HONDA HR-V 2016 2.G Quick Guide

134 || 135 CUSTOMER INFORMATION SPECIFICATIONS
TABLE OF CONTENTS
INDEX
VISUAL INDEX
VOICE COMMAND
INDEX
SAFETY
INFORMATION
CUSTOMER
INFORMATION
INSTRUMENT PANEL
SPECIFICATIONS
VEHICLE
CONTROLS
MAINTENANCE
AUDIO AND
CONNECTIVITY
HANDLING THE
UNEXPECTED
BLUETOOTH®
HANDSFREELINK®
DRIVING
HONDALINK®
NAVIGATION
Vehicle
Engine and Fuel
Tires
Light Bulbs
Fluids*1: 2WD
*2: AWD
ModelHR-V
No. of Passengers:
Front 2
Rear 3
Total 5
Weights:Gross Vehicle
Weight Rating 4,001 lbs (1,815 kg)*14,166 lbs (1,890 kg)*2Gross Axle Weight
Rating (Front)2,127 lbs (965 kg)*12,178 lbs (988 kg)*2Gross Axle Weight
Rating (Rear)1,873 lbs (850 kg)*11,988 lbs (902 kg)*2Air Conditioning:
Refrigerant Type HFC-134a (R-134a)
Charge Quantity 14.3 - 16.0 oz (405 - 455 g)
Lubricant Type ND-OIL8
Engine Specifications
Fuel
Displacement109.8 cu-in (1,800 cm3)
Spark PlugsNGK DILZKR7B11GS
DENSODXU22HCR-D11S
Fuel:
TypeUnleaded gasoline, Pump octane number
of 87 or higher
Fuel Tank Capacity 13.2 US gal (50 liters)
RegularSize215/55R17 94VPressure
psi (kPa[kgf/cm2])Front32 (220 [2.2])Rear30 (210 [2.1])
Compact
SpareSize T135/90D16 102M
Pressure
psi (kPa[kgf/cm
2])60 (420 [4.2])
Wheel SizeRegular17 x 7 1/2JCompact Spare16 x 4T
Headlights (High/Low Beam)60/55W (HB2)
Fog Lights*35W (H8)Side Marker Lights5W
Front Turn Signal/Parking Lights 28/8W (Amber)
Brake/Tail/Side Marker LightsLED
Back-Up Lights 16W
Rear Turn Signal Lights21W (Amber)
High-Mount Brake Light LED
Side Turn Signal Lights*LED
Rear License Plate Lights 5W
Interior LightsVanity Mirror Light*1.8WMap Lights8WCeiling Light8WCargo Area Light5W
Brake Fluid
Continuously Variable Transmission Fluid
*
*1: 2WD
*2: AWD
Manual Transmission Fluid*
SpecifiedHonda Heavy Duty Brake Fluid DOT 3
SpecifiedHonda HCF-2 Transmission Fluid
Capacity Change3.7 US qt (3.5 L)*14.2 US qt (4.0 L)*2
SpecifiedHonda Manual Transmission Fluid
Capacity Change 2.0 US qt (1.9 L)
Engine Oil
Engine Coolant
*1: Continuously variable transmission models
*2: Manual transmission models
Recommended·Genuine Honda Motor Oil 0W-20
·API Premium-grade 0W-20 detergent oil
CapacityChange 3.7 US qt (3.5 L)
Change
including
filter3.9 US qt (3.7 L)
SpecifiedHonda Long-Life Antifreeze/Coolant Type2
Ratio 50/50 with distilled water
Capacity
1.39 US gal (5.25 L)*1(change including the remaining
0.13 US gal (0.5 L) in the reserve tank)
1.38 US gal (5.24 L)*2
(change including the remaining
0.13 US gal (0.5 L) in the reserve tank)
Washer Fluid
Tank CapacityU.S.: 2.6 US qt (2.5 L)
Canada: 4.8 US qt (4.5 L)
Rear Differential Fluid*SpecifiedHonda Dual Pump Fluid II
Capacity Change 1.318 US qt (1.247 ℓ)
SPECIFICATIONS
Learn about information specifi c to you as a Honda customer and how to get help.
