audio HONDA ODYSSEY 2014 RC1-RC2 / 5.G Navigation Manual

166

Playing Hard Disc Drive (HDD) Audio
Recording a Music CD to HDD
Audio
Recording a Music CD to HDDThe songs on music CDs are automatically recorded by factory default to the HDD
the first time you play each disc. You can then play the songs directly from the HDD.
1.Press the MENU button. (in CD mode)
2.Rotate i to select Cancel Record to HDD. Press u.
1.Press the MENU button. (in CD mode)
2.Rotate i to select Rec to HDD. Press u.
1Recording a Music CD to HDD
You can add tracks to user playlists, where you
can mix and match tracks from other CDs
recorded on the HDD.
2Editing an Album or Playlist P. 171
2Editing Track Information P. 173
If you stop the engine or the power system is
turned off while recording a CD, there may be
pauses between songs when you play back from
the HDD.
■Stopping Recording■Recording a CD Manually
Recording indicator
Recording
Ready to record
Repeat, random, and scan functions are not
available during recording.
You can play music from other sources (e.g., XM,
HDD, etc.) while recording.
Please note that there is no compensation
offered in the case of unsuccessful recording of
audio data or the loss of audio data due to any
cause whatsoever.
Clearing the HDD
Any music tracks stored on the HDD can be
deleted.

167

Playing Hard Disc Drive (HDD) Audio
Audio Screen Control
Audio
Audio Screen ControlControl the audio system through the navigation screen and touchscreen.
1.Rotate i or u press to display
the song list.
2.Rotate i, move w or y to
select a track from the list. Press
u.

Press MENU button to display
the menu items2Audio Menu P. 149
1.Select n skip to the next playlist/
album, and b to skip to the
beginning of the previous playlist/
album.
2.Select c or x to change tracks.
Select and hold to move rapidly
within a track.

Select More to display the menu
item.2Audio Menu P. 149
Interface Dial
Track AAATrack AAATrack AAA010101
Album AAAAlbum AAAAlbum AAA
010101
Touchscreen

168

Playing Hard Disc Drive (HDD) Audio
Audio Menu
Audio
Audio MenuHMENU button (in HDD mode)
Rotate i to select an item. Press u.
The following items are available:
•Scan:
Scan Albums: Provides 10-second sampling of the first track in each album.
Scan Tracks: Provides 10-second sampling of all tracks on HDD.
•Music Search: Selects a file from the Music Search list.
2
How to Select a Track from the Music Search List
P. 170
•Change Source: Changes the audio source mode.
•Random/Repeat: The following menu items vary depending on the category you
selected by the Music Search list.
Repeat Artist: Repeats all tracks in the current artist.
Repeat Album: Repeats all tracks in the current album.
Repeat Track: Repeats the current track.
Random in Artist: Plays all tracks in the current artist in random order.
Random in Album: Plays all tracks in the current album in random order.
Random All Tracks: Plays all tracks in random order.
•Edit/Delete: Change the playlist name, album name, genre, and track order of
the current playlist. You can also delete tracks, playlists, and albums.
Interface Dial

169

Playing Hard Disc Drive (HDD) Audio
Audio Menu
Audio
1.Select More.
2.Select a setting item.
The following items are available:
•Sound Settings: Displays the sound preferences screen.
2
Adjusting the Sound
P. 145
•Random/Repeat: The following menu items vary depending on the category you
selected by the Music Search list.
Repeat Artist: Repeats all tracks in the current artist.
Repeat Album: Repeats all tracks in the current album.
Repeat Track: Repeats the current track.
Random in Artist: Plays all tracks in the current artist in random order.
Random in Album: Plays all tracks in the current album in random order.
Random All Tracks: Plays all tracks in random order.
•Scan:
Scan Albums: Provides 10-second sampling of the first track in each album.
Scan Tracks: Provides 10-second sampling of all tracks on HDD.
•Screen Settings: Displays the screen preferences screen.
2
Changing the Screen Settings
P. 82
Touchscreen

170

Playing Hard Disc Drive (HDD) Audio
Audio Menu
Audio
HMENU button (in HDD mode)
 Music Search
1.Move w or y to select a search
category. Press u.
2.Rotate i to select a track from
the Music Search list. Press u.
■How to Select a Track from the Music Search List

171

Playing Hard Disc Drive (HDD) Audio
Audio Menu
Audio
HMENU button (in HDD mode)
 Edit/Delete
1.Rotate i to select Albums or
Playlist. Press u.
2.Rotate i to select an album or
playlist that you want edit or
delete. Press u.

The pop-up menu appears on
the screen.
3.Rotate i to select an item. Press
u.
The following items are available:
•Edit Name: Enter a new name using the interface dial or the touchscreen.
•Delete: Deletes the selected album or playlist.
•List Tracks: Change the track title, artist name, genre and composer. You can
also delete tracks.
■Editing an Album or Playlist
1Editing an Album or Playlist
The maximum number of songs in each of the six
user playlists is 999. Adding new songs
overwrites the oldest songs.
The maximum number of original playlists is 999
with a maximum of 99 songs in each playlist.
Each album CD counts as an original playlist.
Adding a track from a user playlist into the same
user playlist will cause the track to appear twice
in the playlist.
Deleting an album (original playlist) also deletes
the album tracks you have stored in any user
playlists.
Deleting a user playlist or deleting all tracks from
a user playlist does not remove the playlist folder.
The folder retains the playlist name and artist
information.

172

Playing Hard Disc Drive (HDD) Audio
Audio Menu
Audio
HMENU button (in HDD mode)
 Edit/Delete
Playlists
Create New Playlist
1.Enter the playlist name using the
interface dial or the touchscreen.
2.Select tracks from the music search
list.
■Creating a new Playlist

173

Playing Hard Disc Drive (HDD) Audio
Audio Menu
Audio
HMENU button (in HDD mode)
 Edit/Delete
 Tracks
Change the track title, artist name, genre and composer. You can also delete tracks.
Rotate i select a track you want to
edit or delete. Press u.
The pop-up menu appears on the
screen.
The following items are available:
•Edit Name: Enter the track information (track name, track artist, etc.) using the
interface dial or the touchscreen.
•Delete: Deletes a track.
■Editing Track Information

174

Playing Hard Disc Drive (HDD) Audio
Audio Menu
Audio
HMENU button (in HDD mode)
 Edit/Delete
Music information (album name, artist name, genre) can be acquired by accessing
the Gracenote® Album Info.
1.Rotate i to select Albums. Press
u.
2.Rotate i to select an album that
you want edit or delete. Press u.

The pop-up menu appears on
the screen.
3.Rotate i to select Edit Name.
Press u.
4.Move r to select Get Music Info.
Press u.

The system starts to access the
Gracenote® Album Info.
■Displaying Music Information

175

Playing Hard Disc Drive (HDD) Audio
Audio Menu
Audio
HSETTINGS button (in HDD mode)
 Audio Settings
Update the Gracenote® Album Info (Gracenote® Media Database) that is included
with the navigation system.
1.Insert the update disc into the disc
slot or connect the USB flash drive
that includes the update.
2.Rotate i to select Update
Gracenote Album Info. Press u.
3.Rotate i to select Update by CD
or Update by USB. Press u.

The system starts updating and
the confirmation message
appears on the screen. Press to
finish u.
■Updating Gracenote® Album Info
1Updating Gracenote® Album Info
To acquire updated files:
•Consult a dealer.
•Visit http://www.navteq.com/gracenote/
honda.
Once you perform an update, any information
you edited before will be overwritten or erased.
