reset HONDA ODYSSEY 2013 RC1-RC2 / 5.G Navigation Manual

232Reference Information
System InitializationThe navigation system must be initialized if
power to the navigation system is
interrupted for any reason (e.g., the
battery was disconnected).Entering the Security CodeWhen you purchased the vehicle, you
should have received a card with the
navigation system security code and serial
number. Keep this card in a safe place. If
you lose the card, you must obtain the
security code from your dealer.
1.Press the VOLUME button to activate
the audio system.
2. Enter the 5-digit security code when
prompted using the radio preset
buttons.
Acquiring GPS InformationDepending on the length of time the
power was interrupted, your system may
require GPS initialization.
If initialization is not necessary, the system
proceeds directly to the Startup
Confirmation screen.
If the system fails to locate a sufficient
number of satellites to locate your position
within 10 minutes, th e following screen is
displayed.
If you are experiencing GPS reception
problems: 2 GPS System
P. 234

249

Voice Commands
Climate Control Commands
Voice Commands
Climate Control CommandsThe system accepts these commands on
most screens.Climate control automatic (maintains
selected temperature)
Climate control off
Air conditioner on *
Air conditioner off *
Climate control defrost on *
Climate control defrost off *
Rear defrost on *
Rear defrost off *
Climate control fresh air
Climate control recirculate
Climate control vent
Climate control bi-level (vent and floor)
Climate control floor
Climate control floor and defrost
Fan speed up
Fan speed down
Fan speed # (#: 1 to 7)
Rear lock on
Rear lock off
Temperature # degrees (#: 57 to 87 °F)
Driver temperature # degrees (#: 57 to
87 °F) Passenger temperature # degrees
(#: 57
to 87 °F)
Temperature up
Temperature down
Driver temperature up
Driver temperature down
Passenger temperature up
Passenger temperature down
Temperature max hot
Temperature max cold
Driver temperature max hot
Driver temperature max cold
Passenger temperature max hot
Passenger temperature max cold
Climate control sync on
Climate control sync off
Front climate control automatic
(maintains selected temperature)
Front climate control off
Rear climate control automatic
(maintains selected temperature)
Rear climate control off
Rear climate control vent
Rear climate control bi-level (vent and
floor)
Rear climate control floor
Rear fan speed up
Rear fan speed down Rear fan speed #
(#: 1 to 5)
* These commands toggle the function on and off, so the command may not
match your intended action.
Audio CommandsThe system accepts these commands on
most screens.
Audio on *
Audio off *
Radio on *
Radio off *
Radio select FM1
Radio select FM2
Radio select AM
Radio tune to # FM (#: frequency, e.g.,
95.5)
Radio tune to # AM (#: frequency, e.g.,
1020)
Radio seek up
Radio seek down
Radio next station
Radio preset # (#: 1 to 6)
Radio FM preset # (#: 1 to 6)
Radio FM1 preset # (#: 1 to 6)■Radio Commands
Continued

250

Voice Commands
Audio Commands
Voice Commands
Radio FM2 preset # (#: 1 to 6)
Radio AM preset # (#: 1 to 6)
Radio auto select*
Radio scan *
Radio select XM1
Radio select XM2
XM channel # (#: 1 to 255)
XM channel up
XM channel down
XM category up
XM category down
XM preset # (#: 1 to 6)
XM1 preset # (#: 1 to 6)
XM2 preset # (#: 1 to 6)
XM scan *
XM category scan *
XM channel scan *
XM category mode
XM channel mode
* These commands toggle the function on and off, so the command may not
match your intended action.
NOTE:
Radio volume levels cannot be controlled
using voice control. DISC play
DISC play track #
(#: 1 to 30)
DISC skip forward
DISC skip back
DISC track random *
DISC track repeat *
DISC track scan*
DISC folder up
DISC folder down
DISC folder random *
DISC folder repeat *
DISC folder scan *
DISC normal play (cancels random,
repeat, or scan play mode, resumes
normal play mode)
* These commands toggle the function on and off, so the command may not
match your intended action.
■Disc Commands
HDD play
HDD search (activates Song By Voice™)
HDD skip forward
HDD skip back
HDD album up *1
HDD album down *1
HDD genre up *1
HDD genre down *1
HDD artist up *1
HDD artist down *1
HDD track up
HDD track down
HDD playlist up *1
HDD playlist down *1
HDD track random *2
HDD track repeat *2
HDD track scan *1
HDD normal play (cancels random,
repeat, or scan play mode, resumes
normal play mode)
What/Who am I listening to?
Who is this?
What’s playing?
Who’s playing?
What album is this?■ HDD Commands

