indicator HONDA ODYSSEY 2012 RB3-RB4 / 4.G Owners Manual

410
uuIndicator, Coming On/BlinkinguIf the Low Tire Pressure/TPMS Indicator Comes On or Blinks
Handling the Unexpected
If the Low Tire Pressure/TPMS Indicator Comes On or Blinks
■
Reasons for the indicator to come on or blink
A tire pressure is significantly low. If there is a problem with the TPMS or
the compact spare tire is installed, the indicator blinks for about one
minute, and then stays on.
■
What to do when the indicator comes on
Stop your vehicle in a safe place. Check the tire pressure and adjust the
pressure to the specified level. The specified tire pressure is on a label on
the driver side doorjamb.
■
What to do when the indicator blinks
Have the tire inspected by a dealer as soon as possible. If the compact
spare tire has triggered the indicator to blink, change the tire to a full-
size tire. The indicator goes off after a while.
Models with multi-information display
1If the Low Tire Pressure/TPMS Indicator Comes On or Blinks
NOTICEDriving on an extremely underinflated tire can cause
it to overheat. An overheated tire can fail. Always
inflate your tires to the prescribed level.

425
Continued
Information
Emissions TestingTesting of Readiness CodesYour vehicle uses "readiness codes," as part of its onboard self diagnostic system.
Some states refer to these codes during testing to see if your vehicle's emissions
components are working properly.
The codes may not be read if you go through the testing just after the battery has
gone dead or been disconnected.
To check if they are set, turn the ignition switch to ON
(w
, without starting the
engine. The malfunction indicator lamp will come on for several seconds. If it then
goes off, the readiness codes are set. If it blinks five times, the readiness codes are
not set.
If you are required to have your vehicle tested before the readiness codes are ready,
prepare the vehicle for retesting by doing the following:
1.Fill the gas tank to approximately 3/4 full.
2.Park the vehicle and leave the engine off for 6 hours or more.
3.Make sure the ambient temperature is between 40°F and 95°F (4°C and 35°C).
4.Start the engine without touching the accelerator pedal, and let it idle for 20
seconds.
5.Keep the vehicle in
(P
. Increase the engine speed to 2,000 rpm, and hold it there
until the temperature gauge rises to at least 1/4 of the scale (about 3 minutes).
6.Let the engine idle with your foot off the accelerator for 20 seconds.
1Testing of Readiness Codes
The readiness codes are erased when the battery is
disconnected, and set again only after several days of
driving under a variety of conditions.
If a testing facility determines that the readiness
codes are not set, you may be requested to return at
a later date to complete the test.
If the testing facility determines the readiness codes
are still not set, see a dealer.

Index
433
Index
Index
AABS (Anti-lock Brake System).................. 316
AC Power Outlet...................................... 177
Accessories and Modifications................ 329
Accessory Power Sockets......................... 176
Additives
Coolant .................................................. 350
Engine Oil ............................................... 345
Washer ................................................... 354
Additives, Engine Oil............................... 345
Adjusting
Armrest .................................................. 168
Front Seats.............................................. 154
Head Restraints ....................................... 157
Mirrors.................................................... 152
Rear Seats ............................................... 162
Steering Wheel ....................................... 151
Temperature ........................................... 100
Air Conditioning System
(Climate Control System)....................... 187
Changing the Mode................................ 187
Defrosting the Windshield
and Windows........................................ 188
Dust and Pollen Filter .............................. 384
Recirculation/Fresh Air Mode................... 187
Sensors ................................................... 192
Using Automatic Climate Control............ 187
Air Conditioning System (Heating and
Cooling System)...................................... 183
Cooling................................................... 185Defrosting the Windshield
and Windows ........................................ 185
Dust and Pollen Filter ............................... 384
Heating ................................................... 184
Air Pressure....................................... 371, 421
Airbags........................................................ 39
Advanced Airbags ..................................... 45
After a Collision ......................................... 43
Airbag Care ............................................... 53
Event Data Recorder .................................. 23
Front Airbags (SRS) .................................... 42
Indicator ........................................ 50, 76, 80
Passenger Airbag Off Indicator .................. 51
Sensors ...................................................... 39
Side Airbag Cutoff System ......................... 48
Side Airbag Off Indicator ........................... 52
Side Airbags .............................................. 46
Side Curtain Airbags .................................. 49
AM/FM Radio.................................... 198, 205
Anti-lock Brake System (ABS).................. 316
Indicator .................................................... 75
Armrest..................................................... 168
Audio Remote Controls............................ 203
Audio System............................................ 194
Adjusting the Sound ........................ 197, 204
Auxiliary Input Jack .................................. 195
Error Messages ........................................ 235
General Information ................................ 237
MP3/WMA/AAC ...................................... 226
Reactivating ............................................. 196
Recommended CDs ................................. 238Recommended Devices............................ 240
Remote Controls ..................................... 203
Security Code .......................................... 196
Theft Protection ...................................... 196
USB Adapter Cable.................................. 195
USB Flash Drives ...................................... 240
Audio/Information Display........................ 91
