length HONDA ODYSSEY 2011 RB3-RB4 / 4.G Owners Manual

µ
µ
µ
µ µ
µ
µ
µ
µ The wipers run at high
speed until you release the lever.
The wipers are not activated.
The wipers run at low speed.
The wipers run at high speed. Pull the
wiper control lever toward you, and
hold it. The washers spray until you
release the lever. The wipers run at
low speed, then complete one more
sweep after you release the lever.
The length of the wipe
interval is varied automatically
according to vehicle’s speed.
Vary the delay by turning the
adjustment ring. If you turn it to the
shortest delay ( position), the
wipers change to low speed
operation when the vehicle speed
exceeds 12 mph (20 km/h).
MIST
OFF
INT Intermittent
LO Low speed
HI High speed
Windshield washers
Push the right lever up or down to
select a position. 1.
2.
3.
4.
5.
6. MIST
OFF
LO
HI
Windshield Washer
INT
Windshield Wipers
Windshield Wipers and Washers
Instruments and Controls
135
ADJUSTMENT RING
10/07/17 09:51:52 31TK8600_140
2011 Odyssey

When preparing to tow, and bef ore
driving away, be sure to check the
f ollowing:All items in or on the trailer are
properly secured and cannot shif t
while you drive.
Your vehicle tires and spare are
properly inf lated, and the trailer
tires and spare are inflated as
recommended by the trailer
maker.The added weight, length, and
height of a trailer will af f ect your
vehicle’s handling and perf ormance,
so driving with a trailer requires
some special driving skills and
techniques.
Foryoursafetyandthesafetyof
others,taketimetopracticedriving
maneuvers bef ore heading f or the
open road, and f ollow the guidelines
below.
Drive slower than normal in all
driving situations, and obey posted
speed limits f or vehicles with trailers.
Use the D position when towing a
trailer on level roads. Do not exceed
55 mph (88 km/h). At higher speeds,
the trailer may sway or affect vehicle
handling.
The vehicle has been properly
serviced, and the suspension,
cooling system, and lights are in
good operating condition.
The trailer has been properly
serviced and is in good condition.
All weights and loads are within
limits.
Thehitch,safetychains,andany
other attachments are secure.
The lights and brakes on your
vehicle and the trailer are working
properly.
Pre-T ow Checklist
Driving Saf ely With a T railer
T owing Speeds and Gears
Towing a Trailer594
10/07/17 10:54:00 31TK8600_599
2011 Odyssey

Slide the new blade into the wiper
arm. Make sure it is engaged in
the slot along its f ull length.
Insert both ends of the blade into
theholder.Makesuretheyare
secure.Install the wiper blade assembly
onto the wiper arm. Make sure it
locks in place.
Lower the wiper arm against the
windshield.
5.
6.
7.
Wiper Blades
Maint enance
641
10/07/17 11:00:06 31TK8600_646
2011 Odyssey

µµ
Î
Î
Î
Î
Î
Î
Î
Specif ications688
Air Conditioning
Dimensions
Engine Weights Capacities
3.3 US qt (3.1
)
5.3 US qt (5.0)
4.2 US qt (4.0)
4.5 US qt (4.3)
2.64 US gal (10.0
)
1.93 US gal (7.3)
24.7 26.5 oz (700 750 g)
ND-OIL8
HFC-134a (R-134a)
21 US gal (79.5)
Refrigerant type
Charge quantity
Lubricant type
78.6 in (1,997 mm) 202.9 in (5,153 mm)
Length
Width
Height
Wheelbase
Track 118.1 in (3,000 mm)
68.1 in (1,730 mm)
68.2 in (1,732 mm)
8,477 lbs (3,845 kg)
Water cooled 4-stroke SOHC
i-VTEC · VCM2, 6-cylinder (V6), gasoline engine
3.50 x 3.66 in (89.0 x 93.0 mm) 212 cu-in (3,471 cm
)
Type
BorexStroke
Displacement
Compression ratio
Spark plugs
DILZKR7A11G
68.4 in (1,737 mm)
10.5 : 1
See the tire information label
attached to the driver’s doorjamb.
Gross vehicle weight rating
Gross combined weight
rating (GCWR) Fuel tank
Engine
coolant
Engine oil
Automatic
transmission
fluid
Windshield
washer
reservoir
4.8 US qt (4.5
)
2.6 US qt (2.5)
7.4 US qt (7.0)
8.0 US qt (7.6)
3.6 US qt (3.4)
Excluding the oil remaining in the engine 0.225 US gal (0.85
)
Including the coolant in the reserve tank and that remaining in the
engine
Reserve tank capacity:
Front
Rear
Approx.
NGK: 1:
2:
3 : Touring modelsChange
Total
Change
Including
filter
Without
filter
Total
Change
Total
U.S. Vehicles
Canada Vehicles
3
1
2
3
10/07/17 11:05:55 31TK8600_693
2011 Odyssey
