service indicator HONDA INSIGHT 2014 2.G Owners Manual

(seat belts, SRS, and child protection)
(main controls)
(indicators, gauges, multi-inf ormation display, dashboard, and steering column)
(climate control, audio, steering wheel, security, cruise control, and other convenience items) (fuel, vehicle break-in, and cargo loading)
(engine and transmission operation) (minder, f luid checking, minor services, and vehicle storage) (f lat tire, jump starting, overheating, and f uses)
(vehicle specif ications, tires, and emissions controls) (warranty and contact inf ormation)
(how to order)
Contents
............................................................
Driver and Passenger Saf ety .5
........................................................................\
........................................................................
Index .I
Service Inf ormation Summary ........................................................................\
.......................
Your Vehicle at a Glance .3
.......
Instruments and Controls .59
............
Features .161
.......................................................................
Bef ore Driving .243
........................................................................\
.................
Driving .261
.................................................
Maintenance .297
........................................
T aking Care of the Unexpected .347
..............................................
T echnical Inf ormation .377
..................
Warranty and Customer Relations (U.S. and Canada only) .393
........................................................................\
..........
A uthorized Manuals (U.S. only) .397
1
12/07/13 16:36:55 31TM8630_006
Owner's Identification Form
Index
Bo ok Ta ble of Contents
Chapter Ta ble of Contents
Navigation KeyYour Vehicle at a Glance
2014 Insight

A summary of the inf ormation you
need when you pull up to the f uel
pump. How to order manuals and other
technical literature.
A convenient ref erence to the
sections in this manual.
A quick ref erence to the main
controls in your vehicle.
What gasoline to use, how to break-
in your new vehicle, and how to load
luggage and other cargo.
The proper way to start the engine,
shif t the transmission, and park.
A summary of the warranties
covering your new vehicle, and how
to contact us for any reason. Refer to
your warranty manual f or detailed
inf ormation.
The Maintenance Minder shows
you when you need to take your
vehicle to the dealer for maintenance
service. There is also a list of things
to check and instructions on how to
check them.
ID numbers, dimensions, capacities,
and technical information. This section covers several problems
motorists sometimes experience,
and details how to handle them.
Important inf ormation about the
proper use and care of your vehicle’s
seat belts, an overview of the
supplemental restraint system, and
valuable inf ormation on how to
protect children with child restraints.
Explains the purpose of each
instrument panel indicator and gauge,
the multi-information display, and
how to use the controls on the
dashboard and steering column.
How to operate the climate control
system, the audio system, and other
convenience f eatures.
Overview of Contents
Contents
Your Vehicle at a Glance
Driver and Passenger Saf ety
Instruments and Controls Bef ore Driving
Driving
Maintenance
Warranty and Customer
Relations
(U.S. and Canada only)
Authorized Manuals
(U.S. only)
Index
Service Inf ormation Summary
T echnical Inf ormation T aking Care of the Unexpected
Features
2
TM
12/07/13 16:37:13 31TM8630_007
2014 Insight

