HONDA ODYSSEY 2008 RB1-RB2 / 3.G Repair Manual
Manufacturer: HONDA, Model Year: 2008, Model line: ODYSSEY, Model: HONDA ODYSSEY 2008 RB1-RB2 / 3.GPages: 524, PDF Size: 9.87 MB
Page 61 of 524
The National Highway Traffic Safety
Administration and Transport
Canada recommend that all children
aged 12 and under be properly
restrained in a back seat.
If the passenger’s front airbag
inf lates in a moderate to severe
f rontal collision, the airbag can cause
serious injuries to a child who is
unrestrained, improperly restrained,
sitting too close to the airbag, or out
of position.
A side airbag also poses risks. If any
part of a larger child’s body is in the
path of a deploying side airbag, the
child could receive possibly serious
injuries.Of course, children vary widely. And
while age may be one indicator of
when a child can saf ely ride in f ront,
there are other important f actors you
should consider.
Physically, a child must be large
enough f or the lap/shoulder belt to
properly f it (see pages and ). If
the seat belt does not f it properly,
with or without the child sitting on a
booster seat, the child should not sit
in f ront.
To saf ely ride in f ront, a child must
be able to f ollow the rules, including
sitting properly, and wearing the seat
belt properly throughout a ride.
If you decide that a child can saf ely
ride up f ront, be sure to:
Caref ully read the owner’s manual,
and make sure you understand all
seat belt instructions and all saf ety
inf ormation.
Move the vehicle seat to the rear-
most position.
Have the child sit up straight, back
against the seat, and feet on or
near the f loor.
Check that the child’s seat belt is
properly and securely positioned.
Supervise the child. Even mature
children sometimes need to be
reminded to f asten the seat belts
or sit properly.
5615
Protecting L arger Children
When Can a L arger Child Sit in
Front
Physical Size
Maturity
58
— — y
y
( y y
2008 Odyssey
Page 62 of 524
This could result
in serious neck injuries during a
crash.
This could
cause very serious injuries during
a crash. It also increases the
chance that the child will slide
under the belt in a crash and be
injured.
If they do, they
could be very seriously injured in a
crash. Devices intended to
improve a child’s comf ort or
reposition the shoulder part of a
seat belt can make the belt less
ef f ective and increase the chance
of serious injury in a crash.
Protecting L arger Children
Additional Saf ety Precautions
Do not let a child wear a seat belt
across t he neck.
Do not let a child put the shoulderpart of a seat belt behind t he backor under t he arm.
T wo children should never use thesame seat belt . Do not put any accessories on a
seat belt.
Driver and Passenger Saf ety
59
— — y
y
( y y
2008 Odyssey
Page 63 of 524
Your vehicle’s exhaust contains
carbon monoxide gas. Carbon
monoxide should not enter the
vehicle in normal driving if you
maintain your vehicle properly and
f ollow the inf ormation on this page.High levels of carbon monoxide can
collect rapidly in enclosed areas,
such as a garage. Do not run the
engine with the garage door closed.
Even with the door open, run the
engine only long enough to move the
vehicle out of the garage.With the tailgate open, air flow can
pull exhaust gas into your vehicle’s
interior and create a hazardous
condition. If you must drive with the
tailgate open, open all the windows
and set the heating and cooling
system/climate control system as
shown below.
Have the exhaust system inspected
f or leaks whenever:
The vehicle is raised f or an oil
change.
You notice a change in the sound
of the exhaust.
The vehicle was in an accident
that may have damaged the
underside. If you must sit in your parked vehicle
with the engine running, even in an
unconf ined area, adjust the heating
and cooling system/climate control
system as f ollows:
Select the f resh air mode.
Select the mode.
Set the f an speed to high.
Set the temperature control to a
comfortable setting.
1.
2.
3.
4.
Carbon Monoxide Hazard
60
Carbon monoxide gas is toxic.
Breathing it can cause
unconsciousness and even kill
you.
Avoid any enclosed areas or
activities that expose you to
carbon monoxide.
— — y
y
( y y
2008 Odyssey
Page 64 of 524
These labels are in the locations
shown. They warn you of potential
hazards that could cause serious
injury or death. Read these labels
caref ully.
If a label comes of f or becomes hard
to read (except for the U.S.
dashboard label which may be
removed by the owner), contact your
dealer f or a replacement.