Authorized Manuals................................ 429
Auto Door Locking/Unlocking................. 116
Customize ............................................... 117
Automatic Lighting.................................. 143
Automatic Transmission........................... 300
Creeping ................................................. 300
Fluid ........................................................ 352
Kickdown ................................................ 300
Operating the Shift Lever................... 17, 302
Shift Lever Does Not Move ...................... 403
Shifting ................................................... 301
Auxiliary Input Jack.................................. 195
Average Fuel Economy.................. 88, 92, 99
Average Speed................................... 92, 100
BBattery...................................................... 379
Charging System Indicator................. 73, 406
Jump Starting .......................................... 401
Maintenance (Checking the Battery) ........ 379
Maintenance (Replacing) ................. 380, 382
Belts (Seat).................................................. 30
Beverage Holders..................................... 174

434Index
Blind Spot Information (BSI) System........ 312
Bluetooth
® Audio..................................... 230
Bluetooth® HandsFreeLink
®..................... 259
Booster Seats (For Children)....................... 67
Brake System............................................. 314
Anti-lock Brake System (ABS) ................... 316
Brake Assist System ................................. 317
Fluid ........................................................ 353
Foot Brake ............................................... 315
Indicator ............................................ 72, 408
Parking Brake .......................................... 314
Brightness Control (Instrument Panel).... 147
BSI (Blind Spot Information) System........ 312
Bulb Replacement..................................... 355
Back-Up/Taillight...................................... 363
Brake/Rear Side Marker/Taillight
and Rear Turn Signal Lights .................... 361
Fog Lights ................................................ 359
Front Turn Signal/Parking/
Side Marker Lights ................................. 360
Headlights ............................................... 355
High-Mount Brake Light .......................... 365
Rear License Plate Light............................ 364
Bulb Specifications.................................... 420
CCarbon Monoxide Gas................................ 68
Cargo Hooks.............................................. 178
Carrying Cargo.................................. 287, 289
CD Library.................................................. 216CD Player........................................... 200, 212
Center Pocket........................................... 173
Certification Label.................................... 422
Changing Bulbs........................................ 355
Charging System Indicator................. 73, 406
Child Safety................................................. 54
Childproof Door Locks............................. 115
Child Seat.................................................... 54
Booster Seats ............................................ 67
Child Seat for Infants................................. 56
Child Seat for Small Children ..................... 57
Installing a Child Seat
with a Lap/Shoulder Seat Belt .................. 62
Larger Children ......................................... 66
Rear-facing Child Seat ............................... 56
Selecting a Child Seat ................................ 58
Using a Tether ........................................... 64
Childproof Door Locks............................. 115
Cleaning the Exterior............................... 387
Cleaning the Interior................................ 385
Climate Control System............................ 187
Changing the Mode ................................ 187
Defrosting the Windshield
and Windows ........................................ 188
Dust and Pollen Filter............................... 384
Recirculation/Fresh Air Mode ................... 187
Sensors ................................................... 192
Using Automatic Climate Control ............ 187
Clock.......................................................... 108
Coat Hooks............................................... 178
Compact Spare Tire.......................... 391, 421Controls.................................................... 107
Coolant (Engine)...................................... 350
Adding to the Radiator ........................... 351
Adding to the Reserve Tank .................... 350
Overheating ............................................ 404
Temperature Gauge .................................. 86
Creeping (Automatic Transmission)........ 300
Cruise Control.......................................... 303
Indicator ................................................... 81
Cup Holders.............................................. 174
Customer Service Information................ 430
Customized Features............................... 101
DDaytime Running Lights.......................... 144
Dead Battery............................................ 401
Defrosting the Windshield
and Windows................................. 185, 188
Devices that Emit Radio Waves............... 423
Dimming
Headlights .............................................. 142
Rearview Mirror ...................................... 152
Dipstick (Engine Oil)................................ 346
Directional Signals (Turn Signal)............. 142
Display/Information Button...................... 98
Door Mirrors............................................. 153
Doors........................................................ 110
Auto Door Locking.................................. 116
Auto Door Unlocking .............................. 116
Door and Tailgate Open Indicator ....... 29, 77

435
Index
Keys........................................................ 110
Locking/Unlocking the Doors
from the Inside...................................... 114
Locking/Unlocking the Doors
from the Outside................................... 112
Lockout Prevention System ..................... 113
DOT Tire Quality Grading........................ 373
Driving...................................................... 285
Automatic Transmission .......................... 300
Braking ................................................... 314
Cruise Control ........................................ 303
