to save the setting and
exit the menu.
*In manual transmission vehicles, when you turn the ignition to LOCK (\b).
* Does not apply to manual transmission vehicles.
A U T O D O O R L O C K S
Program how and when the vehicle doors automatically lock and unlock.
F U E L F I L L D O O R
Opening and Closing the Fuel Fill Door
To open\b push and release the fuel
door in the area shown until you
hear a click and it pops open.To close\b pushthe fuel door flush
with the body.
Easytoopen fuel door keeps your fuel cap covered.
5. Select “ALL DOORS.”
11 CRZ TRG\fATG_NEW STYLE 4/15/2010 9\f58 AM Page 3

1213
AUTO IDLE STOP
Under certain conditions\b the Auto Idle Stop system shuts the engine off at a stop in
order to maximize fuel efficiency. Idle stop duration may vary depending on the
outside humidity.
How It Works
Manual Restart Assist*
While driving\b the
engine is on. A U T O M A T I C T R A N S M I S S I O N
While at a stop\b
with the brake
pedal pressed\b the
engine turns off. When you take your
foot off the brake
pedal\b the engine
turns back on.
Note: Auto Idle Stop only functions if you come to a stop while driving with the
transmission in D or N position.
While driving\b the
engine is on. M A N U A L T R A N S M I S S I O N
While at a stop
with the brake
pedal pressed and
the transmission
in neutral\b the
engine turns off. When you take
your foot off the
brake pedal and
fully depress the
clutch\b the engine
turns back on.
Paddle Modes
P A D D L E S H I F T I N G *
While in the D position\b 7Speed Manual Shift Mode allows you to manually shift your
vehicle’s speeds up or down. Useful for engine braking or when driving in hilly terrain
or cornering.
If this message appears on the MID\b make sure the clutch
pedal is fully depressed to restart the engine.
*in manual transmission vehicles *in automatic transmission vehicles
Pull
() to shift down. Pull(
+ ) to shift up.
DECELERATESTOPRESTART
NORMAL or ECON Mode
•
Pull (+) or () to temporarily switch from
automatic to manual shift mode.
• The speed number is displayed on the shift indicator display.
• When the vehicle’s speed is constant\b the mode returns to automatic.
SPORT Mode
•Pull (+) or () to switch to manual shift mode.
• The M indicator and speed number are displayed on the shift indicator display.
• Pull (+) or () to change transmission speeds.
• Pull and hold (+) to cancel this mode.
L (Low) Mode
•Pull and hold (+) and () at the same time
until L is displayed on the shift indicator display.
• Use this mode to get higher torque when climbing steep hills.
• Pull and hold again to cancel this mode.
11 CRZ TRG\fATG_NEW STYLE 4/15/2010 10\f00 AM Page 8