Frequently Asked Questions/ Troubleshooting
Below are some frequently asked questions and troubleshooting items that you may
have about the vehicle.
Q: How do I set the vehicle clock?
A: For vehicles without navigation, see page 47. For vehicles with navigation, the
time is automatically set using GPS signals.
Q: Why doesn’t the vehicle start when I press the ENGINE START/STOP button?*
A: The brake pedal must be pressed to start the engine.
Q: What is the AUTO setting on my headlight lever?
A: When in the AUTO position, the vehicle’s exterior lights will automatically turn
on or off depending on the ambient lighting.
Q: Why won’t the driver’s door unlock when I grab the door handle, even though
the keyless access remote is within range?*
A: If you pull the handle too quickly, the system may not have time to confi rm the
door is unlocked. Wait to hear a beep to confi rm the door is unlocked. If you are
wearing gloves, the system may be slow to respond.
Q: After my battery was disconnected or went dead, the audio system is asking for
a code. Where do I nd this?
A: In most cases, you do not need to enter a code. Turn on the vehicle and the
audio system, and press and hold the power button until the system reactivates.
Q: Why can’t I operate Pandora
® through the audio system?
A: Audio may be streaming through Bluetooth® Audio. Make sure Pandora mode
is selected and the phone cable is properly connected to the USB adapter.
Some phones may prompt you to “Allow” a connection.
Q: Is my phone compatible with Bluetooth features?
A: Visit handsfreelink.com (U.S.) or handsfreelink.ca (Canada) to check phone
compatibility for Bluetooth
® Audio, Bluetooth® HandsFreeLink®, and SMS text
messaging.
Q: Every time I press the Talk button, the system gives me voice prompts. Can I turn
these off?*
A: From the Home screen, select Settings. Select the Voice Recog tab, then select
Voice Prompt. Select Off.
CUSTOMER INFORMATION
*if equipped *if equipped

136 || 137 CUSTOMER INFORMATION CUSTOMER INFORMATION
TABLE OF CONTENTS
INDEX
VISUAL INDEX
VOICE COMMAND
INDEX
SAFETY
INFORMATION
CUSTOMER
INFORMATION
INSTRUMENT PANEL
SPECIFICATIONS
VEHICLE
CONTROLS
MAINTENANCE
AUDIO AND
CONNECTIVITY
HANDLING THE
UNEXPECTED
BLUETOOTH®
HANDSFREELINK®
DRIVING
HONDALINK®
NAVIGATION
Contact Us
Honda dealer personnel are trained professionals. They should be able to answer
all your questions. If you encounter a problem that your dealership does not solve
to your satisfaction, please discuss it with the dealership’s service manager or
general manager. If you are dissatisfi ed with the decision made by the dealership’s
management, contact Honda Automobile Customer Service.
U.S. Owners:
American Honda Motor Co., Inc.
Honda Automobile Customer Service
1919 Torrance Blvd.
Mail Stop 500-2N-7A
Torrance, CA 90501-2746
Tel: (800) 999-1009
In Puerto Rico and
the U.S. Virgin Islands:
Bella International
P.O. Box 190816
San Juan, PR 00919-0816
Tel: (787) 620-7546
When you call or write, please give us the following information:
• Vehicle Identifi cation Number
• Date of purchase
• Odometer reading of your vehicle
• Your name, address, and telephone number
• A detailed description of the problem
• Name of the dealer who sold the vehicle to youCanadian Owners:
Honda Canada, Inc.
Customer Relations
180 Honda Blvd.
Markham, ON
L6C 0H9
Tel: (888) 946-6329
Fax: (877) 939-0909
e-mail: [email protected] Q: Why can’t I select an item using the selector knob or touchscreen*?
A: To prevent driver distraction, certain items are limited are inoperable while the
vehicle is moving. Use voice commands or pull over to select the items.
Q: Where can I nd the vehicle identi cation number (VIN)?
A: Check the label on the driver’s doorjamb.
