sensor HONDA ODYSSEY 2008 RB1-RB2 / 3.G Owner's Guide

You can turn the monitor on and of f
by pressing the monitor of f button
when the shif t lever is in reverse.
The monitor turns on everytime you
shif t to reverse, even if you turned it
of f the last time.Monitor brightness is adjusted
automatically by sensors. If you use
the monitor continuously at high
temperature, the monitor will
gradually dim.
If a bright light (such as sunlight) is
shining on the inside mirror, the
image may be dif f icult to see. The inside mirror will be hot when
you use the monitor f or an extended
period of time.
On U.S. EX-L without navigation system
and Canadian EX-L models
Rearview Camera and Monitor
Features
357
REAR VIEW MONITOR
SENSOR
SENSOR MONITOR OFF BUTTON
——yy
(yy
2008 Odyssey

Store or secure all items that could
be thrown around and hurt
someone during a crash.
Be sure items placed on the f loor
behind the f ront seats cannot roll
under the seats and interf ere with
the pedals, the seat operation, or
the proper operation of the
sensors under the seats.
Keep the glove boxes closed while
driving. If either are open, a
passenger could be injured during
a crash or sudden stop.If you remove or f old the rear seats
down, tie down items that could be
thrown about the vehicle during a
crash or sudden stop. Also, keep all
cargo below the bottom of the
windows. If it is higher than the
windows, it could interf ere with the
proper operation of the side curtain
airbags.
Distribute cargo evenly on the
f loor of the cargo area, placing the
heaviest items on the bottom and
as far forward as possible. Tie
down items that could be thrown
about the vehicle during a crash or
sudden stop.
If you carry large items that
prevent you f rom closing the
tailgate, exhaust gas can enter the
passenger area. To avoid the
possibility of
, f ollow the instructions
on page . 60
Carrying Cargo
Carrying Items in the Passenger
Compartment Carrying Cargo in the Cargo A rea
or on a Roof Rack
carbon monoxide
poisoning
Bef ore Driving
373
——yy
(yy
2008 Odyssey

µ
When the low tire pressure indicator
is on, one or more of your tires is
signif icantly underinf lated. You
should stop and check your tires as
soon as possible, and inf late them to
the proper pressure as indicated on
the vehicle’s tire inf ormation placard.
If you think you can saf ely drive a
short distance to a service station,
proceed slowly, and inf late the tire to
the recommended pressure shown
on the driver’s doorjamb.
If the tire is f lat, or if the tire
pressure is too low to continue
driving, replace the tire with the
compact spare tire (see page ).
If you cannot make the low tire
pressure indicator go out af ter
inf lating the tires to the specif ied
values, have your dealer check the
system as soon as possible.Driving on a signif icantly under-
inf lated tire causes the tire to
overheat and can lead to tire failure.
Under-inf lation also reduces f uel
efficiency and tire tread life, and may
af f ect the vehicle’s handling and
stopping ability.
Becausetirepressurevariesby
temperature and other conditions,
the low tire pressure indicator may
come on unexpectedly.
Each tire has its own pressure
sensor (not including the spare tire).
If the air pressure of a tire becomes
signif icantly low while driving, the
sensor in that tire immediately sends
a signal that causes the low tire
pressure indicator to come on. Your vehicle is equipped with a tire
pressure monitoring system (TPMS)
that turns on every time you start the
engine and monitors the pressure in
your tires while driving.
457
On LX, EX, EX-L and Canadian DXmodelsLow Tire Pressure
Indicator
Tire Pressure Monitoring System (TPMS) Except Touring models
388
—

—y


y
(yy
2008 Odyssey

µ
As required by the FCC:This device complies with Part 15 of theFCC rules. Operation is subject to thef ollowing two conditions: (1) This devicemay not cause harmf ul interf erence, and(2) this device must accept anyinterf erence received, includinginterf erence that may cause undesiredoperation.
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
This device complies with IndustryCanada Standard RSS-210.Operation is subject to the f ollowing twoconditions: (1) this device may not causeinterf erence, and (2) this device mustaccept any interf erence that may causeundesired operation of the device.
If you have a f lat tire, the low tire
pressure indicator will come on.
Replace the flat tire with the
compact spare tire (see page ).
Each wheel (except the compact
sparetirewheel)isequippedwitha
tire pressure sensor mounted inside
the tire behind the valve stem. You
must use TPMS specif ic wheels. It is
recommended that you always have
your tires serviced by your dealer or
qualif ied technician.
After you replace the flat tire with
thecompactsparetire,thelowtire
pressure indicator stays on. This is
normal; the system is not monitoring
the spare tire pressure. Manually
check the spare tire pressure to be
sure it is correct. Af ter several miles
(kilometers) driving with the
compact spare tire, the TPMS
indicator comes on and the low tire
pressure indicator goes of f . The low tire pressure indicator or
the TPMS indicator will go off, after
several miles (kilometers) driving,
when you replace the spare tire with
the specif ied regular tire equipped
with the tire pressure monitor sensor.
Never use a puncture-repairing agent
in a f lat tire. If used, you will have to
replace the tire pressure sensor.
Havetheflattirerepairedbyyour
dealer as soon as possible.
457
Changing a T ire with T PMS
Tire Pressure Monitoring System (TPMS) Except Touring models
390
——yy
(yy
2008 Odyssey