µ
This section gives you important
inf ormation about how to protect
yourself and your passengers. It
shows you how to use seat belts. It
explains how your airbags work. And
it tells you how to properly restrain
inf ants and children in your vehicle.
.........
Important Safety Precautions . 6
.......
Your Vehicle’s Saf ety Features . 8
.......................................
Seat Belts . 9
.........................................
Airbags .10
.........
Protecting Adults and Teens . 12
.....
1. Close and Lock the Doors . 12
...........
2. Adjust the Front Seats . 14
............
3. Adjust the Seat-Backs . 15
...
4. Adjust the Head Restraints . 16
5. Fasten and Position the .............................
Seat Belts .17
6. Maintain a Proper Sitting ................................
Position .18
.....
Advice f or Pregnant Women . 19
...
Additional Safety Precautions . 20Additional Inf ormation About
.......................
Your Seat Belts .21
..
Seat Belt System Components . 21
......................
Lap/Shoulder Belt .22
Automatic Seat Belt ...............................
Tensioners .23
...............
Seat Belt Maintenance . 24
Additional Inf ormation About ...........................
Your Airbags .25
......
Airbag System Components . 25
How Your Front Airbags .........................................
Work .28
...
How Your Side Airbags Work . 32
How Your Side Curtain Airbags .........................................
Work .33
..
How the SRS Indicator Works . 34
How the Side Airbag Of f ......................
Indicator Works .34
How the Passenger Airbag Of f ......................
Indicator Works .35
.............................
Airbag Service .36
...
Additional Safety Precautions . 37
Protecting Children General ................................
Guidelines .38
All Children Must Be ...............................
Restrained .38 All Children Should Sit in a
.................................
Back Seat .39
The Passenger’s Front Airbag .........
Can Pose Serious Risks . 39
If You Must Drive with Several ...................................
Children .41
If a Child Requires Close ..................................
Attention .41
...
Additional Safety Precautions . 42
Protecting Inf ants and Small ...................................
Children .43
.......................
Protecting Inf ants .43
.........
Protecting Small Children . 44
.....................
Selecting a Child Seat .45
....................
Installing a Child Seat .46
...............................
With LATCH .47
.........
With a Lap/Shoulder Belt . 49
..............................
With a Tether .51
...........
Protecting Larger Children . 52
...............
Checking Seat Belt Fit . 52
..................
Using a Booster Seat . 53
When Can a Larger Child Sit in .........................................
Front .54
...
Additional Safety Precautions . 55
.............
Carbon Monoxide Hazard . 56
...................................
Saf ety Labels .57
Driver and Passenger Saf ety
Driver and Passenger Saf ety
5
12/07/13 16:37:31 31TM8630_010
2014 Insight

Take your vehicle to an
authorized dealer as soon as
possible. If you ignore this
indication, your airbags may not
operate properly.
Even if your
airbags do not inflate, your dealer
should inspect the driver’s seat
position sensor, the f ront
passenger’s weight sensors, the
f ront seat belt tensioners, and all
seat belts and their anchors worn
during a crash to make sure they
are operating properly.
Your airbag systems are virtually
maintenance f ree, and there are no
parts you can saf ely service.
However, you must have your
vehicle serviced if:
Any airbag
that has deployed must be
replaced along with the control
unit and other related parts. Any
seat belt tensioner that activates
must also be replaced.
If no obstructions are f ound, have
your vehicle checked by a dealer as
soon as possible. If the indicator comes on with no
f ront seat passenger and no objects
on the seat, or with an adult riding
there, something may be interf ering
with the weight sensors. Look f or
and remove: Any items under the f ront
passenger’s seat.
Any object(s) hanging on the seat
or in the seat-back pocket.
Any object on the f loor that is
touching the rear of the seat-back.
Do not try to remove or replace
anyairbagbyyourself.Thismust
be done by an authorized dealer or
a knowledgeable body shop. We recommend against the use
of salvaged airbag system
components, including the
airbag, tensioners, sensors,
and control unit.
Additional Inf ormation About Your Airbags
T he SRS indicat or alert s you t o aproblem.
If your vehicle has a moderat e t osevere impact .
An airbag ever inf lates.Airbag Service
36
12/07/13 16:41:19 31TM8630_041
Driver and Passenger Saf etyTOC
2014 Insight

If this happens, pull to the side of the
road when it is safe, check which tire
has lost pressure, and determine the
cause. If it is because of a f lat tire,
replace the flat tire with the compact
spare (seepage), and have the
f lat tire repaired as soon as possible.
If two or more tires are underinf lated,
call a prof essional towing service.
Refer to page for more
inf ormation.
If this indicator begins to flash,
there is a problem with the tire
pressure monitoring system
(TPMS). You will also see a
‘‘CHECK TPMS SYSTEM’’
message on the multi-information
display. The indicator continues to
flash for a while (approximately 1
minute), then stays on. If this
happens, have your dealer check
the system as soon as possible.
For more information, see .
This indicator normally comes on
for a few seconds when you turn
the ignition switch to the ON (II)
position. If it comes on at any
other time, it indicates a
problem in the integrated motor
assist (IMA) system. With the IMA
indicator on, the vehicle may not
accelerate as it normally does. Have
the vehicle checked by the dealer
as soon as possible.
You will also see a ‘‘CHECK IMA
SYSTEM’’ message on the multi-
inf ormation display.
See pages and .
You will also see a ‘‘CHECK TIRE
PRESSURE’’ message on the multi-
inf ormation display (see
page ).
If it comes on while driving, it
indicates that one or more of your
vehicle’s tires are signif icantly low
on pressure.
This indicator has two f unctions: This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position.
1.
2.
281 283 289349
374
U.S. models only
Instrument Panel Indicators
Low Tire Pressure/
TPMS Indicator
IMA System Indicator
A uto Idle Stop Indicator
66
12/07/13 16:45:34 31TM8630_071
Inst rument s and Cont rolsTOC
page 290
2014 Insight

