Rearview Camera/Parking Sensors
Rearview Camera (EX-L and Touring)
2. The rear view is shown in the display area.
The display shows a view behind the vehicle.
To Turn the Camera On
1. Shift into Reverse (R).
To Turn the Display Off
All models: Shift out of Reverse.
EX-L without navigation: Pressthe monitor
on/off button while in Reverse with your foot on
the brake. Press again to turn back on.
Models with
navigationEX-L without navigation
Monitor
On/Off
button
10 Odyssey TRG_Base:Base 9/24/2009 3:42 PM Page 9 2010 Odyssey

Rearview Camera/Parking Sensors
Parking Sensor System (Touring)
Warns you of the proximity between your vehicle and nearby surrounding ob\
jects when parking or in Reverse.
To Turn the System On and Off
Press the parking sensor button.
A light appears when the system
is on.
Corner Sensors Rear Center Sensors
Corner Sensor Indicator Rear Center Sensor Indicator Within approx. 20 in. (50 cm) Within approx. 70 in. (1.8 m)
How It Works
When the system senses an object, an indicator appears in the
MID and a beep sounds. As you get closer to an object, the
beep rate increases.
