HONDA PILOT 2009 2.G Owners Manual
Manufacturer: HONDA, Model Year: 2009, Model line: PILOT, Model: HONDA PILOT 2009 2.GPages: 578, PDF Size: 12.57 MB
Page 141 of 578

Make sure the shif t lever is in the
Park (P) position.
Turn the ignition switch to the ON
(II) position, and open the driver’s
door.
Your vehicle has customizable
settings f or the doors and tailgate to
automatically lock and unlock. There
are default settings for each of these
f eatures. You can turn of f or change
the settings for these features as
described on the f ollowing pages.
When you customize the setting,
make sure your vehicle is parked
saf ely, the engine is of f , and apply
the parking brake. Make all settings
bef ore you start driving.
To change the ‘‘AUTO DOOR
LOCK’’ setting, see page .
To change the ‘‘AUTO DOOR
UNLOCK’’ setting, see page . The auto door locking f eature has
three possible settings:
The auto door locking is
deactivated all the time.
Thedoorsandthetailgatelock
whenever you move the shif t lever
out of the Park (P) position.
Thedoorsandthetailgatelock
when the vehicle speed reaches
9mph(15km/h).
This is the def ault setting. 1.
2.
114
115
CONT INUED
On Touring models
Except Touring models
Except Touring models
A uto Door L ocking/Unlocking A uto Door L ockingT o t urn of f t he A ut o Door L ock
modes:
Door L ocks
Inst rument s and Cont rols
137
——
y
y
(/y
y
2009 Pilot
Page 142 of 578

Locks all doors and tailgate when theshif t lever is moved out of the Park (P)position.
Make sure the shif t lever is in the
Park (P) position. Release the switch, and within 5
seconds, turn the ignition switch
to the LOCK (0) position.
Turn the ignition switch to the ON
(II) position, and make sure to
close the driver’s door. Pushandholdthefrontof the
master door lock switch on the
driver’s door. You will hear a click.
Keep holding the switch until you
hear another click (after about 5
seconds).
Pushandholdthefrontof the
master door lock switch on the
driver’s door until you hear a click
(af ter about 5 seconds).
Release the switch, and within 5
seconds, turn the ignition switch
to the LOCK (0) position.
4.
1.
2. 3.
4. 3.
To program the Park Lock mode:
Door L ocks
138
——
y
y
(/y
y
2009 Pilot
Page 143 of 578

Locks all doors and tailgate when thevehicle’s speed reaches about 9 mph(15 km/h). Except Touring models
Make sure the shif t lever is in the
Park (P) position.Pushandholdthefrontof the
master door lock switch on the
driver’s door. You will hear a click.
Keep holding the switch until you
hear another click (after about 5
seconds). Push and hold the brake pedal,
and move the shif t lever out of the
Park (P) position.
Release the switch and, within 5
seconds, turn the ignition switch
to the ACCESSORY (I) position.
Move the shift lever to the Park
(P) position.
Turn the ignition switch to the
LOCK (0) position.
Turn the ignition switch to the ON
(II) position, and make sure to
close the driver’s door. The auto door unlocking f eature has
f ive possible settings:
The auto door unlocking is
deactivated all the time.
The driver’s door unlocks when
you move the shif t lever to the
Park (P) position.
This is the def ault setting.
All doors and tailgate unlock when
you move the shif t lever to the
Park (P) position.
The driver’s door unlocks
whenever you turn the ignition
switch to the ACCESSORY (I)
position.
All doors and tailgate unlock
whenever you turn the ignition
switch to the ACCESSORY (I)
position.
3.
4.
1.
2. 5.
6.
CONT INUED
T o program t he Drive L ock mode:A uto Door Unlocking
Door L ocks
Inst rument s and Cont rols
139
——
y
y
(/y
y
2009 Pilot
Page 144 of 578