Shifting Gear .......................................... 301
Starting the Engine ................................. 297
Driving Position Memory System............ 149
Dust and Pollen Filter.............................. 384
EElapsed Time........................................ 92, 99
Electronic Stability Control (ESC)............ 306
Emergency................................................ 417
Emissions Testing (Readiness Codes)...... 425
Engine....................................................... 422
Coolant .................................................. 350
Jump Starting ......................................... 401
Oil .......................................................... 345
Starting................................................... 297
Switch Buzzer ......................................... 141
Engine Coolant........................................ 350
Adding to the Radiator ........................... 351
Adding to the Reserve Tank .................... 350Overheating ............................................ 404
Temperature Gauge .................................. 86
Engine Oil................................................. 345
Adding .................................................... 347
Checking ................................................. 346
Displaying Oil Life ............................ 335, 339
Low Oil Pressure Indicator .................. 72, 406
Recommended Engine Oil ........................ 345
Exhaust Gas Hazard
(Carbon Monoxide).................................. 68
Exterior Care (Cleaning)........................... 387
Exterior Mirrors........................................ 153
FFeatures..................................................... 193
Filters
Dust and Pollen ....................................... 384
Oil ........................................................... 348
Flat Tire..................................................... 391
Flip-up Trash Bag Ring............................. 172
Floor Mats................................................. 386
Fluids
Automatic Transmission ........................... 352
Brake ....................................................... 353
Engine Coolant ........................................ 350
Power Steering ........................................ 354
Windshield Washer .................................. 354
Fog Light Indicator..................................... 80
Folding Down the Rear Seats.......... 162, 166
Foot Brake................................................. 315Front Airbags (SRS)..................................... 42
Front Seats................................................ 154
Adjusting ................................................ 154
Fuel...................................................... 18, 325
Economy ................................................. 328
Gauge ....................................................... 86
Instant Fuel Economy .......................... 92, 99
Low Fuel Indicator ..................................... 75
Range ........................................... 88, 92, 99
Recommendation .................................... 325
Refueling................................................. 325
Fuel Economy........................................... 328
Fuel Fill Cap........................................ 18, 327
Message.................................................. 407
Fuel Fill Door...................................... 18, 326
Fuses.......................................................... 411
Inspecting and Changing......................... 416
Locations................. 411, 412, 413, 414, 415
GGasoline (Fuel)
Economy ................................................. 328
Gauge ....................................................... 86
Information ............................................. 325
Instant Fuel Economy .......................... 92, 99
Low Fuel Indicator ..................................... 75
Refueling................................................. 325
Gauges........................................................ 86
Gear Shift Lever Positions
Automatic Transmission .......................... 301

436Index
Glass (care)................................................ 388
Glove Box.................................................. 171
Grocery Bag Hooks................................... 179HHalogen Bulbs................................... 355, 359
Handling the Unexpected........................ 389
HandsFreeLink
® (HFL)............................... 259
HandsFreeLink® (HFL)
Automatic Answering .............................. 270
Automatic Import of Cellular Phonebook and
Call History ............................................ 272
Automatic Transferring ............................ 270
HFL Buttons ............................................. 259
HFL Menus .............................................. 261
HFL Status Display.................................... 260
Making a Call .......................................... 276
Options During a Call .............................. 281
Phone Setup ............................................ 264
Receiving a Call ....................................... 280
Speed Dial ............................................... 273
HandsFreeLink® (HFL)
To Clear the System ................................. 271
HandsFreeLink® (HFL)
To Create a Security PIN........................... 269
Hazard Warning Button............................... 2
Head Restraints......................................... 157
Headlights................................................. 142
Aiming .................................................... 355
Automatic Operation ............................... 143Dimming ......................................... 142, 144
Operating................................................ 142
Heaters (Seat)........................................... 181
Heating and Cooling System................... 183
Cooling ................................................... 185
Defrosting the Windshield
and Windows ........................................ 185
Dust and Pollen Filter............................... 384
Heating ................................................... 184
HFL (HandsFreeLink
®)............................... 259
High Beam Indicator.................................. 79
IIdentification Numbers............................ 422
Engine and Transmission ......................... 422
Vehicle Identification ............................... 422
Ignition Switch......................................... 141
Illumination Control................................. 147
Knob ....................................................... 147
Immobilizer System.................................. 134
Indicator.................................................... 80
Indicators.................................................... 72
ABS (Anti-lock Brake System)..................... 75
BSI (Blind Spot Information) System ........... 83
Charging System ............................... 73, 406
CRUISE CONTROL ............................. 81, 304
CRUISE MAIN .................................... 81, 303
Daytime Running Lights............................. 77
Door and Tailgate Open ...................... 29, 77
Fog Light ................................................... 80Fuel Economy ........................................... 81
High Beam ................................................ 79
Immobilizer System ................................... 80
Lights On .................................................. 79
Low Fuel ................................................... 75
Low Oil Pressure ............................... 72, 406
Low Tire Pressure .............................. 78, 308
Low Tire Pressure/TPMS ............ 78, 308, 309
Maintenance Minder......................... 82, 335
Malfunction Indicator Lamp .............. 73, 407
Parking Brake and Brake System ....... 72, 408
Parking Sensor .......................................... 77
Power Sliding Door ................................... 83
Power Tailgate .......................................... 82
Seat Belt Reminder.............................. 31, 75
Security System Alarm............................... 81
Shift Lever Position.................................... 74
Side Airbag Off ................................... 52, 80
Starter System........................................... 81
Supplemental Restraint System ........... 50, 76
System Message ....................................... 79
TPMS ................................................ 78, 310
Transmission ............................................. 74
Turn Signal ............................................... 79
VSA
® (Vehicle Stability Assist)
System ............................................ 76, 306
VSA® OFF .......................................... 76, 307
Washer Level ............................................ 82
Information.............................................. 419
Information Display................................... 87
Instant Fuel Economy.................... 88, 92, 99

437
Index
Instrument Panel........................................ 71
Brightness Control .................................. 147
Integrated Sunshades.............................. 182
Interior Lights........................................... 169
Interior Rearview Mirror......................... 152JJack (Wheel Nut Wrench)........................ 394
Jump Starting........................................... 401KKey Number Tag...................................... 111
Keyless Lockout Prevention..................... 113
Keys........................................................... 110
Lockout Prevention ................................. 113
Master Keys ............................................ 110
Number Tag............................................ 111
Rear Door Won’t Open ........................... 115
Remote Transmitter ................................ 112
Types and Functions................................ 110
Valet Key ................................................ 111
Won’t Turn ............................................... 21
Kickdown (Automatic Transmission)...... 300LLanguage (HFL)........................................ 260
LATCH (Child Seats)................................... 59
Lights................................................ 142, 355
Automatic............................................... 143Bulb Replacement .................................... 355
Daytime Running Lights ........................... 144
Fog Lights ................................................ 144
High Beam Indicator .................................. 79
Interior .................................................... 169
Light Switches ......................................... 142
Lights On Indicator .................................... 79
Turn Signals ............................................. 142
Load Limits................................................ 289
Locking/Unlocking.................................... 110
Auto Door Locking/Unlocking .................. 116
Childproof Door Locks ............................. 115
From Inside .............................................. 114
From Outside ........................................... 112
Keys ........................................................ 110
Using a Key ............................................. 113
Lockout Prevention System...................... 113
Low Battery Charge.................................. 406
Low Fuel Indicator...................................... 75
Low Oil Pressure Indicator................. 72, 406
Lower Anchors............................................ 59
Luggage (Maximum Load Limit)............. 289
MMaintenance............................................. 331
Battery .................................................... 379
Brake Fluid .............................................. 353
Cleaning .................................................. 385
Climate Control System ........................... 384
Coolant ................................................... 350Heating and Cooling System ................... 384
Maintenance Minder™ ........................... 335
Oil ........................................................... 346
Power Steering Fluid................................ 354
Precautions ............................................. 332
Radiator .................................................. 351
Remote Control
and Wireless Headphone ....................... 382
Remote Transmitter ................................. 380
Replacing Light Bulbs .............................. 355
Safety...................................................... 333
Service Items ................................... 337, 341
Tires ........................................................ 370
Transmission Fluid ................................... 352
Under the Hood ...................................... 343
Malfunction Indicator Lamp.............. 73, 407
Map Lights................................................ 170
Maximum Load Limit............................... 289
Meters, Gauges........................................... 86
Mirrors...................................................... 152