252

Voice Commands
Audio Commands
Voice Commands
Play song (specify song)
What/Who am I listening to?
Who is this?
What’s playing?
Who’s playing?
What album is this?
NOTE:
Song By Voice™ commands are available
for tracks stored on the HDD or iPod®.
Rear audio on*
Rear audio off*
Rear radio on*
Rear radio off*
Rear radio select FM1
Rear radio select FM2
Rear radio select AM
Rear radio tune to # FM (#: frequency,
e.g., 95.5)
Rear radio tune to # AM (#: frequency,
e.g., 1020)
Rear radio seek up
Rear radio seek down
Rear radio next station
Rear radio preset # (#: 1 to 6)
Rear radio FM preset # (#: 1 to 6)
Rear radio FM1 preset # (#: 1 to 6)■Rear Radio Commands
Rear radio FM2 preset # (#: 1 to 6)
Rear radio AM preset # (#: 1 to 6)
Rear radio auto select*
Rear radio scan*
Rear radio select XM1
Rear radio select XM2
Rear XM channel # (#: 0 to 255)
Rear XM channel up
Rear XM channel down
Rear XM category up
Rear XM category down
Rear XM preset # (#: 1 to 6)
Rear XM1 preset # (#: 1 to 6)
Rear XM2 preset # (#: 1 to 6)
Rear XM scan*
Rear XM category scan*
Rear XM channel scan*
Rear XM category mode
Rear XM channel mode
* These commands toggle the function between on and off, so the command
may not match your intended action.
NOTE:
Radio volume levels cannot be controlled
using voice control. Rear CD play
Rear CD play track #
(#: 1 to 30)
Rear CD skip forward
Rear CD skip back
Rear CD track random*
Rear CD track repeat*
Rear CD track scan*
Rear CD normal play (resumes “Play”
from the random-, repeat-, or scan-play)
Rear CD folder up
Rear CD folder down
Rear CD folder random*
Rear CD folder repeat*
Rear CD folder scan*
* These commands toggle the function between on and off, so the command
may not match your intended action.
■Rear CD Commands

