engine HONDA FIT 2011 2.G Technology Reference Guide

Malfunction IndicatorsIf an indicator remains on, there may be a problem; see your dealer
On/Off Indicators
Condition IndicatorsAction is needed by driver
PASSENGERAIRBAG
OFFPASSENGER AIRBAG OFF(located on center panel)
SIDE AIRBAGOFF
CRUISE CONTROL on*
VSAOFF*
Fog lights on*
Headlights on
Turn signals/hazards on
High beamson
Charging system
Low brake fluid
Low oil pressure
ABS(anti\block brake system)
DRL(daytime running lights)
Malfunction lamp(check engine light)
VSA*(vehicle stability assist)SRS(supplemental restraint system)
Low temperature
EPS(electronic power steering)
TPMS(tire pressure monitoring system)
Parking brake on:
Release
Door/Tailgate open:
Close door(s)/tailgate
Maintenance MinderTM:
Make dealer appointment
Low fuel:
Refill
* Sport model only
* Sport model only
High temperature:
Slow down or pull over
Low tire pressure:
Add air
INSTRUMENT PANEL INDICATORS
Immobilizer
Flashes: improperly coded key;
use correct key
Briefly appear with each engine start. Red and amber indicators are most critical.
Blue and green indicators are used for general information.
45
CRUISE MAIN on*
Seat belt reminder:
Fasten seat belt(s)
11 Fit TRG\fATG_NEW STYLE 8/3/2010 2\f07 PM Page 4

Accessing the Information Display
Information Displays
I N F O R M A T I O N D I S P L A Y
Consists of several displays that provide you with useful information.
6
Instant MPG,
OdometerInstant MPG,
Trip meter
Oil life
\b
Instant and
average MPG
What to Do
How It Works
TIRE PRESSURE MONITORING SYSTEM (TPMS)
Monitors the vehicle’s tire pressures.
Each tire valve stem contains
a TPMS sensor.
When the tire pressure drops
significantly below recommended
levels, the low tire pressure
indicator comes on.
If the TPMS indicator appears, there
may be a problem with the system.
See your dealer.
\f. Visually inspect the tires for
damage.
2. Use a tire air pressure gauge to
check which tire(s) have low
pressure.
3. Inflate the tire(s), if necessary,
to the recommended pressures
listed on the label on the
driver’s doorjamb.
To toggle between the different
displays, press and release the
select/reset knob repeatedly.When you start the engine, the
display shows your last active
selection from the previous drive
cycle.
11 Fit TRG\fATG_NEW STYLE 8/3/2010 2\f07 PM Page 5

1918
O W N E R L I N K
Owner Link allows you to explore features and technologies specific to your vehicle,
schedule service appointments, obtain and update maintenance and service records,
manage your financial services account, and access other useful information. Register
at www.owners.honda.com to ensure that you continue to enjoy the experience of
owning a Honda.
S A F E T Y R E M I N D E R
Your vehicle is equipped with airbags. Airbags do not replace seat belts; they add to
the protection offered by seat belts. Airbags can help protect you in some types of
collisions, but they do not provide protection in all collisions.
Always make sure you and your passengers wear seat belts, and that young children
are properly secured in a child seat or booster in the rear seat. Never place an infant
seat in the front passenger’s seat as the force of a deploying airbag can seriously
injure an infant.
F U E L R E C O M M E N D A T I O N
• Only use unleaded gasoline of 87 octane or higher.
• Some gasoline in North America contains MMT, a manganese\bbased fuel additive. Prolonged and consistent use of gasoline containing MMT can deteriorate your
vehicle’s performance, fuel economy, and the emission control system. Always use
MMT\bfree gasoline if available. Failures caused by use of gasoline containing MMT
may not be covered under warranty.
• “TOP TIER Detergent Gasoline” meets a new gasoline standard jointly established by leading automotive manufacturers to meet the needs of today's advanced
engines. In most cases, qualifying gasoline retailers will identify their gasoline as
having met “TOP TIER Detergent Gasoline” standards at the retail location. This
fuel is guaranteed to contain the proper level of detergent additives and be free of
metallic additives. This helps avoid build\bup of deposits in your engine and
emission control system. Because the level of detergency and harmful metallic
additives (such as MMT) in gasoline vary in the market, Honda endorses the use
of “TOP TIER Detergent Gasoline” where available to help maintain the
performance and reliability of your vehicle. For more information, visit
www.toptiergas.com.
• For further important information on fuel and lubricants for your car and information on gasoline that does not contain MMT, contact your dealer or visit
Owner Link at www.owners.honda.com.
11 Fit TRG\fATG_NEW STYLE 8/3/2010 2\f09 PM Page 11
