ignition HONDA INSIGHT 2014 2.G Owner's Guide

µ
µ
The ignition switch has f our
positions: LOCK (0), ACCESSORY
(I), ON (II), and START (III). You can
operate the audio system and
the accessory power sockets
in this position.
If you leave the key in the ignition
switch in the ACCESSORY (I)
position and open the driver’s door,
you will see a ‘‘RETURN IGNITION
SWITCH TO LOCK (0) POSITION’’
message on the multi-inf ormation
display and hear a reminder beeper.
If you turn the ignition key to the
ACCESSORY (I) position with the
driver’s door closed, you will see an
‘‘ACCESSORY (I) POSITION’’
message on the multi-information
display to inform you of the key
position.
You can insert or
remove the key only in this position.
To turn the key, the shift lever must
be in Park, and you must push the
key in slightly.
If the f ront wheels are turned, the
anti-thef t lock may make it dif f icult
to turn the key. Firmly turn the
steering wheel to the lef t or right as
you turn the key.
CONT INUED
A CCESSORY (I)
LOCK (0)
Ignition Switch
131
12/07/13 16:53:40 31TM8630_136
Inst rument s and Cont rolsTOC
2014 Insight

µ
µ Use this position
only to start the engine. The switch
returns to the ON (II) position when
you let go of the key.
You will hear a reminder beeper if
you leave the key in the ignition
switch in the LOCK (0) or the
ACCESSORY (I) position and open
thedriver’sdoor.Removethekeyto
turn of f the beeper.
You will also see a ‘‘REMOVE KEY’’
message on the multi-inf ormation
display.
TheshiftlevermustbeinPark
bef ore you can remove the key f rom
the ignition switch.
This is the normal key
position when driving. Several of
the indicators on the instrument
panel come on as a test when
you turn the ignition switch
from the ACCESSORY (I) to the
ON (II) position. ST A RT (III)
ON (II)
Ignition Switch
132
12/07/13 16:53:44 31TM8630_137
Inst rument s and Cont rolsTOC
2014 Insight

The childproof door locks are
designed to prevent children seated
in the rear f rom accidentally opening
the rear doors. Each rear door has a
lock lever near the edge. With the
lever in the LOCK position (lever is
down), the door cannot be opened
f rom the inside regardless of the
position of the lock tab. To open the
door, push the lock tab f orward and
use the outside door handle.
To lock any passenger’s door when
getting out of the vehicle, pull the
lock tab rearward and close the
door. To lock the driver’s door,
remove the key from the ignition
switch, pull the lock tab rearward or
push the front of the master switch,
then close the door.
When the vehicle speed reaches
about 10 mph (U.S.)/15 km/h
(Canada) or more, all the doors and
the hatch lock automatically.
When you shif t to P af ter driving, the
driver’s door unlocks.
If you f orget and leave the key in the
ignition switch, lockout prevention
will not allow you to lock the driver’s
door. With any door or the hatch
open and the key in the ignition
switch, locking with master door
lock switch is disabled. If the driver’s
door is closed, the lock tab on the
driver’s door is not disabled. Pulling
the driver’s lock tab rearward will
lock all doors and the hatch. If you
try to lock an open driver’s door by
pulling the lock tab rearward, the
driver’s door lock tab pops out and
unlocks the driver’s door.
Def ault setting
L ockout Prevent ion
Childproof Door L ocks
Door L ocks
134
Unlock
Lock
LEVER
12/07/13 16:53:59 31TM8630_139
Inst rument s and Cont rolsTOC
2014 Insight

µµ
The ceiling light and the door
activated spotlights come on when
you press the UNLOCK button if the
lights are in the door activated
position. If you do not open any door
or the hatch within 30 seconds (or
whatever setting of the interior light
dimming time is set to), the light(s)
will f ade out. If you relock the doors
and the hatch with the remote
transmitter before 30 seconds have
elapsed, the light(s) will go of f
immediately.
To change the lock/unlock setting
and the relock timer setting, refer to
the customized settings on
page .
The keyless lock acknowledgment
beep and f lashing of the lights can
be deactivated (see
page).
Press this button once to
lock all doors and the hatch. Some
exterior lights will f lash once. When
you press LOCK twice within 5
seconds, the horn will sounds to
verif y that the doors are locked. You
cannot lock the doors if any door or
the hatch is not f ully closed or if the
key is in the ignition switch. If you press the LOCK button twice
within 5 seconds, you will hear a
horn to verify that the security
system has set.
Press this button once
to unlock the driver’s door (or all the
doors and the hatch depending on
the door lock setting). Press it twice
to unlock the remaining doors and
the hatch. Some exterior lights will
f lash twice when you press the
button the first time.
If you do not open any door or the
hatch within 30 seconds, they will
automatically relock, and the
security system (if equipped) will
reset. 114
108
CONT INUED
On LX and EX models
LOCK UNL OCK
Remote Transmitter
135
LED
LOCK BUTTON
UNLOCK
BUTTON PANIC
BUTTON
12/07/13 16:54:07 31TM8630_140
Inst rument s and Cont rolsTOC
2014 Insight