Adjusting ................................................ 152
Door ....................................................... 153
Exterior ................................................... 153
Interior Rearview ..................................... 152
Modifications (and Accessories).............. 329
Moonroof................................................. 140
MP3........................................... 200, 212, 226
Multi-Information Display......................... 98

438Index
NNumbers (Identification).......................... 422OOdometer.............................................. 87, 99
Oil (Engine)............................................... 345
Adding .................................................... 347
Checking ................................................. 346
Displaying Oil Life ............................ 335, 339
Low Oil Pressure Indicator .................. 72, 406
Recommended Engine Oil ........................ 345
Viscosity .................................................. 345
Opening/Closing
Hood ....................................................... 344
Moonroof ................................................ 140
Power Windows ...................................... 137
Sliding Door............................................. 126
Tailgate ................................................... 120
Outside Temperature Display............ 89, 100
Overheating.............................................. 404PPanic Mode............................................... 136
Parking...................................................... 318
Parking Brake............................................ 314
Parking Brake and Brake System
Indicator............................................ 72, 408
Parking Sensor System.............................. 319
Passenger Airbag Off Indicator................. 51Passing Indicators..................................... 142
Power Sliding Door.................................. 128
Power Tailgate......................................... 122
Power Windows....................................... 137
Precautions While Driving....................... 299
Rain ........................................................ 299
Pregnant Women....................................... 37
Puncture (Tire).......................................... 391
RRadiator.................................................... 351
Radio (AM/FM)................................. 198, 205
Radio Data System (RDS)................. 199, 208
Range.............................................. 88, 92, 99
RDS (Radio Data System)................. 199, 208
Readiness Codes (Emissions Testing)....... 425
Rear Defogger/Heated Door Mirror
Button..................................................... 148
Rear Entertainment System..................... 241
Rear Seats (Folding Down).............. 162, 166
Rearview Camera..................................... 323
Rearview Mirror....................................... 152
Refueling.................................................. 325
Fuel Gauge................................................ 86
Gasoline .......................................... 325, 420
Low Fuel Indicator ..................................... 75
Regulations............................... 309, 373, 423
Remote Transmitter................................. 112
Removable Center Console...................... 171
Removing a Second Row Outer Seat...... 163Removing the Second Row
Center Seat............................................. 165
Replacement
Battery ............................................ 380, 382
Bulbs ...................................................... 355
Fuses ...................... 411, 412, 413, 414, 415
Tires........................................................ 376
Wiper Blade Rubber ................................ 366
Reporting Safety Defects......................... 424
Resetting a Trip Meter......................... 88, 99
SSafe Driving................................................ 25
Safety Check............................................... 29
Safety Labels.............................................. 69
Safety Message.......................................... 24
Seat Belts.................................................... 30
Adjusting the Shoulder Anchor ........... 34, 35
Automatic Seat Belt Tensioners ................. 32
Checking .................................................. 38
Fastening .................................................. 33
Installing a Child Seat
with a Lap/Shoulder Seat Belt .................. 62
Pregnant Women...................................... 37
Reminder .................................................. 31
Warning Indicator ............................... 31, 75
Seat Heaters............................................. 181
Seats.......................................................... 154
Adjusting ................................................ 154
Front Seats.............................................. 154

439
Index
Rear Seats ............................................... 162
Seat Heaters ........................................... 181
Security System........................................ 134
Immobilizer System Indicator..................... 80
Security System Alarm Indicator ................ 81
SEL/RESET Knob.................................... 87, 98
Select Lever........................................ 17, 301
Operation ......................................... 17, 302
Releasing ................................................ 403
Won’t Move ........................................... 403
Selecting a Child Seat................................ 58
Selector Knob (Audio)............................. 202
Setting the Clock...................................... 108
Shift Lever.......................................... 17, 301
Shift Lever Position Indicator............ 74, 302
Shifting (Transmission)............................ 301
Shoulder Anchor.................................. 34, 35
Side Airbags............................................... 46
Cutoff System ........................................... 48
Off Indicator ............................................. 48
Side Curtain Airbags.................................. 49
Sliding Door............................................. 126
Power Sliding Door ................................. 128
Sliding the Second Row Outer Seats
Outward................................................. 164
Snow Tires................................................ 378
Spare Tire......................................... 391, 421