261Index
IndexSymbolsK (Back) Button
.................................... 5
, 22
a (Display Mode) Button
...................... 29
j (Hang-Up) Button
................................ 185
h (Pick-Up) Button
.......................... 185
, 186
8 (Sound) Button
............................. 6
, 166
d (Talk) Button
...................................... 5
, 22
AA.SEL (Auto Select)
.................................... 133
Add to Address Book
.......................... 90
, 127
Add to Dest. List
..........90
, 121
, 125
, 126
, 127
Add to Playlist
............................................ 151
Address
Editing Address Book
................................. 40
Editing Avoid Area
..................................... 54
Setting Destination
..................................... 70
Address BookEditing Address Book
................................. 38
Setting Destination
..................................... 75
Address Book PIN
........................................ 43
Adjust Time
.................................................. 59
Advanced (Place Category)
........................ 80
AM/FM Button
....................................... 6
, 132
AM/FM Radio
Playing
...................................................... 132
Voice Commands List
............................... 249
Audio
........................................................... 129
Basic Operation
............................................ 6
Control Display
............................................. 7
Remote Control
........................................ 167
Sound Setup
............................................. 166
Voice Commands List
............................... 249
AUDIO Button
................................................7
Audio Menu
Bluetooth ® Audio
....................................165
Disc
...........................................................142
FM/AM Radio
............................................133
HDD
..........................................................146
iPod®
........................................................157
USB Flash drive
.........................................162
XM® Radio
...............................................137
Auto Daylight
...............................................58
Auto Service (Place Category)
....................80
Auto Time Zone
...........................................58
AUX
Input Jack
..................................................131
Voice Commands List
...............................251
Avoid Streets
.............................................. 117
BBanking (Place Category)
...........................80
Basic Settings
................................................ 26
Black Level
....................................................24
Bluetooth® Audio
Playing
......................................................164
Voice Commands List
...............................251
Bluetooth ® HandsFreeLink®
...................169
Editing User Name/PIN
..............................180
Importing Phonebook
...............................177
Making a Call
...........................................182
Pairing a Phone
.........................................172
Receiving a Call
.........................................185
Setting Speed Dials
...................................178
Brightness
...............................................24
, 29
CCalculator
................................................... 213
Calendar
..................................................... 211
Call
Calculate Route Screen
...................... 90
, 127
Call History
................................................. 184
Cancel Route
.............................................. 117
Category
Editing Address Book
................................. 40
Place Category List
................................... 258
Setting Destination
.................................... 80
CATEGORY Bar
.............................................. 6
Category Scan
............................................ 137
CD Button
............................................... 6
, 141
CD Recording
............................................. 149
Cellular Phone
Voice Commands List
.............................. 254
CH (Channel) Button
................................ 168
Change Language
....................................... 20
Change Route Preference
.......................... 91
Change State
............................................... 71
Channel List
............................................... 137
Channel Scan
............................................. 137
City
................................................................ 72
City Vicinity
Setting Destination
.................................... 81
Clear Personal Data
.................................... 65
Clock Adjustment
........................................ 58
Adjust Time
................................................ 59
Auto Daylight
............................................. 58
Auto Time Zone
......................................... 58
Resetting
.................................................... 59

263

Index
Index
KKey to ZAGAT Ratings
.............................. 216
LLanguage
...................................................... 31
Leisure (Place Category)
............................. 80
Lodging (Place Category)
........................... 80
MMap Color
..................................................... 28
Map Data Update
Checking Version
..................................... 215
Obtaining Update DVD
............................ 237
Viewing Upda te Status
............................. 216
Map Information
....................................... 105
Map Input
Editing Avoid Area
..................................... 54
Setting Destination
..................................... 88
Map Legend
......................................... 10
, 110
Map Menu
.................................................... 98
Map Screen
................................................... 93
Icon
............................................. 10
, 106
, 112
Orientation
............................................... 108
Scale
......................................................... 111
MAP/GUIDE Button
............................. 11
, 103
Menu (Dest. Menu 1)
.................................. 68
Menu (Dest. Menu 2)
.................................. 68
Menu (Route)
............................................. 116
MENU Button
Changing Route
....................................... 116
Entering a Destination
................................ 68
Menu Color
.................................................. 28
Mode
...........................................................137
MODE Button
.............................................167
More Speed Dial
........................................170
Music Search
.................................................45
HDD
..........................................................150
iPod®
........................................................158
Phonetic Modification
................................47
Song By Voice
.....................................46
, 159
Mute
............................................................185
NNight Mode
Map Color
...................................................28
Menu Color
................................................ 28
Switching Display Mode
.............................29
North-up
..................................................... 108
Note
.............................................................138
OOff-road Tracking
Driving
........................................................96
Setting
........................................................62
Open Map
...................................................102
PPair Phone
...................................................172
Pass-Key
.......................................................174
Personal Information
..................................37
Phone Setup
...............................................170
Phonebook
Importing
..................................................177
Making a Call
...........................................183
PIN Numbers
................................................ 43
Place Category
Editing Address Book
................................. 40
Place Category List
................................... 258
Setting Destination
.................................... 80
Place Name
Editing Address Book
................................. 40
Setting Destination
.............................. 77
, 81
Place Phone No.Editing Address Book
................................. 40
Setting Destination
.................................... 84
Preset Buttons
............................................... 6
Previous Destination
Deleting
...................................................... 44
Editing Address Book
................................. 40
Setting Destination
.................................... 76
RRadioFM/AM
..................................................... 132
XM®
........................................................ 136
RandomDisc
........................................................... 142
HDD
......................................................... 147
Pass-Key
................................................... 174
USB Flash Drive
........................................ 162
RDS Search
................................................. 134
Read Radio Text
........................................ 135
Rearview Camera
...................................... 217
Rec to HDD
................................................. 149
Recalculation
......................................... 50
, 95
Reminder
.............................................. 21
, 212

