The vehicle's fuses are located in two
fuse boxes. The under-hood fuse box
is located in the engine compartment
on the driver's side. To open it, push
the tabs as shown.
The interior fuse box is underneath
the steering column. To remove the
fuse box lid, turn the knobs
clockwise and pull the lid out of its
hinges.Checking and Replacing Fuses
If something electrical in your
vehicle stops working, check for a
blown fuse first. Determine from the
chart on pages 242 and 243, or the
diagram on the fuse box lid, which
fuse or fuses control that device.
Check those fuses first, but check all
the fuses before deciding that a
blown fuse is the cause. Replace any
blown fuses, and check if the device
works.
1. Turn the ignition switch to the
LOCK (0) position. Make sure the
headlights and all other
accessories are off.
2. Remove the cover from the fuse box.
UNDER-HOOD
TAB
INTERIOR
KNOBS
CONTINUED
Fuses
239
Taking Care of the Unexpected
10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu

INTERIOR FUSE BOXNo.Amps. Circuits Protected1 － Not Used
2 10 A Rear Accessory Power Socket
3 10 A Daytime Running Lights/ TPMS
4 10 A ACG
5 － Not Used
No. Amps.
Circuits Protected6 7.5 A Power Window Relay
7 20 A AMP
ꭧ
8 7.5 A Accessory, Radio
9 10 A Rear Wiper
10 7.5 A Meter
11 － Not Used
No. Amps.
Circuits Protected12 7.5 A Daytime Running Lights
13 10 A SRS
14 10 A Remote Control Mirrors
15 20 A LAF Heater
16 15 A Ignition Relay
17 15 A Fuel Pump
18 15 A Front Accessory Power
Socket
19 7.5 A Turn Signal Lights
20 20 A Front Wiper
21 － Not Used
22 20 A Passenger's Power Window
23 20 A Driver's Power Window
24 － Not Used
25 － Not Used
ꭧ : If equipped
Fuse Locations24210/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu

If your vehicle needs to be towed, call
a professional towing service or
organization. Never tow your vehicle
with just a rope or chain. It is very
dangerous.On 4WD modelsThe only way you can safely tow
your vehicle is with flat-bed
equipment.The operator will load
your vehicle on the back of a truck.
Any other method of towing will
damage the drive system. When you
contact the towing agency, inform
them a flat-bed is required.Towing with only two tires on the
ground will damage parts of the 4WD
system. It should be transported on a f
lat-bed truck or trailer.
On 2WD modelsThere are two ways to tow your
vehicle:Flat-bed Equipment
－ The operator
loads your vehicle on the back of a
truck. This is the best way to
transport your vehicle.
Wheel-lift Equipment
－ The tow
truck uses two pivoting arms that go
under the front tires and lift them off
the ground. The rear tires remain on
the ground. This is an acceptable
way to tow your vehicle. If, due to damage, your vehicle must
be towed with the front wheels on
the ground, do this:
●Start the engine.●Shift to D position and hold for 5
seconds, then to N.●Turn off the engine.●Leave the ignition switch in the
ACCESSORY (I) position so the
steering wheel does not lock.●Release the parking brake.Improper towing preparation will
damage the transmission. Follow the
above procedure exactly. If you cannot
shift the transmission or start the
engine, your vehicle must be
transported with the all four wheels off
the ground.
Emergency Towing24410/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu

With the front wheels on the ground,
it is best to tow the vehicle no farther
than 50 miles (80 km), and keep the
speed below 35 mph (55 km/h).The steering system can be damaged if
the steering wheel is locked. Leave the
ignition switch in the ACCESSORY (I)
position, and make sure the steering
wheel turns freely before you begin
towing.
Emergency Towing
245
Taking Care of the Unexpected
10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu

Exhaust Emissions Controls
The exhaust emissions controls
include three systems: PGM-FI,
ignition timing control, and three
way catalytic converter. These three
systems work together to control the
engine's combustion and minimize
the amount of HC, CO, and NOx that
comes out the tailpipe. The exhaust
emissions control systems are
separate from the crankcase and
evaporative emissions control
systems.
PGM-FI SystemThe PGM-FI system uses sequential
multiport fuel injection. It has three
subsystems: air intake, engine
control, and fuel control. The
powertrain control module (PCM)
uses various sensors to determine
how much air is going into the
engine. It then controls how much
fuel to inject under all operating
conditions.Ignition Timing Control SystemThis system constantly adjusts the
ignition timing, reducing the amount
of HC, CO, and NOx produced.Three Way Catalytic ConverterThe three way catalytic converter is
in the exhaust system. Through
chemical reactions, it converts HC,
CO, and NOx in the engine's exhaust
to carbon dioxide (CO
2), nitrogen
(N
2), and water vapor. Replacement Parts
The emissions control systems are
designed and certified to work
together in reducing emissions to
levels that comply with the Clean Air
Act. To make sure the emissions
remain low, you should use only new
Honda replacement parts or their
equivalent for repairs. Using lower
quality parts may increase the
emissions from your vehicle.
The emissions control systems are
covered by warranties separate from
the rest of your vehicle. Read your
warranty manual for more
information.
Emissions Controls
259
Technical Information
10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu

A
Accessories andModifications
..........................
149
ACCESSORY (Ignition Key Position)
...................................
79
Accessory Power Sockets
..........
100
Additives, Engine Oil
.................
194
Adjusting the Steering Wheel
......
74
Advanced Airbags
........................
26
Airbag (SRS)
............................
9, 22
Air Conditioning System
............
104
Air Pressure, Tires
..............
212, 213
Alcohol in Gasoline
....................
142
Antifreeze
...................................
196
Anti-lock Brakes (ABS) Indicator
............................
59, 168
Operation
................................
167
Anti-theft, Audio System
.............
132
Anti-theft Steering Column Lock
.........................................
79
Audio System
.............................
109
Automatic Seat Belt Tensioners...
20
Automatic Speed Control
...........
137 Automatic Transmission
............
161
Capacity, Fluid
........................
251
Checking Fluid Level
..............
198
Shifting
...................................
161
Shift Lever Position Indicators
............................
161
Shift Lever Positions
...............
161
Shift Lock Release
...................
163
Auxiliary Input Jack
...................
136
B
Battery Charging System
Indicator
........................
58, 235
Jump Starting
..........................
231
Maintenance
...........................
218
Specifications
..........................
252
Before Driving
...........................
141
Belts, Seat
................................
8, 18
Beverage Holders
........................
99
Booster Seats
...............................
50
Brakes
Anti-lock Brakes (ABS)
...........
167
Break-in, New Linings
.............
142 Bulb Replacement
...................
206
Fluid
.......................................
199
Parking
....................................
94
System Design
........................
166
System Indicator
...............
58, 237
Wear Indicators
.......................
167
Braking System
..........................
166
Break-in, New Vehicle
................
142
Brightness Control, Instruments
..............................
72
Bulb Replacement Back-up Lights
........................
206
Brake Lights
...........................
206
Daytime Running Lights
.........
203
Front Parking/Turn Signal Lights
..................................
204
Front Side Marker Lights
........
206
Headlights
..............................
202
High-mount Brake Light
.........
208
Rear Bulbs
..............................
206
Rear License Plate Lights
........
207
Side Turn Signal Lights
...........
204
Specifications
..........................
252
Taillights
.................................
206
Turn Signal Lights
..........
204, 206
CONTINUED
Index
I
INDEX
10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu

I
Identification Number,Vehicle
...................................
248
Ignition Keys
.........................................
75
Switch
......................................
79
Immobilizer System
.....................
76
Important Safety Precautions
.........
6
Indicators, Instrument Panel
........
57
ABS (Anti-lock Brake)
.......
59, 168
Brake (Parking and Brake System)
.........................
58, 237
Charging System
..............
58, 235
Cruise Control
..........................
60
Cruise Main
.............................
60
Door and Tailgate Open
...........
61
DRL (Daytime Running Lights)
..................................
60
High Beam
...............................
61
Key (Immobilizer System)
.......
60
Lights On
.................................
61
Low Fuel
..................................
61
Low Oil Pressure
..............
58, 235
Low Tire Pressure
.............
62, 169 Maintenance Minder
TM
.....
59, 185
Malfunction Indicator Lamp
.............................
58, 236
Passenger Airbag Off
...............
32
Seat Belt Reminder
.............
18, 58
Side Airbag Off
....................
31, 59
SRS
.....................................
30, 59
TPMS
................................
63, 170
Turn Signal and Hazard Warning
...............................
60
VSA OFF
..................................
62
VSA System
.............................
62
Individual Map Lights
..................
95
Infant Restraint
............................
40
Infant Seats
..................................
40
Tether Anchorage Points
.........
48
Inflation, Proper Tire
..................
212
Recommended Pressures
.......
213
Inside Mirror
...............................
93
Inspection, Tire
..........................
214
Installing a Child Seat
..................
43
Instrument Panel
..........................
57
Instrument Panel Brightness
.......
72
Instruments and Controls
.............
55
Interior Lights
..............................
95
Introduction
...................................
i J
Jacking up the Vehicle
...............
223
Jack, Tire
...................................
223
Jump Starting
.............................
231
K
Keys
.............................................
75
L
Label, Certification
.....................
248
Lane Change, Signaling
...............
71
Lap/Shoulder Belt
.................
14, 19
LATCH Anchorage System
..........
44
Light Control Switch
....................
95
Lights Bulb Replacement
...................
202
Indicator
...................................
57
Interior
.....................................
95
Parking
....................................
71
Turn Signal
..............................
71
Load Limit
..................................
152
CONTINUED
Index
V
INDEX
10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu

LOCK (Ignition Key Position)
......
79
Locks Anti-theft Steering Column
.......
79
Fuel Fill Door
..........................
143
Glove Box
...............................
100
Hatch
.......................................
81
Lockout Prevention
..................
81
Power Door
..............................
80
Tailgate
....................................
82
Low Coolant Level
......................
145
Lower Anchors
.............................
44
Low Fuel Indicator
.......................
61
Low Oil Pressure Indicator
...........................
58, 235
Lubricant Specifications Chart...
251
Luggage, Storing (cargo)
...........
151
M
Maintenance
..............................
183
Main Items and Sub Items
......
188
Minder
....................................
185
Minder Indicator
......................
59
Owner's Maintenance Checks
................................
190 Safety
......................................
184
Malfunction Indicator Lamp
................................
58, 236
Meters, Gauges
............................
64
Methanol in Gasoline
.................
142
Mirrors, Adjusting
........................
93
Modifications
.............................
150
Modifying Your Vehicle
.............
150
N
Neutral Gear Position
.................
162
New Vehicle Break-in
.................
142
NOTICE, Explanation of
................
i
Numbers, Identification
.............
248
O
Octane Requirement, Gasoline
.................................
142
Odometer
.....................................
65
Off-Highway Driving Guidelines
..............................
180
Off-Road Precautions
..................
180 Oil
Change, How to
......................
194
Change, When to
....................
185
Checking Engine
....................
145
Life, Engine
.............................
185
Pressure Indicator
.............
58, 235
Selecting Proper Viscosity Chart
...................................
193
Onboard Refueling Vapor Recovery
................................
258
ON (Ignition Key Position)
..........
79
Opening the Tailgate
....................
82
Outside Mirrors
...........................
93
Outside Temperature Indicator
....
68
Overhead Console
......................
101
Overheating, Engine
..................
233
Owner's Maintenance Checks
....
190
Oxygenated Fuels
......................
142
P
Panel Brightness Control
.............
72
Park Gear Position
.....................
161
Parking
......................................
165
Parking Brake
..............................
94
IndexVI10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu

Seat Belts
.................................
8, 18
Additional Information
.............
18
Advice for Pregnant Women
....
16
Automatic Seat Belt
Tensioners
...........................
20
Cleaning
..................................
209
Lap/Shoulder Belt
..............
14, 19
Maintenance
............................
20
Reminder Indicator and Beeper
.............................
18, 58
System Components
................
18
Use During Pregnancy
.............
16
Wearing a Lap/Shoulder Belt
..................................
14, 19
Seats
............................................
83
Head Restraints
........................
85
Seats, Adjusting the
.....................
83
Sensors Driver's Seat Position Sensor
...
26
Front Passenger's Weight Sensors
................................
26
Impact Sensors
........................
22
Serial Number
............................
248
Service Intervals
.........................
185
Service Manual
..........................
267
Service Station Procedures
........
143 Setting the Clock
........................
133
Shifting the Automatic Transmission
..........................
161
Shift Lever Position Indicators
...
161
Shift Lock Release
......................
163
Side Airbags
.................................
28
How the Side Airbag Off Indicator Works
...................
31
How Your Side Airbags Work..28
Side Curtain Airbags
....................
29
How Your Side Curtain Airbags Work
....................................
29
Side Marker Lights, Bulb Replacement in
.......................
206
Signaling Turns
............................
60
Snow Tires
.................................
217
Sound System
............................
109
Spare Tire
..................................
222
Inflating
...........................
212, 222
Specifications
..........................
252
Spark Plugs
................................
250
Specifications
.............................
250
Speed Control
............................
137
Speed Limiter
.............................
163
Speedometer
................................
64 SRS, Additional Information
.........
22
Additional Safety Precautions
...
33
Airbag Service
..........................
33
Airbag System Components
.....
22
How the Side Airbag Off Indicator Works
...................
31
How the SRS Indicator Works..30
How Your Front Airbags Work
....................................
24
How Your Side Airbags Work..28
How Your Side Curtain Airbags Work
....................................
29
SRS Indicator
.........................
30, 59
START (Ignition Key Position).....
79
Starting the Engine
....................
160
In Cold Weather at High Altitude
................................
160
With a Dead Battery
................
231
State Emissions Testing
.............
261
Steam Coming from Engine
.......
233
Steering Wheel
Adjustment
...............................
74
Anti-theft Column Lock
............
79
Buttons
...........................
135, 137
Stereo Sound System
..........
109, 110
Storing Your Vehicle
..................
219
IndexVIII10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu
