lock HONDA CR-Z 2012 1.G Owners Manual

Contents
This owner’s manual should be considered a permanent part of the
vehicle and should remain with the vehicle when it is sold.
This owner’s manual covers all models of your vehicle. You may find
descriptions of equipment and features that are not on your
particular model.
Images throughout this owner’s manual (including the front cover)
represent features and equipment that are available on some, but
not all, models. Your particular model may not have some of these features.
This owner's manual is for vehicles sold in the United States and Canada.
The information and specifications included in this publication were
in effect at the time of approval for printing. Honda Motor Co., Ltd.
reserves the right, however, to discontinue or change specifications
or design at any time without notice and without incurring any
obligation.2 Safe Driving P. 29
For Safe Driving P. 30 Seat Belts P. 34 Airbags P. 41
2Instrument Panel P. 67
Indicators P. 68 Gauges and Multi-Information Display P. 81
2Controls P. 97
Setting the Clock P. 98 Locking and Unlocking the Doors P. 99
Operating the Switches Around the Steering Wheel P. 109
Interior Lights/Interior Convenience Items P. 124
2Features P. 135
Audio System P. 136 Audio without Navigation System P. 141
General Information on the Audio System P. 169
2Driving P. 191
Before Driving P. 192 Towing a Trailer P. 197
Refueling P. 232 Fuel Economy P. 235
2Maintenance P. 237
Before Performing Maintenance P. 238 Maintenance Minder ™
P. 241
Checking and Maintaining Wiper Blades P. 266
Climate Control System Maintenance P. 280
2 Handling the Unexpected P. 285
Tools P. 286 If a Tire Goes Flat P. 287
Overheating P. 297 Indicator, Coming On/Blinking P. 299
2Information P. 311
Specifications P. 312 Identification Numbers P. 314
Emissions Testing P. 317 Warranty Coverages P. 319
Main Menu2012 CR-Z Online Reference Owner's Manual

Visual Index
4
Quick Reference Guide
❙Passenger's Front Airbag (P 44)❙Driver's Front Airbag (P 44)
❙Driver’s Door Lock Switch (P 102)
❙Door Mirror Controls (P 118)
❙Hood Release Handle (P 246)
❙Interior Fuse Box (P 305)
❙Power Door Lock Master Switch (P 102)
❙Power Window Switches (P 107)
❙Shift Lever
Automatic Transmission (CVT)
(P 203) Manual Transmission (P 208)
❙Glove Box (P 125)
❙Auxiliary Input Jack (P 138)
❙Center Pocket
❙USB Adapter Cable (P 127)
❙Accessory Power Socket
(P 127)
❙Parking Brake (P 220)

Visual Index
6
Quick Reference Guide
❙Maintenance Under the Hood (P 245)
❙Windshield Wipers (P 113, 266)
❙Door Lock/Unlock
Control (P 100)
❙Headlights
(P 110, 258)
❙Front Turn Signal/Parking/
Side Marker Lights (P 110, 262)
❙Tires
(P 269, 287)
❙Fog Lights *
(P 112)❙Rear License Plate Light (P 265)
❙Brake/Taillights
(P 264)
❙Back-Up Lights (P 263)
❙Rear Turn Signal Lights (P 263)
❙Rear Side Marker Lights (P 264)
❙High-Mount Brake Light (P 265)
❙How to Refuel
(P 233)
❙Rear Wiper (P114,268)
❙Opening/Closing the Hatch (P 104)
❙Hatch Release
(P104)
❙Side Turn Signal Lights (P 110, 262)
❙Door Mirrors
(P 118)

9
Quick Reference GuideDrive Cycle Score/Lifetime Points ●Comes on when the ig nition switch is in LOCK
(0.
Real Time Score (re presents your current trip) (P86)
● Each time you turn the ignition switch to ON
(w, the Eco Guide screen starts withou t any leaves on the plants. Leaves accumulate
or diminish based on your driving style during the current trip.
Eco Guide Feedback with Eco Drive Bar (P87)
● Keep the bar from extending
too much to the left or right
side. The shorter the bar is
while driving, the higher the
fuel economy becomes.
Advancing to Second Stage
Advancing to Third Stage
Receding to Second Stage
Receding to First Stage Drive Cycle Score
Lifetime Points
The bar extends to
the right when you
press the accelerator pedal.
The bar extends to
the left when you
press the brake pedal.Slow, steady acceleration/
Maximizes fuel economy
Slow deceleration/
Maximizes fuel economy
Moderate de
celeration
Moderate a
cceleration Aggressive/Inconsistent
acceleration
Aggressive deceleration
First Stage
Second StageThird Stage
* Not available on all models

