294Reference Information
System LimitationsGPS SystemThe signals received from the GPS satellites
are extremely weak (less than a millionth
of the strength of a local FM station) and
require an unobstructed view of the sky.
The GPS antenna is located in the
dashboard. The signal reception can easily
be interrupted or interfered with by the
following:
•Metallic window tint on the front or side
windows
•Cell phones, PDAs, or other electronic
devices docked in a cradle or lying loose
on the dashboard
•Remote starters or “hidden” vehicle
tracking systems mounted near the
navigation unit
•Audio electronic devices mounted near
the navigation unit
•Trees, tall buildings, freeway overpasses,
tunnels, or overhead electrical power
wires
The GPS is operated by the U.S.
Department of Defense. For security
reasons, there are certain inaccuracies built
into the GPS for which the navigation
system must constantly compensate. This can cause occasional positioning errors of
up to several hundred feet.
Address CalculationThe destination icon shows only the
approximate location of a destination
address. This occurs if the number of
possible addresses is different from the
number of actual addresses on a block. For
example, the address 1425 on a 1400
block with 100 possible addresses
(because it is followed by the 1500 block)
will be shown a quarter of the way down
the block by the system. If there are only
25 actual addresses on the block, the
actual location of address 1425 would be
at the end of the block.
DatabaseThe digitized map database reflects
conditions as they existed at various points
in time before production. Accordingly,
your database may contain inaccurate or
incomplete data or information due to the
passage of time, road construction,
changing conditions, or other causes.
For example, some places/landmarks may
be missing when you search the database
because the name was misspelled, the
place was improperly categorized, or a
place/landmark is not yet in the database.
This is also true for police stations,
hospitals, and other public institutions. Do
not rely on the navigation system if you
need law enforcement or hospital services.
Always check with local information
sources.

307
Voice Commands
Voice Commands.................................. 308
Navigation Commands ......................... 308
Voice Portal Commands ....................... 310
Phone Commands................................ 310
Info Commands ................................... 311
Climate Control Commands ................. 311
Audio Commands ................................ 312
On-Screen Commands ......................... 316
Spelling Assistance ............................... 316

308Voice Commands
Voice CommandsNavigation CommandsThe system accepts these commands on a
map/guidance screen.Display phone (equivalent to PHONE)
Display audio (equivalent to AUDIO)
Display navigation (if en route, displays
the Route screen)
Display information (equivalent to INFO)
Display menu (equivalent to MENU. if en
route, displays Route Options)
Display setting (equivalent to SETTING)
Display map
Display map guide (when en route,
shows the next guidance point)
Display rear audio
Display front audio
Cancel
What time is it?
What is today’s date?
Voice help (displays commands for
current screen)■ General Commands
Display current location (shows current
latitude, longitude, and elevation)
Display/Hide (specify icon type):
ATM
gas station
restaurant
post office
grocery store
lodging (hotel, motel)
parking garage
parking lot
school
hospital
freeway exit information
traffic
traffic speeds
traffic icons
traffic incidents
Go home
Register the current location (stores
current location in the Address Book)■ Map Display Commands
Display north up
Display heading up
Display 3D map
Display zoom in
Display zoom out
Display (specify scale):
1/20 mile (80 m) scale
1/8 mile (200 m) scale
1/4 mile (400 m) scale
1/2 mile (800 m) scale
1 mile (1600 m) scale
2 mile (3 km) scale
5 mile (8 km) scale
15 mile (24 km) scale
50 mile (80 km) scale
150 mile (240 km) scale
350 mile (560 km) scale
1000 mile (1600 km) scale
Max zoom in
Max zoom out■ Map Scale Commands

310

Voice Commands
Voice Portal Commands
Voice Commands
Toy store
Travel center
Airport
Automobile club
Bus station
Camping
Commuter rail station
Ferry terminal
Named place
Park & ride
Parking garage
Parking lot
Rental car agency
Rest area
Ski area
Tourist information
Train station
Travel agency
Truck stopThe system accepts these commands when
a route is set.
How long to the destination?*
How far to the destination?*
Display destination map
Display entire route
Cancel route
Repeat guidance
* These commands are not available if
you scroll through the map while en
route to a destination.
■Route Commands
Voice Portal CommandsThe system accepts these commands on
the Voice Portal screen.
•Call Your contact name
•Call Phone Number
•Find nearest POI category name
•Go home
•Route menu
•Cancel routePhone CommandsThe system accepts these commands on
any screen.
•Call by number
•Call by name
Contacts that are imported from your
phone to the vehicle are all made available
by voice. Voice Tags can also be recorded
for each of your Speed Dial entries.

