This gauge shows you the charge/
discharge status of the Integrated
Motor Assist (IMA). When the IMA
is assisting the engine, the pointer
stays in the assist gauge (upper part
of the gauge). When the IMA
battery is being charged, the pointer
stays in the charge gauge (lower part
of the gauge).You can also check the status of the
IMA system function on the multi-
inf ormation display (see
page).
If the IMA battery is too hot or too
cold, the IMA system limits the IMA
battery’s output power to protect the
battery. This disables the IMA assist
and auto idle stop, even though the
battery level indicator on the multi-
information display may show that
the battery is well-charged (see ~~~~ ). Therefore, if the motor
It takes a short time to normalize the
IMA battery’s output power
depending on the weather. 84
Charge/Assist Gauge
Gauges
74
IMA ASSIST GAUGE
IMA CHARGE GAUGE
12/07/13 16:46:32 31TM8630_079
Inst rument s and Cont rolsTOC
assist is frequently used, the
battery becomes hot and starts to
limit its output power.
page 85
2014 Insight

The multi-inf ormation display in the
instrument panel displays various
inf ormation and messages when the
ignition switch is in the ON (II)
position. Some of the messages help
you operate your vehicle more
comf ortably. Others help to keep
you aware of the periodic
maintenance your vehicle needs f or
continued trouble-f ree driving.If you do not f asten your seat belt,
you will see a ‘‘FASTEN SEAT
BELT’’ message on the multi-
information display when
you turn the ignition switch to
the ON (II)position.
These messages go of f several
seconds af ter the key is inserted into
the ignition switch.
There are three types of messages:
normal display messages, engine oil
lif e and maintenance messages, and
system messages.
You can select the displayed
language and also customize some
vehicle control settings to your liking
with the multi-information display
and the three buttons on the steering
wheel (see
page). You will see an ‘‘ECON ON’’ or
‘‘ECON OFF’’ message on the multi-
inf ormation display according to the
previous ECON setting when you
turn the ignition switch to the ON
(II) position (see
page).
76 127
CONT INUED
Normal Display Messages
Multi-Inf ormation Display
75
ECON is On.
ECON is Off.
12/07/13 16:46:40 31TM8630_080
Inst rument s and Cont rolsTOC
2014 Insight

In the multi-information display, the
system message is also displayed
(seepage ) and you can
customize your vehicle control
settings (see page).
The multi-inf ormation display
consists of an upper segment, a
middle segment and a lower
segment. In the normal display mode, the
upper and middle segments display
trip computer inf ormation, such as
f uel economy or average speed. The
lower segment displays the
odometer/trip meter (A/B), outside
temperature, and engine oil lif e and
maintenance item code(s).
88
91
CONT INUED
Multi-Inf ormation Display
77
MIDDLE
SEGMENT
U.S. model is shown. LOWER
SEGMENTUPPER
SEGMENT
12/07/13 16:46:52 31TM8630_082
Inst rument s and Cont rolsTOC
2014 Insight

Î
Ý
Û
Î
Multi-Inf ormation Display
78
U.S. model is shown.
:
This display will be shown when the
BluetoothHandsFreeLinkis activated. IMA System Power
Flow Monitor/
IMA Battery Level
Indicator
(See
page 84, 85)
: Press the INFO button .
: Press the INFO button .
: Press the SEL/RESET button. HFL (Seepage87
)
Average Fuel
Economy Record
(See page 81)
Engine Oil Life
(Seepage 80)
Outside Temperature
(See page 80) Trip Computer (See
page 81)
Ecological
Drive Display
(See
page 81)
12/07/13 16:46:58 31TM8630_083
Inst rument s and Cont rolsTOC
2014 Insight

This shows the outside Fahrenheit
temperature in U.S. models, and
Celsius temperature in Canadian
models.In certain weather conditions,
temperature readings near f reezing
(32°F, 0°C) could mean that ice is
f orming on the road surf ace.
You can adjust the outside
temperature display (see
page).
The temperature sensor is in the
f ront bumper. The temperature
reading can be affected by heat
ref lection f rom the road surf ace,
engine heat, and the exhaust f rom
surrounding traf f ic. This can cause
an incorrect temperature reading
when your vehicle speed is under
19 mph (30 km/h). When you start
your trip, the sensor is not f ully
acclimatized, theref ore it may take
several minutes until the proper
temperature is displayed.
This shows the remaining engine oil
lif e. It shows 100% af ter the engine
oil is replaced and the display is reset.
The engine oil lif e is calculated
based on engine operating conditions.
For more inf ormation, seepage.
98 299
Outside Temperature
Engine Oil Lif e
Multi-Inf ormation Display
80
OUTSIDE TEMPERATURE ENGINE OIL LIFE
U.S. Canada
12/07/13 16:47:16 31TM8630_085
Inst rument s and Cont rolsTOC
2014 Insight