Unlocks the driver’s door or all doorsand tailgate when the shif t lever ismoved into the Park (P) position.
Make sure the shif t lever is in the
Park (P) position.
Turn the ignition switch to the ON
(II) position, and make sure to
close the driver’s door.
Make sure the shif t lever is in the
Park (P) position.
Turn the ignition switch to the ON
(II) position, and open the driver’s
door. Pushandholdtherearof the
master door lock switch on the
driver’s door. You will hear a click,
and after about 5 seconds, you will
hear another click.
Release the switch, and within 5
seconds, turn the ignition switch
to the LOCK (0) position.
1.
2.
1.
2. 3.
4.
To program the Park Unlock mode:
T o t urn of f t he A ut o Door Unlock
modes:
Door L ocks
140
——
y
y
(/y
y
2009 Pilot
Page 145 of 578

Unlocks the driver’s door or all doorsand tailgate when the ignition switch ismoved out of the ON (II) position.
all doors and tailgate
unlock f eature driver’s door unlock
feature.
Make sure the shif t lever is in the
Park (P) position. Pushandholdtherearof the
master door lock switch on the
driver’s door. You will hear a click.
Continue to hold the switch:
Release the switch and, within 5
seconds, turn the ignition switch
to the ACCESSORY (I) position.
Move the shift lever to the Park
(P) position.
Turn the ignition switch to the
LOCK (0) position.
Turn the ignition switch to the ON
(II) position, and make sure to
close the driver’s door. Push and hold the brake pedal,
and move the shif t lever out of P.
Release the switch, and within 5
seconds, turn the ignition switch
to the LOCK (0) position. Pushandholdtherearof the
master door lock switch on the
driver’s door. You will hear a click.
Continue to hold down the switch: Or, until you hear two more
clicks (af ter about 10 seconds)
to activate
.
Until you hear another click
(af ter about 5 seconds) to
activate the driver’s door unlock
feature.
Or, until you hear two more
clicks (af ter about 10 seconds)
to activate all doors and tailgate
unlock f eature.
Until you hear another click
(af ter about 5 seconds) to
activate
4.
5.
1.
2. 3.
6.
3.
4.
T o program t he Ignit ion Swit ch
Unlock mode:
Door L ocks
Inst rument s and Cont rols
141
——
y
y
(/y
y
2009 Pilot
Page 146 of 578

With any door and the tailgate open
andthekeyintheignition,both
master door lock switches are
disabled. They are not disabled if all
thedoorsandthetailgateareclosed.
If you try to lock an open driver’s
door by pulling the lock tab rearward
the lock tab on the driver’s door pops
out.The childproof door locks are
designed to prevent children seated
in the rear f rom accidentally opening
the rear doors. Each rear door has a
lock lever near the edge. With the
lever in the LOCK position (lever is
down), the door cannot be opened
fromtheinsideregardlessof the
position of the lock tab. To open the
door, push the lock tab f orward and
use the outside door handle.Make sure the shif t lever is in the
Park (P) position.
To open the tailgate, press and hold
the switch, then lift up. To close the
tailgate, use the inner handle to pull
it down, then press down on the back
edge.
L ockout Prevent ionChildproof Door L ocks
T ailgate
Door L ocks, T ailgat e and Glass Hat ch
142
Lock
——
y
y
(/y
y
2009 Pilot
Page 147 of 578

The tailgate can be opened and
closed with the remote transmitter
(see page ) or the switch in the
driver’s door pocket when both f ront
doors are unlocked.
Keep the tailgate closed at all times
while driving to avoid damaging the
tailgate and to prevent exhaust gas
f rom getting into the interior. See
on page
.
If you push the same button or
switch again while the tailgate is
opening or closing, you will hear
three beeps, and the tailgate will stop
moving, reverse direction, and stop
at the f ully opened or closed position. Press and hold the tailgate button on
the remote transmitter or the switch
f or about 1 second to open or close
the tailgate. Each time you press the
button on the remote transmitter or
the switch, you will hear a beep, and
some f ront and rear lights will f lash. If the glass hatch is opened, remote
transmitter operation is canceled
until it is closed.
59
149
CONT INUED
On Touring models
Power Tailgate
Carbon Monoxide Hazard
Tailgate and Glass Hatch
Inst rument s and Cont rols
143
POWER TAILGATE SWITCH
——
y
y
(/y
y
2009 Pilot
Page 148 of 578

