Instruments and Controls

This section gives information about the controls and displays that
contribute to the daily operation of
your Honda. All the essential controls are within easy reach.

Control Locations............................ 50

Indicator Lights................................ 51

Gauges.............................................. 56
Speedometer................................ 56
Tachometer.................................. 56

Odometer...................................... 56

Trip Meter.................................... 56

Fuel Gauge................................... 57
Temperature Gauge.................... 57 Maintenance Required Indicator.................................... 58
Controls Near the Steering

Wheel........................................ 59

Headlights.................................... 60
Daytime Running Lights............. 60
Instrument Panel Brightness..... 61
Turn Signals................................. 61
Windshield Wipers...................... 62
Windshield Washers................... 63
Hazard Warning........................... 63

Rear Window Defogger.............. 63
Steering Wheel Adjustment....... 64

Steering Wheel Controls ................ 65

Cruise Control.............................. 65
Keys and Locks................................ 68

Keys...............................................68

Learning Key................................ 69
Immobilizer System..................... 69
Ignition Switch............................. 70
Power Door Locks....................... 72
Lockout Prevention..................... 73

Trunk............................................73
Glove Box.....................................74
Seat Adjustments............................. 75 Front Seat Adjustments.............. 75Driver's Seat Height Adjustment............................... 76

Rear Seat Access .........................
76

Head Restraints...........................
77
Seat Heaters..................................... 78
Folding Rear Seat............................ 79
Power Windows............................... 80

Moonroof..........................................82

Mirrors.............................................. 83
Adjusting the Power Mirrors.....

83

Parking Brake..................................
84

Digital Clock..................................... 85
Beverage Holder.............................. 86 Console Compartment.................... 87
Coin Box........................................... 88
Accessory Power Socket................ 88
Ashtrays............................................ 89
Interior Lights.................................. 89 Ceiling Lights............................... 89
Courtesy Lights........................... 90
Instruments and ControlsProCarManuals.comMain Menu s t

Indicator Lights

The instrument panel has many indicators to give you important

information about your vehicle.

Lamp Chec

k

These indicator lights come on when you turn the ignition switch ON (II), allowin

g you to see that they are

working:
SRS
Indicator

Malfunction Indicator Lamp
Charging System Indicator Low Oil Pressure Indicator
Anti-lock Brake System Indicator
Seat Belt Reminder Light

D4 Lamp

Immobilizer System Indicator
Active Torque Transfer
System

Indicator

If an
indicator does not light during
this test, it cannot alert you if that system

develops a problem. Have the
dealer check your vehicle for
burned-ou

t bulbs or other problems.
* The
U.S. instrument panel is shown. Differences for the Canadian model

are

noted in the text.
Instruments
and Controls
MALFUNCTION
INDICATOR LAM
P
TRUNK-OPEN INDICATOR
SUPPLEMENTAL

RESTRAINT

SYSTEM

INDICATOR

DOOR-OPEN
INDICATOR
PARKING BRAKE AND
BRAKE SYSTEM INDICATOR*
ANTI-LOCK BRAKE SYSTEM INDICATOR*
IMMOBILIZER
SYSTEM INDICATOR
LOW OIL PRESSURE

INDICATOR
SEAT BELT
REMINDER LIGHT LOW
FUEL

INDICATOR

CHARGING SYSTEM
INDICATOR
HIGH

BEAM

INDICATOR
CRUISE CONTRO L

INDICATOR
ProCarManuals.comMain Menu Table of Contents s t

Indicator Lights

Seat Belt Reminder Light

This indicator lights when you turn the ignition switch ON (II). It is a
reminder to you and your passengers
to protect yourselves by fastening
the seat belts. A beeper also sounds
if you have not fastened your seat

belt.

If you do not fasten your seat belt,
the beeper will stop after a few
seconds but the light stays on until
you do. Both the light and the beeper stay off if you fasten your seat belt
before turning on the ignition.