Spark Plugs............................................... 420
Specifications........................................... 420
Specified Fuel................................... 325, 420
Speedometer.............................................. 86SRS Airbags (Airbags)................................. 42
Starting the Engine.................................. 297
Does Not Start ......................................... 400
Engine Switch Buzzer .............................. 141
Jump Starting .......................................... 401
Steering Wheel......................................... 151
Adjusting ................................................. 151
Stopping.................................................... 318
Summer Tires............................................ 378
Sunglasses Holder..................................... 180
Supplemental Restraint System (SRS)........ 42
Switches
(Around the Steering Wheel)........ 2, 3, 141
System Message Indicator.......................... 79
TTachometer................................................. 86
Tailgate..................................................... 120
Unable to Open ....................................... 418
Temperature
Gauge ....................................................... 86
Outside Temperature Display ............. 89, 100
Temperature Gauge................................... 86
Temperature Sensor................... 89, 100, 192
Time (Setting)........................................... 108
Tire Pressure Monitoring System
(TPMS)..................................................... 308
Indicator .................................... 78, 409, 410
Tires........................................................... 370
Air Pressure ..................................... 371, 421Checking and Maintaining ...................... 370
Inspection ............................................... 370
Labeling .................................................. 371
Puncture (Flat Tire) .................................. 391
Regulations ............................................. 373
Rotation .................................................. 377
Spare Tire ........................................ 391, 421
Summer .................................................. 378
Tire Chains .............................................. 378
Wear Indicators ....................................... 375
Winter..................................................... 378
Tools.......................................................... 390
Towing a Trailer....................................... 291
Equipment and Accessories ..................... 292
Load Limits .............................................. 291
Towing Your Vehicle
Emergency .............................................. 417
TPMS (Tire Pressure Monitoring
System).................................................... 308
Indicator.................................... 78, 409, 410
Transmission............................................. 301
Automatic ............................................... 301
Fluid ........................................................ 352
Number................................................... 422
Shift Lever Position Indicator.............. 74, 302
Trip Meter....................................... 88, 92, 99
Troubleshooting....................................... 389
Blown Fuse.............. 411, 412, 413, 414, 415
Brake Pedal Vibrates .................................. 21
Buzzer Sounds When Opening Door.......... 22
Emergency Towing .................................. 417

440Index
Engine Won’t Start .................................. 400
Noise When Braking .................................. 22
Overheating............................................. 404
Puncture/Flat Tire ..................................... 391
Select Lever Won’t Move ......................... 403
Sliding Door Won’t Open................... 21, 115
Warning Indicators .................................... 72
Tucking away the One-Motion Third row
magic Seat............................................... 166
Turn Signals............................................... 142
Indicators (Instrument Panel) ...................... 79
UUnlocking the Doors................................. 112
Unlocking the Front Doors
from the Inside........................................ 114
USB Adapter Cable........................... 194, 195
USB Flash Drives........................................ 240VValet Key................................................... 111
Vanity Mirrors............................................... 5
Vehicle Identification Number................. 422
Vehicle Stability Assist (VSA
®).................. 306
Vehicle Stability Assist (VSA®)
Off Button ............................................... 307
Off Indicator .............................................. 76
System Indicator ........................................ 76
Ventilation........................................ 183, 187Viscosity (Oil).................................... 345, 421
VSA
® (Vehicle Stability Assist).................. 306
WWallpaper................................................... 94
Warning and Information Messages......... 84
Warning Indicator On/Blinking............... 406
Warning Labels........................................... 69
Warranties (Warranty Manual provided
separately).............................................. 427
Watts......................................................... 420
Wear Indicators (Tire).............................. 375
Wheel Cover............................................. 395
Wheel Nut Wrench (Jack Handle)........... 394
Window Washers..................................... 145
Adding/Refilling Fluid .............................. 354
Switch ..................................................... 145
Windows (Opening and Closing)............ 137
Windshield................................................ 145
Cleaning ................................................. 388
Defrosting ....................................... 185, 188
Washer Fluid ........................................... 354
Wiper Blades ........................................... 366
Wipers and Washers................................ 145
Winter Tires.............................................. 378
Snow Tires .............................................. 378
Tire Chains .............................................. 378
Wipers and Washers................................. 145
Checking and Replacing Wiper Blades ..... 366
WMA......................................... 200, 212, 226Worn Tires................................................ 370
