Page 341 of 420

HONDA ODYSSEY 2006 RB1-RB2 / 3.G Owners Manual Pour the f luid slowly and caref ully
so you do not spill any. Clean up
any spill immediately; it could
damage components in the engine
compartment.
Always use Honda ATF-Z1
(automatic transmission f l

Page 342 of 420

HONDA ODYSSEY 2006 RB1-RB2 / 3.G Owners Manual Always use Honda Heavy Duty
Brake Fluid DOT 3. If it is not
available, you should use only DOT 3
or DOT 4 f luid, f rom a sealed
container, as a temporary
replacement.
Using any non-Honda brake f luid

Page 343 of 420

HONDA ODYSSEY 2006 RB1-RB2 / 3.G Owners Manual µµ
Always use Honda Power Steering
Fluid. You may use another power
steering f luid as an emergency
replacement, but have the power
steering system f lushed and ref illed
with Honda PSF as soon as

Page 344 of 420

HONDA ODYSSEY 2006 RB1-RB2 / 3.G Owners Manual Your vehicle has halogen headlight
bulbs, two on each side. When
replacing a bulb, handle it by its base
and protect the glass from contact
with your skin or hard objects. If you
touch the glass, clea

Page 345 of 420

HONDA ODYSSEY 2006 RB1-RB2 / 3.G Owners Manual Remove the electrical connector
f rom the bulb by pushing on the
tab and pulling the connector
down.
Remove the bulb by turning it one-
quarter turn counterclockwise.Open the hood. Remove the
socket f

Page 346 of 420

HONDA ODYSSEY 2006 RB1-RB2 / 3.G Owners Manual Insert the socket back into the
headlight assembly. Turn it
clockwise to lock it in place.
Turn on the lights to make sure
the new bulb is working.Open the hood. Remove the
socket f rom the headlight

Page 347 of 420

HONDA ODYSSEY 2006 RB1-RB2 / 3.G Owners Manual Use a wrench to remove the
mounting bolt f rom the underbody
through the hole in the splash
shield.
Remove the f og light assembly
f rom the bumper by pulling its
inner edge f irst, then the whole
ass

Page 348 of 420

HONDA ODYSSEY 2006 RB1-RB2 / 3.G Owners Manual Remove the two bolt covers on the
rear pillar by prying on the bottom
edge with a flat-tip screwdriver.
Remove the bolts with a Phillips-
head screwdriver, and remove the
light assembly f rom the rear

Page 349 of 420

HONDA ODYSSEY 2006 RB1-RB2 / 3.G Owners Manual Remove the socket f rom the light
assembly by turning it one-quarter
turn counterclockwise.
Pull the bulb straight out of its
socket. Push a new bulb into the
socket until it bottoms. Reinstall
the as

Page 350 of 420

HONDA ODYSSEY 2006 RB1-RB2 / 3.G Owners Manual If your seat belts get dirty, use a sof t
brush with a mixture of mild soap
and warm water to clean them. Do
not use bleach, dye, or cleaning
solvents. Let the belts air dry bef ore
you use the vehicl