314

Voice Commands
Audio Commands
Voice Commands
•Bluetooth Audio play
• Bluetooth Audio skip forward
• Bluetooth Audio skip back
• Bluetooth Audio group up
• Bluetooth Audio group down
• Bluetooth Audio pause
• Bluetooth Audio resume
NOTE:
Bluetooth ® Audio commands may not
work on some phones or Bluetooth®
Audio devices.
• Auxiliary play■Bluetooth® Audio commands■AUX commands
The system accepts these commands while
the Pandora® is playing.
• Pandora play
• Pandora skip forward
• Pandora station up
• Pandora station down
• Pandora pause
• Pandora resume
• Pandora thumbs up
• Pandora thumbs down
The system accepts these commands while
the Aha
TM is playing.
• Aha radio play
• Aha radio skip forward
• Aha radio skip back
• Aha radio station up
• Aha radio station down
• Aha radio resume
• Aha radio pause
• Aha radio like
• Aha radio dislike
■Pandora® commands■Aha
TM Radio commands
• Internet service play
• Internet service skip forward
*1
•Internet service skip back
*1
•Internet service station up
*1
•Internet service station down
*1
•Internet service resume
*1
•Internet service pause
*1
•Internet service like
*1
•Internet service dislike
*1
*1: The system accepts these commands
while the Internet service is playing.
Rear audio on*
Rear audio off*
Rear radio on*
Rear radio off*
Rear radio select FM
Rear radio select AM
Rear radio tune to # FM (#: frequency,
e.g., 95.5)
Rear radio tune to # AM (#: frequency,
e.g., 1020)
Rear radio seek up
Rear radio seek down
Rear radio next station■ Internet service commands■Rear Radio Commands

316

Voice Commands
On-Screen Commands
Voice Commands
Rear HDD play
Rear HDD skip forward
Rear HDD skip back
Rear HDD album up
Rear HDD album down
Rear HDD track up
Rear HDD track down
Rear HDD playlist up
Rear HDD playlist down
Rear HDD track random*
Rear HDD track repeat*
Rear HDD track scan*
Rear HDD normal play (resumes “Play”
from the random-, repeat-, or scan-play)
* These commands toggle the function between on and off, so the command
may not match your intended action.■Rear HDD Commands
Rear iPod play
Rear iPod skip forward
Rear iPod skip back
Rear iPod track shuffle*
Rear iPod album shuffle*
Rear iPod track repeat*
Rear iPod normal play (resumes “Play”
from the shuffle- or repeat-play)
* These commands toggle the function between on and off, so the command
may not match your intended action.
Rear AUX play (or Rear Auxiliary play)■Rear iPod Commands■Rear AUX Commands
On-Screen CommandsThe system accepts these commands on
any screen. There are over 100 on-screen
commands. Say what is written on the
screen to activate that selection. For lists,
you can say the list item number to select
that item.
Next (or Down)
Previous (or Up)
Return
OK (excluding Startup Confirmation
screen)
DeleteSpelling AssistanceThe voice control system can also
recognize phonetic alphabet input for
numbers, letters, accented letters,
punctuation marks, and symbols.
NOTE:
When selecting letters using the voice
control system, a confirmation box may
pop up to confirm the entry.