14
Quick Reference Guide
Instrument Panel (P67)
Tachometer
CHRG/ASST Indicators
IMA Battery Charge Level Indicator
Shift Up/Down Indicator *Multi-Information
Display
7-Speed Manual Shift Mode Indicator
*
System Indicators
Lights Reminders
Instant Fuel
Economy GaugeSpeedometer
Fuel Gauge
Security Alarm
System Indicator
Shift Lever
Position Indicator
Gauges
(P81)/Multi-Information Display (P83)/System Indicators (P68)
Ambient Meter
System Indicators System Indicators
System IndicatorsLights On Indicator
High Beam Indicator
Fog Light Indicator *
Malfunction
Indicator Lamp
Low Oil Pressure Indicator
12 Volt Battery
Charging System Indicator
Anti-lock Brake
System (ABS) Indicator
Vehicle Stability Assist (VSA
®) System
Indicator
VSA ® OFF Indicator
Turn Signal and
Hazard Warning
Indicators
Electric Power Steering (EPS) Indicator
Immobilizer System Indicator
IMA System Indicator
Auto Idle Stop
Indicator
Seat Belt Reminder
Indicator
Parking Brake and
Brake System
Indicator
Supplemental
Restraint System
Indicator
Side Airbag Off
Indicator
Low Tire Pressure/
TPMS Indicator
U.S. models only
Door/Hatch Open
Indicator
Cruise Main Indicator
Cruise Control
Indicator
System Message
Indicator
High Temperature Indicator
Low Temperature Indicator
SPORT Mode
Indicator
NORMAL Mode
Indicator
ECON Mode
Indicator Low Fuel Indicator

15
Quick Reference Guide
Controls (P97)
Turn Signals (P110)
Lights (P110)
Turn Signal Control Lever
Right
Left
Light Control Switches
Low Beam High Beam
Flashing Wipers and Washers
(P113)
Wiper/Washer Control Lever
Adjustment Ring: Long Delay
: Short Delay
MIST
OFF
INT: Low speed with intermittent
LO: Low speed wipe
HI: High speed wipe Pull toward you to spray
washer fluid.
Steering Wheel
(P117)
● To adjust, pull the adjustment lever
towards you, adjust to the desired
position, then lock the lever back in place.
* Not available on all models

16
Quick Reference Guide
Hatch (P104)
● With the doors unlocked, press the hatch
release button on the hatch to open it.
Door Mirrors (P118)
● With the ignition switch in ON
(w, move
the selector switch to L or R.
● Push the appropriate edge of the
adjustment switch to adjust the mirror.
Selector Switch
Adjustment Switch
Power Windows (P107)
● With the ignition switch in ON
(w, open
and close the power windows.
● If the power window lock button is in the
OFF position, the passenger's window can
be opened and closed with its own switch.
● If the power window lock button is in the
ON position, the passenger's window
switch is disabled.
Power Window Lock Button
Window Switch
Clock (P98)
a Press the FM/AM button until you hear
a beep. The displayed time begins flashing.
b Press the
(1 (Hour) or (2 (Minute)
button to set the time. Press the
(3
(Reset) button to set the time to the nearest hour.
c Press the FM/AM button again to set the time.
The navigation system receives signals from
GPS satellites, updating the clock
automatically.
Models without navigation system
Models with navigation system

20
Quick Reference Guide
Driving (P191)
Manual Transmission (P208)
Automatic Transmission (CVT)
(P203) ● Shift to
(P and depress the brake pedal when
starting the engine.
● Shifting 7-Speed Manual Shift Mode
(P205)
● Allows you to manually shift the transmission up or down without
removing your hands from the steering wheel.
●Pulling a paddle shifter changes the
mode from automatic transmission (CVT)
to 7-speed manual shift mode. The
(M
indicator and the selected speed number
are displayed in the shift indicator.
● Pulling a paddle shifter temporarily
changes the mode from automatic
transmission (CVT) to 7-speed manual
shift mode. The selected speed number is
displayed in the shift indicator.
L (Low) Mode (P207)
● Use Low to get more power when
climbing steep hills.
● Pull the
(+ and (- paddle shifters at the
same time until the shift indicator display
changes to “L”.
SPORT Mode
NORMAL Mode/ECON Mode
(
M Indicator
Shift Indicator
Shift Down
(-
Paddle Shifter Shift Up (+

Paddle Shifter
Ignition Switch
Release
ButtonShift Lever
Park
Turn off or start the engine.
Transmission is locked.
Reverse
Neutral
Transmission is not locked.
Drive
Normal driving.
7-speed mode can be used.
L mode is available.
Depress the brake pedal
and press the release button to move out of
(P.
Move the shift lever
without pressing the
release button.
Press the release button to
move the shift lever.

22
Quick Reference Guide
Maintenance (P237)
Under the Hood (P245)
● Check engine oil, engine coolant, and window washer fluid. Add when necessary.
● Check transmission fluid (CVT).
● Check brake fluid and clutch fluid.
● Check the 12 volt battery regularly.
a Pull the hood release handle under the corner of the
dashboard.
b Locate the hood latch lever, pull the lever up, and lift up
the hood.
c When finished, close the hood and make sure it is firmly
locked in place.
Lights (P258)
● Inspect all lights regularly.
Wiper Blades
(P266)
● Replace blades if they leave streaks
across the windshield.
Tires (P269)
● Inspect tires and wheels regularly.
● Check tire pressures regularly.
● Install snow tires for winter driving.

24
Quick Reference Guide
What to Do If
The ignition switch does
not turn from
(0 to (q.
Why?
● The steering wheel may be locked.
● Try to turn the steering wheel left and
right while turning the ignition key.
The ignition switch does
not turn from
(q to (0 and
I cannot remove the key.
Why?
The shift lever s hould be moved to (P on
the automatic transmission (CVT) model.
Why does the brake pedal
pulsate slightly when
applying the brakes?This can occur when the ABS act ivates, and does not indicate a
problem. Apply firm, steady pressure on the brake pedal. Never
pump the brake pedal.
Why do the doors lock
after I unlocked the doors
using a remote
transmitter?If you do not open the doors within 30 seconds, the doors are
relocked automatically for security.
