TPMS HONDA ODYSSEY 2008 RB1-RB2 / 3.G Owner's Manual

Replace your tires with radial tires of
the same size, load range, speed
rating, and maximum cold tire
pressure rating (as shown on the
tire’s sidewall).
Mixing radial and bias-ply tires on
your vehicle can reduce braking
ability, traction, and steering
accuracy. Using tires of a dif f erent
size or construction can cause the
ABS and vehicle stability assist
system (VSA) to work inconsistently.
The ABS and VSA system work by
comparing the speed of each wheel.
When replacing tires, use the same
size originally supplied with the
vehicle. Tire size and construction
can af f ect wheel speed and may
cause the system to activate.Your vehicle is not designed f or
Michelin PAX system wheels or tires.
Useonlythewheelsandtires
designated in this owner’s manual.
Never mix conventional wheels or
tires with PAX system wheels or
tires.
It is best to replace all f our tires at
thesametime.If thatisnotpossible
or necessary, replace the two f ront
tires or two rear tires as a pair.
Replacing just one tire can seriously
af f ect your vehicle’s handling.
If you ever replace a wheel, make
sure that the wheel’s specif ications
match those of the original wheels.
Also be sure you use only TPMS
specif ic wheels. If you do not, the
tire pressure monitoring system will
not work.Replacement wheels are available at
your dealer.
Vehicles without the Michelin PAX
system
Tires
Replacing T ires and Wheels
446
Installing improper tires on your
vehicle can affect handling and
stability. This can cause a crash
in which you can be seriously
hurt or killed.
Always use the size and type of
tires recommended in this
owner’s manual.
——y
y
(y
y
2008 Odyssey

´Ì
Wheels: Tires marked ‘‘M S’’ or ‘‘All
Season’’ on the sidewall have an all-
weather tread design suitable for
most winter driving conditions.
For the best perf ormance in snowy
or icy conditions, you should install
snow tires or tire chains. They may
be required by local laws under
certain conditions.
If you mount snow tires on your
vehicle, make sure they are radial
tires of the same size and load range
as the original tires. Mount snow
tires on all f our wheels. The traction
provided by snow tires on dry roads
maybelowerthanyouroriginaltires.
Check with the tire dealer f or
maximum speed recommendations.
There are no snow tires compatible
with the PAX system.
Tires:
Mount tire chains on your tires when
required by driving conditions or
local laws. Install them only on the
f ront tires.
Because your vehicle has limited tire
clearance, Honda strongly
recommends using the chains listed
below.
See page f or inf ormation about
DOT Tire Quality Grading, and page f or tire size and labeling
inf ormation. 488
490 Link-type: SCC Quick Grip QG1142
Cable-type: SCC SC Cable SC1042
Link-type: Laclede 1142
Cable-type: SCC SC Cable SC1042 Link-type: SCC Quick Grip QG1138
Cable-type: SCC SC Cable SC1038
CONT INUED
On models with the Michelin PAX
system
On models with the Michelin PAXsystem
All models except Touring models
All models except Touring models
Touring models without the Michelin
PAX system
Touring models without the MichelinPAX system All except Touring models
On models with Michelin PAX system
On Touring models
Tires
Wheel and T ire Specif ications Winter Driving
Snow T iresTire Chains
Maint enance
447
16x7J
225 x 460A
235/65R16 103T
235-710R460A 104T 17x7J
235/60R17 102T
(TPMS) (TPMS)
(TPMS&PAX)
(PAX)
——y
y
(yy
2008 Odyssey

Your vehicle is equipped with the
Michelin PAX system which,
together with the tire pressure
monitoring system (TPMS), enables
you to continue driving even if one or
more of your tires loses its pressure.
The tires and wheels on your vehicle
are specially designed f or the PAX
system, and the PAX system is
specif ically designed and f ine-tuned
foryourvehicle.
Because of these reasons, use only
the wheels and tires designated in
this owner’s manual. Never mix PAX
system wheels or tires with
conventional wheels or tires.There are no snow tires compatible
with the PAX system, and not all tire
chains are suitable f or use on the
PAX system tires.
If you mount snow chains on your
tires, use the chains recommended
by Honda (see page ).
Do not replace the PAX system tires
and wheels with conventional tires
andwheels.Doingsowoulddisable
the PAX system and the tire
pressure monitoring system (TPMS),
and may void your new vehicle
warranty.
Never use a tire repair agent in a
PAX system tire, and never repair
a PAX system tire by yourself .
Repair or replacement must be
done by a Honda dealer or an
authorized Michelin PAX system
dealer.
If you must continue driving with a
f lat tire, f ollow all the procedures
and precautions described on page
.
447
458
If equipped
Tires
MichelinPAX SystemImport ant Precaut ions
Maint enance
449
TM
——y
y
(yy
2008 Odyssey