323Index
IndexSymbolsa (Display Mode) Button ..................... 70
J (Hang-Up/Back) Button ............... 5, 22
d (Talk) Button..................................... 5, 22Numerics3D Angle Adjustment ................................ 73AAddress
Editing Address Book ................................ 39
Editing Avoid Area .................................... 56
Setting Destination.................................... 86
Address Book
Editing Address Book ................................ 37
Setting Destination.................................... 92
Address Book PIN ....................................... 43
Aha
TM Radio.............................................. 289
ATM/Bank (Place Category) ....................... 94
Audio
Remote Control ...................................... 142
Settings .................................................. 143
Touchscreen ............................................... 6
Voice Commands List .............................. 312
Audio Menu
Bluetooth® Audio ................................. 199
Disc ........................................................ 158
FM/AM Radio .......................................... 147
HDD ....................................................... 165
Internet Radio ......................................... 189
iPod® ..................................................... 177
USB Flash drive........................................ 193XM® Radio ............................................ 153
Audio System
Auxiliary Input Jack ................................. 138
Security Code ......................................... 139
Theft Protection ...................................... 139
USB Port ................................................. 137
Auxiliary Input Jack ................................. 138
Avoid Streets ............................................ 130
Avoided Area ............................................. 55
BBlack Level.................................................. 25
Bluetooth® Audio
Playing.................................................... 199
Voice Commands List ............................. 314
Bluetooth® HandsFreeLink®
Editing User Name/PIN .................... 221, 222
Importing Phonebook Data ..................... 212
Making a Call ......................................... 226
Pairing a Phone....................................... 206
Phone Settings........................................ 221
Receiving a Call ...................................... 231
Setting Up Speed Dialing ........................ 213
Brightness................................................... 25CCalendar ................................................... 271
Call
Calculate Route Screen ................... 108, 134
Call History ............................................... 229
Cancel Route ............................................ 123
Category
Editing Address Book ................................ 39Place Category List .................................. 320
Setting Destination .................................... 94
Category History
Deleting .................................................... 45
Change State .............................................. 87
City .............................................................. 88
City Vicinity
Setting Destination .................................... 95
Clock Adjustment ....................................... 27
Community (Place Category) ..................... 94
Continue Trip............................................ 134
Contrast ...................................................... 25
Coordinate ................................................ 107
Correct Vehicle Position ............................. 80
Current Location ........................................ 74
Current Position
Editing Address Book ................................ 39
Setting Destination .................................. 105
DDay Mode
Day ........................................................... 69
Night......................................................... 69
Switching Display Mode ............................ 70
Delete Tracking .......................................... 79
Destination List
Adding Waypoint .................................... 124
Editing .................................................... 128
Detour ....................................................... 130
Dial ............................................................ 228
Directions .................................................. 118
Disc
Playing .................................................... 158
Voice Commands List .............................. 313

324

Index
Index
Display Tracking ......................................... 79
Driving .................................................... 113
Setting ...................................................... 79
Download POI
Editing Category ....................................... 47
Importing Category ................................... 46
Setting Destination .................................. 102EEdit Go Home ............................................. 42
Edit Home Entry ....................................... 108
Edit POI Search Radius Along Route ......... 54
Edit/Delete Entry ...................................... 108
Emergency (Place Category) ...................... 94
ENTER Button ............................................... 7
Error Messages ......................................... 284
Aha
TM Radio ............................................ 289
CD Player ................................................ 285
Hard Disc Drive (HDD) Audio ................... 286
iPod®/USB Flash Drive ............................. 287
Navigation System ................................... 284
Pandora® ............................................... 288
Estimated Time ........................................... 64
Exit Info..................................................... 119
FFM/AM Radio
Playing .................................................... 147
Voice Commands List .............................. 312
Folder List
Disc ......................................................... 162
USB Flash Drive ....................................... 198
Fuel/Auto (Place Category) ........................ 94
GGo Home .................................................... 11
Go Home PIN .............................................. 43
Gracenote Info. Update........................... 175
Guidance (Navi Settings) ........................... 57
Guidance Mode.......................................... 58
Guidance Point........................................... 63HHDD
Playing .................................................... 165
Voice Commands List.............................. 312
Home Address ...................................... 11, 42
Honda Automobile Customer Service .... 296
House Number ........................................... 91IImport Phonebook Data.......................... 212
Interface Dial................................................ 7
Intersection .............................................. 104
iPod®
Connecting, Disconnecting ............. 177, 193
Playing .................................................... 177
Voice Commands List.............................. 313LLanguage Settings ..................................... 33
Lodging (Place Category) .......................... 94
MMap (Navi Settings) ................................... 65
Map Data Update
Checking Version ................................... 272
Obtaining Update Data ........................... 297
Map Input
Editing Avoid Area .................................... 56
Setting Destination ................................. 105
Map Legend ........................................... 9, 75
Map Menu ............................................... 116
Map Screen .............................................. 110
Changing View......................................... 72
Icon ...................................................... 9, 77
Scale ........................................................ 76
Map/Guidance ......................................... 117
MENU Button
Changing Route ..................................... 122
Entering a Destination .............................. 84
Multi-View Rear Camera ......................... 274
Music Search
HDD ....................................................... 153
iPod® ..................................................... 183
Phonetic Modification ............................. 186
Song By Voice ........................................ 185NNAV Button .......................................... 10, 58
Navigation Menu (Destination) ................ 84
Navigation Menu (Route Option)........... 122
Next Maneuver Pop up ............................. 62
Night Mode
Switching Display Mode ........................... 70
Non-map screens ....................................... 61

