HONDA S2000 2003 1.G Workshop Manual

The lef t or right turn signal light
blinks when you signal a lane change
or turn. If the light does not blink or
blinks rapidly, it usually means one
of the turn signal bulbs is burned out
(see page ). Replace the bulb as
soon as possible, since other drivers
cannot see that you are signaling.
This light comes on with the high
beam headlights. See page for
inf ormation on the headlight
controls.This indicator lights when you turn
the ignition switch to ON (II) with
the headlight switch of f and the
parking brake set. It should go of f if
youturnontheheadlightsorrelease
the parking brake. If it comes on at
any other time, it means there is a
problem with the DRL. There may
also be a problem with the high
beam headlights.
This indicator comes on f or a f ew
seconds when you turn the ignition
switch ON (II). It will then go of f if
you have inserted a properly-coded
ignition key. If it is not a properly-
coded key, the indicator will blink
and the engine will not start (see
page ).
WhenyouturnontheHazard
Warning switch, both turn signal
lights blink. All turn signals on the
outside of the car should f lash. This indicator also blinks several
times when you turn the ignition
switch f rom ON (II) to ACCESSORY
(I) or LOCK (0).
This light comes on as a reminder
that you must ref uel soon. This lights when you set the cruise
control. See page f or inf ormation
on operating the cruise control.
200
53 59 115
Canadian models only
Indicator L ights
Inst rument s and Cont rols
Turn Signal and
Hazard Warning
Indicators
High Beam Indicator ‘‘Daytime Running
Lights’’ Indicator
Immobilizer System
Indicator
Low Fuel Indicator Cruise Control Indicator
48

The tachometer shows the engine
speed in revolutions per minute
(rpm). To protect the engine f rom
damage, never drive with the
tachometerreadingintheredzone.
This shows the temperature of the
engine’s coolant. During normal
operation, the reading should be in
the middle of the gauge. In severe
driving conditions, such as very hot
weather or a long period of uphill
driving, the reading may reach near
the red mark. If it reaches the red
mark, pull saf ely to the side of the
road. Turn to page for
instructions and precautions on
checking the engine’s cooling
system.
The Select button switches the
speedometer reading between miles
perhourandkilometerperhour.It
also changes the odometer and trip
meters to read in miles or kilometers
correspondingly. To change the
readings, push the Select button and
hold it until you hear a beep.
This shows your speed in miles per
hour (mph) or kilometers per hour
(km/h).
229
Gauges
Inst rument s and Cont rols
T achometer
Select Button Temperature Gauge
Speedometer
49
TEMPERATURE GAUGE SPEEDOMETERTACHOMETER
SELECT BUTTON

This shows how much f uel you have.
It is most accurate when the car is on
level ground. It may show slightly
more or less than the actual amount
whenyouaredrivingoncurvyor
hilly roads.The odometer shows the total dis-
tance your car has been driven. It
displays in miles and kilometers.
It is illegal under U.S. f ederal law and
Canadian provincial regulations to
disconnect, reset, or alter the
odometer with the intent to change
the number of miles or kilometers
indicated.
Gauges
Inst rument s and Cont rols
Fuel Gauge
Odometer
50
TRIP METER FUEL GAUGE
TRIP BUTTON
ODOMETER SELECT BUTTON
Avoid driving with an extremely low
f uel level. Running out of f uel could
cause the engine to misf ire, damaging
the catalytic converter.

When the distance driven since the
last scheduled maintenance reaches
6,000 miles (9,600 km), the indicator
starts blinking. If you exceed 7,500
miles (12,000 km), the indicator
stays on.
Your dealer will reset the indicator
when they perf orm the scheduled
maintenance. If someone else
perf orms the maintenance, reset the
indicator yourself .
To reset the maintenance required
indicator, turn the ignition switch to
the LOCK position, then press and
hold the trip meter reset button
while you turn the ignition switch
ON. Continue holding the button
until the indicator resets (the
indicator light goes out).
Ref er to the Maintenance Schedules
f or Normal and Severe Driving
Conditions on pages and . This indicator reminds you that it is
time to take your car in for
scheduled maintenance.
This meter shows the number of
miles or kilometers driven since you
last reset it.
There are two trip meters, Trip A
and Trip B. Switch between Trip A
and Trip B by pressing the TRIP
button repeatedly. Each trip meter
works independently, so you can
keep track of two dif f erent distances.
To reset a trip meter, display it and
then press and hold the TRIP button
until you hear a beep and the
number resets to 0.0.
152 154
Inst rument s and Cont rols
Gauges
Maintenance Required Indicator
Trip Meter
51
MAINTENANCE REQUIRED INDICATOR

