2004 Insight Online Reference Owner's Manual
Use these links (and links throughout this manual) to navigate through\
this reference.
For a printed owner's manual, click on authorized manuals or go to www.h\
elminc.com.
Contents
Owner's Identification Form
Introduction ........................................................................\
................................................................. i
A Few Words About Safet y........................................................................\
.........................................ii
Your Vehicle at a Glanc e........................................................................\
.............................................2
Driver and Passenger Safety ........................................................................\
......................................5
Proper use and care of your vehicle's seat belts, and Supplemental Restr\
aint System.
Instruments and Control s........................................................................\
........................................ .39
Instrume nt panel indicator and gauge, and how to use dashboard and steering colu\
mn controls.
Comfort and Convenience Features ........................................................................\
....................... .71
How to operate the climate control system, the audio system, and other c\
onvenience features.
Before Driving........................................................................\
........................................................... .91
What gasoline to use, how to break -in your new vehicle, and how to load luggage and other cargo.
Driving ........................................................................\
..................................................................... .105
The proper way to start the engine, shift the transmission, and park, pl\
us towing a trailer.
Maintenance........................................................................\
.............................................................123
The Maintenance Schedule shows you when you need to take you r vehicle to the dealer.
Taking Care of the Unexpecte d........................................................................\
..............................163
This section covers several problems motorists sometimes experience, an d how to handle them.
Technical Informatio n........................................................................\
.............................................189
ID numbers, dimensions, capacities, and technical information.
Warranty and Customer Relations (U.S. and Canada)................................................................201
A summary of the warranties covering your new Acura, and how to contact \
us.
Authorized Manu als (U.S. only)........................................................................\
..............................205
How to order manuals and other technical literature.
Index........................................................................\
........................................................................\
...... I
Service Information Summary
A summary of information you need when you pull up to the fuel pump.
Page 17 of 218
This could cause
very serious injuries in a crash.
If a seat belt does not seem to work
as it should, it may not protect the
occupant in a crash.
Using a seat
belt that is not working properly can
result in serious injury or death.
Have your Honda dealer check the
belt as soon as possible.
See page f or additional
inf ormation about your seat belts
and how to take care of them. After all occupants have adjusted
their seats and put on seat belts, it is
very important that they continue to
sit upright, well back in their seats,
with their feet on the floor, until the
vehicle is parked and the engine is
off.
Sitting improperly can increase the
chance of injury during a crash. For
example, if an occupant slouches,
lies down, turns sideways, sits
forward, leans forward or sideways,
or puts one or both f eet up, the
chance of injury during a crash is
greatly increased.
In addition, an occupant who is out of
position can be seriously or f atally
injured in a crash by striking interior
parts of the vehicle or being struck
by an inf lating airbag.
17
Never place t he shoulder port ion of a
lap/shoulder belt under your arm orbehind your back.
No one should sit in a seat wit h aninoperat ive seat belt .
Protecting A dults and Teens
Driver and Passenger Saf ety
Maintain a Proper Sitting
Position
5.
14
Sitting improperly or out of
position can result in serious
injury or death.
Always sit upright, well back in
the seat, with your feet on the
floor.
Page 24 of 218
Your Honda has automatic seat belt
tensioners f or added protection
during a moderate to severe frontal
collision.
If your airbags inf late, the tensioners
immediately tighten the seat belts to
help hold the occupants in place. The
belts will remain tight until you
unbuckle them in the normal manner.The SRS indicator alerts
you to a potential problem
with your airbags or seat belt
tensioners.
When you turn the ignition switch to
ON (II), this indicator will come on
brief ly then go out. This tells you
that the system is working properly.
If the indicator comes on at any
other time, or does not come on at all,
you should have the system checked
by your dealer. For example:
If the SRS indicator does not come
on after you turn the ignition
switch to ON (II).
If the indicator stays on after the
engine starts. If the indicator comes on or
flashesonandoff whileyoudrive.
If you see any of these indications,
the airbags and the seat belt
tensioners may not work properly
when you need them.
Additional Inf ormation About Your Airbags
Driver and Passenger Saf ety
How the Automatic Seat Belt
T ensioners Work How the SRS Indicator Works
21
Ignoring the SRS indicator can
result in serious injury or death
if the airbag systems or
tensioners do not work properly.
Have your vehicle checked by a
dealer as soon as possible if
the SRS indicator alerts you to
a possible problem.
Page 39 of 218
Your vehicle’s exhaust contains
carbon monoxide gas. You should
have no problem with carbon
monoxide entering the vehicle in
normal driving if you maintain your
vehicle properly.The vehicle is raised f or an oil
change.