* The U.S. Type SH instrument panel is shown. Differences for the Canadian
model are noted in the text.
Instruments and Controls MALFUNCTION
INDICATOR LAMP
SUPPLEMENTAL
RESTRAINT
SYSTEM INDICATOR
TRUNK-OPEN
INDICATOR
DOOR-OPENINDICATOR PARKING BRAKE AND
BRAKE SYSTEM INDICATOR*
ACTIVE TORQUE TRANSFER SYSTEM INDICATOR
ANTI-LOCK BRAKE SYSTEM INDICATOR*
IMMOBILIZER
SYSTEM INDICATOR
LOW OIL PRESSURE
INDICATOR
CHARGING SYSTEM INDICATOR SEAT BELT
REMINDER LIGHT
HIGH BEAM
INDICATOR LOW FUEL
INDICATOR
CRUISE CONTROL INDICATORProCarManuals.comMain Menu Table of Contents s t

Indicator Lights

Supplemental Restraint

System Indicator

This indicator lights when you turn the ignition switch ON (II). If itcomes on at any other time, itindicates a problem in the

supplemental restraint system. For

complete information, see page 43.

Immobilizer System
Indicator
This indicator comes on for a few seconds when you turn the ignition
switch ON (II). It will then go off if
you have inserted a properly-coded ignition key. If it is not a properly-coded key, the indicator will blink
and the engine will not start (see

page 69).

This indicator also blinks several times when you turn the ignitionswitch OFF (II). Charging System
Indicator
If this light comes on when the
engine is running, the battery is not
being charged. For complete
information, see page 241.

Low Oil Pressure
Indicator
The engine can be severely damaged if this light flashes or stays on when
the engine is running. For complete

information, see page 240.

Malfunction Indicator
Lamp

See page 242.

Cruise Control Indicator
This lights when you set the cruise
control. See page 65 for information

on operating the cruise control.
Parking Brake
and Brake

System

Indicator
This light has two functions:
1. It lights as a reminder that you have not released the parking
brake. Driving with the parking
brake applied can damage the brakes and tires.
2. If it remains lit after you release the parking brake while the engine
is running, or comes on whiledriving, it can indicate a problem
in the brake system. For complete information, see page 243.
Instruments and Controls
S R S

BRAKE

CRUISE

CONTROL
U.S.


Canada
ProCarManuals.comMain Menu Table of Contents s t

Indicator Lights

Anti-lock BrakeSystem (ABS)
Indicator
This light normally comes on for a few seconds when you turn the
ignition switch ON (II), and when
the ignition switch is turned to
START (III). If this light comes on at
any other time, there is a problem in
the ABS. If this happens, take the
vehicle to your dealer to have it checked. With the light on, your
vehicle still has normal braking ability but no anti-lock. Active Torque Transfer
System (ATTS) Indicator

Type SH only

This indicator normally comes on for a few seconds when you turn the
ignition switch ON (II).
If it comes on at any other time,
there is a problem in the Active
Torque Transfer System (ATTS). If this happens, take the vehicle to
your dealer to have it checked. With the indicator on, your vehicle willcorner normally, but you will not
have active torque transfer. Turn Signal and
Hazard Warning
Indicators
The left or right turn signal light blinks when you signal a lane changeor turn. If the light does not blink or
blinks rapidly, it usually means one of the turn signal bulbs is burned out (see page 210). Replace the bulb as
soon as possible, since other drivers
cannot see that you are signalling.
When you turn on the Hazard Warning switch, both turn signallights blink. All turn signals on the
outside of the vehicle should flash.
Instruments and Controls

ABS

ATTS

U.S.