Your vehicle is equipped with the
Michelin PAX system. Since each
Michelin PAX system tire has an
inner support ring that allows it to
continue running without air, it may
be dif f icult to immediately judge
f rom its appearance if a tire is
punctured. Your vehicle is also
equipped with a tire pressure
monitoring system (TPMS), and this
system may be your f irst detection of
a f lat tire. The TPMS monitors the air pressureof all f our tires whenever the ignition
switch is in the ON (II) position. It
will immediately sense if a tire starts
to lose its pressure, and give you
warning with the low tire pressure/
TPMS indicator in the instrument
panel and a ‘‘CHECK TIRE
PRESSURE’’ message on the multi-
inf ormation display. If the indicator
and the warning message do not
come on again af ter you inf late the
tire to its correct air pressure (seepage ), it was probably a natural
loss of the air pressure and you can
continue driving as bef ore.
If the indicator and the message
come on again, you probably have a
flat tire. In this case, you will see a
‘‘PAX SYSTEM WARNING’’
message on the multi-information
display.
444
If equipped
Driving With a Flat Tire
MichelinPAX System
454
TM
——y

y
(yy
2008 Odyssey

Replace the tire when you can see
the tread wear indicator bars. The
replacement should be the same size
and design tire, mounted on the
same wheel. The spare tire is not
designed to be mounted on a regular
wheel, and the spare wheel is not
designed f or mounting a regular tire.
Use the compact spare tire as a
temporary replacement only. Get
your regular tire repaired or replaced,
and put it back on your vehicle as
soon as you can.
Check the inf lation pressure of the
compact spare tire every time you
check the other tires. It should be
inf lated to:
Follow these precautions:
Never exceed 50 mph (80 km/h).
This tire gives a harsher ride and
less traction on some road
surf aces. Use greater caution
while driving.
Do not mount snow chains on the
compact spare tire. Do not use your compact spare
tire on another vehicle unless it is
thesamemakeandmodel.
The low tire pressure indicator
comes on and stays on af ter you
replace the flat tire with the
compact spare tire. Af ter several
miles (kilometers) driving with the
compact spare tire, the TPMS
indicator comes on and the low
tire pressure indicator goes of f .
After the flat tire is replaced with
the spare tire, the low tire
pressure/TPMS indicator stays on.
Af ter several miles (kilometers)
driving with the spare, this
indicator begins to f lash, then
stays on again. You will also see a
‘‘CHECK TPMS SYSTEM’’
message on the multi-inf ormation
display (see page ).
395
Models without Michelin PAX System
Except Touring models
Touring models
Compact Spare T ire
T aking Care of t he Unexpect ed
457
INDICATOR LOCATION MARK
TREAD WEAR INDICATOR BAR
60 psi (420 kPa , 4.2 kgf/cm)
——y
y
(yy
2008 Odyssey

µµ
Î
Î ÎÎ
Î
Î Î
No.
No. Amps. Amps.
Circuits Protected Circuits Protected
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17 7.5 A
15 A
10 A
15 A
10 A
7.5 A
7.5 A
15 A
7.5 A 30 A
15 A
20 A
20 A
20 A
20 A
20 A 15 A
15 A
10 A
7.5 A 10 A
7.5 A 20 A
20 A
20 A
20 A
20 A
10 A
15 A
10 A
7.5 A
TPMS
IG Coil
Daytime Running Light
LAF
Radio
Interior Lights
Back Up
Not Used
Front Accessory Socket
OPDS
IG Wiper
Rear Accessory Socket
Left Power Sliding Door
Closer
Driver Power Seat Slide
Pedal Position Adjustment
Dr Power Seat Recline
Power Tailgate Closer IG ACG
IG Fuel Pump
IG Washer
IG Meter
IG SRS
IGP
Left Rear Power Window
Right Rear Power Window
Passenger’s Power Window
Driver’s Power Window
Moonroof
Not Used
IG HAC
IG SOL
ACC
HAC OP
For some types
:
Fuse Locations
478
Front
INTERIOR FUSE BOX
Driver’s Side
——y
y
(yy
2008 Odyssey

