This section explains why it is important
to keep your vehicle well maintained and
how to follow basic maintenance safety
precautions.
This section also includes instructions
on how to read the Maintenance Minder
messages on the information display,
and instructions for simple maintenance
tasks you may want to take care of
yourself.
If you have the skills and tools to
perform more complex maintenance
tasks on your vehicle, you may want to
purchase the service manual. See page
267 for information on how to obtain a
copy, or see your dealer.Maintenance, replacement, or repair
of emissions control devices and
systems may be done by any
automotive repair establishment or
individual using parts that are
‘‘
certified ’’to EPA standards.
Maintenance Safety
.....................
184
Maintenance Minder
TM
...............
185
Fluid Locations
...........................
192
Adding Engine Oil
......................
193
Changing the Engine Oil and Filter
.......................................
194
Engine Coolant
...........................
196
Windshield Washers
...................
197
Automatic Transmission Fluid
....
198
Brake Fluid
.................................
199
Power Steering Fluid
..................
200
Cleaning the Body Panels
...........
201
Lights
..........................................
201
Cleaning the Seat Belts
...............
209
Floor Mats
..................................
209
Dust and Pollen Filter
.................
210
Wiper Blades
..............................
210
Wheels
........................................
212
Tires
...........................................
212
Checking the Battery
..................
218
Vehicle Storage
...........................
219
Maintenance
183
Maintenance
10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu

However, service at a dealer is not
mandatory to keep your warranties in
effect. Maintenance may be done by
any qualified service facility or
person who is skilled in this type of
automotive service. Make sure to
have the service facility or person
reset the display as previously
described. Keep all receipts as proof
of completion, and have the person
who does the work fill out your
Honda Service History. Check your
warranty booklet for more
information.
We recommend using Honda parts
and fluids whenever you have
maintenance done. These are
manufactured to the same high
quality standards as the original
components, so you can be confident
of their performance and durability.According to state and federal
regulations, failure to perform
maintenance on the items marked
with
＃will not void your emissions
warranties. However, all
maintenance services should be
performed in accordance with the
intervals indicated by the information
display.
Owner's Maintenance Checks
You should check the following
items at the specified intervals. If you
are unsure of how to perform any
check, turn to the appropriate page
listed.
●Engine oil level －Check every
time you fill the fuel tank. See page
145.●Engine coolant level －Check the
radiator reserve tank every time
you fill the fuel tank. See page 145.●Automatic transmission －Check
the fluid level monthly. See page
198.
●Brakes －Check the fluid level
monthly. See page 199.●Tires －Check the tire pressure
monthly. Examine the tread for
wear and foreign objects. See page
212.●Lights －Check the operation of
the headlights, parking lights,
taillights, high-mount brake light,
and license plate lights monthly.
See page 201.
Maintenance Minder
TM
19010/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu

ENGINE OIL
FILL CAP
ENGINE OIL
DIPSTICK
(Orange tab)
POWER
STEERING FLUID
(Red cap)
WASHER FLUID
(Blue cap)
ENGINE
COOLANT
RESERVOIR
RADIATOR CAPBRAKE FLUID
(Gray cap)
AUTOMATIC
TRANSMISSION
FLUID DIPSTICK
(Yellow loop)
Fluid Locations19210/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu

Fill the reservoir with a good-quality
windshield washer fluid. This
increases the cleaning capability and
prevents freezing in cold weather.
When you refill the reservoir, clean
the edges of the windshield wiper
blades with windshield washer fluid
on a clean cloth. This will help to
condition them.Do not use engine antifreeze or a
vinegar/water solution in the
windshield washer reservoir. Antifreeze
can damage your vehicle's paint, while
a vinegar/water solution can damage
the windshield washer pump. Use only
commercially-available windshield
washer fluid.Automatic Transmission Fluid
Check the fluid level with the engine
at normal operating temperature.
1. Park the vehicle on level ground.
Start the engine, let it run until the
radiator fan comes on, then shut
off the engine. For accurate
results, wait about 60 seconds (but
no longer than 90 seconds) before
doing step 2.
2. Remove the dipstick (yellow loop)
from the transmission, and wipe it
with a clean cloth.
3. Insert the dipstick all the way intothe transmission securely as
shown in the illustration.
4. Remove the dipstick and check the fluid level. It should be between
the upper and lower marks.
DIPSTICK
UPPER
MARK
LOWER
MARK
Windshield Washers, Automatic Transmission Fluid19810/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu

5. If the level is below the lowermark, add fluid into the dipstick
hole to bring it to the level
between the upper and lower
marks.
Pour the fluid slowly and carefully
so you do not spill any. Clean up
any spill immediately; it could
damage components in the engine
compartment.
Always use Honda ATF DW-1
(automatic transmission fluid).
Use only Honda ATF DW-1 (automatic
transmission fluid). Do not mix with
other transmission fluids.
Using transmission fluid other than
Honda ATF DW-1 may cause
deterioration in transmission operation
and durability, and could result in
damage to the transmission.
Damage resulting from the use of
transmission fluid other than Honda
ATF DW-1 is not covered by the Honda
new vehicle warranty.
6. Insert the dipstick all the way backinto the transmission securely as
shown in the illustration.
The transmission should be drained
and refilled with new fluid according
to the Maintenance Minder ™(see
page 185).
If you are not sure how to add fluid,
contact your dealer. Brake Fluid
Check the fluid level in the brake
fluid reservoir monthly.
Independent of the Maintenance
Minder display, replace the brake
fluid every 3 years.
Always use Honda Heavy Duty
Brake Fluid DOT 3. If it is not
available, you should use only DOT 3
or DOT 4 fluid, from a sealed
container, as a temporary
replacement.
Using any non-Honda brake fluid can
cause corrosion and decrease the life
of the system. Have the brake
system flushed and refilled with
Honda Heavy Duty Brake Fluid DOT
3 as soon as possible.
Brake fluid marked DOT 5 is not
compatible with your vehicle's
braking system and can cause
extensive damage.
CONTINUED
Automatic Transmission Fluid, Brake Fluid
199
Maintenance
10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu

CapacitiesFuel tank Approx.
15.9 US gal (60 L)
Engine oil Change
ꭧ 1
Including filter 4.4 US qt (4.2 L)
Without filter 4.2 US qt (4.0 L)
Total 5.6 US qt (5.3 L)
Capacities Engine coolant Change
ꭧ 2
1.35 US gal (5.1 L)
Total 1.90 US gal (7.2 L)
Automatic
transmission
fluid Change
4WD 2.6 US qt (2.5 L)
2WD 2.7 US qt (2.6 L)
Total 4WD 7.6 US qt (7.2 L)
2WD 7.4 US qt (7.0 L)
Rear
differential
fluid (4WD) Change 1.1 US qt (1.0 L)
Total 1.3 US qt (1.2 L)
Windshield washer reservoir 4.8 US qt (4.5 L)
ꭧ1: Excluding the oil remaining in the engine
ꭧ2: Including the coolant in the reserve tank and that remaining in the engine Reserve tank capacity:
0.15 US gal (0.55 L)
Specifications
251
Technical Information
10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu

A
Accessories andModifications
..........................
149
ACCESSORY (Ignition Key Position)
...................................
79
Accessory Power Sockets
..........
100
Additives, Engine Oil
.................
194
Adjusting the Steering Wheel
......
74
Advanced Airbags
........................
26
Airbag (SRS)
............................
9, 22
Air Conditioning System
............
104
Air Pressure, Tires
..............
212, 213
Alcohol in Gasoline
....................
142
Antifreeze
...................................
196
Anti-lock Brakes (ABS) Indicator
............................
59, 168
Operation
................................
167
Anti-theft, Audio System
.............
132
Anti-theft Steering Column Lock
.........................................
79
Audio System
.............................
109
Automatic Seat Belt Tensioners...
20
Automatic Speed Control
...........
137 Automatic Transmission
............
161
Capacity, Fluid
........................
251
Checking Fluid Level
..............
198
Shifting
...................................
161
Shift Lever Position Indicators
............................
161
Shift Lever Positions
...............
161
Shift Lock Release
...................
163
Auxiliary Input Jack
...................
136
B
Battery Charging System
Indicator
........................
58, 235
Jump Starting
..........................
231
Maintenance
...........................
218
Specifications
..........................
252
Before Driving
...........................
141
Belts, Seat
................................
8, 18
Beverage Holders
........................
99
Booster Seats
...............................
50
Brakes
Anti-lock Brakes (ABS)
...........
167
Break-in, New Linings
.............
142 Bulb Replacement
...................
206
Fluid
.......................................
199
Parking
....................................
94
System Design
........................
166
System Indicator
...............
58, 237
Wear Indicators
.......................
167
Braking System
..........................
166
Break-in, New Vehicle
................
142
Brightness Control, Instruments
..............................
72
Bulb Replacement Back-up Lights
........................
206
Brake Lights
...........................
206
Daytime Running Lights
.........
203
Front Parking/Turn Signal Lights
..................................
204
Front Side Marker Lights
........
206
Headlights
..............................
202
High-mount Brake Light
.........
208
Rear Bulbs
..............................
206
Rear License Plate Lights
........
207
Side Turn Signal Lights
...........
204
Specifications
..........................
252
Taillights
.................................
206
Turn Signal Lights
..........
204, 206
CONTINUED
Index
I
INDEX
10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu

FluidsAutomatic Transmission
.........
198
Brake
......................................
199
Location
..................................
192
Power Steering
........................
200
Windshield Washer
.................
197
FM/AM Radio Reception
...........
130
Folding the Rear Seats
.................
88
Four-way Flashers
........................
73
Front Airbags
...........................
9, 24
Front Seat Adjusting
..................................
83
Fuel
............................................
142
Check Fuel Cap Message
........
66
Economy
.................................
146
Fill Door and Cap
....................
143
Gauge
......................................
66
Low Fuel Indicator
...................
61
Octane Requirement
...............
142
Reserve Indicator
.....................
61
Tank, Filling the
......................
143
Fuel Economy
............................
146
Fuses, Checking the
..................
239 G
Gas Mileage, Improving
.............
147
Gasoline
.....................................
142
Gauge
......................................
66
Low Fuel Indicator
...................
61
Octane Requirement
...............
142
Tank, Refueling
.......................
143
Gas Station Procedures
..............
143
Gauges Engine Coolant Temperature...
67
Fuel
..........................................
66
Odometer
.................................
65
Outside Temperature Indicator
...............................
68
Speedometer
............................
64
Tachometer
..............................
64
Trip meter
................................
66
Gearshift Lever Positions Automatic Transmission
.......................
161
Glove Box
..................................
100
Gross Axle Weight Rating (GAWR)
.................................
174 Gross Vehicle Weight Rating
(GVWR)
..........................
153, 174
H
Halogen Headlight Bulbs
...........
202
Hatch
...........................................
81
Hazard Warning Flashers
............
73
Headlights Aiming
....................................
201
Daytime Running Lights
..........
72
High Beam Indicator
................
61
High Beams, Turning on
..........
71
Lights On Indicator
..................
61
Low Beams, Turning on
...........
71
Reminder Chime
......................
71
Replacing Halogen Bulbs
........
202
Turning on
...............................
71
Head Restraints
............................
85
Heating and Cooling
..................
104
High Altitude, Starting at
............
160
Hood, Opening and Closing the
..........................................
144
Horn
........................................
4, 69
IndexIV10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu

Sun Visor
...................................
100
Supplemental Restraint System
..............................
9, 22
Servicing
..................................
33
SRS Indicator
......................
30, 59
System Components
................
22
Synthetic Oil
..............................
194
T
Tachometer
..................................
64
Tailgate
........................................
82
Open Indicator
.........................
61
Opening the
.............................
82
Taillights, Changing Bulbs in
.....
206
Taking Care of the Unexpected
............................
221
Technical Descriptions DOT Tire Quality Grading (U.S. Vehicles)
.............................
253
Emissions Control Systems
.....
258
Three Way Catalytic Converter
............................
260
Tire Labeling
...........................
255 Tire Pressure Monitoring System
(TPMS) －Required Federal
Explanation
......................
256
Temperature Gauge
.....................
67
Tensioners, Seat Belts
..................
20
Tether Anchorage Points
.............
48
Theft Protection, Radio
..............
132
Three Way Catalytic Converter
...............................
260
Tilt the Steering Wheel
................
74
Time, Setting the
........................
133
Tire Chains
................................
217
Tire, How to Change a Flat
........
223
Tire Information
.........................
255
Tire Labeling
..............................
255
Tire Pressure Monitoring System (TPMS)
...........................
169, 256
Tires
..........................................
212
Air Pressure
............................
213
Chains
.....................................
217
Checking Wear
.......................
214
Compact Spare
........................
222
DOT Tire Quality Grading (U.S. Vehicles)
.............................
253
Inflation
...................................
212
Inspection
...............................
214 Labeling
..................................
255
Low Tire Pressure Indicator
........................
62, 169
Maintenance
...........................
215
Pressure Monitoring System
...
169
Replacing
................................
215
Rotating
..................................
215
Snow
.......................................
217
Specifications
..........................
252
Tools, Tire Changing
.................
223
Towing A Trailer
..................................
174
Emergency Wrecker
...............
244
TPMS (Tire Pressure Monitoring System)
..............................
169
Indicator
............................
63, 170
Required Federal Explanation
.........................
256
Transmission Checking Fluid Level
..............
198
Fluid Selection
........................
198
Identification Number
.............
248
Shifting the Automatic
.............
161
Treadwear
..................................
253
Trip Meter
...................................
66
CONTINUED
Index
IX
INDEX
10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu

Gasoline:
Unleaded gasoline, pump octane
number of 87 or higher.
Fuel Tank Capacity:
15.9 US gal (60 L)
Recommended Engine Oil:
API Premium grade 5W-20
detergent oil (see page 193).
Oil change capacity (including
filter):
4.4 US qt (4.2 L)
Automatic Transmission Fluid:
Honda ATF DW-1 (automatic
transmission fluid) (see page 198).
4WD models onlyRear Differential Fluid:
Honda Dual Pump Fluid II. Do not
use ATF.
Capacity:
1.1 US qt (1.0 L)
Power Steering Fluid:
Honda Power Steering Fluid
preferred, or another brand of
power steering fluid as a
temporary replacement. Do not
use ATF (see page 200).Brake Fluid:
Honda Heavy Duty Brake Fluid
DOT 3 preferred, or a DOT 3 or
DOT 4 brake fluid as a temporary
replacement (see page 199).
Tire Pressure (measured cold):
Front:
33 psi (230 kPa, 2.3 kgf/cm
2)
Rear: 35 psi (240 kPa, 2.4 kgf/cm2)
Spare Tire Pressure: 60 psi (420 kPa, 4.2 kgf/cm2)
Service Information Summary10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu
