HONDA ODYSSEY 2010 RB3-RB4 / 4.G Owners Manual

See page95, 362
See page 11, 92
See page 21, 91
See page 92, 479
See page 94, 479 See page
98, 479
See page 95, 399 See page
97, 477
See page 97, 477
See page 98, 478
See page 98
See page 34, 99
See page
96, 402
Multi-Inf ormation Display
88
U.S.
Canada
U.S.
Canada Canada U.S.
——
y
y
(yy
2010 Odyssey

Î
Î
CONT INUED
Canadian model only
:
See page
100, 138
See page 100, 160
See page
99, 392
See page 97, 394 See page
100, 166
See page 99, 363
See page 94
See page 93
See page 94 See page
96, 417
See page 92
See page 35, 95
Multi-Inf ormation Display
Inst rument s and Cont rols
89
Canada Canada
U.S. Canada U.S.
U.S.
——
y


y
(yy
2010 Odyssey

The system message(s) triggers the
appropriate indicator(s) on the
instrument panel, including the
system message indicator, to come
on. The system message indicator
does not go of f until the problem(s)
is corrected.You will also hear a beep when the
system message comes on f or the
first time.
Most of the messages are displayed
f or about 5 seconds, and then the
normal display returns. If there are
several system messages to be
shown, the display switches these
messages every 5 seconds.
To cancel the message(s) bef ore 5
seconds elapsed, press the INFO
button on the steering wheel.
Multi-Inf ormation Display
90
SYSTEM MESSAGE INDICATOR
——
y


y
(yy
2010 Odyssey

CONT INUED
In addition to the seat belt reminder
indicator in the instrument panel,
you will also see a ‘‘FASTEN SEAT
BELT’’ or ‘‘FASTEN PASSENGER
SEAT BELT’’ message. This remains
displayed if you ignore it and do not
f asten the seat belt while driving.
Even if you press the INFO button,
some messages stay on or come on
again at regular intervals until the
problem is corrected:
You can see the message(s) again by
pressing the INFO button repeatedly
if the system message indicator
remains lit on the instrument panel.
FASTEN SEAT BELT
FASTEN PASSENGER SEAT
BELT
RELEASE PARKING BRAKE
WARNING: APPROACHING
OBJECT
Multi-Inf ormation Display
Fast en Seat Belt
Inst rument s and Cont rols
91
——
y


y
(yy
2010 Odyssey

If you leave the key in the ignition
switch in the LOCK (0) or
ACCESSORY (I) position and open
the driver’s door, you will see
‘‘REMOVE KEY’’ on the display and
hear a reminder beeper.
If the tailgate or any door(s) is not
closed tightly, the display reminds
you to close the tailgate or the
door(s) bef ore you start driving.
This display continues until you
close the door(s) or the tailgate.
Pressing the INFO button on the
steering wheel momentarily changes
the display to the normal display, but
it will come back af ter 5 seconds. If you start driving without releasing
the parking brake, the multi-
inf ormation display interrupts the
current display and shows
‘‘RELEASE PARKING BRAKE.’’
This message continues, and a
chime sounds, until you release the
parking brake, or the vehicle speed
slows down to less than 0.5 mph (0.8
km/h).
Multi-Inf ormation Display
Remove Key
Door and Tailgate Open Release Parking Brake
92
Canada
U.S.
——
y

y
(yy
2010 Odyssey

Your vehicle’s on board diagnostic
system will detect a loose or missing
f uel f ill cap as an evaporative system
leak. The f irst time a leak is detected
a ‘‘TIGHTEN FUEL CAP’’ message
appears on the multi-inf ormation
display. Turn the engine of f , and
conf irm the f uel f ill cap is installed. If
it is, loosen it, then retighten it until
it clicks at least once. The message
should go of f af ter several days of
normal driving once you tighten orreplace the f uel f ill cap. To scroll to
another message, press the INFO
button. The ‘‘TIGHTEN FUEL CAP’’
message will appear each time you
restart the engine until the system
turns the message of f .
If the system still detects a leak in
your vehicle’s evaporative emissions
system, the malf unction indicator
lamp (MIL) comes on. If the f uel f ill
cap was not already tightened, turn
the engine of f , and check or
retighten the f uel f ill cap until it
clicks at least once. The MIL should
go off after several days of normal
driving once the cap is tightened or
replaced. If the MIL does not go of f ,
have your vehicle inspected by a
dealer. For more inf ormation, see
page .
478
CONT INUED
Tighten Fuel Cap
Multi-Inf ormation Display
Inst rument s and Cont rols
93
——
y