Help assure your vehicle’s f uture
reliability and perf ormance by paying
extra attention to how you drive
during the f irst 600 miles (1,000 km).
During this period:Avoid full-throttle starts and rapid
acceleration.
You should also f ollow these
recommendations with an
overhauled or exchanged engine, or
when the brakes are replaced. Your vehicle is designed to operate
on unleaded gasoline with a pump
octane number of 87 or higher. Use
of a lower octane gasoline can cause
a persistent, heavy metallic rapping
noise that can lead to engine damage.
Do not change the oil until the
scheduled maintenance time.
Avoidhardbrakingforthefirst
200 miles (300 km). Use of gasoline with these additives
may adversely affect performance,
and cause the malfunction indicator
lamp on your instrument panel to
come on. If this happens, contact
your dealer for service. Some
gasoline today is blended with
oxygenates such as ethanol. Your
vehicle is designed to operate on
oxygenated gasoline
containing up to 15% ethanol by
volume. Do not use gasoline
containing methanol. If you notice
any undesirable operating
symptoms, try another service
station or switch to another brand
of gasoline.
Break-in Period
Fuel Recommendation
Break-in Period, Fuel Recommendation
244
T o help prevent harmf ul f uel system
and engine deposits, use high quality
f uel containing detergent and additives.
In addition, in order to maintain good
perf ormance, f uel economy, and
emissions control, we strongly
recommend the use of gasoline that
does NOT contain harmf ul manganese-
based f uel additives such as MMT , if
such gasoline is available.
12/07/13 17:08:06 31TM8630_249
Bef ore DrivingTOC
2014 Insight

Your vehicle’s on board diagnostic
system will detect a loose or missing
fuel fill cap as an evaporative system
leak. The first time a leak
is detected a ‘‘TIGHTEN FUEL
CAP’’ message appears on the multi-
information display.Turn the engine of f , and conf irm the
f uel f ill cap is installed. If it is, loosen
it, then retighten it until it clicks at
least once. The message should go
off after several days of normal
driving once you tighten or replace
thefuelfillcap.Toscrolltoanother
message, press the INFO button.
The ‘‘TIGHTEN FUEL CAP’’
message will appear each time you
restart the engine until the system
turns the message off.
Screw the fuel fill cap back on
until it clicks at least once. If you
do not properly tighten the cap,
you will see a ‘‘TIGHTEN FUEL
CAP’’ message on the multi-
inf ormation display. If the system
still detects an evaporative system
leak af ter retightening the cap, the
malf unction indicator lamp may
come on (see
page).
Push the f uel f ill door closed until
it latches.
6. 5.
365
CONT INUED
Tighten Fuel Cap Message
Service Station Procedures
247
12/07/13 17:08:26 31TM8630_252
Bef ore DrivingTOC
2014 Insight