*if equipped
Honda Roadside Assistance
24-hour emergency road service is available to you in the United States and Canada
throughout your 3-year/36,000-mile warranty term. Services include jump starting,
fl at tire and lockout assistance, towing, and more (limitations apply).
Call (866) 864-5211 (U.S.) or (800) 465-7587 (Canada).
Warranty Coverages
Below is a brief summary of the warranties covering your new vehicle.
New Vehicle Limited Warranty: Covers your new vehicle, except for the emissions
control system and accessories, against defects in materials and workmanship.
Emissions Control Systems Defects Warranty and Emissions Performance
Warranty: Covers your vehicle’s emissions control systems. Time, mileage, and
coverage are conditional.
Seat Belt Limited Warranty: Covers seat belts that fail to function properly.
Rust Perforation Limited Warranty: Covers all exterior body panels that rust through
from the inside.
Accessory Limited Warranty: Covers Honda accessories.
Replacement Parts Limited Warranty: Covers all Honda replacement parts against
defects in materials and workmanship.
Replacement Battery Limited Warranty: Provides prorated coverage for a
replacement battery purchased from a Honda dealer.
Replacement Muf er Lifetime Limited Warranty: Covers a replacement muffl er for
the duration of the ownership.
Restrictions and exclusions apply to all these warranties. See the Warranty Manual
on the Owner Information CD or at owners.honda.com (U.S.) or myhonda.ca
(Canada) for complete descriptions of each warranty, including time, mileage, and
other conditional limitations.
Your vehicle’s original tires are covered by their manufacturer. Tire warranty
information can be found on the Owner Information CD or at owners.honda.com
(U.S.) or myhonda.ca (Canada).

138 || 139 VOICE COMMAND INDEX VOICE COMMAND INDEX
TABLE OF CONTENTS
INDEX
VISUAL INDEX
VOICE COMMAND
INDEX
SAFETY
INFORMATION
CUSTOMER
INFORMATION
INSTRUMENT PANEL
SPECIFICATIONS
VEHICLE
CONTROLS
MAINTENANCE
AUDIO AND
CONNECTIVITY
HANDLING THE
UNEXPECTED
BLUETOOTH®
HANDSFREELINK®
DRIVING
HONDALINK®
NAVIGATION
Learn about all available voice commands to help you operate the vehicle. Available
on vehicles with navigation.
Press the Talk button before you say a command. To view a list of available
commands in the vehicle, say “Voice help.” Select a category to hear the commands
read aloud.
Global Commands
The system accepts these commands on any screen.
Navigation Commands
The system accepts these commands on the map/guidance screen.
General Commands
• Display map
• Display navigation
• Go home 1 (or 2)
Map Display Commands • Voice help
• Display menu
• Display setting
• Display navigation
• Display information• Display audio
• Display phone
• Back/Cancel
• What is today’s date?
• What time is it?
