HONDA ODYSSEY 2010 RB3-RB4 / 4.G Owners Manual

If the indicator comes on repeatedly,
even though it may turn of f as you
continue driving, have your vehicle
checked by your dealer as soon as
possible.The indicator may also come on with
the ‘‘D’’ indicator.
You will also see a ‘‘CHECK
EMISSION SYSTEM’’ message on
the multi-information display (see
page ).
Your vehicle has certain ‘‘readiness
codes’’ that are part of the on-board
diagnostics f or the emissions
systems. In some states, part of the
emissions testing is to make sure
these codes are set. If they are not
set, the test cannot be completed.To check if they are set, turn the
ignition switch to the ON (II)
position without starting the engine.
The malf unction indicator lamp will
come on f or 20 seconds. If it then
goes of f , the readiness codes are set.
If it blinks 5 times, the readiness
codes are not set. If possible, do not
take your vehicle for a state
emissions test until the readiness
codes are set. Ref er to
f or more inf ormation (see
page ).
If your vehicle’s battery has been
disconnected or gone dead, these
codes are erased. It can take several
days of driving under various
conditions to set the codes again.
If this indicator comes on while
driving, it means one of the engine’s
emissions control systems may have
a problem. Even though you may
f eel no dif f erence in your vehicle’s
perf ormance, continued operation
may cause serious damage.
88
504
On Touring models
Malf unction Indicator L amp, Readiness Codes
Readiness Codes Emissions
Testing
Malf unction Indicator
Lamp
478
If you keep driving with the
malf unction indicator lamp on, you can
damage your vehicle’s emissions
controls and engine. Those repairs may
not be covered by your vehicle’s
warranties.
——
y
y
(yy
2010 Odyssey

The brake system
indicator normally
comesonwhenyou
turn the ignition switch to the ON
(II) position, and as a reminder to
check the parking brake. It will stay
on if you do not f ully release the
parking brake.
If the brake system indicator comes
on while driving, the brake f luid level
is probably low. Press lightly on the
brake pedal to see if it f eels normal.
If it does, check the brake f luid level
thenexttimeyoustopataservice
station (see page ). Slow down by shif ting to a lower
gear, and pull to the side of the road
when it is saf e. Because of the long
distance needed to stop, it is
hazardous to drive the vehicle. You
should have it towed and repaired as
soon as possible (see
on page ).
If the f luid level is low, take your
vehicle to a dealer, and have the
brake system inspected f or leaks or
worn brake pads.
However, if the brake pedal does not
f eel normal, you should take
immediate action. A problem in one
part of the system’s dual circuit
design will still give you braking at
two wheels. You will f eel the brake
pedal go down much f arther bef ore
the vehicle begins to slow down, and
you will have to press harder on the
pedal.
If the ABS indicator and the VSA
indicator come on with the brake
system indicator, have the vehicle
inspected by your dealer
immediately. If you must drive the vehicle a short
distance in this condition, drive
slowly and caref ully.
You will also see a ‘‘CHECK BRAKE
SYSTEM’’ message on the multi-
inf ormation display (see page ).
You will also see a ‘‘BRAKE FLUID
LOW’’ message on the multi-
inf ormation display (see page ).
88 88
435 486
On Touring models
On Touring models
Brake System Indicator
Emergency
Towing
T aking Care of t he Unexpect ed
479
U.S. Canada
——
y
y
(yy
2010 Odyssey

The vehicle’s f uses are contained in
f our f use boxes (three, if the vehicle
does not have a rear entertainment
system).To open the passenger’s f use box,
pull the right edge of the cover.
Theinteriorfuseboxesarelocated
under the dashboard on the driver’s
and passenger’s side. The primary under-hood f use box is
on the passenger’s side. To open it,
pushthetabsasshown.
The secondary under-hood f use box
is behind the primary f use box.
Fuses
480
DRIVER’S SIDE INTERIOR FUSE BOX PASSENGER’S SIDE INTERIOR
FUSE BOXPRIMARY UNDER-HOOD FUSE BOX
SECONDARY UNDER-HOOD FUSE BOX
——
y

y
(yy
2010 Odyssey

Check the smaller f uses in the
under-hood f use box and all the
fuses in the interior fuse boxes by
pulling out each f use with the f use
puller provided in the primary
under-hood f use box.
Turn the ignition switch to the
LOCK (0) position. Make sure the
headlights and all other
accessories are of f . Check each of the large f uses in
the primary under-hood f use box
by looking through the top at the
wire inside. Removing these f uses
requires a Phillips-head
screwdriver.
If something electrical in your
vehicle stops working, the first thing
youshouldcheckforisablownfuse.
Determine f rom the chart on pages
through , or the diagram on
thefuseboxlid,whichfuseorfuses
control that device. The diagram f or
theinteriordriver’ssidefuseboxis
on the kick panel below the f use box.
Check those f uses f irst, but check all
the f uses bef ore deciding that a
blown f use is the cause. Replace any
blown f uses, and check if the device
works.
Remove the cover f rom the f use
box.
1.
2. 3.
4.
483 485
CONT INUED
Checking and Replacing Fuses
Fuses
T aking Care of t he Unexpect ed
481
FUSE
BLOWN FUSE PULLER
——
y
y
(yy
2010 Odyssey

If the replacement fuse of the
same rating blows in a short time,
there is probably a serious
electrical problem with your
vehicle. Leave the blown fuse in
that circuit, and have your vehicle
checked by a qualif ied technician.
If you cannot drive the vehicle
without f ixing the problem, and you
do not have a spare fuse, take a fuse
of the same rating or a lower rating
f rom one of the other circuits. Make
sureyoucandowithoutthatcircuit
temporarily (such as the accessory
power socket or radio).
If you replace the blown f use with a
spare f use that has a lower rating, it
might blow out again. This does not
indicate anything wrong. Replace the
f use with one of the correct rating as
soon as you can.
Look f or a blown wire inside the
fuse.If itisblown,replacethefuse
withoneof thesparefusesof the
same rating or lower. If the driver’s power window f use is
removed, the AUTO f unction of the
driver’s window will be disabled. You
should reset the AUTO f eature, (see
page ).
If the radio f use is removed, the
audio system will disable itself . The
nexttimeyouturnontheradioyou
will see ‘‘CODE’’ in the f requency
display. Use the preset buttons to
enter the f ive-digit code (see page
).
5. 6.
187
284
On EX, EX-L and Touring models
Fuses
482
BLOWN
Replacing a f use with one that has a
higher rating greatly increases the
chances of damaging the electrical
system. If you do not have a
replacement f use with the proper
rating f or the circuit, install one with
a lower rating.
——
y
y
(yy
2010 Odyssey

µ µÎÎÎ
Î Î
ÎÎ Î
Î
No.
Circuits Protected
No. Amps. Circuits Protected No.
No.
CONT INUED
Circuits Protected
Circuits Protected
Amps.
Amps.
Amps.
1
2
3
4
5
6
7
8
9
10
11
12 Left Headlight Low
Rear Defroster Coil
Left Headlight High
Small Lights
Right Headlight High
Right Headlight Low
Back Up
FI ECU (PCM)
Condenser Fan
Not used
Cooling Fan
MG Clutch
1
2
3
4
5
6 40 A
40 A
40 A
20 A
20 A Not Used
Left Power Sliding Door
Right Power Sliding Door
Power Tailgate
Premium
AC Inverter 13
14
15
16
17
18
19
20
21
22
23
7
8
9
10
11 Horn, Stop
Rear Defroster
Back Up, ACC
Hazard
VSA Motor
VSA
Option 1
Option 2
Heater Motor
Passenger’s Fuse Box
Battery
IG1 Main
Power Window Main
Fog Light
ACM
AS power Seat Slide
AS power Seat Recline
Rear Entertainment System
10 A
30 A
10 A
15 A
10 A
10 A
7.5 A 15 A
30 A
30 A
7.5 A 20 A
30 A
40 A
15 A
30 A
30 A
30 A
40 A
40 A
70 A
120 A 50 A
50 A
40 A
20 A
10 A
20 A
20 A
7.5 A
For some types
:
Fuse Locations
T aking Care of t he Unexpect ed
483
PRIMARY UNDER-HOOD FUSE BOX
SECONDARY UNDER-HOOD FUSE BOX
——
y
y
(yy
2010 Odyssey