Park the vehicle, and set the
parking brake. Pull the hood
release handle located under the
lower lef t corner of the dashboard.
The hood will pop up slightly.
If the system still detects a leak in
the vehicle’s evaporative emissions
system, the malf unction indicator
lamp (MIL) comes on. If the f uel f ill
cap was not already tightened, turn
the engine of f , and check or
retighten the f uel f ill cap until it
clicks at least once. The MIL should
go off after several days of normal
driving once the cap is tightened or
replaced. If the MIL does not go of f ,
have your vehicle inspected by a
dealer. For more inf ormation, see
page
.
If the hood latch handle moves
stiffly, or if you can open the
hood without lifting the handle,
the mechanism should be
cleaned and lubricated. Put your f ingers under the f ront
edge of the hood near the center.
Slide your hand to the lef t until
you f eel the hood latch handle.
Push this handle to the lef t to
release the hood. Lif t up the hood.
1.
2.
365 Opening and Closing the Hood
Service Station Procedures
248
LATCH
HOOD RELEASE HANDLE
Pull
12/07/13 17:08:33 31TM8630_253
Bef ore DrivingTOC
2014 Insight

If you think you can safely drive a
short distance to a service station,
proceed slowly to the station, then
inflate the tire to the
recommended pressure.
Driving on a signif icantly under-
inf lated tire causes the tire to
overheat and can lead to tire failure.
Under-inf lation also reduces f uel
efficiency and tire tread life, and may
af f ect the vehicle’s handling and
stopping ability.
Becausetirepressurevariesby
temperature and other conditions,
the low tire pressure/TPMS
indicator may come on unexpectedly. If the tire is flat, or if the tire
pressure is too low to continue
driving, replace the tire with the
compact spare tire (seepage).
When the low tire pressure/TPMS
indicator is on, one or more of your
tires is significantly underinflated.
You should stop and check your
tires as soon as possible, and inflate
them to the proper pressure
as indicated on the vehicle’s tire
information placard.
Your vehicle is equipped with a tire
pressure monitoring system (TPMS)
that turns on every time you start the
engine and monitors the pressure in
your tires while driving.
Each tire has its own pressure
sensor. If the air pressure of a tire
becomes signif icantly low, the
sensor in that tire immediately sends
a signal that causes the low tire
pressure/TPMS indicator in the
instrument panel to come on. If this
happens, you will see a ‘‘CHECK
TIRE PRESSURE’’ message on the
multi-inf ormation display.
If you cannot make the low tire
pressure/TPMS indicator and
message on the multi-information
display go out after inflating the
tires to the specified values, have
your dealer check the
system as soon as possible. 348
CONT INUED
U.S. models onlyLow Tire Pressure/
TPMS Indicator
Tire Pressure Monitoring System (TPMS)
289
12/07/13 17:13:58 31TM8630_294
Bef ore DrivingTOC
2014 Insight

This indicator and the warning
message on the multi-inf ormation
display will go of f , af ter several miles
(kilometers) driving, when the spare
tire is replaced with the specified
regular tire equipped with the tire
pressure monitor sensor.
Also, the low tire pressure/TPMS
indicator begins to f lash, then stays
on (see
page ).
If the low tire pressure/TPMS
indicator comes on, or the multi-
inf ormation display shows a
‘‘CHECK TPMS SYSTEM’’ message,
the VSA system automatically turns
on even when the VSA system is
turned of f by pressing the VSA OFF
switch (see page). If this
happens, you cannot turn the VSA
system of f by pressing the VSA OFF
switch again.
When you restart the vehicle with
thecompactsparetire,theTPMS
system message will also be
displayed on the multi-inf ormation
display af ter several miles
(kilometers) driving. If you have a f lat tire, the low tire
pressure/TPMS indicator will come
on. Replace the f lat tire with the
compact spare tire (see
page).
After the flat tire is replaced with
the spare tire, the low tire pressure/
TPMS indicator stays on while
driving. After several miles
(kilometers) driving, this indicator
begins to flash, then stays on again.
You will also see a ‘‘CHECK TPMS
SYSTEM’’ message on the multi-
information display. This is normal;
the system cannot monitor the
spare tire pressure. Manually check
the spare tire pressure to be sure it
is correct. Each wheel (except the compact
sparetirewheel)isequippedwitha
tire pressure sensor. You must use
TPMS specif ic wheels. It is
recommended that you always have
your tires serviced by your dealer or
qualif ied technician.
289
294 349
CONT INUED
Changing a T ire with T PMS
Tire Pressure Monitoring System (TPMS)
291
12/07/13 17:14:13 31TM8630_296
Bef ore DrivingTOC
2014 Insight
