oil temperature HONDA PRELUDE 1990 Owners Manual

Engine Exhaust Gas Warning
A properly maintained car is your best protection against exhaust
gas entering the passenger compartment. The exhaust system should be thoroughly inspected by acompetent mechanic whenever:

The car is raised for an oil change.
You notice a change in the sound of the exhaust.
The exhaust system or the rear or underside of the car is

damaged.

Avoid breathing exhaust gases. They contain carbon monoxide, which is a colorless, odorless gas that can cause loss of
consciousness and eventual death. If you suspect that exhaust gas is entering the passenger compartment, have the cause
determined and corrected as soon as possible. If you must drive
under these conditions, drive only with all windows fully open. Do not drive with the trunk lid open. An open trunk may draw
exhaust gases into the passenger compartment. If you must
drive with the trunk lid open, drive only with all the windows
wide open.
Do not run the engine in confined areas, such as garages, any
longer than necessary to move the car in or out. If you must sit in a parked car with the engine running for more
than a short time, adjust the heating/ventilation system as
follows:
1. Push the
and buttons on.
2. Set the temperature lever for best comfort.
3.Turn the fan to the highest speed.

NOTE:

To insure proper operation of the car's ventilation system, keep the
front air inlet clear of snow, mud, leaves or other obstructions.ProCarManuals.comMain Menu t s

Engine Oil and Filter

Checking

Check the engine oil a couple of minutes after shutting the engine
off, with the car parked on level ground. Remove the dipstick and wipe it clean. Reinsert it all the way down, then pull it out and read
the level. The level should be between the upper and lower marks.
ENGINE OIL
FILLER CAP

Adding
If the level has dropped close to the lower mark, add oil until it is
even with the upper mark. 1 .Turn the oil filler cap counterclockwise to remove. Add oil, then check the level again. Do not overfill.
2. Reinstall the cap and twist clockwise until it stops.

CAUTION:
Be sure the oil filler cap is correctly replaced before starting the

engine.
Engine oil is a major factor affecting the performance and

service life of the engine; you should use only a premium quality

detergent oil labeled SG grade.
LOOK FOR THIS LABEL
ON THE OIL CONTAINER

Use the proper viscosity oil for the
climate in which you drive:
Some oil labels may also include additional designations of quality
such as CC or CD. However, these are acceptable only when
used together with SG.
NOTE:

5W-30 viscosity
oil is recommended for improved fuel economy.

(cont'd)

Ambient Temperature

UPPER

LOWER
DIPSTICKProCarManuals.comMain Menu t s

Use the proper

viscosity oil for

the climate in
which you drive:
Ambient Temperature
Automatic
The automatic transmission fluid level is checked (with the engine off and the car on level ground) using the dipstick in the right end of
the transmission housing. Remove the dipstick and wipe it off.
Insert the dipstick and remove it. The fluid level should be between
the upper and lower marks.
If necessary, add fluid and recheck. Use only DEXRON ®
II
Automatic Transmission Fluid (A.T.F.) when adding or changing fluid. After checking the fluid level, push the dipstick in securely.

AUTOMATIC TRANSMISSION
FLUID CHANGE CAPACITY:
2.8 l (3.0 US qt, 2.5 Imp qt) DIP STICK

UPPER

LOWERProCarManuals.comMain Menu t s

Index (cont'd)

Emission Controls.........................130

Engine
Coolant.......................................88
Coolant Temperature
Gauge....................................20
Identification Number .............127
Oil and Filter...............................83
Oil Pressure
Warning

Light .......................................22

Specification ...........................125

Exhaust Controls....................131
Engine Exhaust Ga
s Warning

....................................................64

Evaporative Emission Control
System ....................................131
Exhaust Gas Recirculation...........132
Exterior Care.................................110
Filters

Air...........................................94
Engine Oil ...................................84

Fuel.............................................96

Fluid .....................................See "Oil"

Foreign Countries, Operation in ...............................56
Four Wheel Steering.......................59 Front Seat
Adjustment..................................5