• Display current location
• Display/Hide (specify icon type):
−ATM
− gas station
− restaurant
− post offi ce
− grocery store
− lodging (hotel, motel)
− parking garage
− parking lot
− school − hospital
− freeway exit information
− traffi c*
− traffi c speeds*
− traffi c icons*
• Display north up
• Display heading up
• Display 3D map
• Display zoom in
• Display zoom out
VOICE COMMAND INDEX
*U.S. models only
Navigation Commands (continued)
Find Place Commands
• Find nearest (specify place):
− Fuel and auto
− Honda dealers
− Gas station
− Auto parts & electronics
− Auto repair & maintenance
− Car wash & detailing
− Motorcycle dealers
− Other car dealerships
− Roadside assistance
−ATM
− Bank
− Check cashing
− Currency exchange
− Community
− Business
− City hall
− Civic center
− Convention center
− Court house
− Higher education
− Library
− Post offi ce
− School
− Emergency room
− Hospital
− Police station
− Veterinarian
− Lodging
− Bed & breakfast
− Hotel
− Resort
− Recreation
− Amusement park
− Golf course
− Historical monument
− Marina
− Movie theater
− Museum
− Park − Performing arts
− Sports complex
− Tourist attraction
− Restaurant
− American restaurant
− Californian restaurant
− Chinese restaurant
− Coffee shop
− Continental restaurant
− Fast food
− French restaurant
− German restaurant
− Greek restaurant
− Indian restaurant
− Italian restaurant
− Japanese restaurant
− Korean restaurant
− Mexican restaurant
− Pizza
− Seafood restaurant
− Thai restaurant
− Vegetarian restaurant
− Vietnamese restaurant
− Other restaurant
− Shopping
− Shopping area
− Accessory store
− Book store
− Clothing store
− Grocery store
− Home improvement store
− Mall
− Offi ce supply store
− Pharmacy
− Pet food store
− Sewing store
− Shoe store
− Sporting goods store
− Toy store

140 || 141 VOICE COMMAND INDEX VOICE COMMAND INDEX
TABLE OF CONTENTS
INDEX
VISUAL INDEX
VOICE COMMAND
INDEX
SAFETY
INFORMATION
CUSTOMER
INFORMATION
INSTRUMENT PANEL
SPECIFICATIONS
VEHICLE
CONTROLS
MAINTENANCE
AUDIO AND
CONNECTIVITY
HANDLING THE
UNEXPECTED
BLUETOOTH®
HANDSFREELINK®
DRIVING
HONDALINK®
NAVIGATION
Route Commands
The system accepts these commands when a route is set.
• How long to the destination?
• How far to the destination?
• Display destination map
• Display entire route − Travel center
− Airport
− Automobile club
− Bus station
− Camping
− Commuter rail station
− Ferry terminal
− Named place
− Park & ride − Parking garage
− Parking lot
− Rental car agency
− Rest area
− Ski area
− Tourist information
− Train station
− Travel agency
− Truck stop
Climate Control Commands
The system accepts these commands on most screens.
• Climate control automatic
(maintains selected temperature)
• Climate control on*
• Climate control off*
• Air conditioner on*
• Air conditioner off*
• Climate control defrost on*
• Climate control defrost off*
• Rear defrost on*
• Rear defrost off*
• Climate control fresh air
• Climate control recirculate
• Climate control vent
• Climate control bi-level (vent and
fl oor)
• Climate control fl oor
• Climate control fl oor and defrost
• Climate control mode automatic• Fan speed up
• Fan speed down
• Fan speed # (#: 1 to 7)
• Temperature # degrees
(#: 57 to 87°F / 15 to 29°C)
• Driver temperature # degrees
(#: 57 to 87°F / 15 to 29°C)
• Passenger temperature # degrees
(#: 57 to 87°F / 15 to 29°C)
• Temperature up
• Temperature down
• Driver temperature up
• Driver temperature down
• Passenger temperature up**
• Passenger temperature down**
• Temperature max heat
• Temperature max cool
*These commands toggle the function on and off, so the
command may not match your intended action.
*if equipped.
• Cancel route
• Repeat guidance
• Route menu
Audio Commands
The system accepts these commands on most screens. Audio volume levels
cannot be controlled using voice commands.
FM/AM Radio Commands
• Audio on*
• Audio off*
• Radio on*
• Radio off*
• Radio select FM
• Radio select AM
• Radio tune to # FM (#: frequency,
e.g., 95.5)
• Radio tune to # AM (#: frequency,
e.g., 1020)
• Radio seek up
• Radio seek down
• Radio next station
• Radio preset # (#: 1 to 12)
• Radio FM preset # (#: 1 to 12)
• Radio AM preset # (#: 1 to 6)
• Radio scan*
SiriusXM
® Radio Commands
• Radio select XM
• XM channel # (#: 0 to 255)
• XM channel up
• XM channel down
• XM category up
• XM category down
• XM preset # (#: 1 to 12)
• XM scan*
• XM category scan*
• XM channel scan*
• XM category mode
• XM channel mode Disc Commands
• Disc play
• Disc play track # (#: 1 to 30)
• Disc skip forward
• Disc skip back
• Disc track random*
• Disc track repeat*
• Disc track scan*
• Disc folder up
• Disc folder down
• Disc folder random*
• Disc folder repeat*
• Disc folder scan*
• Disc normal play
*These commands toggle the function on and off, so the
command may not match your intended action.