µ
Thediagramsinthissectiongive
you the dimensions and capacities of
your vehicle and the locations of the
identif ication numbers. It also
includes inf ormation you should
know about your vehicle’s tires and
emissions control systems.
................
Identif ication Numbers . 484
................................
Specif ications .486
DOT Tire Quality Grading .......................
(U.S Vehicles) .488
Unif orm Tire Quality ..................................
Grading .488
.................................
Treadwear .488
......................................
Traction .488
.............................
Temperature .489
.................................
Tire Labeling .490
Tire Pressure Monitoring System (TPMS) Required Federal ............................
Explanation .492
.......................
Emissions Controls .495
.....................
The Clean Air Act .495
Crankcase Emissions Control ....................................
System .495
Evaporative Emissions Control ....................................
System .495
Onboard Ref ueling Vapor ................................
Recovery .495
...
Exhaust Emissions Controls . 496
....................
PGM-FI System .496
Ignition Timing Control ................................
System .496 Exhaust Gas Recirculation
...................
(EGR) System . 496
Three Way Catalytic ...........................
Converter .496
....................
Replacement Parts . 496
..
Three Way Catalytic Converter . 497
........................
Emissions Testing .498
....
Testing of Readiness Codes . 498
T echnical Inf ormation
Technical Inf ormation
483
——y
y
(yy
2008 Odyssey

µ
As an added safety feature, your
vehicle has been equipped with a tire
pressure monitoring system (TPMS)
that illuminates a low tire pressure
telltale
when one or more of your tires is
signif icantly under-inf lated.
Accordingly, when the low tire
pressure telltale illuminates, you
should stop and check your tires as
soon as possible, and inf late them to
the proper pressure.Driving on a signif icantly under-
inf lated tire causes the tire to
overheat and can lead to tire failure.
Under-inf lation also reduces f uel
efficiency and tire tread life, and may
af f ect the vehicle’s handling and
stopping ability.
Please note that the TPMS is not a
substitute for proper tire
maintenance, and it is the driver’s
responsibility to maintain correct tire
pressure, even if under-inf lation has
not reached the level to trigger
illumination of the TPMS low tire
pressure telltale.
(If your vehicle has tires of a
dif f erent size than the size indicated
on the vehicle placard or tire
inf lation pressure label, you should
determine the proper tire inf lation
pressure f or those tires.) Each tire, including the spare (if
provided), should be checked
monthly when cold and inf lated to
the inf lation pressure recommended
by the vehicle manuf acturer on the
vehicle placard or tire inf lation
pressure label.All models
Tire Pressure Monitoring System (TPMS) Required Federal Explanation
492
——y

y
(yy
2008 Odyssey

µ
Always check the TPMS malf unction
telltale af ter replacing one or more
tires or wheels on your vehicle to
ensure that the replacement or
alternate tires and wheels allow the
TPMS to continue to f unction
properly.
TPMS malf unctions may occur f or a
variety of reasons, including the
installation of replacement or
alternate tires or wheels on the
vehicle that prevent the TPMS f rom
f unctioning properly. When the malf unction indicator is
illuminated,
the system may not be able to detect
or signal low tire pressure as
intended. Your vehicle has also been equipped
with a TPMS malf unction indicator
to indicate when the system is not
operating properly. The TPMS
malf unction indicator is provided by
a separate telltale, which displays the
symbol ‘‘TPMS’’ when illuminated.Except Touring models
Tire Pressure Monitoring System (TPMS) Required Federal Explanation
Technical Inf ormation
493
——y

y
(yy
2008 Odyssey

µ
TPMS malf unctions may occur f or a
variety of reasons, including the
installation of replacement or
alternate tires or wheels on the
vehicle that prevent the TPMS f rom
f unctioning properly.
Always check the TPMS malf unction
telltale af ter replacing one or more
tires or wheels on your vehicle to
ensure that the replacement or
alternate tires and wheels allow the
TPMS to continue to f unction
properly.
When the malf unction indicator is
illuminated, the system may not be
able to detect or signal low tire
pressure as intended. Your vehicle has also been equipped
with a TPMS malf unction indicator
to indicate when the system is not
operating properly. The TPMS
malf unction indicator is combined
with the low tire pressure telltale.
When the system detects a
malf unction, the telltale will f lash f or
approximately one minute and then
remain continuously illuminated.
This sequence will continue upon
subsequent vehicle start-ups as long
as the malfunction exists.Touring model
Tire Pressure Monitoring System (TPMS) Required Federal Explanation
494
——y



y
(yy
2008 Odyssey
