display HONDA ELEMENT 2010 1.G Technology Reference Guide

Indicators/InfoDisplay/TPMS
Instrument Panel Indicators
Indicators briefly appear with each engine start. Red and amber indicators are most critical. Blue and green indicators are used for general information.
DRL
ABS (anti-lock brake system)
DRL (daytime running lights)
Malfunction lamp (check engine light)
TPMS (tire pressure monitoring system)
VSA (vehicle stability assist)
Malfunction Indicators:If an indicator remains on, there may be a problem; see your dealer.
Charging system
Low oil pressure
SRS (supplemental restraint system)
Low brake fluid
10 Element TRG_Inside Front:Inside Cvr 8/24/2009 2:46 PM Page 1
2010 Element

Information DisplayConsists of several displays that provide you with useful information.
When you start the engine, the information display shows your last active selection from theprevious drive cycle.
To toggle between the different displays, pressand releasethe select/reset knob repeatedly.
Information DisplaysAccessing the Information Display
Oil life, Outside temperature*
Trip B, Outsidetemperature*
Trip A, Outsidetemperature*
Odometer, Outsidetemperature*
* if equipped
10 Element TRG_1ab:ExtraPages.qxd 8/26/2009 10:24 AM Page b1
2010 Element

Indicators/InfoDisplay/TPMS
Tire Pressure Monitoring System (TPMS)
Each tire valve stem contains a TPMS sensor.
When the tire pressure drops significantly below recommended levels,the low tire pressure indicator comes on.
Visually inspectthe tires and usea tire air pressuregauge to check which tire(s) have low pressure.
How It WorksWhat to Do
Inflatethe tire(s) to the recommended pressureslisted on the label on the driver’s doorjamb.
INSPECT
Monitors the vehicle’s tire pressures.
and
10 Element TRG_Base:Base 8/26/2009 10:23 AM Page 2
2010 Element

Navigation(if equipped)
Say “City” (or “Change state” if necessary).
Say “Display menu.”1
Say “Address.”2
3
A list of city names appears. Say the number listed next to the city you want to select.
Say the street name. Do not include the direction (N, S, E, W) or type (St., Ave., Blvd., etc.).
4
6
Say the name of the city you want, or say “Current city” to select the city currently shown.
5
A list of street names appears. Say the number listed next to the street you want to select.
Say the entire street address number. For example, “1-2-5-0.”
7
8
The system calculates the route and displays the “Calculate route to” screen. Say “OK” to set the route.
9
Entering a Destination Using Voice Commands
Press and release the NAVI Talk button before you give a command.
Note:Entering destinations can also be done manuallyfrom the Menu screen.
10 Element TRG_3abc:ExtraPages.qxd 8/24/2009 2:47 PM Page a3
2010 Element

1. Say“Find nearest ATM.”
2. A list of the nearest ATMs aredisplayed by shortest distance to destination.
3. Saythe number you want to select.
4. The system calculates the route anddisplays the “Calculate route to” screen.Say“OK”to set the route.
Press and release the NAVI Talk button before you give a command.
Entering a Destination Using the “Find Nearest” Command Try these simple steps to find a nearby point of interest, such as a gas station, movie theater, restaurant, etc.
10 Element TRG_3abc:ExtraPages.qxd 8/24/2009 2:47 PM Page b3
2010 Element

Commonly Used Voice Commands
Here are some examples of commonly used voice commands. Try some of these to familiarize yourself with the voice command system.
Press and release the NAVI Talk button before you give a command.
Look for Restaurants in Your Location
Saya command like “Display restaurant”to seerestaurant icons appear on the map.
Make Audio Selections
Saya command like “Radio 97.1 FM”or “CD playtrack 5”to select that station or song.
Get Estimated Distance to Destination
After a destination is entered,say“How far todestination?”to hear the remaining distance.
Adjust the System Volume
Say“Display setup” then “Volume up” to increasethe volume of the system voice response.
10 Element TRG_3abc:ExtraPages.qxd 8/24/2009 2:47 PM Page c3
2010 Element

Commonly Used Voice Commands (continued)
Navigation Commands(Accepted on Map screenafter a destination is entered)
• How long/far to the destination? • Display destination• Display entire route
• Find nearest:- ATM - gas station- Mexican restaurant- post office
- bank- Honda dealer- airport- hospital
Display Commands(Accepted on Map screen)
• Display (or hide):- ATM- gas station- restaurant- post office
• Display north up/heading up• Zoom in/out• Go home• Display currentlocation
• Display map• Display menu• Setup
• Information• Display audio screen• What time is it?
Press and release the NAVI Talk button before you give a command.
General Commands(Accepted on most screensto change displays)
Find Place Commands(Accepted on Map screen)
10 Element TRG_3abc:ExtraPages.qxd 8/24/2009 2:47 PM Page d3
2010 Element

AudioComponents
Connecting and Beginning Play
1. PressOPEN.
PC Card Instructions (models with navigation)
2. If necessary, insertyour PC card into a PCcard adapter.4. PressAUDIO to show the audio display. Usethe |

and |buttons to skip throughtracks on the card.
3. Insertthe PC card into the slot and pressCLOSE.
CLOSE Button
PC cardslot