Song By Voice™ Commands
Available for iPod and USB music
search.
• What am I listening to?
• Who am I listening to?
• Who is this?
• Who’s playing?
• What’s playing?
• What album is this?
• Play artist (name)
• Play track/song (name)
• Play album (name)
• Play genre/category (name)
• Play playlist (name)
• Play composer (name)
• List artist (name)
• List album (name)
• List genre/category (name)
• List playlist (name)
• List composer (name)

142 || 143 VOICE COMMAND INDEX VOICE COMMAND INDEX
TABLE OF CONTENTS
INDEX
VISUAL INDEX
VOICE COMMAND
INDEX
SAFETY
INFORMATION
CUSTOMER
INFORMATION
INSTRUMENT PANEL
SPECIFICATIONS
VEHICLE
CONTROLS
MAINTENANCE
AUDIO AND
CONNECTIVITY
HANDLING THE
UNEXPECTED
BLUETOOTH®
HANDSFREELINK®
DRIVING
HONDALINK®
NAVIGATION
Audio Commands (continued)
USB Commands
• USB play
• USB play track # (#: 1 to 30)
• USB skip forward
• USB skip back
• USB track random*
• USB track repeat*
• USB track scan*
• USB folder up
• USB folder down
• USB folder random*
• USB folder repeat*
• USB folder scan*
• USB normal play Pandora® Commands
• Pandora play*
• Pandora skip forward
• Pandora station up
• Pandora station down
• Pandora pause*
• Pandora resume*
• Pandora like this song
• Pandora dislike this song
*These commands toggle the function on and off, so the
command may not match your intended action.
iPod® Commands
• Music search
• iPod play
• iPod play track # (#: 1-30)
• iPod skip forward
• iPod skip back
• iPod track shuffl e*
• iPod album shuffl e*
• iPod track repeat*
• iPod normal play
• What/Who am I listening to?
• Who is this?
• What’s playing?
• Who’s playing?
• What album is this? Bluetooth
® Audio Commands
• Bluetooth audio play
• Bluetooth audio skip forward
• Bluetooth audio skip back
• Bluetooth audio pause
• Bluetooth audio resume
• Bluetooth audio group up
• Bluetooth audio group down
Commands may not work on some
phones or devices.
AUX Commands
• Auxiliary play
Phone Commands
The system accepts these commands on most screens.
Info Commands
The system accepts these commands on most screens.
• Trip computer
• Display traffi c list*
• Display traffi c on my route*• Display clock
• Display wallpaper
On-screen Commands
The system accepts these commands on any screen where applicable. All
available commands are highlighted in yellow when you press the Talk button.
