HUMMER H2 2005 Owners Manual

To open a door on the console, push on the rear edge
of the door and let it swing open. Push the door up
until it latches to close the door.
The overhead consoles also includes reading lamps, the
HomeLink transmitter buttons and the sunroof switch
(if equipped).
Center Console Storage Area
Your vehicle has a console compartment between the
bucket seats.
To open it, press the button on the side of the console
and swing the console lid open.
Luggage Carrier
If your vehicle has this feature, you can load cargo on
your vehicle.
For the SUV the luggage carrier consists of siderails
attached to the roof. The crossrails attach into the
siderails and can be moved back and forth (fore and aft)
to accommodate securing various cargo sizes.For the SUT the luggage carrier consists of siderails
that run the length of the roof and the cargo area. The
crossrails attach into the siderails and can be moved
back and forth (fore and aft) to accommodate securing
various cargo sizes.
Notice:Loading cargo on the luggage carrier that
weighs more than 300 lbs. (136 kg) or hangs
over the rear or sides of the vehicle may damage
your vehicle. Load cargo only on top of the
crossrails and tie the cargo down to the crossrail
support cargo tie-down loops, making sure to fasten
it securely.
Don’t exceed the maximum vehicle capacity when
loading your vehicle. For more information on vehicle
capacity and loading, seeLoading Your Vehicle on
page 4-58.
2-55

Adjusting the Crossrails
Adjust the crossrails to t your load by doing the
following:
1. Loosen the lock knobs on the crossrail supports by
turning the knobs counterclockwise. Only loosen
them enough to allow the crossrails to slide easily.
2. Slide the crossrails to the desired position, being
sure to align the lines in the side rails with the
arrows on the crossrail supports.3. Tighten the lock knobs and then try to move the
crossrails back and forth to be sure that they do
not move.
4. Once you load the cargo onto the crossrails, secure
it by tying it down to the crossrail support cargo
tie-down loops. Do not load cargo directly on
the roof of your vehicle.
Be sure you do not cover the roof marker lamps or
the Center-High-Mounted Stoplamp (CHMSL)
(If equipped) with cargo.
To prevent damage or loss of cargo check now and
then to make sure the luggage and cargo are still
securely fastened and the crossrails are tight.
2-56

Stop Tabs
If your vehicle has a sunroof, it will have a crossrail
stop tab placed in the siderail in the spot labeled
SUN—ROOF STOP. This tab prevents you from moving
the crossrails past the opening of the sunroof and
loading cargo too far forward.
Your vehicle will also have a stop tab in the crossrail in
the spot labeled ON STAR STOP. This tab prevents
loading cargo too close to the OnStar antenna which will
cause the OnStar and navigation system (if equipped)
to function improperly or not at all.Vehicles with the off-road lamps will have additional
stop tabs placed in the siderails to prevent you
from moving the lamps too far rearward, causing them
to shine into the optional sunroof opening.
Crossrail Channels
Notice:If you drive your vehicle through an
automatic car wash that does not have enough
clearance for any roof-mounted accessories (such
as off-road lamps or a roof basket) on your vehicle,
you can damage your vehicle. To avoid damaging
your vehicle in a car wash, remove any
roof-mounted accessories if you can, and do not
use an automatic car wash while roof-mounted
accessories are on your vehicle. SeeWashing Your
Vehicle on page 5-96for more information.
The crossrails have built in channels to allow you to
attach other items designed for this system, such
as basket luggage carriers, bike racks, ski racks, etc.
2-57

To use the crossrail channels, do the following:
1. Use the included key to unlock the crossrail end
cap by turning it counterclockwise. If you ever
lose a key, your dealer will be able to help
you obtain a replacement.2. Pull the end cap
straight out from the
crossrail.
3. Peel back the rub strip from the crossrail.
4. Slide the accessory you are using into the crossrail
channel and secure it as the accessory instructions
direct.
5. Place the crossrail endcap back on and lock it with
the key.
You will not be using the rub strip when using crossrail
accessories. When you remove any crossrail
accessory, be sure to reinstall the rub strip. To do this,
press the rub strip in place until it seats into the
channel of the crossrail.
2-58

Rear Seat Armrest
Your vehicle is equipped with a rear armrest/cupholder.
To open it, pull up and then out on the tab, located at the
top center of the armrest, and pull the armrest down.
Cargo Tie Downs (SUT)
There are four oval shaped openings (A) in the cargo
bed that allow access to four tie downs. You can
use these tie downs to secure cargo.
All-Weather Cargo Area (SUT)
Your vehicle is equipped with features to help it resist
the elements and protect cargo inside the cargo area.
Even when the water management system is working
properly and the cover system is on, there may be some
instances (heavy rains, automated car washes, etc.)
when water may be present in the following areas:
A. Drain Hole
2-59