Fuel

Filter Door and Cap...................56
Fuel Reserve
Warning

Light .......................................22

Gauge.........................................20

Gasohol......................................55

Gasoline ......................................55

Requirement..............................55

Filter...........................................96
Fuse

Checking and Replacing .........101

Specification...........................126 Gasoline............................See"Fuel"
Gas Station Information
...........................................back cover

Gauges............................................20
Glove Box ........................................39
Hazard Warning

Indicator Light ...........................21
Hazard Warning System................33

Headlights

Flasher.......................................31
Headlight Motor
Switch ...........32

High Beam Indicator..................21
High Beam/Low

Beam

Switch...................................31
If the

Retractable Headlights
do not operate ...................123

Reminder Chime

.......................30

Retractable Headlight Motor Warning Light .......................25

Switch.......................................30
Headlight High
Beam Indicator

Light ...........................................21

Head Restraints.................................8

Heating.............................................45

High Bea
m

Switch .......................................31
Indicator Light ...........................21

Hood Latch.....................................39
Identification Numbers.................127
Ignition
Keys.............................................3

Switch........................................58

Indicator Lights ...............................20
Inflation Pressures, Tire..............105
Instrument Panel....................19
Instrument Panel
Brightness

Control.......................................33

Interior light .....................................33
Interior Trim Care .........................110 Jack .............................................116
Jump Starting ...............................119ProCarManuals.comMain Menu t s

Index (cont'd)

Replacement

Air Filter .....................................94
Bulbs........................................ 103

Engine Oil ...................................84

Fuel Filter ...................................96
Fuses .......................................101Oil Filter
......................................84

Radiator Coolant .......................90
Spark Plugs...............................92

Tires.........................................107
Wiper Blades .............................93Retractable Headlights I
f the Retractable Headlights
do not operate ...................123
Rust Prevention.........................111
Safety Items ...................................63
Seat Belt Reminder Light and
Beeper ..................................... .21

Seat Belts
Anchor Points ...........................16
Buckling the FrontSeat Belts .............................10
Buckling the Rear Seat Belts............................12
Child Restraint......................14

Cleaning .....................................17

Warning Light and Warning Beeper ...................13
Inspection ..................................17
Lap/Shoulder Belts ...................10
Pregnant Women ......................16
Reminder Light ..........................20
Replacement .............................17
Seats
Driver's Lumbar Support ...........7
Driver's Side Support..............7
Front Seat ....................................5

Head Restraints ...........................8

Shift Lever Position Indicator........20
Shifting

Automatic..................................67
5-Speed......................................65

Spare Tire

Changing a Flat Tire................116

COMPACT Spare Tire ...........114
Specifications .........................125
Spark Plugs...................................92
Specifications...............................125Speedometer ..................................
20

Starting the Engine .........................61

Steering Anti-theft Column Lock ...........
58Four Wheel Steering............59
Power Steerin g
.........................97
Tilt Steering ........................26
Stereo Sound System
Operation...................................47

Stuck Car ..............................122
Sunroof

If the Sunroof Won't

Close .....................................54

Maintenance...........................54
Operation ........................ 53

Sunshade.......................................
53

Tachometer.............................20

Temperature Gauge
,
Coolant

....................................................20

Thermostat...................................90
Tilt Steering.....................................26
Tire
Air Pressure ............................105

Balancing ................................106

Chains...................................106
Changing a Fla
t Tire................118

COMPACT Spare .................114
DOT Tir
e
Quality Grades........128
Inflation Pressures ..................105

Requirement ..................................128

Rotation ...................................
106

Snow Tires ........................ 105

Spare Tire................................114

Specification ....................... .
126

To Get In/Out of Rear Seat..............6
Tools ..............................................
116

Towing...........................................121
Towing a Traile
r ..............................
71
Transmission

Identification
Number............127

Oil/Fluid......................................86

Shifting the Automatic.............67

Shifting the Manual...................65

Capacity ...................................125ProCarManuals.comMain Menu t s