Also check that passengers,
especially children, do not have their
hands on the edge of the tailgate or
on the tailgate sill. The auto reverse
featurestopsworkingwhenthe
tailgate is about to latch so the motor
can pull the tailgate shut.
If your vehicle’s battery is
disconnected, goes dead, or the f use
is removed while the tailgate is f ully
open, the power tailgate needs to be
reset. After connecting the battery
or installing the f use, close the
tailgate f ully by hand.
The power tailgate may not open or
close under the these conditions:The vehicle is parked on a steep
hill.
When the vehicle is swayed in a
strong wind.
The power tailgate has an auto-
reverse f eature. If it meets
resistance while opening or closing,
it will beep three times and reverse
direction. However, the tailgate may
not reverse immediately. Always
make sure passengers and objects
are clear of the tailgate before
opening or closing it.
The tailgate can also be closed by
pressing the button on the tailgate. If
you press the button again while the
tailgate is closing, you will hear three
beeps, and the tailgate will stop
moving, reverse direction, and stop
at the f ully opened position.A ut o-Reverse
Tailgate and Glass Hatch
144
TAILGATE SWITCHClosing a power tailgate while
anyone is in the path of the
tailgate can cause serious
injury.
Make sure everyone is clear
before closing the power
tailgate.
——
y
y
(/y
y
2009 Pilot
Page 149 of 578

CONT INUED
If you try to drive off with the
tailgate not closed completely, a
beeper sounds and a ‘‘DOOR &
TAILGATE OPEN’’ message is
shown on the multi-inf ormation
display.
Keep the tailgate closed at all times
while driving to avoid damaging the
tailgate and to prevent exhaust gas
f rom getting into the interior. Seeon page
.
If there is a problem in the power
tailgate system, you will see a
‘‘CHECK POWER TAILGATE’’
message on the multi-inf ormation
display. Have the system checked by
your dealer.
With this message shown on the
multi-inf ormation display, you can
still open or close the tailgate
manually.
When the tailgate or the roof is
covered with snow or ice.
Do not install any accessories on the
tailgate. It may cause the tailgate not
to f unction properly. If there is snow
or ice on the tailgate, make sure to
remove it bef ore you operate the
tailgate.
The tailgate has sensors on both
sides. Be caref ul not to damage them.
If the sensors are damaged, the
power tailgate does not f unction
properly. If you push the tailgate release
button inside the handle while the
tailgate is opening or closing, it will
stop moving. You need to open or
close it the rest of the way manually. If the power door lock system cannot
unlock the tailgate, unlock it
manually.
Use a small flat-tipped screwdriver to
remove the cover on the back of the
tailgate.
59 Unlocking the T ailgate
Carbon Monoxide Hazard
Tailgate and Glass Hatch
Inst rument s and Cont rols
145
——
y
y
(/y
y
2009 Pilot
Page 150 of 578

To open the glass hatch, press the
glass hatch release button on the
tailgate.
If you need to unlock the tailgate
manually, it means there is a
problem with the tailgate. Have the
vehicle checked by your dealer. Push the release lever to the right as
shown. Make sure the shif t lever is in the
Park (P) position. If youcannotopenthetailgate,
remove the cover on the back of the
tailgate (see page ). Make sure
the shif t lever is in the Park (P)
position. Push the release lever to
the right as shown, then pull the
outer handle to open the tailgate.To close the glass hatch, lower it and
press on the handle until it latches.
145
Except Touring models
On Touring models
Tailgate and Glass Hatch
Glass Hatch
146
GLASS HATCH RELEASE BUTTON
——
y
y
(/y
y
2009 Pilot