Removal and Cleaning
To ensure that the water management system performs
properly, be sure that the midgate, tailgate and cover
system are fully closed and that each element of
the water management system is clean and not blocked
with debris. Follow the instruction given next in this
section for the proper procedures on cleaning each item
of the water management system.
Side Rail Channels
The side rail channels are located on top of both sides
of the roof and the cargo area. You may want to
ush them out with clean water if you notice any debris
collecting inside of them.
When loading cargo into the cargo area, be careful not
to damage the rails.
For more information on this feature seeLuggage
Carrier on page 2-55
Cargo Area Floor Drains
Your vehicle also has four cargo-area oor drains (a)
located under the cargo mat, if equipped, near the sides
of the cargo area. These drains should be cleaned
periodically to allow water to exit the cargo area.
The cargo mat has cutouts for the drains. You can ush
the drains through the cutouts, but if the cargo area
is extremely dirty you can lift up the edges of the cargo
oor mat or take the whole mat out and ush the
drains with water.
2-60

Tonneau Cover (SUT)
{CAUTION:
If you remove the tonneau cover, do not store it
in the vehicle without securing it to the vehicle.
An improperly stored tonneau cover could be
thrown about the vehicle during a collision or
sudden maneuver. You or others could be
injured. When you put the cover back on,
always be sure that it is securely reattached.
Your vehicle may have a hard tonneau cover, you can
use it to cover items in the cargo area of your vehicle.
Your tonneau cover will have two lock cylinders on it.
One lock cylinder is to secure the cover closed and
the other lock cylinder will allow you to secure the
tailgate close.
2-61

You will be able to open the cover by turning the cover
release latch in a clockwise direction, which will allow
you to lift the cover with the assistance of the struts.
Sunroof
The vehicle may have a power sliding sunroof. To
operate it, the ignition or RAP must be in the ON
position. The switch used to operate the sunroof is
located in the overhead console.
The sunroof has ve positions:
First open stop:To open the sunroof and sunshade,
press the rear of the switch until the sunroof reaches
the rst open stop then release the switch. For more
information on using the sunshade, see “Sunshade
Operation” later in this section.
Second open stop:To open the sunroof further,
press the rear of the switch until the sunroof reaches
the second open stop then release the switch.
2-62

Fully open:To open the sunroof completely, press
and hold the rear of the switch until the sunroof
opens completely.
Closed:To close the sunroof, press the front of the
switch until the sunroof reaches the desired position
or until it is fully closed and stops on its own.
Vent:The vent position allows the rear of the sunroof
to be opened and tilted upward. With the sunroof in
the fully closed position, press and hold the front of
the switch until the sunroof reaches the desired vent
position or until it stops moving. To close the sunroof
from the vent position, press and hold the rear of the
switch until the sunroof is fully closed.
Do not to leave the sunroof open for long periods of
time as debris may collect in the tracks.
Sunshade Operation
The sunshade will open automatically when opening
the sunroof.
However, it can manually be pulled shut after the
sunroof is closed. To adjust the sunshade, push it
backward or pull it forward to the desired position. The
sunshade cannot be adjusted further than the current
closed position of the sunroof.
Vehicle Personalization
Memory Seat
If your vehicle has this
feature, the controls for the
memory function are
located on the driver’s door.
These buttons are used to program and recall memory
settings for the driver’s seat and both the driver’s
and passenger’s outside mirrors. The settings for these
features can be saved for up to two drivers.
2-63

To store the memory settings, do the following:
1. While the vehicle is in PARK (P), adjust the driver’s
seat, including the seatback recliner, lumbar, and
side wing area, and both outside mirrors to
your preference.
2. Press and hold the 1 or 2 button of the memory
control for three seconds. A double chime will
sound to let you know that the position has been
stored.
To repeat the procedure for a second driver, follow the
preceding steps, but press the other numbered
memory control button.
Each time button 1 or 2 is pressed and released while
the vehicle is in PARK (P), a single chime will sound and
the memory position will be recalled.
To stop recall movement of the memory seat feature at
any time, press one of the memory buttons or power
seat controls.
Easy Exit Seat
The controls for this memory function are located on the
driver’s door.
B(Easy Exit Seat):This button is used to program
and recall the desired driver’s seat position when
exiting/entering the vehicle. The seat position can be
saved for up to two drivers.To store the seat exit position, do the following:
1. Press and release the 1 or 2 button. The seat will
move to the stored memory position.
2. Adjust the seat to the desired exit position.
3. Press and hold the exit button of the memory
control for three seconds. A double chime will sound
to let you know that the position has been stored
for the selected button 1 or 2.
To repeat the procedure for a second driver, follow
the preceding steps, but press the other numbered
memory control button.
To use the seat exit position, do one of the following:
Press the exit button on the memory control.
Or, if this feature is activated in the DIC, removing
the key from the ignition will move the seat to the
exit position.
See “Easy Exit Seat” underDIC Vehicle Personalization
on page 3-54for more information on activating this
feature in the DIC.
2-64