CONT INUED
Canadian modelsU.S. models only
U.S. models
Saf ety L abels
Driver and Passenger Saf ety
61
DASHBOARD
SUN VISORS
— — y
y
( y y
2008 Odyssey
Page 65 of 524
U.S. modelsCanadian models
U.S. modelsCanadian models
Saf ety L abels
62
HOOD DOORJAMB
RADIATOR CAP
— — y
y
( y y
2008 Odyssey
Page 66 of 524
This section gives inf ormation about
the controls and displays that
contribute to the daily operation of
your vehicle. All the essential
controls are within easy reach............................
Control Locations .64
............................
Instrument Panel .65
..........
Instrument Panel Indicators .67
.............................................
Gauges .77
.............
Multi-Inf ormation Display .81
Controls Near the Steering
.........................................
Wheel .133 Windshield Wipers and
.................................
Washers .134
Rear Window Wiper and
...................................
Washer .135
....
Turn Signal and Headlights . 135
......
Instrument Panel Brightness . 139
...............
Hazard Warning Button . 140
...............
Rear Window Def ogger . 140
........
Steering Wheel Adjustment . 141
.............................
Keys and Locks .142
......................
Immobilizer System .143
..............................
Ignition Switch .144
.....................
Remote Transmitter .145
Opening or Closing the Power .........................
Sliding Doors .148
Opening or Closing the Power ..................................
Tailgate .148
....................................
Door Locks .151
....................
Power Door Locks . 151
Auto Door Locking/ ..............................
Unlocking .152
............
Childproof Door Locks . 157
..........................................
Tailgate .157
..........................
Power Tailgate .158
.................................
Sliding Doors .161
...............................................
Seats .167 ..................................
Seat Heaters .183
Driving Position Memory ........................................
System .184
............................
Power Windows .186
.......................................
Moonroof .189
...........................................
Mirrors .190
...............................
Parking Brake .192
.
Adjustable Driver’s Foot Pedals . 193
.........
Interior Convenience Items . 194
..........
Retractable Center Tray . 195
.....................
Beverage Holders .195
................
Integrated Sunshade . 197
....................
Sunglasses Holder .197
................
Conversation Mirror . 198
...................................
Sun Visor .198
............................
Vanity Mirror .199
...................
Rear Compartment . 199
................
Second Row Console . 199
...............
In-Floor Storage Area . 200
..............................
Glove Boxes .201
...........................
Center Pocket .202
...............................
Coin Pocket .202
........
Accessory Power Sockets . 203
.......................
AC Power Outlet .203
...............................
Interior Lights .205
Instruments and Controls
Inst rument s and Cont rols
63
— — y
y
( y y
2008 Odyssey
Page 67 of 524
Î
Î
: If equipped
Control L ocations
64
SEAT HEATER
SWITCHESRETRACTABLE
CENTER TRAY
PARKING BRAKE
PEDAL ACCESSORY
POWER SOCKETAUXILIARY
INPUT JACK
Vehicle with navigation system is shown. (P
.192)
(P.203) (P
.283) (P.195)
AUTOMATIC TRANSMISSION
SHIFT LEVER
(P
.378)
(P.183) (P.
210 )
INSTRUMENT PANEL INDICATORS
(P
.65, 66)
GAUGES
MIRROR
CONTROLS
(P .191)
POWER DOOR
LOCK SWITCH
(P .151)
DRIVING POSITION
MEMORY SYSTEM
BUTTONS
(P .184)
POWER WINDOW
SWITCHES
(P .186)
FUEL FILL DOOR
RELEASE HANDLE
(P .361)
HOOD RELEASE HANDLE
(P .362) (P
.77)
GLOVE BOXES
(P.201 )
HEATING AND COOLING SYSTEM/
CLIMATE CONTROL SYSTEM
— — y
y
( y y
2008 Odyssey
Page 68 of 524
The U.S. instrument panel is shown. Dif f erences f or the Canadian models are noted in the text.
Instrument Panel
Inst rument s and Cont rols
LX, EX, EX-L and Canadian DX models
65
HIGH BEAM
INDICATOR
IMMOBILIZER
SYSTEM
INDICATOR
POWER SLIDING
DOOR INDICATOR
DOOR AND
TAILGATE OPEN
INDICATOR
CHARGING
SYSTEM
INDICATOR FUEL ECONOMY
INDICATOR
MALFUNCTION
INDICATOR
LAMP LOW TIRE PRESSURE
INDICATOR
LIGHTS ON INDICATOR CRUISE MAIN INDICATOR
VEHICLE STABILITY ASSIST
(VSA) SYSTEM INDICATOR
ANTI-LOCK BRAKE
SYSTEM (ABS)
INDICATOR
CRUISE CONTROL
INDICATOR
LOW FUEL INDICATOR
SEAT BELT REMINDER
INDICATOR SIDE AIRBAG OFF
INDICATOR
SUPPLEMENTAL
RESTRAINT
SYSTEM (SRS)
INDICATOR
PARKING BRAKE AND BRAKE
SYSTEM INDICATOR SECURITY
SYSTEM
INDICATOR
(P
.70)
(P .75)
(P .76) (P
.34, 67)
(P.75)(P
.76)
(P.21, 68)(P
.35, 68)
(P
.74) (P.