You notice a change in the sound
of the exhaust.
The vehicle was in an accident
that may have damaged the under-
side.
Have the exhaust system inspected
f or leaks whenever:
With the hatch open, air flow can
pull exhaust gas into your vehicle’s
interior and create a hazardous
condition. If you must drive with the
hatch open, open all the windows,
and set the heating/climate control
system as shown below.
If you must sit in your parked vehicle,
even in an unconf ined area, with the
engine running, adjust the heating/
climate control system as f ollows:
Select the Fresh Air mode.
Select the mode.
Turn the f an on high speed.
Set the temperature control to a
comfortable setting.
High levels of carbon monoxide can
collect rapidly in enclosed areas,
such as a garage. Do not run the
engine with the garage door closed.
Even with the door open, run the
engine only long enough to move the
vehicle out of the garage. 1.
2.
3.
4.
Carbon Monoxide Hazard
Driver and Passenger Saf ety36
Carbon monoxide gas is toxic.
Breathing it can cause
unconsciousness and even kill
you.
Avoid any enclosed areas or
activities that expose you to
carbon monoxide.
Page 45 of 218
The instrument panel has many
indicators to give you important
inf ormation about your vehicle.
If you turn the ignition switch to ON
(II) bef ore f astening your seat belt,
the beeper sounds and the indicator
f lashes. If you do not f asten your
seat belt bef ore the beeper stops, the
indicator stops f lashing but remains
on.
If you continue driving without
f astening your seat belt, the beeper
sounds and the indicator f lashes
again at regular intervals.The engine can be severely damaged
if this indicator f lashes or stays on
when the engine is running. For
more inf ormation, see page .
If this indicator comes on when the
engine is running, the battery is not
being charged. For more inf ormation,
see page .
This indicator comes on when you
turn the ignition switch to ON (II). If
it comes on at any other time, it
indicates a potential problem with
your airbags or automatic seat belt
tensioners. For more inf ormation,
see page .This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to ON (II). If it comes
on at any other time, it indicates a
problem in the Integrated Motor
Assist (IMA) system. Have the
vehicle checked by the dealer as
soon as possible.
(Manual Transmission)
See pages and . See page . (Automatic Transmission) See page .
The seat belt system includes an
indicator on the instrument panel
and a beeper to remind you and your
passenger to f asten your seat belts.
177
178
21 109
111 110 117
Instrument Panel Indicators
Inst rument s and Cont rols
Seat Belt Reminder
Indicator
Supplemental Restraint
System Indicator L ow Oil Pressure
Indicator
Charging System
IndicatorIMA System Indicator
Shif t Up/Shif t Down Indicators
A uto Idle Stop Indicator Shif t L ever Position Indicators
42
Page 46 of 218
This indicator has two f unctions:This indicator comes on when you
turn the ignition switch to ON (II).
It is a reminder to check the
parking brake. Driving with the
parking brake not f ully released
can damage the brakes and tires.
If it remains lit af ter you f ully
release the parking brake while
the engine is running, or if it
comes on while driving, there
could be a problem with the brake
system. For more inf ormation, see
page . See page .
The lef t or right turn signal indicator
blinks when you signal a lane change
or turn. If the indicators do not blink
or blink rapidly, it usually means one
of the turn signal bulbs is burned out
(see page ). Replace the bulb as
soon as possible, since other drivers
cannot see that you are signaling.
WhenyouturnontheHazard
Warning button, both turn signal
indicators blink. All turn signals on
the outside of the vehicle should
flash. This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to ON (II), and when
the ignition switch is turned to
START (III). If it comes on at any
other time, there is a problem in the
ABS. If this happens, have your
vehicle checked by your Honda
dealer. With this indicator on, your
vehicle still has normal braking
ability but no anti-lock. For more
inf ormation, see page .
2. 1.
180 178
146 120
Instrument Panel Indicators
Inst rument s and Cont rols
Parking Brake and Brake System
IndicatorMalf unction Indicator
Lamp
Turn Signal and Hazard Warning
Indicators Anti-lock Brake System
(A BS) Indicator
43
U.S. Canada
Page 47 of 218
This indicator comes on with the
high beam headlights. See pagef or inf ormation on the headlight
controls.
On Canadian models, this indicator
comes on with reduced brightness
when the Daytime Running Lights
(DRL) are on (see page ).
