technical specifications HONDA ELEMENT 2009 1.G Owners Manual

2009 Element Online Reference Owner's Manual
Contents

Owner's Identification Form

Introduction .......................................................................................................................................................... i A Few Words About Safety .............................................................................................................................. iii Important Handling Information .................................................................................................................... iv
Your Vehicle at a Glance (main controls) .................................................................................................... 3
Driver and Passenger Safety (seat belts, SRS, and child protection) .................................................... 5
Instruments and Controls
(indicators, gauges, dashboard, and steering column)
............................................ 55
Features (
heating and cooling, audio, steering wheel, cruise control and other convenience items
)
................... 103
Before Driving (fuel, vehicle break- in, and cargo loading) ..................................................................... 197
Driving (engine and transmission operation) ................................................................................................ 213
Maintenance (minder, fluid checking, minor services, and vehicle storage)........................................... 241
Taking Care of the Unexpected (flat tire, dead battery, overheating, and fuses) ............................. 281
Technical Information (vehicle specifications, tires, and emissions controls) ....................................... 305
Warranty and Customer Relations (U. S. and Canada only) (warranty and contact information) ... 321
Index ........................................................................................................................................................................ I


Service Information Summary ( fluid capacities and tire pressures)
1 00X31-SCV-6600

The diagrams in this section give you
the dimensions and capacities of
your vehicle and the locations of the
identification numbers. It also
includes information you should
know about your vehicle's tires and
emissions control systems.Identification Numbers
...............
306
Specifications
..............................
308
DOT Tire Quality Grading (U.S. Vehicles)
.............................
311
Uniform Tire Quality Grading
...............................
311
Treadwear
...............................
311
Traction
..................................
311
Temperature
...........................
312
Tire Labeling
..............................
313
Tire Pressure Monitoring System
(TPMS) －Required Federal
Explanation
.........................
314
Emissions Controls
.....................
316
The Clean Air Act
....................
316
Crankcase Emissions Control System
................................
316
Evaporative Emissions Control
System
................................
316
Onboard Refueling Vapor
Recovery
.............................
316
Exhaust Emissions
Controls
..............................
317 Three Way Catalytic
Converter
................................
318
Emissions Testing
.......................
319
Technical Information
305
Technical Information
2009 Element

CapacitiesFuel tank Approx.
15.9 US gal (60 L)
Engine oil Change
ꭧ 1
Including filter 4.4 US qt (4.2 L)
Without filter 4.2 US qt (4.0 L)
Total 5.6 US qt (5.3 L)
Capacities
Engine
coolant Automatic
Transmission
Change
ꭧ2
1.35 US gal (5.1 L)
Total 1.90 US gal (7.2 L)
Manual
Transmission Change
ꭧ2
1.37 US gal (5.2 L)
Total 1.93 US gal (7.3 L)
Automatic
transmission
fluid Change
4WD 2.6 US qt (2.5 L)
2WD 2.7 US qt (2.6 L)
Total 4WD 7.6 US qt (7.2 L)
2WD 7.4 US qt (7.0 L)
Manual
transmission
fluid Change
2.0 US qt (1.9 L)
Total
4WD 2.4 US qt (2.3 L)
2WD 2.3 US qt (2.2 L)
Rear
differential
fluid (4WD) Change
1.1 US qt (1.0 L)
Total 1.3 US qt (1.2 L)
Windshield washer reservoir 4.8 US qt (4.5 L)
ꭧ1: Excluding the oil remaining in the engine
ꭧ2: Including the coolant in the reserve tank and that remaining in the engine
Reserve tank capacity:
0.15 US gal (0.55 L)
Specifications
309
Technical Information
2009 Element

How Your Side Curtain AirbagsWork
....................................
30
SRS Indicator
.........................
31,59
START (Ignition Key Position).....
79
Starting the Engine
....................
216
In Cold Weather at High Altitude
................................
216
With a Dead Battery
................
291
State Emissions Testing
.............
319
Steam Coming from Engine
.......
293
Steering Wheel Adjustment
...............................
74
Anti-theft Column Lock
............
79
Buttons
...........................
191,193
Stereo Sound System
.................
109
Storing Your Vehicle
..................
278
Sun Visor
...................................
100
Supplemental Restraint System
..............................
9,22
Servicing
..................................
33
SRS Indicator
......................
31,59
System Components
................
22
Synthetic Oil
..............................
252 T
Tachometer
..................................
64
Tailgate
........................................
82
Open Indicator
.........................
61
Opening the
.............................
82
Taillights, Changing Bulbs in
.....
266
Taking Care of the
Unexpected
............................
281
Technical Descriptions DOT Tire Quality Grading (U.S. Vehicles)
.............................
311
Emissions Control Systems
.....
316
Three Way Catalytic Converter
............................
318
Tire Pressure Monitoring System (TPMS) －Required Federal
Explanation
......................
314
Temperature Gauge
.....................
67
Tensioners, Seat Belts
..................
20
Tether Anchorage Points
.............
48
Theft Protection, Radio
..............
188
Three Way Catalytic Converter
...............................
318
Tilt the Steering Wheel
................
74 Time, Setting the
........................
189
Tire Chains
................................
276
Tire, How to Change a Flat
........
283
Tire Information
.........................
313
Tire Labeling
..............................
313
Tire Pressure Monitoring System (TPMS)
...........................
227,314
Tires
..........................................
271
Air Pressure
............................
272
Chains
.....................................
276
Checking Wear
.......................
273
Compact Spare
........................
282
DOT Tire Quality Grading (U.S. Vehicles)
.............................
311
Inflation
...................................
271
Inspection
...............................
273
Labeling
..................................
313
Low Tire Pressure Indicator
........................
62,227
Maintenance
...........................
274
Pressure Monitoring System
...
227
Replacing
................................
274
Rotating
..................................
274
Snow
.......................................
275
Specifications
..........................
310
CONTINUED
Index
IX
INDEX
2009 Element