CanadaProCarManuals.comMain Menu Table of Contents s t

Indicator Lights

Trunk-open Indicator

This light comes on if the trunk lid is not closed tightly.
Door-open Indicator
This light comes on if either door is not closed tightly.
High Beam Indicator
This light comes on with the high beam headlights. See page 60 forinformation on the headlight
controls.
On Canadian models, this indicator
comes on with reduced brightness
when the Daytime Running Lights (DRL) are on (see page 60). Low Fuel Indicator
This indicator is located in the fuel gauge. It comes on as a reminderthat you must refuel soon. "Daytime Running
Lights" Indicator

Canadian models only

This indicator lights when you turn the ignition to ON (II) with the
headlight switch off and the parkingbrake set. It should go off if you turnon the headlights or release the
parking brake. If it comes on at any
other time, it means there is a
problem with the DRL. There may also be a problem with the high
beam headlights.
Instruments and Controls

D
R
L

LOW FUEL INDICATORProCarManuals.comMain Menu Table of Contents s t

Controls Near the Steering Wheel
The two levers on the steering column contain controls for driving
features you use most often. The left
lever controls the turn signals,
headlights, and high beams. The
right lever controls the windshield
washers and wipers.
The controls under the left air vent are for the moonroof, cruise controland instrument panel brightness.
The switches for the hazard warning lights and rear window defogger are
to the right of the steering column.
The tilt adjustment lever on the underside of the steering columnallows you to tilt the steering wheel.

Instruments and Controls

CRUISE
CONTROL
INSTRUMENT PANEL
BRIGHTNESS HAZARD WARNING
LIGHTS
WINDSHIELD

WIPERS/WASHERS

REAR WINDOW

DEFOGGER

HORN

BUTTONS

TILT

ADJUSTMENT

HEADLIGHTS/
TURN SIGNALS

MOONROOFProCarManuals.comMain Menu Table of Contents s t

Controls Near the Steering Wheel

Headlights

The rotating switch on the left lever controls the lights. Turning this switch to the position turns
on the parking lights, taillights,
instrument panel lights, side-marker
lights, and rear license plate lights. Turning the switch to the
position turns on the headlights. If you leave the lights on with the
ignition switch in ACCESSORY (I)
or LOCK (0), you will hear a
reminder chime when you open the
driver's door.
To change between low beams and high beams, pull the turn signal lever
until you hear a click, then let go.
The blue high beam indicator will light (see page 55). To flash the high beams, pull the
turn signal lever back lightly, then
release it. The high beams will comeon and go off.
The high beams will stay on for as long as you hold the lever back, nomatter what position the headlightswitch is in.
Daytime Running Lights (Canadian Models)
With the headlight switch off, the high beam headlights come on with
reduced brightness when you turn
the ignition switch to ON (II) and
release the parking brake. Theyremain on until you turn the ignition
off, even if you set the parking brake.
The headlights revert to normal operation when you turn them on
with the switch.
Instruments and ControlsProCarManuals.comMain Menu Table of Contents s t

Controls Near the Steering Wheel

Instrument Panel Brightness

The dial on the dashboard to the left of the instrument panel controls the
brightness of the instrument panel
lights. Turn the dial to adjust the
brightness. Turn Signals
Signal a turn or lane change with this
lever. Push down on the lever tosignal a left turn, and up to signal a
right turn. If you push it up or down
all the way, the turn signal continues
to blink even when you release the
lever. It shuts off automatically as
you complete the turn. To signal a lane change, push lightly
on the turn signal lever in the proper
direction and hold it. The lever will
return to the center position as soon
as you release it.
Instruments and Controls
TURN SIGNAL LEVERProCarManuals.comMain Menu Table of Contents s t

Controls Near the Steering Wheel

Windshield Washers
To clean the windshield, pull back on the wiper control lever. The washersspray until you release the lever.
The wipers run at low speed while you're pulling the lever, thencomplete one more sweep of the
windshield after you release it.
Hazard Warning

Push the red button to the left of the
clock to turn on the hazard warning
lights (four-way flashers). This causes all four outside turn signals
and both indicators in the instrument
panel to flash. Use the hazard
warning lights if you need to park in a dangerous area near heavy traffic,
or if your vehicle is disabled. Rear Window Defogger
The rear window defogger will clear fog, frost, and thin ice from the
window. Push the defogger button to turn it on and off. The light in the
button lights to show the defogger ison. If you do not turn it off, thedefogger will shut itself off after
about 25 minutes. It also shuts off
when you turn off the ignition. You
have to turn it on again when you restart the vehicle.
Instruments and Controls
CONTINUEDProCarManuals.comMain Menu Table of Contents s t