µ
Your vehicle is equipped with a tire
pressure monitoring system (TPMS)
that turns on every time you start the
engine and monitors the pressure in
your tires while driving.
Each tire has its own pressure
sensor. If the air pressure of a tire
becomes signif icantly low, the
sensor in that tire immediately sends
a signal that causes the low tire
pressure/TPMS indicator in the
instrumental panel and the
appropriate tire position indicator on
thetirepressuremonitoronthe
multi-inf ormation display (see page)tocomeon. Refer to page for tire inflation
guidelines.
If there is a problem with the TPMS,
this indicator begins to f lash. It stops
flashing after approximately 1
minute, then stays on. You will also
see a ‘‘CHECK TPMS SYSTEM’’
message on the multi-information
display (see page ). For example, if you check and f ill
your tires in a warm area, then drive
in extremely cold weather, the tire
pressure will be lower than
measured and could be underinflated
and cause the low tire pressure/
TPMS indicator to come on. Or, if
youcheckandadjustyourtire
pressure in cooler conditions, and
drive into extremely hot conditions,
the tire may become overinf lated.
However, the low tire pressure/
TPMS indicator will not come on if
the tires are overinflated.
When the low tire pressure/TPMS
indicator is on, one or more of your
tires is signif icantly underinf lated.
The multi-inf ormation display also
shows a ‘‘CHECK TIRE PRESSURE’’
message (see page ). You should
stop and check your tires as soon as
possible, and inflate them to the
proper pressure as indicated on the
vehicle’s tire inf ormation placard.
Driving on a signif icantly under-
inf lated tire causes the tire to
overheat and can lead to tire failure.
Under-inf lation also reduces f uel
efficiency and tire tread life, and may
af f ect the vehicle’s handling and
stopping ability.
Becausetirepressurevariesby
temperature and other conditions,
the low tire pressure/TPMS
indicator may come on unexpectedly.
393
442
395
393
CONT INUED
Low Tire Pressure/
TPMS Indicator
Tire Pressure Monitoring System (TPMS) Touring models
Driving
391
——y
y
(yy
2008 Odyssey

µ
Although your tire pressure is
monitored, you must manually check
thetirepressuresmonthly.
Each tire, including the spare, should
be checked monthly when the
vehicle is cold, and set to the
recommended inf lation pressure as
specif ied on the vehicle placard and
intheowner’smanual(seepage).
If the tire is f lat, or if the tire
pressure is too low to continue
driving, replace the tire with the
compact spare tire (see page ). If you think you can saf ely drive a
short distance to a service station,
proceed slowly to the station, then
inflate the tire to the recommended
pressure. If you have a f lat tire, the low tire
pressure/TPMS and tire monitor
indicators will come on. Replace the
indicated f lat tire with the compact
sparetire(seepage ).
After the flat tire is replaced with the
spare tire, the low tire pressure/
TPMS indicator stays on while
driving. Af ter several miles
(kilometers) driving, this indicator
begins to f lash, then stays on again.
You will also see a ‘‘CHECK TPMS
SYSTEM’’ message on the multi-
inf ormation display. This is normal;
the system cannot monitor the spare
tire pressure. Manually check the
spare tire pressure to be sure it is
correct.
This indicator and the warning
message on the multi-inf ormation
display will go of f , af ter several miles
(kilometers) driving, when the spare
tire is replaced with the specifiedregular tire equipped with the tire
pressure monitor sensor.
Never use a puncture-repairing agent
in a f lat tire. If used, you will have to
replace the tire pressure sensor.
Havetheflattirerepairedbyyour
dealer as soon as possible.
Each wheel is equipped with a tire
pressure sensor mounted inside the
tire behind the valve stem. You must
use TPMS specif ic wheels. It is
recommended that you always have
your tires serviced by your dealer or
a qualif ied technician.
458
443
457Changing a T ire with T PMS
Tire Pressure Monitoring System (TPMS) Touring models
392
——y
y
(yy
2008 Odyssey