• Next (or previous)
• Up (or down)
• Right (or left)
• Return
• OK (excluding Startup Confi rmation screen)
• Delete
*if equipped
• Dial/call by number
• Dial/call by name
• Call (phone number or name)

144 || 145 INDEX INDEX
TABLE OF CONTENTS
INDEX
VISUAL INDEX
VOICE COMMAND
INDEX
SAFETY
INFORMATION
CUSTOMER
INFORMATION
INSTRUMENT PANEL
SPECIFICATIONS
VEHICLE
CONTROLS
MAINTENANCE
AUDIO AND
CONNECTIVITY
HANDLING THE
UNEXPECTED
BLUETOOTH®
HANDSFREELINK®
DRIVING
HONDALINK®
NAVIGATION
INDEX
ABS ................................................................25
Accessory Power Socket ...........................48
Airbags ............................................................9
About Your Airbags ..................................11
Advanced Airbags ......................................9
Airbag Care ...............................................14
Airbag System Components ...................13
Airbag System Indicators .......................11
Front Airbags (SRS) ....................................9
Passenger Airbag Off Indicator .............12
Side Airbags ..............................................10
Side Curtain Airbags ................................10
Supplemental Restraint System Indicator 11
Air Conditioning System .............................44
All Wheel Drive (AWD) ................................25
Ambient Meter .............................................94
Anti-lock Brake System (ABS) .............25, 92
Audio Commands .......................................141
Audio Operation ...........................................48
Accessory Power Socket .......................48
Auxiliary Input Jack .................................49
Bluetooth
® Audio ................................56, 64
Color Audio System ..................................51
Compact Disc (CD) .............................53, 61
FM/AM Radio ......................................52, 59
HDMI Port ..................................................48
HDMI Video ...............................................66
HondaLink™ ..............................................58
iPod
® .....................................................54, 62
Pandora® ....................................................65
SiriusXM® Radio .......................................60
Sound .........................................................50
Steering Wheel Controls .........................49
Touchscreen Operation ...........................57
USB Flash Drive ..................................55, 63
USB Port ....................................................48
Automatic Brake Hold .................................93
Automatic Dimming Rearview Mirror .......43
AUX Commands .........................................142
Auxiliary Input Jack .....................................49
AWD ...............................................................25
BACK button .................................................67
Battery .........................................................123
Bluetooth
® Audio ...................................56, 64
Bluetooth® Audio Commands ..................142
Bluetooth® HandsFreeLink® (HFL) .............67
E-Mail .........................................................75
HFL Controls ........................................67, 70
HondaLink™ Assist ..................................76
Making a Call ......................................69, 73
Pairing a Phone ..................................68, 72
Siri Eyes Free ............................................76SMS Text Messaging ...............................75
Speed Dial ...........................................69, 74
Talk Button Tips .........................................71
Brake Assist System ...................................92
Brake depress ..............................................27
Brake hold .....................................................27
Brake system ..........................................24, 25
Braking ..........................................................91
Brightness Control .......................................36
Built-in key ....................................................30
Calibration ...................................................106
Carbon Monoxide Gas ..................................4
Cargo Area Lights ........................................37
Changing a Flat Tire ...................................107
Changing Settings ........................................29
Changing Wiper Blades ............................124
Charging system ..........................................24
Childproof Door Locks .................................32
Child Safety ...................................................15
Child Seat ......................................................17
Adding Security with a Tether ................20
Installing a Child Seat ..............................18
Selecting a Child Seat .............................17
Climate Control Commands ......................140
Climate Control System ...............................45
Clock ..............................................................47
Color Audio System .....................................51
Compact Disc (CD) .................................53, 61
Compact Disc (CD) Commands ................141
Contact Us ...................................................136
Continuously Variable Transmission (CVT) 89
Coolant .........................................................122
Cruise Control .........................................27, 95
Customer Information ...............................135
Customized Features ...................................29
CVT .................................................................89
Dashboard and Other Controls ....................2
Destination ....................................................80
Detour ............................................................83
Dialing a Number ...................................69, 73
Door Mirrors .................................................43
Door Operation .......................................31, 32
Door/tailgate open .......................................26
DOT Tire Quality Grading ..........................130
Driving ............................................................84
Braking .......................................................91
Cruise Control ...........................................95
Eco Assist System ....................................94
Forward Collision Warning (FCW) .........96
Ignition .......................................................88
Lane Departure Warning (LDW) ............97
LaneWatch™ .............................................98Maximum Load Limit ................................86
Multi-View Rear Camera .................99, 100
Paddle Shifters .........................................90
Power Mode ..............................................89
Refueling ..................................................101
Shifting .......................................................89
Vehicle Stability Assist (VSA
®) ...............94
