In MP3 or WMA mode, you can use
the seek function to select folders.
Press and hold the top ( ) of the
CH button until you hear a beep to
skip f orward to the f irst f ile of the
next folder. Press the bottom ( ) to
skip backward to the previous f older.
If you are playing a PC card, press
the top ( ) of the CH button to
advance to the next file. Press the
bottom( )togobacktothe
previous f ile.
Your vehicle has the auxiliary input
jack on the f ront panel. The system
will accept auxiliary input f rom
standard audio accessories.
When a compatible audio unit is
connected to the jack, press the CD/
AUX (on vehicles with navigation
system) or AUX (on vehicles without
navigation system) button to select it. Auxiliary Input Jack
Remote Audio Controls, Auxiliary Input Jack
252
On vehicles without navigation system
On vehicles with navigation system
—
—y

y
)"yy
2010 Insight

If your vehicle’s battery is
disconnected or goes dead, or the
radio f use is removed, the audio
system will disable itself . If this
happens, you will see ‘‘ENTER
CODE’’ in the f requency display the
nexttimeyouturnonthesystem.
Use the preset buttons to enter the
code. On vehicles with navigation
system, touch the icon to enter the
code number, then touch the Done
icon to set the code. The code is on
the radio code card included in your
owner’s manual kit. When it is
entered correctly, the radio will start
playing.
Your vehicle’s audio system will
disable itself if it is disconnected
f rom electrical power f or any reason.
To make it work again, you must
enter a specif ic code using the preset
buttons (icon on vehicle’s with
navigation system). Because there
are hundreds of number
combinations possible f rom specif ic
digits, making the system work
without knowing the exact code is
nearly impossible.
If you make a mistake entering the
code, do not start over; complete the
sequence, then enter the correct
code. You have 10 tries to enter the
correct code. If you are unsuccessf ul
in 10 attempts, you must then leave
the system on f or 1 hour bef ore
trying again.
Youshouldhavereceivedacardthat
lists your audio system’s code and
serial numbers. It is best to store this
card in a saf e place at home. In
addition, you should write the audio
system’s serial number in this owner’s
manual.
If you lose the card, you must obtain
the code number f rom a dealer. To
do this, you will need the system’s
serial number.
Radio T hef t Protection
Features
253
—
—y


y
)"yy
2010 Insight

The navigation system receives
signals f rom the global positioning
system (GPS), and the displayed
time is updated automatically by the
GPS. Ref er to the navigation system
manual f or how to adjust the time.
For example:
Press and hold the FM/AM
(CLOCK) button until the displayed
time begins to blink, then release the
button. Change the hours by
pressing the 1 (H) button until the
numbers advance to the desired time.
Change the minutes by pressing the
2 (M) button until the numbers
advance to the desired time.
PresstheFM/AM(CLOCK)button
again to enter the set time.
You can quickly set the time to the
nearest hour. If the displayed time is
bef ore the half hour, press the FM/
AM (CLOCK) button until you hear
a beep, then press the 3 (R) button
tosettheclockbacktotheprevious
hour. If the displayed time is af ter
the half hour, the clock sets forward
to the beginning of the next hour.
1:06 will reset to 1:00
1:53 will reset to 2:00
On vehicles without navigation system
On vehicles with navigation system
Setting the Clock
254
FM/AM (CLOCK)
BUTTONCLOCK
2 (M) BUTTON
1 (H) BUTTON 3 (R) BUTTON
—
—y

y
)"yy
2010 Insight

Try to reduce all background
noise. If the microphone picks up
voices other than yours,
commands may be misinterpreted.Many commands can be spoken
together. For example, you can
say ‘‘Call 123-456-7890’’ or ‘‘Dial
Peter.’’
Press and release the HFL Talk
button each time you want to
make a command. Af ter the beep,
speak in a clear, natural tone.
When HFL is in use, navigation
voice commands cannot be
recognized.
To change the volume level of
HFL, use the audio system volume
knob or the steering wheel volume
controls.
Airorwindnoisefromthe
dashboard and side vents and
windows may interfere with the
microphone. Adjust or close them
as necessary.
BluetoothHandsFreeL ink
Voice Cont rol T ips
260
MICROPHONE
—
—y

y
)"yy
2010 Insight

A notif ication that there is an
incoming call, or HFL is in use, will
appear on the navigation screen
when the audio system is on.When there is an incoming call, or
HFL is in use, ‘‘HFL’’ will appear at
the bottom of the map screen.
BluetoothHandsFreeL ink
262
HFL MESSAGE
—
—y

y
)"yy
2010 Insight

(available on some phones)handsf reelink.honda.
com
www.honda.ca,
If you selectfrom the navigation system
menu, you will see f our HFL options.
In the U.S., visit or call (888) 528-7876.
In Canada, visit or call
(888) 9-HONDA-9. The entire phonebook data of the
cell phone that is linked to HFL can
be imported to the navigation system.
Select ‘‘
,’’ and HFL will begin
importing the phonebook. Select
‘‘ ’’ af ter the import is completed. Once a phonebook has been
imported, you can search the phone
numbers by the person’s name.
Select ‘‘
,’’ and a list of imported
phonebooks will be displayed.
Select a phonebook f rom the list.
For a list of cell phones that are
compatible with this f eature:
CONT INUED
BluetoothHandsFreeL ink
Cellular Phonebook Options
Cellular Phonebook
Options
Import Cellular
Phonebook
OK Search Cellular
PhonebookImport Cellular Phonebook: Search Import ed Phonebook:
Features
275
IMPORTED PHONEBOOK
IMPORTED DATEPIN ICON
—
—y

y
)"yy
2010 Insight

If your vehicle’s battery is
disconnected, or goes dead, the time
setting may be lost. To reset the time,
see page .
If your vehicle’s battery is
disconnected or goes dead, the audio
system may disable itself . The next
timeyouturnontheradio,youwill
see ‘‘ENTER CODE’’ in the
f requency display. Use the preset
buttons to enter the code (see page). The navigation system will also
disableitself.Thenexttimeyouturn
on the ignition switch, the system
will require you to enter a PIN
bef ore it can be used. Ref er to the
navigation system manual.
254
253On vehicles with navigation system
Checking the 12 Volt Battery
382
—
—y

y
)"yy
2010 Insight

If the replacement fuse of the
same rating blows in a short time,
there is probably a serious
electrical problem with your
vehicle. Leave the blown fuse in
that circuit, and have your vehicle
checked by a qualif ied technician.
When the audio system is disabled,
the clock setting in the audio system
will be canceled. You will need to
reset the clock according to the
instructions in the audio system
sectioninthisowner’smanual. The navigation system will also
disableitself.Thenexttimeyouturn
on the ignition switch, the system
will require you to enter a PIN
bef ore it can be used. Ref er to the
navigation system manual. If the radio f use is removed, the
audio system will disable itself . The
nexttimeyouturnontheradio,you
may see ‘‘ENTER CODE’’ in the
f requency display. Use the preset
buttons to enter the digit code (see
page ).
6. 253
On vehicles with navigation system
Fuses
T aking Care of t he Unexpect ed
409
Replacing a f use with one that has a
higher rating greatly increases the
chances of damaging the electrical
system. If you do not have a
replacement f use with the proper rating
f or the circuit, install one with a lower
rating.
—
—y

y
)"y
y
2010 Insight

T he publications shown below can be purchased f rom Helm
Incorporated. You can order by phone or online:Call Helm Inc. at 1-800-782-4356 (credit card orders only)
Go online at
If you are interested in other years or models, contact Helm Inc.
at 1-800-782-4356.Covers maintenance and recommended procedures f or
repair to engine and chassis components. It is written
f or the journeyman mechanic, but it is simple enough
f or most mechanically inclined owners to understand.
Complements the Service Manual by providing in-depth
troubleshooting inf ormation f or each electrical circuit
in your vehicle.
Describes the procedures involved in the replacement
of damaged body parts.
Purchasing Factory Authorized Manuals
Service Manual:
Electrical T roubleshooting Manual:
Body Repair Manual:
(U.S. only)
Authorized Manuals
Authorized Manuals
435
Publication
Form Number 61TM800
61TM800EL
61TMA30
31TM8600
31TM8800
31TM8M00 31TM8Q00 HON-R Form Description
2010 Honda Insight Service Manual 2010 Honda Insight
Electrical Troubleshooting Manual 2010 Model Series Honda Insight Body Repair Manual
2010 Honda Insight Owner’s Manual 2010 Honda Insight
Navigation System Owner’s Manual
2010 Honda Insight Honda Service History
2010 Honda Insight Technology Reference Guide Order Form for Previous Years-
Indicate Year and Model Desired