ÃŽ
ÃŽ
Thetwoleversonthesteering
column contain controls f or driving
f eatures you use most of ten. The lef t
lever controls the turn signals,
headlights, and high beams. The
right lever controls the windshield
washers and wipers.
The engine start button and the
remote audio controls are under the
lef t air vent.
The instrument panel brightness
control is in the lower lef t corner of
the speedometer.
The cruise control master switch is
to the lef t of the steering column.To use the horn, press the pad
around the ‘‘H’’ logo.
Controls Near the Steering Wheel
Inst rument s and Cont rols52
HEADLIGHTS/TURN SIGNALS
(P.53)
REMOTE AUDIO
CONTROLS
ENGINE
START
BUTTON
HOOD RELEASE
HANDLE
CRUISE CONTROL MASTER SWITCH WINDSHIELD WIPERS/WASHERS
(P.55) REAR WINDOW
DEFOGGER BUTTON
(P.
57)
INSTRUMENT PANEL BRIGHTNESS
(P.54)
(P.113)
(P.135)
(P.122)
(P.115) HORN

The rotating switch on the lef t lever
controls the lights. Turning this
switch to the ‘‘ ’’ position turns
on the parking lights, taillights,
instrument panel lights, side-marker
lights, and rear license plate lights.
Turning the switch to the ‘‘ ’’
position turns on the headlights.To change f rom low beams to high
beams, push the turn signal lever
f orward until you hear a click. The
blue high beam indicator will light
(see page ). To return to low
beams, pull the turn signal lever
back. If you leave the lights on with the
ignition switch in ACCESSORY (I)
or LOCK (0), you will hear a
reminder tone when you open the
driver’s door.
To f lash the high beams, pull the
turn signal lever back lightly, then
release it. The high beams will come
on and go of f . The high beams will
stay on f or as long as you hold the
lever back, no matter what position
the headlight switch is in.
48
Headlights
Inst rument s and Cont rols
Controls Near the Steering Wheel
53

´µ´µ
µ´
Thedisplaydimswhentheparking
lights or headlights are turned on.
Adjust the brightness to the desired
level with the headlight switch of f ,
and also with the headlight switch on.
Both settings will remain at those
levels until you change them.
The buttons in the lower left corner
of the instrument panel adjust the
brightness of the display in f ive steps.
Push the or button five times
to see the f ull range. With the headlight switch on, you
can switch the display to f ull daytime
brightness by pushing and holding
the button. Push the button to
return the display to the original
brightness.
With the headlight switch off, the
high beam headlights come on with
reduced brightness when you turn
the ignition switch to ON (II) and
release the parking brake. They
remain on until you turn the ignition
of f , even if you set the parking brake.
The headlights revert to normal
operation when you turn them on
with the switch.
Canadian models only
Controls Near the Steering Wheel
Instrument Panel Brightness
Daytime Running L ights
Inst rument s and Cont rols54
BUTTON BUTTON

Signal a turn or lane change with this
lever. Push down on the lever to
signal a lef t turn, and up to signal a
right turn. If you push it up or down
all the way, the turn signal continues
to blink even when you release the
lever. It shuts off automatically as
you complete the turn.To signal a lane change, push lightly
on the turn signal lever in the proper
direction and hold it. The lever will
return to the center position as soon
as you release it.
This lever controls the windshield
wipers and washers. It has five
positions:MIST: mist
OFF: off
INT: intermittent
LO: low speed
HI: high speed
To select a position, push the lever
up or down.
CONT INUED
Controls Near the Steering Wheel
T urn Signals Windshield Wipers
Inst rument s and Cont rols55
TURN SIGNAL LEVER

In intermittent, the wipers operate
every f ew seconds. In low speed and
high speed, the wipers run continu-
ously.To operate the wipers in mist mode,
push the control lever up f rom the
OFF position. The wipers run at high
speed until you release the lever.
This gives you a quick way to clear
the windshield.To clean the windshield, pull back on
the wiper control lever. The washers
spray until you release the lever.
The wipers run at low speed while
you’re pulling the lever, then
complete one more sweep of the
windshield af ter you release it.
Inst rument s and Cont rols
Controls Near the Steering Wheel
Windshield Washers
56

The rear window def ogger will clear
fog,frost,andthinicefromthe
window. Push the def ogger button to
turn it on and of f . The light in the
buttoncomeontoshowthe
def ogger is on. If you do not turn it
of f , the def ogger will shut itself of f
af ter about 15 minutes. It also shuts
of f when you turn of f the ignition.
You have to turn it on again when
you restart the car.Thedefoggerwiresontheinsideof
the rear window can be accidentally
damaged. When cleaning the glass,
always wipe side to side. Make sure the rear window is clear
and you have good visibility bef ore
starting to drive. Do not push the def ogger button
when the convertible top is f olded.
Controls Near the Steering Wheel
Rear Window Def ogger
Inst rument s and Cont rols57