Eco Assist System .......................................94
ECON Button .................................................94
ECON mode ...................................................27
Electric parking brake .....................25, 27, 92
Electric Power Steering (EPS) ...................25
Electronic Stability Control (ESC) ..............94
E-Mail .............................................................75
Emergency Engine Stop ............................105
Emergency Towing ....................................105
Engine and Fuel ..........................................134
Engine Coolant ...........................................122
Engine Oil ....................................................120
ENGINE START/STOP button .....................89
Exterior lights ..........................................27, 37
Fastening a Seat Belt ....................................7
FCW ..........................................................25, 27
Find Nearest Place ......................................81
Find Place Commands ...............................139
Flat Tire ........................................................107
Floor Mats .....................................................40
Fluids ............................................................134
FM/AM Radio ..........................................52, 59
FM/AM Radio Commands .........................141
Fog lights .................................................27, 37
Foot Brake .....................................................91
Forward Collision Warning (FCW) .25, 27, 96
Frequently Asked Questions ....................135
Front Airbags (SRS) .......................................9
Front Door Inner Handle .............................32
Front Seats ....................................................39
Front Wipers .................................................38
Fuel Information .........................................101
Fuse Locations ...........................................111
Handling Information .....................................4
Hang-Up/Back button .....................67, 70, 77
Hazard lights .................................................27
HDMI Port .....................................................48
HDMI Video ...................................................66
Headlight-Wiper Integration ......................38
Head Restraints ............................................41
Heated Windshield Button .........................46
HFL Controls ............................................67, 70
High beams ...................................................27
High temperature .........................................25
Home Address ..............................................80
HondaLink™ ..................................................58
HondaLink™ Assist ......................................76
Honda Roadside Assistance ....................137Hood .............................................................119
Ignition ...........................................................88
Immobilizer ....................................................27
Info Commands ..........................................143
Information Display .....................................28
Instrument Panel ..........................................24
Condition Indicators .................................26
Malfunction Indicators ............................24
On/Off Indicators ......................................27
Interior Lights ...............................................36
Intermittent Wipers .....................................38
iPod
® ........................................................54, 62
iPod® Commands .......................................142
Jump Starting .............................................102
Key ..................................................................30
Lane Departure Warning (LDW) ....25, 26, 97
LaneWatch™ ................................................98
Lap/Shoulder Seat Belts ...............................5
LATCH-Compatible Child Seat....................18
LDW ..............................................25, 26, 27, 97
Light Bulbs ..................................................134
Lights ..............................................................36
Locking the Tailgate .....................................31
Lock Tab .........................................................32
Low fuel .........................................................26
Low oil pressure ...........................................24
Low temperature ..........................................26
Low tire pressure .........................................26
Maintenance ..............................................116
Maintenance Minder™ ...................27, 117
Safety Precautions .................................116
Service Codes .........................................118
Under the Hood .......................................119
Making a Call ..........................................69, 73
Malfunction indicator lamp ........................25
Manual Transmission ..................................91
Map Display Commands ...........................138
Map Legend ..................................................82
Map Lights ....................................................36
Master Door Lock Switch ...........................32
Maximum Load Limit ...................................86
Mirrors ...........................................................43
Moonroof .......................................................35
Multi-View Rear Camera ....................99, 100
Navigation .....................................................77
Detour .........................................................83
Display and Controls ................................78
Entering a Destination .............................80
Find Nearest Place ...................................81
Home Address ..........................................80
Map Legend ..............................................82
Place Category .........................................81
Routing .......................................................82
Steering Wheel Controls .........................77
Street Address ..........................................80

146 || 147 INDEX INDEX
TABLE OF CONTENTS
INDEX
VISUAL INDEX
VOICE COMMAND
INDEX
SAFETY
INFORMATION
CUSTOMER
INFORMATION
INSTRUMENT PANEL
SPECIFICATIONS
VEHICLE
CONTROLS
MAINTENANCE
AUDIO AND
CONNECTIVITY
HANDLING THE
UNEXPECTED
BLUETOOTH®
HANDSFREELINK®
DRIVING
HONDALINK®
NAVIGATION
Talk Button Tips .........................................79
Traffi c..........................................................83
Voice Prompt .............................................79
Navigation Commands ..............................138
One-Touch Turn Signal ................................37
On-screen Commands ..............................143
Opening the Hood ......................................119
Overheating ................................................104
Paddle Shifters .............................................90
