HONDA ODYSSEY 2011 RB3-RB4 / 4.G Owners Manual

Select ‘‘Phone Name/PIN’’ f rom
the Phone Setup screen.
Select ‘‘PIN.’’
Enter a 4-digit PIN, re-enter it, and
select ‘‘OK.’’If you get into the vehicle while you
are on the phone, the call can be
automatically transferred to HFL
with the ignition switch in the
ACCESSORY (I) or ON (II) position.
Select ‘‘Auto Transf er’’ f rom the
Phone Setup screen.
Select ‘‘OFF’’ or ‘‘ON.’’
When you set a PIN f or a phone, you
will be asked to enter the PIN every
time you select the phone on the
Phone screen.
If you select ‘‘DO NOT USE PIN,’’
bef ore entering any number, the
phone will not have a PIN.
If the phone is already PIN-protected,
you need to enter the current PIN
bef ore creating a new one.
1.
2.
2. 1.
3.
To create a PIN f or each phone:
A ut omat ic T ransf erringBluetooth
HandsFreeL ink
(Models with navigation system)
528
10/07/17 10:45:26 31TK8600_533
2011 Odyssey

YoucanchoosewhentheHFL
system automatically answers
incoming calls.Select ‘‘Auto Answer’’ f rom the
Phone Setup screen.
Select ‘‘Of f ,’’ ‘‘2sec,’’ ‘‘5sec,’’ or
‘‘10sec.’’ Clearing a phone name will clear all
settings, such as call history and
phonebook.
Select ‘‘Clear Phone Inf ormation’’
f rom the Phone Setup screen.
Select the phone you want to clear.
A trash icon appears next to the
selected phone. Select ‘‘OK’’ to
continue.
Select ‘‘Yes’’ f rom the
conf irmation screen.
2. 1.
2.
1. 3.
4.
CONT INUED
A ut omat ic A nsweringT o clear t he phone inf ormat ion
Bluetooth
HandsFreeL ink
(Models with navigation system)
Features
529
10/07/17 10:45:37 31TK8600_534
2011 Odyssey

ÃŽ
ÃŽ Up to three category icons appear
next to the phonebook entries .
These indicate how many numbers
are stored f or the name. If a name
has more than three category icons,
‘‘…’’ is displayed.Availableonsomephones Select a ‘‘No Entry’’ f ield to store a
speed dial entry, or use the f ollowing
procedure. Up to 20 speed dial numbers can be
stored per phone name, and the f irst
f our numbers are displayed on the
Phone screen.
When your phone is paired, the
contents of its phonebook and call
history are automatically imported to
HFL.
:
(available on some phones) Edit Speed Dial
A ut omat ic Import Cellular
Phonebook and Call Hist oryBluetooth
HandsFreeL ink
(Models with navigation system)
530
Preference
Home
Mobile
Work
Pager Voice Car Fax
Other
The first four speed dial entries.
10/07/17 10:45:46 31TK8600_535
2011 Odyssey

µ
µ µ
To store a speed dial number:
Select ‘‘Edit Speed Dial’’ f rom the
Phone Setup screen.
Select a number on the speed dial
listwhereyouwanttostorethe
number.
Choose a number f rom:
Phonebook the linked cell
phone’s imported phonebook
Select ‘‘Store Speed dial.’’
When the speed dial number is
successf ully stored, you are asked
to store a voice tag f or the number.
Follow the prompts.
When a voice tag is stored for the
entry, you can dial the number by
saying ‘‘Call’’ and the voice tag name.
Dial manual number input Call History the last 20
numbers
2.
4.
1.
3.
5.
CONT INUED
Bluetooth
HandsFreeL ink
(Models with navigation system)
Features
531
10/07/17 10:45:55 31TK8600_536
2011 Odyssey

To add a voice tag to a stored speed dialnumber: To delete a voice tag:
Select ‘‘Edit Speed Dial’’ f rom the
Phone Setup screen.
Select ‘‘Store Voice Tag.’’
Select the number you want to
storeavoicetagfor.
Follow the prompts to complete
the voice tag.
Avoid using duplicate voice tags.
Avoid using ‘‘home’’ as a voice tag.
It is easier f or HFL to recognize a
longername.Forexample,use
‘‘John Smith’’ instead of ‘‘John.’’Select ‘‘Edit Speed Dial’’ f rom the
Phone Setup screen.
Select ‘‘Delete Voice Tag.’’
Select the number you want to
delete the voice tag for.
A trash icon appears next to the
selected numbers. Select ‘‘OK’’ to
continue.
1.
2.
3.
4. 1.
2.
3.
4.
Bluetooth
HandsFreeL ink
(Models with navigation system)
532
NOTE:
10/07/17 10:46:06 31TK8600_537
2011 Odyssey

To delete a speed dial number:To make a call using a name in the
Phonebook:
Select ‘‘Edit Speed Dial’’ f rom the
Phone Setup screen.
A trash icon appears next to the
selected numbers. Select ‘‘OK’’ to
continue. You can make calls by inputting any
phone number, using the imported
phonebook, using the call history, or
with speed dial entries.
Select ‘‘Delete Speed Dial.’’ When your phone is paired, the
contents of its phonebook are
automatically imported to HFL.
Select ‘‘Phonebook’’ f rom the
Phone screen.
Select a name f rom the list.
Select the number you want to
delete, and push ENTER.
2. 1.
3.
4.
1.
2.
CONT INUED
Making a Call
Bluetooth
HandsFreeL ink
(Models with navigation system)
Features
533
10/07/17 10:46:16 31TK8600_538
2011 Odyssey

To make a call using a phone number: To make a call using Call History:
Select ‘‘Dial’’ f rom the Phone
screen.
Enter the phone number, and
select ‘‘Dial.’’
To enter the phone number by voice,
say it in a continuous string. Select ‘‘Call History’’ f rom the
Phone screen.
Call History is sorted by ‘‘All,’’
‘‘Dial,’’ ‘‘Receive,’’ and ‘‘Missed.’’
Selecting a number begins
automatic dialing.
Push ENTER to list the number or
numbers stored f or the selected
name.
Select a number and push ENTER
to begin automatic dialing.
Some phones do not support
‘‘All’’ in the Call History.
1.
2.
3.
1.
2.
4.
Bluetooth
HandsFreeL ink
(Models with navigation system)
534
NOTE:
HISTORY LIST
10/07/17 10:46:26 31TK8600_539
2011 Odyssey

To make a call using Speed Dial:To make a call using More Speed Dial:
To make a call using Redial:Select one of the f our entries on the
Phone screen, and push ENTER to
begin automatic dialing. Select ‘‘More Speed Dial’’ on the
Phone screen.
When you receive a call, a
notif ication appears on the screen
(see page ).
To end or decline the call, press the
HANG-UP button. To answer the call, press the
PICK-UPbuttononthesteering
wheel.
A list of 20 stored speed dial
entries is shown. Select the entry
you want to call, and push ENTER
to begin automatic dialing.
: Any voice-tagged speed dial
entry can be dialed by voice f rom
any screen.
Press and hold the PICK-UP button
to redial the last number dialed in
your phone’s history. While the
display showing Phone screen, you
can also redial by pressing and
holding ENTER. 2. 1.
518
Receiving a Call
Bluetooth
HandsFreeL ink
(Models with navigation system)
Features
535
NOTE
VOICE TAG ICON
SPEED DIAL PHONE ICON
10/07/17 10:46:36 31TK8600_540
2011 Odyssey

뵵
µ
ÃŽ
The f ollowing options are available
during a call: Allows you to send
numbers or names during a call. This
is usef ul when you call a menu-
driven phone system. Allows you to transf er a
call f rom HFL to your phone, or
f rom your phone to HFL.
Allows you to mute your
voice.
Availableonsomephones If your phone has Call Waiting, press
and release the PICK-UP button to
put the original call on hold and
answer the incoming call.
To return to the original call, press
the PICK-UP button again. If you
don’t want to answer the incoming
call, disregard it and continue with
your original call. If you want to hang
up the original call and answer the
new call, press the HANG-UP button.
:
During a Call
Dial T ones Transfer
Mut e Call Wait ingBluetooth
HandsFreeL ink
(Models with navigation system)
536Example
10/07/17 10:46:44 31TK8600_541
2011 Odyssey

As required by the FCC:This device complies with Part 15 of theFCC rules. Operation is subject to thef ollowing two conditions: (1) This devicemay not cause harmf ul interf erence, and(2) this device must accept anyinterf erence received, includinginterf erence that may cause undesiredoperation.
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
This device complies with IndustryCanada Standard RSS-210.Operation is subject to the f ollowing twoconditions: (1) this device may not causeinterf erence, and (2) this device mustaccept any interf erence that may causeundesired operation of the device.
Bluetooth
Bluetooth
An incoming call on HFL will
interrupt
Audio when it is
playing. Audio will resume when the
call is ended. The
name and logos are
registered trademarks owned by
Bluetooth SIG, Inc. and any use of
such marks by Honda Motor Co.,
Ltd. is under license. Other
trademarks and trade names are
those of their respective owners.
HFL L imitations
Wireless Technology
Bluet oot h
Bluetooth
HandsFreeL ink
(Models with navigation system)
Features
537
10/07/17 10:46:50 31TK8600_542
