HONDA FIT 2007 1.G Owners Manual

Refill the engine with the recom-
mended oil.
Engine oil change capacity
(including f ilter):
Replace the engine oil f ill cap.
Start the engine. The oil pressure
indicator should go out within 5
seconds. If it does not, turn of f the
engine, and check your work.
Let the engine run f or several
minutes, then check the drain bolt
and oil f ilter f or leaks.
Turn of f the engine and let it sit
f or several minutes, then check
the oil level on the dipstick. If
necessary, add more oil.
Remove the oil f ilter, and let the
remaining oil drain. A special
wrench (available from your
dealer) is required. Put a new washer on the drain bolt,
then reinstall the drain bolt.
Tighten the drain bolt to:
Install a new oil f ilter according to
the instructions that come with it. Make sure the oil f ilter gasket is
not stuck to the engine block. If it
is, remove it bef ore installing a
new oil f ilter.
3.
4. 5.
6.
7.
8.
9.
Changing the Engine Oil and Filter
Maint enance
179
OIL FILTER
29 lbf·ft (39 N·m , 4.0 kgf·m)
3.8 US qt (3.6
) Improper disposal of engine oil can be
harmf ul to the environment. If you
change your own oil, please dispose of
the used oil properly. Put it in a sealed
container and take it to a recycling
center. Do not discard it in a trash bin
or dump it on the ground.

If Honda antif reeze/coolant is not
available, you may use another
major-brand non-silicate coolant as a
temporaryreplacement.Makesureit
is a high-quality coolant
recommended f or aluminum engines.
Continued use of any non-Honda
coolant can result in corrosion,
causing the cooling system to
malf unction or f ail. Have the cooling
system f lushed and ref illed with
Honda antif reeze/coolant as soon as
possible.If the reserve tank is completely
empty, you should also check the
coolant level in the radiator.
If the coolant level in the reserve
tank is at or below the MIN line, add
coolant to bring it up to the MAX line.
Inspect the cooling system f or leaks. Always use Honda Long-lif e Anti-
f reeze/Coolant Type 2. This coolant
is pre-mixed with 50 percent
antif reeze and 50 percent water.
Never add straight antifreeze or
plain water.
Engine Coolant
A dding Engine Coolant
180
RESERVE TANK
Removing the radiator cap
while the engine is hot can
cause the coolant to spray out,
seriously scalding you.
Always let the engine and
radiator cool down before
removing the radiator cap.

The coolant level should be up to
the base of the f iller neck. Add
coolant if it is low.
Pourthecoolantslowlyand
caref ully so you do not spill any.
Clean up any spill immediately; it
could damage components in the
engine compartment.Do not add any rust inhibitors or
other additives to your vehicle’s
cooling system. They may not be
compatible with the coolant or
engine components.
Pour coolant into the reserve tank.
Fill it half way between the MAX
and MIN marks. Put the cap back
on the reserve tank.
Make sure the engine and radiator
are cool.
Relieve any pressure in the cooling
system by turning the radiator cap
counterclockwise, without
pressing down.
Remove the radiator cap by
pushing down and turning
counterclockwise. Put the radiator cap back on, and tighten it fully.
3. 4.
2. 1.
5.6.
Engine Coolant
Maint enance
181
RADIATOR CAP
RESERVE TANK

Check the fluid level in the
windshield washer reservoir at least
monthly during normal use.
Check the fluid level by removing
the cap and looking at the level
gauge. The
low washer
level indicator comes on when the
level is low (see page ).
Fill the reservoir with a good-quality
windshield washer f luid. This
increases the cleaning capability and
prevents f reezing in cold weather.
When you ref ill the reservoir, clean
the edges of the windshield wiper
blades with windshield washer f luid
on a clean cloth. This will help to
condition the blade edges. 64On Canadian models:
Windshield Washers
182
LEVEL GAUGE
Do not use engine antif reeze or a
vinegar/water solution in the
windshield washer reservoir. Antif reeze
can damage your vehicle’s paint, while
a vinegar/water solution can damage
the windshield washer pump. Use only
commercially-available windshield
washer f luid.

Check the f luid level with the engine
at normal operating temperature.Park the vehicle on level ground.
Shut of f the engine.
Remove the dipstick (yellow loop)
f rom the transmission, and wipe it
with a clean cloth. Insert the dipstick all the way into
the transmission securely as
shown in the illustration.
If the level is below the lower
mark, add f luid into the f iller hole
to bring it to the upper mark.Pour the f luid slowly and caref ully so
you do not spill any. Clean up any
spill immediately; it could damage
components in the engine
compartment.
Remove the dipstick, and check
the f luid level. It should be
between the upper and lower
marks. Always use Honda ATF-Z1
(automatic transmission f luid). If it’s
not available, you may use a
DEXRON
III automatic
transmission f luid as a temporary
replacement. However, continued
use can affect the shift quality. Have
the transmission f lushed and ref illed
with Honda ATF-Z1 by your dealer
as soon as it is convenient.
1.
2. 3.
5. 4.
CONT INUED
T ransmission Fluid
Automatic Transmission Fluid
Maint enance
183
DIPSTICK
UPPER
MARK
LOWER
MARK