y
(yy
2010 Odyssey

If the brake f luid level is at or below
theMINmarkonthesideof the
brake f luid reservoir in the engine
compartment, you will see ‘‘BRAKE
FLUID LOW.’’ If you see this
message, have the brake system
checked by your dealer (see page). If the f luid level in the windshield
washer reservoir gets low, you will
see ‘‘WASHER FLUID LOW’’ on the
multi-inf ormation display.
If the level of the fuel in the tank
gets low, you will see ‘‘FUEL LOW’’
on the multi-information display, and
you must ref uel soon. The low f uel
indicator on the instrument panel will
also come on.
479On Canadian Touring model only
Brake Fluid L ow
Fuel L ow Washer Fluid L ow
Multi-Inf ormation Display
94
U.S.
Canada
——
y


y
(yy
2010 Odyssey

This message, and the indicator to
the lef t of the message, is part of the
parking sensor system. If you are
approaching too close to an object,
you will see ‘‘WARNING:
APPROACHING OBJECT’’ on the
display and hear a beeper. See pagef or more inf ormation.
If the passenger’s side airbag has
automatically shut of f , you will see
‘‘PASSENGER SIDE AIRBAG OFF’’
on the multi-inf ormation display. See
page f or more inf ormation.
If one or more of your vehicle tires
are low on pressure, you will see a
‘‘CHECK TIRE PRESSURE’’
message on the display. See page
f or more inf ormation on the tire
pressure monitoring system (TPMS).
35
399
362
CONT INUED
Passenger Side A irbag Of f Check T ire PressureWarning: A pproaching Object
Multi-Inf ormation Display
Inst rument s and Cont rols
95
U.S.
Canada
——
y

y
(y
y
2010 Odyssey

When the engine oil lif e reaches 15%,
the display shows ‘‘SERVICE DUE
SOON’’ and the code f or the
maintenance items to be perf ormed.
When the engine oil lif e reaches 5%,
the display shows ‘‘SERVICE DUE
NOW’’ along with the same
maintenance items.If there is a problem in the tire
pressure monitoring system (TPMS),
you will see ‘‘CHECK TPMS
SYSTEM’’ on the multi-inf ormation
display. If you see this message, the
TPMS is not monitoring tire
pressures. Have the TPMS checked
by your dealer as soon as possible
(see page ).
Have your dealer do the indicated
maintenance as soon as you see this
message, and have them reset the
display af ter completing the service.
If you do not perf orm the indicated
maintenance or do not reset the
display, the message changes to
‘‘SERVICE PAST DUE’’ when the
engine oil lif e becomes 0%.
These messages appear on the multi-
inf ormation display each time you
turn the ignition switch to the ON
(II) position.
For details on engine oil lif e and
maintenance messages, ref er to page
.
Also ref er to page f or important
maintenance saf ety precautions. 417
414 402
Maint enance Messages Check T PMS Syst em
Multi-Inf ormation Display
96
——
y

y
(y

y
2010 Odyssey

If you see ‘‘CHECK CHARGING
SYSTEM’’ on the multi-inf ormation
display, it means the battery is not
being charged. See page f or
more inf ormation.
If the engine oil is very low or has
lost pressure, you will see ‘‘CHECK
ENGINE OIL LEVEL’’ on the multi-
inf ormation display. You will also see
the low oil pressure indicator in the
instrument panel f lashing or staying
on. If you see this message, you
should take immediate action since
serious engine damage is possible.
Follow the procedure on page .
If there is a problem with the vehicle
stability assist (VSA) system, you
will see ‘‘CHECK VSA SYSTEM’’ on
the multi-information display. If you
see this message, have the VSA
system checked by your dealer (see
page ).
394
477477
CONT INUED
Check Charging Syst em
Check Engine Oil L evel
Check VSA Syst em
Multi-Inf ormation Display
Inst rument s and Cont rols
97
——
y

y
(y
y
2010 Odyssey