µµ
Î
Î ÎÎ
Î
Î Î
No.
No. Amps. Amps.
Circuits Protected Circuits Protected
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17 7.5 A
15 A
10 A
15 A
10 A
7.5 A
7.5 A
15 A
7.5 A 30 A
15 A
20 A
20 A
20 A
20 A
20 A 15 A
15 A
10 A
7.5 A 10 A
7.5 A 20 A
20 A
20 A
20 A
20 A
10 A
15 A
10 A
7.5 A
TPMS
IG Coil
Daytime Running Light
LAF
Radio
Interior Lights
Back Up
Not Used
Front Accessory Socket
OPDS
IG Wiper
Rear Accessory Socket
Left Power Sliding Door
Closer
Driver Power Seat Slide
Pedal Position Adjustment
Dr Power Seat Recline
Power Tailgate Closer IG ACG
IG Fuel Pump
IG Washer
IG Meter
IG SRS
IGP
Left Rear Power Window
Right Rear Power Window
Passenger’s Power Window
Driver’s Power Window
Moonroof
Not Used
IG HAC
IG SOL
ACC
HAC OP
For some types
:
Fuse Locations
484
INTERIOR FUSE BOX
Driver’s Side
Front
——
y

y
(yy
2010 Odyssey

Î
Î
µ
µ
µ
Î
No. Circuits Protected No.
Circuits Protected
Amps. Amps.
1S
TS 1
2
3
4
5
6
7
8
9
Rear Blower
Not Used
DBW
Door Lock
Not Used
Heated Seat
Instrument Panel
Right Power Sliding Door
Closer
Not Used
7.5 A 30 A
15 A
20 A
15 A
7.5 A 20 A
: For some types
Fuse Locations
T aking Care of t he Unexpect ed
485
INTERIOR FUSE BOX UPPER AREA
Driver’s Side INTERIOR FUSE BOX
Passenger’s Side
——
y
y
(yy
2010 Odyssey

µµ
If your vehicle needs to be towed,
call a prof essional towing service or
organization. Never tow your vehicle
with just a rope or chain. It is very
dangerous.
Therearetwowaystotowyour
vehicle:
With the f ront wheels on the ground,
it is best to tow the vehicle no farther
than 50 miles (80 km), and keep the
speedbelow35mph(55km/h).
The operator
loads your vehicle on the back of a
truck. The tow
truck uses two pivoting arms that go
under the tires and lif t them of f the
ground. The f lat tire side (f ront or
rear)shouldbeliftedbythewheel-
lift equipment. The other two tires
remain on the ground.
If , due to damage, your vehicle must
be towed with the f ront wheels on
the ground, do this:
Start the engine.
Press on the brake pedal. Move
the shif t lever through all its
positions.
Shif t to D position and hold f or 5
seconds, then to N.
Turn of f the engine.
Release the parking brake.
Leave the ignition switch in the
ACCESSORY (I) position so the
steering wheel does not lock.Flat -bed Equipment Wheel-lif t Equipment
T his is the best way to
transport your vehicle. T his is an
acceptable way to tow your
vehicle.
Emergency Towing
486
Improper towing preparation will
damage the transmission. Follow the
above procedure exactly. If you cannot
shif t the transmission or start the
engine, your vehicle must be
transported with the f ront wheels of f
the ground.
——
y
y
(y
y
2010 Odyssey

Emergency Towing
T aking Care of t he Unexpect ed
487
Trying to lif t or tow your vehicle by the
bumpers will cause serious damage.
The bumpers are not designed to
support the vehicle’s weight.
The steering system can be damaged if
the steering wheel is locked. Leave the
ignition switch in the ACCESSORY (I)
position, and make sure the steering
wheel turns f reely bef ore you begin
towing.
——
y
y
(yy
2010 Odyssey