Mile indication(U.S. models):
Kilometer indication (Canadian models):Average Fuel Economy A:
Average Fuel Economy B:
This shows your vehicle’s instant
f uel economy in mpg. This shows your vehicle’s average
f uel economy in mpg (U.S. models)
or l/100 km
(Canadian models) since
you last reset trip computer A.
This shows your vehicle’s average
fuel economy in mpg (U.S. models)
or l/100 km (Canadian models) since
you last reset trip computer B. You can customize the Trip A and
Average Fuel Economy A reset
condition on the multi-information
display (see
page).
This shows your vehicle’s instant
f uel economy in l/100 km.
When you turn of f the engine, the
instant fuel economy (mpg or The average f uel economy will be
reset when you reset the trip meter,
or if the vehicle’s 12 volt battery goes
dead or is disconnected.
99
A verage Fuel Economy A /B
Inst ant Fuel Economy
Multi-Inf ormation Display
82
U.S.
AVERAGE FUEL
ECONOMY A
AVERAGE FUEL
ECONOMY B
U.S.
INSTANT
FUEL
ECONOMY
Canada Canada
12/07/13 16:47:40 31TM8630_087
Inst rument s and Cont rolsTOC
1/100 km) is also reset.
2014 Insight

The IMA system power f low monitor
shows the status of the IMA system.
The energy source, and powering
status of the engine and IMA motor
(engine operation icon and IMA
battery) are represented by arrows
on the display. The battery level
indicator shows the state of charge
of the IMA battery.The table in the next column shows
the basic monitoring display
examples and their descriptions.
Example
Descriptions
Only IMA motor is
powering the vehicle and
IMA battery is discharging.
IMA motor is assisting the
engine with powering the
vehicle. IMA battery is
discharging and the system
is consuming fuel.
IMA system is charging
IMA battery.
Only engine is powering
vehicle. The system is
consuming f uel.
Engine is powering vehicle
and IMA system is charging
IMA battery. T he system is
consuming f uel.IMA System Power Flow MonitorPowering Status
Multi-Inf ormation Display
84
IMA BATTERY/BATTERY
LEVEL INDICATOR POWER FLOW
ENGINE
OPERATION
ICON
12/07/13 16:47:57 31TM8630_089
Inst rument s and Cont rolsTOC
2014 Insight

ÛÝÛÝ
ÛÝ
If there is a problem with your
vehicle, f or example the engine oil
level is low or a door is not f ully
closed, the multi-inf ormation display
will show you the problem. It does
this by interrupting the current
display with one or more messages. The system message(s) triggers the
appropriate indicator(s) on the
instrument panel, including the
system message indicator, to come
on. The system message indicator
does not go of f until the problem(s)
is corrected.
You will also hear a beep when the
system message comes on f or the
first time.
Most of the messages are displayed
f or about 5 seconds, and then the
normal display returns. If there are
several system messages to be
shown, the display switches these
messages every 5 seconds.
To switch the message(s) bef ore 5
seconds have elapsed, press the
INFO( / )buttononthesteering
wheel.
Even if you press the INFO ( / )
button, some messages stay on or
come on again at regular intervals
until the problem is corrected.
If the system message indicator
remains lit on the instrument panel,
you can see the corresponding
message(s) again by pressing the
INFO ( / ) button repeatedly.
System Messages
Multi-Inf ormation Display
88
SYSTEM MESSAGE INDICATOR
12/07/13 16:48:24 31TM8630_093
Inst rument s and Cont rolsTOC
A list of all messages begins on the
next page:
2014 Insight

Press the ECON button to activate
the ECON mode. ECON ON will be
displayed on the multi-inf ormation
display and the ECON mode
indicator will illuminate in the
instrument panel. Press the ECON
button again to turn it off. ECON
OFF will appear on the multi-
inf ormation display.
The ECON button turns the ECON
mode on and off. The ECON mode
helps you improve your fuel
economy by modifying some
vehicle functions. When the ECON
mode is on: In addition, when the ECON mode is
on, you may get more Eco Assist
points (seepage).
The climate control system will
have greater temperature
f luctuations Engine perf ormance will be
dif f erent Whenyouturnoff andthenrestart
the engine, the ECON mode setting
remains the same as previously set.
264
ECON Button
127
MULTI-INFORMATION DISPLAY ECON MODE INDICATOR
ECON BUTTON
12/07/13 16:53:12 31TM8630_132
Inst rument s and Cont rolsTOC
2014 Insight

These keys contain electronic
circuits that are activated by the
immobilizer system. They will not
work to start the engine if the
circuits are damaged.Protect the keys f rom direct
sunlight, high temperature, and
high humidity.
Donotdropthekeysorsetheavy
objects on them.
Keep the keys away f rom liquids.
If they get wet, dry them
immediately with a sof t cloth.
Two ignition keys come with your
vehicle. You should keep one of
them in a saf e place, away f rom the
vehicle, as a spare.
They f it all the locks on your vehicle. Youshouldhavereceivedakey
number tag with your keys. You will
need this number if you ever have to
get a lost key replaced. Use only
Honda-approved key blanks.
Keys and Locks
129
KEY
NUMBER
TAG
IGNITION KEYS
WITH REMOTE
TRANSMITTER
12/07/13 16:53:26 31TM8630_134
Inst rument s and Cont rolsTOC