Pairing a Phone ......................................68, 72
Pandora
® .......................................................65
Pandora® Commands ................................142
Panic button ..................................................30
Parking brake ...............................................26
Passenger Airbag Off Indicator .................12
Phone .......................................................68, 72
Phonebook ..............................................69, 73
PHONE button ...............................................67
Phone Commands ......................................143
Pick-Up button ..................................67, 70, 77
Place Category .............................................81
Power Door Mirrors ....................................43
Power Mode .................................................89
Power Moonroof ..........................................35
Power Windows ...........................................34
Radio ........................................................52, 59
Readiness Codes .......................................133
Rear Camera .........................................99, 100
Rear Seats ...............................................40, 42
Rearview Mirror ...........................................43
Rear Wiper ....................................................38
Refueling .....................................................101
Remote Battery Strength ..........................102
Remote Transmitter .....................................30
Reporting Safety Defects ...........................23
Roadside Assistance .................................137
Route Commands .......................................140
Routing ...........................................................82
Safety Information .........................................3
Carbon Monoxide Gas ...............................4
Childproof Door Locks .............................32
Child Safety ...............................................15
Handling Information .................................4
Reporting Safety Defects ........................23
Safety Label Locations ............................22
Safety Messages ........................................3
Seat Belts ........................................................5
Fastening a Seat Belt .................................7
Lap/Shoulder Seat Belts ...........................5
Seat Belt Inspection ..................................6
Seat Belt Reminder ..................................26
Seat Belt with Detachable Anchor ..........8
Shoulder Anchor ........................................7
Seat Heaters .................................................47
Seats ..............................................................39Front Seats ................................................39
Rear Seats ...........................................40, 42
Selector knob ...............................................67
Select/reset knob ...................................28, 29
Service Codes ............................................118
Settings ..........................................................29
Setting the Clock ..........................................47
Shifting ...........................................................89
Shift Lever Does Not Move ......................103
Shoulder Anchor ............................................7
Side Airbags .................................................10
Side Curtain Airbags ...................................10
Siri Eyes Free ................................................76
SiriusXM
® Radio ...........................................60
SiriusXM® Radio Commands ....................141
Smart entry system ................................25, 31
SMS Text Messaging ..................................75
Song By Voice™ Commands ....................141
Sound .............................................................50
Specifi cations .............................................134
Speed Dial ...............................................69, 74
Starter system ..............................................25
Steering Wheel ............................................44
Steering Wheel and Nearby Controls ........1
Steering Wheel Controls ......................49, 77
Street Address .............................................80
Supplemental Restraint System (SRS) 11, 24
System message ..........................................26
Tailgate ..............................................30, 31, 33
Talk button .........................................67, 70, 77
Talk Button Tips ......................................71, 79
Text Messaging ............................................75
Tire Chains...................................................128
Tire Information ..........................................126
DOT Tire Quality Grading .......................130
Infl ation Guidelines ................................126
Tire and Loading Information Label .....127
Tire and Wheel Replacement ...............127
Tire Identifi cation Number (TIN) ..........129
Tire Labeling ............................................129
Tire Service Life ......................................128
Tire Terminology .....................................129
Wear Indicators ......................................126
Tire Pressure Monitoring System (TPMS)
.........................................................25, 106, 132
Tires ..............................................................134
Touchscreen Operation ..............................57
Towing ..........................................................105
TPMS .............................................25, 106, 132
Traffi c .............................................................83
Troubleshooting ..........................................135
Turn Signal ..............................................27, 37
Under the Hood ..........................................119
USB Commands .........................................142
USB Flash Drive .....................................55, 63USB Port ........................................................48
Vehicle .........................................................134
Vehicle Controls ...........................................30
Vehicle Stability Assist (VSA
®) ......25, 27, 94
Visual Index ....................................................1
Voice Command Index ..............................138
Voice Prompt ................................................79
VSA
® ...................................................25, 27, 94
Warranty Coverages .................................137
Washer fl uid level ........................................27
Wear Indicators .........................................126
Window Washer Fluid ...............................123
Windows .......................................................34
Winter Tires.................................................128
Wiper Blades ..............................................124
Wiper Operation ...........................................38