264

Index
Index
RepeatDisc
...........................................................142
HDD
..........................................................147
iPod®
........................................................157
USB Flash Drive
.........................................162
Rerouting
......................................................50
Reset Clock Settings
....................................59
Reset Factory Default
..................................64
Restaurant (Place Category)
.......................80
Route (Menu)
.............................................116
Route Pref.
....................................................91
Routing & Guidance
....................................49
SScan
Disc
...........................................................143
FM/AM Radio
............................................133
HDD
..........................................................147
USB Flash Drive
.........................................162
SCAN/TITLE Bar
...............................................6
Scenic Road Information
..........................215
Schedule
Calendar
...................................................211
Search a Next Connected Phone
.............176
Search Along
..............................................119
Search Around
............................................119
Search by Keyword
......................................81
Search Phonebook
.....................................183
Security PIN Code
.......................................232
Shopping (Place Category)
.........................80
Show Icon on Map
.....................................106
Shuffle
.........................................................157
Single Screen
..............................................103
SKIP Bar
...........................................................6
Song By Voice
Searching Music
....................................... 159
Setting
........................................................ 46
Voice Commands List
.............................. 251
Sort by Distance to Travel
.......................... 81
Sound Setup
............................................... 166
Speed Dial
Making a Call
........................................... 184
Registering
............................................... 178
Split Screen
................................................ 104
Street
............................................................ 73
Street Name Guidance
............................... 56
System/Device Information
...................... 215
TTITLE Button
.................................................. 6
Traffic Detail
.............................................. 115
Traffic Rerouting
....................................... 114
Transfer
...................................................... 185
Travel (Place Category)
.............................. 80
Trip Computer
........................................... 210
Tune
FM/AM Radio
........................................... 133
XM® Radio
.............................................. 137
TUNE Bar
........................................................ 6
UUnit Conversion
......................................... 213
Units (mile or km)
....................................... 26
Unverified Area Routing
............................ 51
Update System Software
Finding Update Information
.................... 237
Obtaining Update DVD
............................ 237
USB Flash Drive
Connecting, Disconnecting
.............. 155
, 160
Playing
...................................................... 160
Voice Commands List
............................... 251
USB/AUX Button
.................... 6
, 156
, 161
, 164
VVehicle
.......................................................... 61
Correct Vehicle Position
............................. 63
Off-road Tracking
....................................... 62
View Area Map
............................................ 53
View Routes
................................................. 91
Voice
Map Menu
.................................................. 97
Voice Commands
Basic Operation
............................................ 9
Help
.............................................................. 5
Voice Commands List
............................... 246
Voice Control System
................................. 22
Voice Control OperationBasic Operation
............................................ 5
Voice Recognition Tutor
............................ 26
Voice Tag
.................................................... 179
VOL (Volume) Button
............................... 167
VOL 9 (Volume/Power) Knob
.................... 6
Volume
.......................................................... 24
WWallpaper
Deleting, Impor ting, Setting
....................... 32
Waypoint
Adding
...................................................... 118
Deleting, Ordering
.................................... 122