This indicator comes on when you
turn the ignition switch to ON (II)
with the headlight switch off and the
parking brake set. It should go of f if
youturnontheheadlightsorrelease
the parking brake. If it comes on at
any other time, it means there is a
problem with the DRL. There may
also be a problem with the high
beam headlights. This indicator comes on f or a f ew
seconds when you turn the ignition
switch to ON (II). It will go of f if you
have inserted a properly-coded
ignition key. If it is not a properly-
coded key, the indicator will blink
and the engine will not start (see
page ).
This indicator also blinks several
times when you turn the ignition
switch f rom ON (II) to ACCESSORY
(I) or LOCK (0).
This indicator comes on if either
door or the hatch is not closed
tightly.
This indicator comes on as a
reminder that you must ref uel soon.This indicator normally comes on
when you turn the ignition to ON (II)
and goes off after the engine starts.
If it comes on at any other time,
there is a problem in the Electric
Power Steering system. If this
happens, stop the vehicle in a saf e
place, and turn of f the engine. Reset
the system by restarting the engine,
and watch the EPS indicator. If it
does not go of f , or comes back on
again while driving, take the vehicle
to your dealer to have it checked.
With the indicator on, the EPS is
turned off, making the vehicle
harder to steer.
54
5458
Canadian models only
Instrument Panel Indicators
High Beam Indicator
‘‘Daytime Running
Lights’’ Indicator Immobilizer System
Indicator
Door and Hatch Open
Indicator
Low Fuel IndicatorElectric Power Steering
(EPS) Indicator
Inst rument s and Cont rols44
Page 48 of 218
This indicator reminds you that it is
time to take your vehicle in for
scheduled maintenance.
Ref er to the Maintenance Schedules
f or Normal and Severe Driving
Conditions on pages and .
When the distance driven since the
last scheduled maintenance reaches
6,000 miles (9,600 km), the indicator
starts blinking. If you exceed 7,500
miles (12,000 km), the indicator
stays on.
Your dealer will reset this indicator
af ter completing the scheduled
maintenance. If this maintenance is
done by someone other than your
Honda dealer, reset the indicator as
f ollows.Turn of f the engine. Press and hold the TRIP button in
the instrument panel, then turn
the ignition switch to ON (II).
Hold the button for about 10
seconds until the indicator resets.
1. 2.
3.
127 128
Instrument Panel Indicators
Inst rument s and Cont rols
Maintenance Required
Indicator
45
TRIP BUTTON
Page 50 of 218
This shows how much f uel you have.
It may show slightly more or less
than the actual amount.This shows the temperature of the
engine’s coolant. During normal
operation, the reading should be in
the middle of the gauge. In severe
driving conditions, the reading may
reach near the red mark. If it
reaches the red mark, pull saf ely to
thesideof theroad.Turntopage
f or instructions and precautions
on checking the engine’s cooling
system. The odometer shows the total
distance your vehicle has been
driven in miles and kilometers. It is
illegal under U.S. f ederal law and
Canadian provincial regulations to
disconnect, reset, or alter the
odometer with the intent to change
the number of miles and kilometers
indicated.
Push the Display Change button to
switch the speedometer, trip meter,
and odometer reading between miles
per hour and kilometers per hour.
175
Gauges
Inst rument s and Cont rols
Fuel Gauge
T emperature GaugeOdometer
Display Change Button
47
NOTICE:Avoid driving with an
extremely low f uel level. Running out
of f uel could cause the engine to
misf ire, damaging the catalytic
converter.
Page 54 of 218
This gauge shows you the state of
charge of the battery for the
Integrated Motor Assist (IMA). This
battery is recharged by the engine,
anddischargedbytheIMAwhenit
is assisting the engine with powering
the vehicle.The gauge reading may drop near
the bottom under driving conditions
that require assist f or a long time,
such as prolonged acceleration or
climbing a long hill. The engine will
recharge the battery as you continue
driving.
If the battery is mostly discharged,
the Auto Idle Stop f unction is
disabled (see pages and ).This gauge shows the status of the
Integrated Motor Assist (IMA). If
the indicator is on the left side of the
gauge, the IMA battery is being
charged. If the indicator is on the
right side of the gauge, the IMA is
assisting the engine.
109 116
Gauges
Inst rument s and Cont rols
Battery Level Gauge Charge/Assist Gauge
51
BATTERY LEVEL
GAUGE
IMA CHARGE/
ASSIST GAUGE BATTERY LEVEL
GAUGE
IMA CHARGE/
ASSIST GAUGE
With
5-speed
With CVT (U.S. only)