The exhaust emissions controls
include f our systems: PGM-FI,
ignition timing control, exhaust gas
recirculation, and three way catalytic
converter. These f our systems work
together to control the engine’s
combustion and minimize the
amount of HC, CO, and NOx that
come out the tailpipe. The exhaust
emissions control systems are
separate f rom the crankcase and
evaporative emissions control
systems.
The PGM-FI system uses sequential
multiport f uel injection.
It has three subsystems: air intake,
engine control, and f uel control. The
powertrain control module (PCM)
uses various sensors to determine
how much air is going into the
engine. It then controls how much
f uel to inject under all operating
conditions.This system constantly adjusts the
ignition timing, reducing the amount
of HC, CO, and NOx produced.
The exhaust gas recirculation (EGR)
system takes some of the exhaust
gas and routes it back into the intake
manif old. Adding exhaust gas to the
air/f uel mixture reduces the amount
of NOx produced when the f uel is
burned.
The three way catalytic converter is
in the exhaust system. Through
chemical reactions, it converts HC,
CO, and NOx in the engine’s exhaust
to carbon dioxide (CO ), nitrogen
(N ), and water vapor.
The emissions control systems are
designed and certif ied to work to-
gether in reducing emissions to
levels that comply with the Clean Air
Act. To make sure the emissions
remain low, you should use only new
Honda replacement parts or their
equivalent f or repairs. Using lower
qualitypartsmayincreasethe
emissions f rom your vehicle.
The emissions control systems are
covered by warranties separate from
the rest of your vehicle. Read your
warranty manual for more informa-
tion.
2
2
Exhaust Emissions Controls Replacement Parts
PGM-FI SystemIgnit ion T iming Cont rol Syst em
Exhaust Gas Recirculat ion (EGR)Syst em
Three Way Catalytic Converter
Emissions Cont rols
496
——y



y
(y
y
2008 Odyssey

Locks.....
Anti-thef t Steering Column .144
............................
Fuel Fill Door .361
..................................
Glove Box .201
..................
Lockout Prevention .151
...............................
Power Door .151
.............................
Sliding Doors .161
......................................
Tailgate .157
........................
Low Coolant Level .364
.........................
Low Fuel Indicator .74
...
Low Oil Pressure Indicator . 67, 471
.........................
Lower Anchors .48, 50
..........................
Lower Glove Box .201
...
Lubricant Specif ications Chart . 486
...........
Luggage, Storing (Cargo) . 370
..................................
Maintenance .405
................................
Minder .407-416
.........................
Minder Indicator .76
...
Owner Maintenance Checks . 415
..........................................
Saf ety .406
.
Malf unction Indicator Lamp . 67, 472
...................
Manual Sliding Doors . 161
...............................
Meters, Gauges .77 ..................
Michelin PAX System . 454
........................
Mirrors, Adjusting .190
.................................
Modif ications .369
...............
Modif ying Your Vehicle . 368
.......................................
Moonroof .189
Moving the Second Row Bucket .............................................
Seat .175
.............
Multi-Inf ormation Display . 81
...................
Neutral Gear Position . 379
..................
New Vehicle Break-in . 360
...................
NOTICE, Explanation of . i
...............
Numbers, Identif ication . 484
...
Octane Requirement, Gasoline . 360
...................................
Odometer .78, 85
.........................
Odometer, Trip .78, 86
Oil ........................
Change, How to .420
......................
Change, When to .407
......................
Checking Engine .363
..............
Pressure Indicator . 67, 471Selecting Proper Viscosity
......................................
Chart .419
.........
ON (Ignition Key Position) . 144
Onboard Ref ueling Vapor ....................................
Recovery .495
............................
Outside Mirrors .191
....................
Overheating, Engine .469
.......
Owner Maintenance Checks . 415
.........................
Oxygenated Fuels .360
............
Panel Brightness Control . 139
........................
Park Gear Position .379
...........................................
Parking .382
...............................
Parking Brake .192
Parking Brake and Brake .................
System Indicator . 69, 473
...............................
Parking Lights .136
................
Parking Sensor System . 352
..
Parking Over Things that Burn . 382
....
Passenger Airbag Of f Indicator . 35
...................................
PAX System .454
.............................
PGM-FI System .496
........................
Power Door Locks .151
Index
M N
P
O
VI
——y


y
(y
y
2008 Odyssey

.....................................
Seat Belts .8, 21
...............
Additional Information . 21
Automatic Seat Belt
...............................
Tensioners .23
.....................................
Cleaning .436
......................
Lap/Shoulder Belt .22
................................
Maintenance .24
Reminder Indicator and
................................
Beeper .21, 68
................................
Replacement .24
...................
System Components . 21
...............
Use During Pregnancy . 19
...
Wearing a Lap/Shoulder Belt . 15
..................................
Seat Heaters .183
...............................................
Seats .167
..............
Adjustments . 168, 169, 170
..........
Drivers Lumbar Support . 170
....
Folding the Third Row Seat . 181
........................
Head Restraints .171
.....
Manual Height Adjustment . 169
....................
Passenger Seating .167
.
Reclining the Third Row Seat . 169
Removing the Second Row .......................................
Seats .177
Removing the Second Row ........................
Plus-One Seat .178 ............
Third Row Seat Access . 174
............................
Security System .318
Sensors
Front Passenger’s Weight .....................................
Sensors .30
....
Driver’s Seat Position Sensor . 30
...............................
Serial Number .484
...........................
Service Intervals .407
.............................
Service Manual .505
...........
Service Station Procedure . 361
..........................
Setting the Clock .281
...
Shif t Lever Position Indicators . 378
........................
Shif t Lock Release .381
................................
Side Airbags .9, 31
..........................
Of f Indicator .35, 68
Side Marker Lights, Bulb ..............................
Replacement .431
.............................
Signaling Turns .136
.................................
Sliding Doors .161
.....................................
Snow Tires .447
................................
Sound System .221
Spare Tire ......................................
Inf lating .457
............................
Specif ications .487
....................
Specif ications Charts . 486
................................
Speed Control .319 ...................................
Speedometer .77
..........
SRS, Additional Inf ormation . 25
...
Additional Safety Precautions . 37
.............................
Airbag Service .36
..
How the SRS Indicator Works . 34
How Your Airbags ............................
Work .27, 31, 33
........................
SRS Components .25
.............................
SRS Indicator .34, 67
..
START (Ignition Key Position) . 144
.......................
Starting the Engine .377
In Cold Weather at High ..................................
Altitude .377
................
With a Dead Battery . 467
..............
State Emissions Testing . 498
........
Steam Coming f rom Engine . 469
Steering Wheel
................................
Adjustment .141
...........
Anti-thef t Column Lock . 144
.........................
Buttons .82, 282, 319
...................
Stereo Sound System . 221
....................
Storing Your Vehicle .451
..........
Second Row Plus-One Seat . 178
........................
Sunglasses Holder .197
........................................
Sun Visor .198
Index
VIII
——y


y
(y
y
2008 Odyssey

CONT INUED
Supplemental Restraint System......................................
Servicing .36
.........................
SRS Indicator .34, 67
...................
System Components .25
..................................
Synthetic Oil .419
Unexpected, Taking Care..........................................
of the .453
....
Unif orm Tire Quality Grading . 488
........................
Unleaded Gasoline .360
...........................
Upper Glove Box .201
.......
Used Oil, How to Dispose of . 421
................................
Vanity Mirror .199
.....................................
Tachometer .77
..........................................
Tailgate .157
.......................
Opening the .157, 158
.......
Open Monitor Indicator . 75, 91
..
Taillights, Changing Bulbs . 433, 434
.
Taking Care of the Unexpected . 453
Technical Descriptions .....
Emissions Control Systems . 495
Three Way Catalytic .......................
Converter .496, 497
.......................
Temperature Gauge .77
........
Temperature, Inside Sensor . 220
...................
Tensioners, Seat Belts . 23
..............
Tether Anchorage Points . 54
............................
Thef t Protection .284
..
Three Way Catalytic Converter . 497
Tilt and Telescoping the .........................
Steering Wheel .141 ..........................
Time, Setting the .281
....................................
Timing Belt .428
....................................
Tire Chains .447
.........
Tire, How to Change a Flat . 458
...............................................
Tires .442
..............................
Air Pressure .442
...................................
Balancing .445
.........................
Checking Wear .444
..........................
Compact Spare .457
......
DOT Tire Quality Grading . 488
......................................
Inf lation .442
..................................
Inspection .444
.....................................
Labeling .490
...................................
Replacing .446
......................................
Rotating .445
................................
Service Lif e .445
...........................................
Snow .447
............................
Specif ications .487
................................
Tire Chains .447
Tire Pressure Monitoring ............
System (TPMS) . 388, 391
...................
Tools, Tire Changing . 458
Towing .....................................
A Trailer .396
................
Emergency Wrecker . 480
....
Equipment and Accessories . 398.............................
Weight Limit .396
.............................
Trailer Loading .396
......................
Trailer Towing Tips .402
Transmission ...............
Checking Fluid Level . 425
...........................
Fluid Selection .426
..............
Identif ication Number . 485
.............
Shif ting the Automatic . 378
.....................................
Treadwear .488
.................................
Trip Meter .78, 86
..................................
Turn Signals .136
Index
U
V
T
INDEX
IX
——y

y
(yy
2008 Odyssey