75)
(P
.70)
(P
.70)
(P
.75)
(P.75)
(P .73)
(P.73) TIRE PRESSURE MONITORING
SYSTEM (TPMS) INDICATOR
(P .73)
MAINTENANCE MINDER
INDICATOR LOW OIL PRESSURE
INDICATOR
DAYTIME RUNNING LIGHTS
(DRL) INDICATOR VSA ACTIVATION
INDICATOR
(P .67, 471)
(P.67, 472)
(P.67, 471) (P
.72, 389) (P
.71, 388)
(P .69, 384)
(P .69, 473)
—
— y
y
( y y
2008 Odyssey
Page 69 of 524
ÎThe U.S. instrument panel is shown. Dif f erences f or the Canadian models are noted in the text.
Instrument Panel
T ouring models
66
SEAT BELT REMINDER
INDICATORDOOR AND TAILGATE
OPEN INDICATOR
SECURITY SYSTEM
INDICATOR SIDE AIRBAG OFF
INDICATOR
(P. 76)
(P.21, 68)
(P
.35, 68) (P
.75)
(P.
75)
(P
.70)
(P
.70)
(P.70)
(P .76)
FUEL ECONOMY
INDICATOR
(P
.75)
MALFUNCTION
INDICATOR LAMP LIGHTS ON INDICATOR
ANTI-LOCK BRAKE SYSTEM
(ABS) INDICATOR
CRUISE CONTROL INDICATOR
CRUISE MAIN INDICATOR (P
.75)
CHARGING SYSTEM INDICATOR
FOG LIGHT INDICATOR IMMOBILIZER SYSTEM INDICATOR
HIGH BEAM INDICATOR
SYSTEM MESSAGE
INDICATOR
LOW OIL PRESSURE INDICATOR LOW FUEL
INDICATOR
PARKING BRAKE AND BRAKE SYSTEM
INDICATOR
SUPPLEMENTAL RESTRAINT SYSTEM
(SRS) INDICATOR (P.
74)
(P .34, 67)
(P
.73)
(P .73)
DAYTIME RUNNING LIGHTS (DRL)
INDICATOR (P.73) (P
.73) LOW TIRE PRESSURE/TPMS
INDICATOR
VSA ACTIVATION
INDICATOR
VEHICLE STABILITY ASSIST (VSA) SYSTEM
INDICATOR
(P .67, 472)
(P .67, 471) (P
.71, 391)
(P.69, 384)
(P .69, 473)
(P
.67, 471)
— — y
y
( y
y
2008 Odyssey
Page 70 of 524
The instrument panel has many
indicators to give you important
inf ormation about your vehicle. If this indicator comes on when theengine is running, the battery is not
being charged. For more inf ormation,
see page .
For more inf ormation, see page .
You will also see a ‘‘CHECK
EMISSION SYSTEM’’ message on
the multi-information display (see
page ). You will also see a ‘‘CHECK
CHARGING SYSTEM’’ message on
the multi-information display (see
page ).
The engine can be severely damaged
if this indicator f lashes or stays on
when the engine is running. For
more information, see page .
You will also see a ‘‘CHECK
ENGINE OIL LEVEL’’ message on
the multi-information display (see
page ).This indicator comes on f or several
seconds when you turn the ignition
switch to the ON (II) position. If it
comes on at any other time, it
indicates a potential problem with
your f ront airbags. This indicator will
also alert you to a potential problem
with your side airbags, passenger’s
side airbag automatic cutoff system,
side curtain airbags, automatic seat
belt tensioners, driver’s seat position
sensor, or the f ront passenger’s
weight sensors. For more
inf ormation, see page .
You will also see a ‘‘CHECK
AIRBAG SYSTEM’’ message on the
multi-inf ormation display (see page
).
88
88
88 34
88
472
471
471
On Touring models
On Touring models
On Touring models
On Touring models
Malf unction Indicator
LampCharging System
Indicator
L ow Oil Pressure
IndicatorSupplemental Restraint
System (SRS) Indicator
Instrument Panel Indicators
Inst rument s and Cont rols
67
— — y
y
( y y
2008 Odyssey