325

Index
Index
PPandora® ................................................. 190
Personal Info .............................................. 36
Phone Setup ............................................. 221
Phonebook
Importing ................................................ 212
Making a Call ......................................... 227
PIN Numbers ............................................... 43
Place Category
Editing Address Book ................................ 39
Place Category List .................................. 320
Setting Destination.................................... 94
Place Name
Editing Address Book ................................ 39
Setting Destination.................................... 96
Place Phone Number
Editing Address Book ................................ 39
Setting Destination.................................... 99
Previous Destinations
Deleting .................................................... 44
Editing Address Book ................................ 39
Setting Destination.................................... 93RRadio
FM/AM ................................................... 147
XM® ...................................................... 153
Random
Disc ................................................ 160, 161
HDD ............................................... 168, 169
USB Flash Drive ............................... 196, 197
Rear Entertainment System ..................... 246
Auxiliary Console Panel ........................... 246Front Control Panel................................. 261
HDMI Input Jack ..................................... 247
Rear Control Panel .................................. 250
Wireless Headphones.............................. 265
Rearview Camera ..................................... 274
Recreation (Place Category) ...................... 94
Repeat
Disc ................................................ 160, 161
HDD ............................................... 168, 169
iPod® ............................................. 181, 182
USB Flash Drive ............................... 196, 197
Restaurant (Place Category)...................... 94
Route Option ........................................... 122
Route Preference ....................................... 50
Routing....................................................... 49
SScan
Disc ................................................ 160, 161
FM/AM Radio ................................. 149, 151
HDD ............................................... 168, 169
USB Flash Drive ............................... 196, 197
Scenic Road Information ......................... 272
Scenic Route ............................................. 103
Schedule
Calendar................................................. 271
Search Along ............................................ 125
Search Around ......................................... 125
Search by Name ......................................... 95
Search Nearby .......................................... 131
Security PIN Code..................................... 292
SETTINGS Button.......................................... 4
Shopping (Place Category) ........................ 94
Show Icon on Map ..................................... 67Song By Voice
TM
Searching Music ...................................... 185
Setting .................................................... 184
Voice Commands List .............................. 312
Sort by Distance to Travel .......................... 95
Sound Setup ..................................... 145, 146
Speed Dial
Making a Call .......................................... 230
Registering .............................................. 214
Straight Line Guide .................................... 73
Street........................................................... 89
Street Name Guidance ............................... 60
System/Device Information ...................... 272TTouchscreen
Basic Operation ........................................... 6
Screen Settings.......................................... 82
Shortcuts................................................. 140
Sound Settings ........................................ 145
Traffic Incidents ........................................ 120
Traffic List ................................................. 120
Traffic Rerouting ...................................... 120
Auto Reroute .......................................... 120
Navi Settings ............................................. 53
Travel (Place Category) .............................. 94
Trip Computer .......................................... 270UUnit Settings ............................................... 32
Unverified Routing..................................... 51
Update System Software
Finding Update Information..................... 297