Check the f luid level with the
transmission at normal operating
temperature and the vehicle on level
ground. Remove the transmission
f iller bolt, and caref ully f eel inside
the bolt hole with your f inger. The
f luid level should be up to the edge
of the bolt hole. If it is not, add
Honda Manual Transmission Fluid
(MTF) until it starts to run out of the
hole.Put a new washer on the f iller bolt,
then reinstall the f iller bolt and
tighten it securely.
If Honda MTF is not available, you
may use an SAE 10W-30 or 10W-40
viscosity motor oil with the API
Certif ication seal that says ‘‘FOR
GASOLINE ENGINES’’ as a
temporary replacement. However,
motor oil does not contain the proper
additives, and continued use can
cause stif f er shif ting. Replace as
soon as it is convenient.
Insert the dipstick all the way back
into the transmission securely as
shown in the illustration.
If you are not sure how to add f luid,
contact your dealer.
If you are not sure how to check and
add f luid, contact your dealer.
6.
T ransmission Fluid
Manual Transmission Fluid
184
WASHER
Correct level FILLER BOLT

Manual Transmission only
A low f luid level can indicate a leak
in the clutch system. Have this
system inspected as soon as possible. The f luid level should be between
theMINandMAXmarksontheside
of the reservoir. If it is not, add
brake f luid to bring it up to that level.
Use the same fluid specified for the
brake system.
Check the brake f luid level in the
reservoirs monthly.
Replace the brake f luid according to
the time recommendation in the
maintenance minder schedule.
Always use Honda Heavy Duty
Brake Fluid DOT 3. If it is not
available, you should use only DOT 3
or DOT 4 f luid, f rom a sealed
container, as a temporary
replacement.
Using any non-Honda brake f luid can
cause corrosion and decrease the lif e
of the system. Have the brake
system f lushed and ref illed with
Honda Heavy Duty Brake Fluid
DOT 3 as soon as possible.
Brake f luid marked DOT 5 is not
compatible with your vehicle’s
braking system and can cause
extensive damage.
The f luid level should be between
theMINandMAXmarksontheside
of the reservoir. If the level is at or
below the MIN mark, your brake
system needs attention. Have the
brake system inspected f or leaks or
worn brake pads/shoes.
Brake and Clutch Fluid
Brake Fluid
Clutch Fluid
Maint enance
185
MIN
MAX
MINMAX

Your vehicle has halogen headlight
bulbs. When replacing a bulb, handle
it by its base, and protect the glass
f rom contact with your skin or hard
objects. If you touch the glass, clean
it with denatured alcohol and a clean
cloth.To change the bulb on the driver’s
side, start the engine, turn the
steering wheel all the way to the
right, then turn off the engine. To
change the bulb on the passenger’s
side, turn the steering wheel to the
lef t.
Use a f lat-tip screwdriver to
remove the holding clip f rom the
inner f ender, then pull the inner
f ender cover back.
Theheadlightswereproperlyaimed
when your vehicle was new. If you
regularly carry heavy items in the
cargo area, readjustment may be
required. Adjustments should be
done by your dealer or other
qualif ied mechanic.
1.
2.
Headlight A iming Replacing a Headlight Bulb
Lights
186
HOLDING CLIP
Halogen headlight bulbs get very hot
when lit. Oil, perspiration, or a scratch
on the glass can cause the bulb to
overheat and shatter.

Remove the electrical connector
f rom the bulb by pulling the
connector straight back.
Remove the rubber weather seal
by pulling on the tab.Make sure that the hold-down
wire is installed properly and
securely. You can check its
installation f rom the inspection
window on the headlight assembly. Install the new bulb into the hole,
making sure the tabs are in their
slots. Pivot the hold-down wire
back in place, and clip the end into
the slot.Install the rubber seal over the
back of the headlight assembly.
Push the electrical connector onto
the new bulb. Make sure it is
connected securely. Turn on the
headlights to test the new bulb.
Reinstall the inner f ender cover.
Then reinstall the holding clip, and
lock it in place by pushing on its
center.
Unclip the end of the hold-down
wire f rom its slot. Pivot the wire
out of the way, then remove the
bulb.
5. 6.
3.
4. 7.8.
9.
10.
Lights
Maint enance
187
RUBBER WEATHER SEAL
HOLD-DOWN
WIRE BULB
ELECTRICAL
CONNECTOR
HOLD-DOWN
WIRE
INSPECTION WINDOW

To change the bulb on the driver’s
side, start the engine, turn the
steering wheel all the way to the
right, then turn of f the engine. To
change the bulb on the passenger’s
side, turn the steering wheel to the
lef t.Use a f lat-tip screwdriver to
remove the holding clip f rom the
inner f ender, then pull the inner
f ender cover back.
Reinstall the socket into the light
assembly by turning it clockwise
until it locks.
Pull the bulb straight out of its
socket. Push the new bulb straight
into the socket until it bottoms. Remove the socket by turning it
one-quarter turn counterclockwise. Reinstall the inner f ender cover.
Then reinstall the holding clip, and
lock it in place by pushing on its
center. Turn on the lights to make sure
the new bulb is working.
1. 2.
3.
4.5.
6.
7.
Lights
Replacing a Parking L ight/Front
Side Marker Bulb and a Turn
Signal Light Bulb
188
HOLDING CLIP
PARKING LIGHT/FRONT SIDE MARKER
BULB TURN SIGNAL LIGHT BULB