µAvoid dropping or throwing the
transmitter.
Protect the transmitter from
extreme temperatures.
Do not immerse the transmitter in
any liquid.
If you lose a transmitter, the
replacement needs to be
reprogrammed by your dealer. If it takes several pushes on the
button to lock or unlock the doors,
replace the battery as soon as
possible.
Battery type: CR1616
Press and hold this
button for about 1 second to attract
attention; the horn will sound, and
the exterior lights will f lash f or about
30 seconds. To cancel panic mode,
press any other button on the remote
transmitter, or turn the ignition
switch to the ON (II) position. Panic
mode does not work when the key is
in the ignition switch.Remote Transmitter CareReplacing
the Transmitter Battery
PA NIC
Remote Transmitter
136
12/07/13 16:54:14 31TM8630_141
Inst rument s and Cont rolsTOC
2014 Insight

Keeptheinsideandoutsidemirrors
clean and adjusted f or best visibility.
Be sure to adjust the mirrors bef ore
you start driving.
The inside mirror has day and night
positions. The night position
reduces glare from headlights
behind you. Flip the tab on the
bottom edge of the mirror to select
the day or night position.Move the selector switch to L
(driver’s side) or R
(passenger’s side). Turn the ignition switch to the ON
(II) position.Push the appropriate edge of the
adjustment switch to move the
mirrorright,left,up,ordown.
When you f inish, move the
selector switch to the center (off)
position. This turns the
adjustment switch off to keep \
1.
2. 3.
4.
Adjusting the Power Mirrors
Mirrors
147
SELECTOR
SWITCH
ADJUSTMENT
SWITCH
TAB
UP
DOWN
Night Position
Daytime Position
12/07/13 16:55:33 31TM8630_152
Inst rument s and Cont rolsTOC
your settings.
2014 Insight

The outside mirrors are heated to
remove fog and frost. With the
ignition switch in the ON (II)
position, turn on the heaters by
pressing the rear window def ogger
button. The indicator in the button
comesonasareminder.Pressthe
button again to turn the heaters and
the def ogger of f .This heated mirror f unction has a
timer (see
page).
126
On U.S. EX models
and all Canadian models
Power Mirror Heaters
Mirrors
148
HEATED MIRROR BUTTON
12/07/13 16:55:38 31TM8630_153
Inst rument s and Cont rolsTOC
2014 Insight

µ
Turn the ignition switch to the ON
(II) position to raise or lower any
window. To open a window, push the
switchdownandholdit.Releasethe
switch when you want the window to
stop. Pull back on the switch and
hold it to close the window. To open or close the
driver’s window, push or pull the
window switch firmly down or up to
the second detent, and release it.
The window will automatically go
down or up all the way. To stop the
window, pull or push the window
switch brief ly.
CONT INUED
AUTO
Power Windows
149
DRIVER’S
WINDOW
SWITCH FRONT
PASSENGER’S
WINDOW SWITCH
MAIN SWITCH
Closing a power window on
someone’s hands or fingers can
cause serious injury.
Make sure your passengers are
away from the windows before
closing them.
12/07/13 16:55:43 31TM8630_154
Inst rument s and Cont rolsTOC
2014 Insight

µ
Auto reverse stops sensing when the
window is almost closed. You should
always check that all passengers and
objects are away from the window
bef ore closing it. The driver’s window auto
reverse f unction is disabled when
you continuously pull up the switch. If the driver’s
window senses any obstacle while it
is closing automatically, it will
reverse direction, and then stop. To
close the window, remove the
obstacle, then use the window
switch again.
The windows and the main switch
feature will operate for up to 10
minutes after you turn off the
ignition switch. Opening either f ront
door cancels this f unction. When you push the main switch in,
the indicator comes on and the
passengers’ windows cannot be
raised or lowered. Use the main
switchwhenyouhavechildreninthe
vehicle so they do not injure
themselves by operating the
windows unintentionally. To cancel
this feature, push on the switch
again. The switch will pop out. AUTO REVERSE
Power Windows
150
NOTE:
12/07/13 16:55:48 31TM8630_155
Inst rument s and Cont rolsTOC
2014 Insight

Your vehicle has an accessory power
socket in the f ront console panel.
To use an accessory power socket,
the ignition switch must be in the
ACCESSORY (I) or ON (II) position.
This socket is intended to supply
power for 12 volt DC accessories
that are rated 120 watts or less
(10 amps).It will not power an automotive type
cigarette lighter element.
Make sure to put the socket cover
back in place to prevent any small
foreign objects from getting into
the socket.
To open the console compartment,
pull up on the lever and lif t the
armrest.
To close, lower the armrest, and
push it down until it latches.On EX and U.S. LX models
Interior Convenience Items
Accessory Power Socket Console Compartment
155
LEVER
12/07/13 16:56:19 31TM8630_160
Inst rument s and Cont rolsTOC
2014 Insight
